Intellinet 509060 User manual

1-Port
USB
WireleSS
Print
Server
qUick
inStallation
gUide
MODEL 509060
INT-509060-QIG-0508-01

Thank you for purchasing the INTELLINET NETWORK SOLUTIONS
™
1-Port USB Wireless
Print Server, Model 509060.
This quick installation guide presents the rudimentary steps required to set up and operate
this device. For more detailed instructions and specications, refer to the user manual 1) on
the CD enclosed with this product; 2) on the Web site listed below; or 3) in some cases, printed
and enclosed with this product. Contact your INTELLINET NETWORK SOLUTIONS dealer
with comments or questions, or visit www.intellinet-network.com for information on the
latest software and rmware updates, related products and additional contact information.
Safety & comPliance StatementS
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC (Federal Communication Commission) Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from the receiver connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution
This equipment must be installed and operated in accordance with provided instructions, and a
minimum of 20 cm spacing must be provided between the computer-mounted antenna and a
person’s body (excluding hands and feet) during wireless modes of operation. As this device
complies with Part 15 of the FCC Rules, operation is subject to the following two conditions:
1) This device may not cause harmful interference; and 2) this device must accept any
interference received, including interference that may cause undesired operation. Any changes
or modications not expressly approved by the party responsible for compliance could void the
authority to operate equipment.
FCC Radiation ExposuRE statEmEnt
This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding these limits, human proximity to the
antenna shall not be less than 20 cm (8 inches) during normal operation. The antenna(s) used
for this transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
R&ttE ComplianCE statEmEnt
This equipment complies with all the requirements of Directive 1999/5/EC of the European
Parliament and the Council of March 9, 1999, on radio equipment and telecommunication
terminal equipment (R&TTE) and the mutual recognition of their conformity. The R&TTE directive
repeals and replaces Directive 98/13/EEC (Telecommunications Terminal Equipment and
Satellite Earth Station Equipment) as of April 8, 2000.
Eu CountRiEs intEndEd FoR usE
The ETSI version of this device is intended for home/ofce use in Austria, Belgium, Denmark,
Finland, France, Germany, Greece, Ireland, Italy, Luxembourg, the Netherlands, Portugal,
Spain, Sweden and the U.K., and is also authorized for use in EFTA member states Iceland,
Liechtenstein, Norway and Switzerland. (EU countries not intended for use: none.)
2

3
hardWare inStallation
1. Connect the 1-Port USB Wireless Print Server to the printer you want to share on the network.
2. Connect the print server to your network by attaching the network cable to the UTP port of
the print server.
3. Connect the power adapter to the print server. The print server will perform the Power-On-
Self-Test (POST) after it is powered on. During the POST, the Status LED will be blinking.
When the Status LED stops blinking (and is no longer lit), the print server is ready for use.
NOTE: Only use the power adapter included with the print server. Do not use any other adapter.
SoftWare inStallation
Administration Utilities Installation
The Administrator Installation program executes a wizard-driven procedure that performs the
following tasks:
• Installs all necessary utilities and drivers on your PC (including the client utilities).
• Prompts to congure the print server (including the print server name and IP address).
• Adds the network port of the print server to your PC.
After the installation, perform the standard “Add Printer” procedure and choose the print
server’s network port in the “Available Ports” list. You can then test the printing function from
the Administrator PC.
The Administrator Installation can be performed on Windows 98SE/Me/NT/2000/XP/Server
2003/Vista with the same user interface. Before the installation, verify that your network
protocol is installed on your PC (TCP/IP, IPX and/or NetBEUI). Note that the following steps
are representative of Windows XP; the procedures are similar for other operating systems.
1. Insert the CD included with the 1-Port USB Wireless Print Server into your CD-ROM drive.
The Autorun.exe program should be executed automatically. If not, run Autorun.exe
manually from CD-ROM drive’s root directory.
2. When the Installation Manager screen displays, click “Administrator Installation.”

3. When the Print Server Utilities screen displays, click “Next.”
4. Click “Next” to install the utilities in the default folder, or click “Change” to specify the
destination folder where you would like to install the utilities.
4

5
5. Select the components you want to install. It is highly recommended that all provided
components be installed. Click “Next” to continue.
6. Click “Install.”

7. The system will start to install the utilities automatically.
8. You have completed the installation phase and can prepare to congure the print server.
The “Choose Print Server” eld will list all print servers within the network. Select the print
server you would like to congure and click “Next.”
NOTE 1: If this is the rst time you’re conguring this print server, the print server name is the
last 6-digits of the device’s MAC ID plus a “PS” prex. Check for the MAC ID on the print server.
NOTE 2: The list can only display the devices from the same manufacturer.
6

7
9. Specify a recognizable name for the print server and click “Next.”
10. Specify the IP address for the print server manually, or click “Next” to keep the default IP
address.

11. The conguration summary is displayed on the next screen. You’ve now completed the
print server setup. Click “Finish” and your system will automatically add the network port
of the print server to your PC.
12. The Administrator Installation procedure is complete. Click “Finish.”
8

9
Client Utilities Installation
The Client Installation program is a wizard-driven procedure which that performs the following
tasks:
• Installs client utilities and drivers onto your PC.
• Automatically adds all network ports to your PC.
The network port driver supports network protocol auto-detection. It will automatically select
an available network protocol (TCP/IP, IPX or NetBEUI) of the client computer to connect to
the print server.
Since both the print-server side and client side support multiple protocols, the conguration
process of the client side is fully automatic.
After the installation, perform the standard “Add Printer” procedure and choose the print
server’s network port in the “Available Ports” list. You can test printing from the PC to the print
server as your local printer.
The Client Installation procedure can be performed on Windows 98SE/Me/NT/2000/XP/
Server 2003/Vista with the same user interface. Before installation, conrm that your PC has
already connected to the network and installed at least one network protocol. Note that the
following steps are representative of Windows XP; the procedures are similar for other
operating systems.
1. Insert the CD included with the 1-Port USB Wireless Print Server into your CD-ROM drive.
The Autorun.exe program should be executed automatically. If not, run Autorun.exe
manually from CD-ROM drive’s root directory.
2. When the Installation Manager screen displays, click “Administrator Installation.”

3. When the Print Server Utilities screen displays, click “Next.”
4. Click “Next” to install the utilities in the default folder, or click “Change” to specify the
destination folder where you would like to install the utilities.
10

11
5. Click “Install.”
6. The system will automatically start to install the utilities.

7. The installation procedure is complete, and
you can now set up the client’s computer. All
network ports of the print servers detected on
the network will automatically be added to
your PC. Click “Continue.”
NOTE: If there are no print servers currently
detected on the network, click “Continue” to nish
the installation. Refer to Section 3.5.1 in the user
manual to manually add network ports of print
servers.
8. The Client Installation procedure is complete. Click “Finish.”
12

13
Windows Add Printer Procedure
After adding a network port of the print server to your PC through either the Administrator or
Client Installation program, you can follow one of the procedures below to add a printer to
your Windows operating system.
Windows Vista
1. On the desktop, go to Start, then Settings\Printers.
2. Click “Add a Printer.”
3. When the Add Printer screen displays, select “Add a local printer.”
4. Choose the suitable printer port created during the installation process and click “Next.”

5. Select the printer manufacturer and the printer model and click “Next.” If your printer is not
on the list, click “Have Disk…” to install the driver of the printer. After installation, the printer
model will be added to the list.
6. Name your printer and set the default printer, then click “Next.”
14

15
7. The printer drivers are being installed.
8. At this point, it’s recommended that you print a test page. Click “Finish.”

9. When the printer is shown as being added to the Printers page, you’ve added the printer to
your computer successfully. Now you can start to print from your computer to the print server.
Windows XP
1. On the desktop, go to Start, then Settings, then select “Printers and Faxes.”
2. Click “Add a Printer.”
3. When the Add Printer Wizard screen displays, click “Next.”
16

17
4. Select “Local printer attached to this computer” and make sure that “Automatically detect
and install my Plug and Play printer” is not selected. Click “Next.”
5. From the drop-down menu in the “Use the following port” eld, choose the suitable print
server network port created during the Administrator Installation or Client Installation
process. Click “Next.”

6. Select the printer manufacturer and the printer model and click “Next.” If your printer is not
on the list, click “Have Disk…” to install the driver of the printer. After installation, the printer
model will be added to the list.
7. Name your printer and set the default printer, then click “Next.”
18

19
8. Choose whether or not to print a test page. (It’s recommended.) Click “Next.”
9. You’ve successfully added the printer to the PC. The printer information is displayed on the
screen. Click “Finish.” You can now start to print from your PC to the print server.

INTELLINET NETWORK SOLUTIONS™offers a complete line
of active and passive networking products.
Ask your local computer dealer for more information or visit
www.intellinet-network.com.
Copyright © INTELLINET NETWORK
SOLUTIONS
All products mentioned are trademarks or registered trademarks of their respective owners.
