SR61 Belt Holster Instructions
The SR61 belt holster (P/N 825-179-xxx) provides you with a
convenient way to carry the SR61 Cordless Scanner when you are
not using it. The versatility of the holster allows you to use it on
your left or right side whether you want to reach straight down or
across your body for your SR61. These instructions describe how
to configure and wear the belt holster.
To configure the holster
1Remove the Phillips screw from the mounting bar.
2Slide the holster cup down and off of the mounting bar.
Mounting
bar
Phillips
screw
Holster
cup
Mounting
bar
Holster
cup
Mounting
loop

3Insert the mounting bar into the other mounting loop on the
holster cup.
4Replace the screw in the bottom of the mounting bar.
To put on the holster and belt
1Slide the holster to the appropriate side of the belt.
2With the holster on the outside of your thigh, buckle the belt
around your waist.
3Adjust the belt so it is snug and comfortable for you, and
secure the loose end of the belt in the J-hook.
4Buckle the leg strap around your thigh.
5Adjust the leg strap so it is snug and comfortable for you.
SR61 BeltHolster Instructions
*943-023-001*
P/N 943-023-001
Waist belt
buckle
J-hook
Leg
strap Leg
strap
