Inalto IMC28BF User manual

V 1 . 0 | 0723
FOR ALL AUSTRALIAN HOMES
USER MANUAL INALTO.HOUSE
MODEL:
28L Built-In
Microwave
IMC28BF

02
User Manual
Congratulations on purchasing your new 28L Built-In Microwave.
InAlto is proudly distributed within Australia by Residentia Group Pty Ltd.
Please refer to the warranty card at the rear of this manual for information
regarding your product’s parts and labour warranty, or visit us online at:
→ residentiagroup.com.au
At Residentia Group, we are customer obsessed and our Support Team are
there to ensure you get the most out of your appliance. Should you want
to learn more about your unit such as the various temperature guides or
importantly taking care of the appliance, our Support Team are here to help.
You can use our online Support Centre at any time by visiting:
→ support.residentiagroup.com.au
Or you can contact us via phone by dialling: 1300 11 HELP (4357)
It is important that you read through the following use and care manual
thoroughly, in order to familiarise yourself with the installation and operation
requirements of your appliance, and to ensure optimum performance.
Again, thank you for choosing an InAlto appliance and we look forward
to being of service to you.
Kind Regards,
The Residentia Team
Residentia Group
—
Head Oce
165 Barkly Avenue
Burnley Victoria
Australia 3121
—
ACN
600 546 656
—
Online
residentia.group
inalto.house
@inalto.house
—
Postage
PO BOX 5177, Burnley
VIC Australia 3121
—
Telephone
1300 11 4357
—
Email
[e-mail]
Welcome

03
User Manual
Contents
Customer Care
Safety Information
Installation Instructions
Your Microwave
Operating Instructions
Cleaning & Maintenance
Troubleshooting
Product Specifications
Purchase Details
Warranty Information


2
4
6
7
8
9
20
InAlto strongly recommends the use of original spare parts.
When contacting our customer service team by calling 1300 11 HELP, or by
e-mailing [e-mail], please ensure that you have
the following information at hand, which can be found on your appliances’
rating plate:
*
Model Number
*
Serial Number

04
User Manual
Safety Information
IMPORTANT SAFETY INSTRUCTIONS
•To reduce the risk of fire, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
•Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or
tamper with the safety interlocks.
•Do not place any object between the oven front
face and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
WARNING: If the door or door seals are damaged,
the oven must not be operated until it has been
repaired by a competent person. If the apparatus is
not maintained in a good state of cleanliness,
its surface could be degraded and aect the lifespan
of the apparatus and lead to a dangerous situation.
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do
not play with the appliance.
•If the supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard. (For
appliance with type Y attachment).
WARNING:Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
WARNING: It is hazardous for anyone other than a
qualified person to carry out any services or repairs
that involve the removal of a cover which gives
protection against exposure to microwave energy.
WARNING: Liquids and other foods must not be
heated in sealed containers since they are often
liable to explode.
•When heating food in plastic or paper containers,
keep an eye on the oven cavity due to the possibility
of ignition.
•Only use utensils that are suitable for use in
microwave ovens.
•If smoke is emitted, switch o or unplug the
appliance and keep the door closed in order to stifle
any flames.
•Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
•The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature
checked before consumption, in order to avoid burns.
•Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
•The oven should be cleaned regularly and any food
deposits removed.
•Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely aect the life of the appliance and possibly
result in a hazardous situation.
•Only use the temperature probe recommended for
this oven.(For ovens provided with a facility to use a
temperature-sensing probe.)
•The microwave oven must be operated with the
decorative door open. (For ovens with a decorative
cabinet door.)
•This appliance is intended to be used in household
and similar applications such as: sta kitchen areas
in shops, oces and other working environments;
by clients in hotels, motels and other residential type
environments; farm houses; and bed and breakfast
type environments.
•The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating
of warming pads, slippers, sponges, damp cloth and
similar may lead to risk of injury, ignition or fire.
•Metallic containers for food and beverages are not
allowed during microwave cooking.
•This microwave should under no circumstances be
cleaned with a steam cleaner.
•The appliance must not be installed behind a
decorative door in order to avoid overheating. (This is
not applicable for appliances with decorative door.)

05
User Manual
Utensils Information
Browning Dish Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer's instructions. Never use cracked or chipped dishes.
Glass Jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat resistant
and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Never use cracked or
chipped dishes.
Oven Bags Follow manufacturer’s instructions. Never close the bag/s with a metal bread tie. Make slits to
allow steam to escape.
Paper Plate/Cups Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
Paper Towels Use to cover food for reheating and absorbing fat. Always use for short-term cooking only.
Parchment Paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled “Microwave
Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling bags” and tightly
closed plastic bags should be slit, pierced or vented as directed by package.
Plastic Wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow plastic
wrap to touch food, as in some circumstances it can melt.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax Paper Use as a cover to prevent splattering and retain moisture.
MICROWAVE SAFE MATERIALS
Utensils Information
Aluminium Trays May cause arcing. Transfer food into microwave-safe dish.
Metal Containers May cause arcing. Transfer food into microwave-safe dish.
Metal Utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal Bread Ties May cause arcing and could cause a fire in the oven.
Paper Bags May cause a fire in the oven.
Plastic Foam Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.
Wood Wood will dry out when used in the microwave oven and may split or crack.
UNSAFE MATERIALS DO NOT USE

06
User Manual
Installation Instructions
INSTALLATION SAFETY INSTRUCTIONS
•DANGER: Electric Shock Hazard. Touching some of
the internal components can cause serious personal
injury or death. Do not disassemble this appliance.
•WARNING: Electric Shock Hazard. Improper use
of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly
installed and grounded. This appliance must be
grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed
and grounded.
•Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood
or if doubt exists as to whether the appliance
is properly grounded. If it is necessary to use an
extension cord, use only a 3-wire
•A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
•If a long cord set or extension cord is used,
the marked electrical rating of the cord set or
extension cord should be at least as great as the
electrical rating of the appliance. The extension cord
must be a grounding-type 3-wire cord.
•The long cord should be arranged so that it will not
drape over the counter top or tabletop where it can
be at risk of being pulled on by children or tripped
over unintentionally.
INSTALLATION & CONNECTION
1 This appliance is only intended for domestic use.
2 This oven is intended for built-in use only. It is not
intended for counter-top use, or for freestanding
use inside a cupboard.
3 Please observe the special installation instructions.
4 The appliance can be installed in a 60cm wide wall-
mounted cupboard.
5 The appliance is fitted with a plug and must only be
connected to a properly installed earthed socket.
6 The mains voltage must correspond to the voltage
specified on the rating plate.
7 The socket must be installed and connecting cable
must only be replaced by a qualified electrician. If the
plug is no longer to accessible following installation,
an all-pole disconnecting device must be present on
the installation side with a contact gap of at least
3mm minimum.
8 Adapters, multi-way strips and extension leads must
not be used. Overloading can result in a risk of fire.
Please note: the accessible surface may be hot
during operation.

07
User Manual
ELECTRICAL CONNECTION
The oven is fitted with a plug and must only be connected
to a properly installed earthed socket. The socket must
only be installed and the connecting cable must only be
replaced by a qualified electrician, and in accordance
with the appropriate regulations. If the plug is no longer
accessible following installation, an all-pole isolating
switch must be present on the installation side with a
contact gap of at least 3mm.
The fitted cabinet must not have a back wall behind the
appliance. A gap must be maintained between the wall
and the base of the unit above. Specific gap size could be
referenced by the diagrams.
Minimum installation height: 85cm.
Do not cover ventilation slots and suction holes.
Note: Do not trap or bend the power cable.
Screws
IMC28BFMounting Bracket

08
User Manual
Installation Instructions (continued)
PLEASE FOLLOW THE CABINETRY SPECIFICATIONS BELOW:
600
(45)
min.
500
362+3 (45)
560+8

09
User Manual
PREPARING THE CABINET
1 Read the instructions contained in the supplied
Cabinetry Installation Template, and place the
template on the bottom plane of cabinet.
2 Make the marks on the bottom plane of cabinet
according to marks Aof the template.
3 Remove the Cabinetry Installation Template and fix
the mounting plate with the supplied screws.
Centre Line
Mounting Bracket
Screws

10
User Manual
Installation Instructions (continued)
INSTALLING YOUR MICROWAVE
4 Install the oven to the cabinet.
Make sure the back of the oven
is locked by mounting plate.
Ensure you do not trap or kink
the power cord.
5 Open the door, fix the oven to
the cabinet with Screw, at the
installation hole.

11
User Manual
TURNTABLE INSTALLATION
Make sure all packaging and shipping tape has been
removed from the turntable shaft. Before using the
appliance to prepare food for the first time, you will need
to put the turntable in place correctly. You must clean the
cooking compartment and accessories.
How to put the turntable in place:
1 Place the turntable ring assembly (3)into the recess
in the cooking compartment.
2 Place the glass tray (1)on the turntable ring
assembly (3). Fit the raised, curved lines in the center
of the glass tray bottom between the three spokes of
the shaft. Make sure that the glass tray (1)engages
in the turntable shaft (2)in the centre of the cooking
compartment floor. The rollers on the (3)should fit
inside the turntable bottom ridge.
TURNTABLE TIPS
1 Never use the appliance without the turntable.
Make sure that it is properly engaged. The turntable
can turn clockwise or anti-clockwise.
2 Never place the glass tray upside down. The glass tray
should never be restricted.
3 Both glass tray and turntable ring assembly must
always be used during cooking.
4 All food and containers of food are always placed on
the glass tray for cooking.
5 Never restrict the movement of the turntable.
6 If glass tray or turntable ring assembly cracks or
breaks, promptly contact InAlto for a replacement.
3
2
1

12
User Manual
Your Microwave
OVEN PARTS AND ACCESSORIES
Your oven comes with the following accessories:
G
C
A
F
D
E
B
Glass Tray Turntable Ring Turntable Shaft
A Control Panel
B Turntable Shaft
C Observation Window
D Door Assembly
E Safety Interlock System
F Oven Cavity
G Control Dial

13
User Manual
CONTROL PANEL
START +30 SEC. | CONFIRM
WEIGHT | TIME
DEFROST
TIMER | CLOCK
MICROWAVE
POWER
STOP | CLEAR
3 SEC.
START +30 SEC. | CONFIRM
WEIGHT | TIME
DEFROST
TIMER | CLOCK
MICROWAVE
POWER
STOP | CLEAR
3 SEC.
Microwave Power
LED Display
Weight | Time Defrost
Time Weight
Timer | Clock Stop | Clear
Start / +30 Sec. | Confirm
Door Open
Auto Menu

14
User Manual
SETTING THE CLOCK
1 When the microwave oven is first turned on, the LED
will display 0:00, and the buzzer tone will ring once.
2 Press the TIMER |CLOCK button twice to select clock
function, the hour figures will flash.
3 Turn the dial clockwise to adjust the hour figures, the
input time should be within 0–23.
4 Pressing the TIMER |CLOCK button confirms the hour.
The minute figures will then flash, indicating they are
ready to be selected.
3 Turn the dial clockwise to adjust the minute figures,
the input time should be within 0–59.
6 Press the TIMER |CLOCK button to confirm your clock
setting. The :will flash, and the time will light.
NOTE: The clock function will not work if it is not set
when the microwave is first powered on.
MICROWAVE COOKING
1 Pressing the MICROWAVE POWER button, the LED will
display P100. Pressing MICROWAVE POWER repeatedly
or turning the dial allows you to choose the power
setting you prefer, from P100, P80, P50, P30 etc.
2 Once you have found the desired power setting, press
the START button to confirm, and turn the dial to set
the cooking time from 0:05 to 95:00. Pressing the
START button will then begin the cooking process.
SETTING THE CLOCK
1 Pressing the TIMER |CLOCK button once, the LED will
display 00:00.
2 Turn the dial to enter the desired cooking time, (the
maximum cooking time is 95 minutes).
3 Press the START button to begin your chosen setting.
NOTE: The kitchen timer itself is not a cooking program,
and is intended for keeping track of time only.
CHILD SAFETY LOCK
•LOCK: While in waiting state, press and hold the
STOP |CLEAR button for 3 seconds. A long beep will
sound denoting that the child safety lock has been set.
•UNLOCK: To unlock simply press and hold the
STOP |CLEAR button for 3 seconds. The long beep will
sound again, and the child safety lock will be o.
QUICK START
1 In waiting state, simply pressing the START button will
start cooking with 100% power for 30 seconds.
2 Alternatively, you can turn the dial anti-clockwise to
set the power to 100% and the cooking time to 90
minutes, then followed by the START button to begin
the cooking process.
NOTE: Each press of the START button increases the
cooking time by 30 second increments.
DEFROST BY WEIGHT
1 Press the WEIGHT |TIME DEFROST button once, and
the oven will display dEF1.
2 Turn the dial to select the food’s weight, choosing from
100g to 1000g.
3 Press the START button to start defrosting.
Defrost by Time
1 Press the WEIGHT |TIME DEFROST button twice, and
the oven will display dEF2.
2 Turn the dial to select the defrost time. The maximum
time is 95 minutes.
3 Press the START button to start defrosting. Please note
that the defrost power is P30 by default, and cannot
be changed.
MULTISTAGE COOKING
1 At most 2 separate stages can be set for cooking.
When using multi-stage cooking, if one of the selected
stages is defrosting, then defrosting will always be
prioritised as the first stage.
2 The kitchen timer and auto-menu can not be used as
part of the multi stage process.
3 Press the START button to increase the cooking time by
30 second increments.
INQUIRY FUNCTION
•At any point during the cooking process, pressing
MICROWAVE POWER will display the current power
setting for 3 seconds.
•Similarly, pressing TIMER |CLOCK will temporarily
display the current time for 3 seconds.
Operating Instructions

15
User Manual
AUTOMENU
1 Turn the dial clockwise to choose the auto-menu,
in which case codes A-1 through to A-8 will display.
These codes refer to dierent programs designed
for cooking specific dishes.
2 Once you have selected the desired program code,
press the START button to confirm.
3 Turn the dial to select between the available default
food weight settings.
4 Press the START button to begin cooking.
Menu Weight Display
A- (Pizza) 200g 200
400g 400
A- (Meat) 250g 250
350g 350
450g 450
A- (Vegetable) 200g 200
300g 300
400g 400
A-4 (Pasta) 50g +450g cold water 50
100g +800g cold water 100
A-5 (Potato) 200g 200
400g 400
600g 600
A-6 (Fish) 250g 250
350g 350
450g 450
A- (Beverage) 1 Cup (120ml) 1
2 Cups (240ml) 2
3 Cups (360ml) 3
A-8 (Popcorn) 50g 50
85g 85
100g 100
AUTOMENU TABLE

16
User Manual
Cleaning & Maintenance
GENERAL CLEANING INSTRUCTIONS
•ALWAYS unplug the appliance from the power supply
when cleaning.
•Regulalarly clean the cavity of the oven after use
with a slightly damp cloth.
•For particularly messy uses, clean the accessories
in the usual way but with lightly soapy water.
•The door frame and seal and neighbouring parts
must be cleaned carefully with a damp cloth when
they are dirty.
•Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering
of the glass.
•Cleaning Tip: For easier cleaning of the cavity walls
that cooked food can stain: Place half a lemon in a
bowl, add 300ml (1/2 pint) water and heat on 100%
microwave power for 10 minutes. Wipe the oven clean
using a soft, dry cloth.

17
User Manual
Troubleshooting
Problem Possible Cause Solution
Microwave Oven Interfering with
TV Reception
Radio and TV reception may be
interfered when microwave oven
operating. It is similar to the
interference of small electrical
appliances, like mixer, vacuum
cleaner, and electric fan. It is normal.
-
Dim Oven Light In low power microwave cooking,
the oven light may become dim.
It is normal, and not to be a cause
for concern.
-
Steam Accumulating On Door,
Hot Air Coming Out of Vents
In cooking, steam may come out of
food. Most will get out from vents.
But some may accumulate on cool
place like oven door. It is normal.
-
Microwabe oven started
accidentally, with no food in.
It is forbidden to run the unit without
any food inside. It is very dangerous.
Cancel the program immediately.
Oven cannot be started. Power cord is not plugged in tightly. Unplug. Then plug again after
waiting for 10 seconds.
Fuse blowing or circuit breaker works. Replace fuse or reset circuit breaker
(repaired by professional personnel
of InAlto).
Trouble with outlet. Test the outlet with other electrical
appliances to see if it functions
correctly and safely.
Oven does not heat. Door is not properly closed. Close the door properly
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.

18
User Manual
Product Specifications
Model Number IMC28BF
Microwave Cavity 28L
Product Dimensions (W × D × H) 595 × 410 × 388mm
Packaging Dimensions (W × D × H) 653 × 500 × 466mm
Net Weight 16.9kg
Gross Weight 19.5kg
Rated Power 1450W
Power Supply 220-240V, ~50Hz

19
User Manual
Purchase Details
Attach Your Receipt Here
For future reference, please record the following information which can be found
on the rating plate and the date of purchase which can be found on your sales invoice.
STORE DETAILS
STORE NAME

ADDRESS

TELEPHONE

PURCHASE DATE

PRODUCT DETAILS
MODEL NO.

SERIAL NO.*


20
User Manual
WARRANTY TERMS AND CONDITIONS
BUILTIN MICROWAVES
This document sets out the terms and conditions of
the product warranties for Residentia Group Appliances.
It is an important document. Please keep it with your
proof of purchase documents in a safe place for future
reference should you require service for your Appliance.
1. IN THIS WARRANTY
(a) ‘acceptable quality’ as referred to in clause 10 of
this warranty has the same meaning referred to in
the ACL;
(b) ‘ACL’ means Trade Practices Amendment (Australian
Consumer Law) Act (No.2) 2010;
(c) ‘Appliance’ means any Residentia Group product
purchased by you accompanied by this document;
(d) ‘ASR’ means Residentia Group authorised service
representative;
(e) ‘Residentia Group’ means Residentia Group Pty Ltd
of 165 Barkly Ave, Burnley VIC 3121, ACN 600 546 656 in
respect of Appliances purchased in Australia;
(f ) ‘major failure’ as referred to in clause 10 of this warranty
has the same meaning referred to in the ACL and includes
a situation when an Appliance cannot be repaired or it
is uneconomic for Residentia Group, at its discretion, to
repair an Appliance during the Warranty Period;
(g) ‘Warranty Period’ means:
(i) where the Appliance is used for personal, domestic
or household use (i.e. normal single family use) as
set out in the instruction manual, the Appliance is
warranted against manufacturing defects for 24
months, following the date of original purchase of
the Appliance;
(h) ‘you’ means the purchaser of the Appliance not having
purchased the Appliance for re-sale, and ‘your’ has a
corresponding meaning.
2. This warranty only applies to Appliances purchased
and used in Australia and is in addition to (and does
not exclude, restrict, or modify in any way) any
non-excludable statutory warranties in Australia.
3. During the Warranty Period Residentia Group or its
ASR will, at no extra charge if your Appliance is readily
accessible for service, without special equipment and
subject to these terms and conditions, repair or replace
any parts which it considers to be defective. Residentia
Group or its ASR may use remanufactured parts to repair
your Appliance. You agree that any replaced Appliances
or parts become the property of Residentia Group.
This warranty does not apply to light globes, batteries,
seals, filters or similar perishable parts.
4. Parts and Appliances not supplied by Residentia Group
are not covered by this warranty.
Warranty Information
