Intracom OSDR User manual

Installation &
Cabling Manual
Edition 3.0 Confidential
Outdoor Software-Defined
Radio (OSDR) platform
GDC-003/54
OSDR

INTRACOM TELECOM
19.7 km Markopoulou Ave., Peania, Athens, GR 19002
T [phone], F [phone]
http://www.intracom-telecom.com
email (product support): [e-mail]
The information contained in this document is subject to change without prior notice.
INTRACOM S.A. TELECOM SOLUTIONS, 2018.All rights reserved.
All copyright, intellectual and industrial rights in this document and in the technical knowledge it contains
are owned by INTRACOM S.A. TELECOM SOLUTIONS and/or their respective owners.
This document is made available to the end users only for their internal use.
No part of this document nor any data herein may be published, disclosed, copied, reproduced,
redistributed by any form or means, electronically or mechanically, or used for any other purpose
whatsoever without the prior written approval of INTRACOM S.A. TELECOM SOLUTIONS.
Information as well as drawings and specifications contained in this document are subject to change
without prior notice.
All trademarks and copyrights mentioned herein are the property of INTRACOM S.A. TELECOM
SOLUTIONS and/or their respective owners.
Any rights not expressly granted herein are reserved.
Printed in Greece.

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
-I-
Document Revision History
Previous Edition: 2.2
Current Edition: 3.0
Reasons of Change
M
= Modified,
A
= Added,
R
= Removed
Details
New materials (M) (A)
New installation procedures (A)
•Sectoral 26/28/32 GHz antenna
•Sectoral 10.5 GHz antenna
•Parabolic antenna 10.5/26/28/32
GHz
•M20 gland
•Outdoor AC PoNE
•Indoor AC PoNE
•XPOL tool kit
Contents restructure (M) Document optimization
Revised installation instructions (M) •OSDR to sectoral/parabolic
antenna
•OSDR to panel antenna
•Panel antenna mounting kit
•ETH cable installation
•Optical cable installation
•Power injectors installation
•Sectoral antenna pole space
requirements

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
-II-

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
-III-
Equipment Disposal
Disposal of old electrical and electronic equipment (applicable through the
European Union and other European countries with separate waste collection
systems).
This symbol, found on this product and any of its parts or on its operating instructions
or on its packaging, indicates that electrical and electronic equipment may not be
disposed of as unsorted municipal waste. Instead, this product should be handed over
to applicable collection points for the recycling of electrical and electronic equipment.
By ensuring the correct disposal of this product, you will help prevent potential
negative consequences to the environment and human health, which could otherwise
be caused by inappropriate disposal of this product.
By recycling, reusing and other forms of recovery of old electrical and electronic
equipment you are making an important contribution to the conservation of natural
resources and to the protection of the environment.
For more information about the recycling of this product, please contact your local
municipal authorities, municipal waste disposal service or the store where you
purchased this product.
Απόρριψη παλαιών ηλεκτρικών και ηλεκτρονικών συσκευών (ισχύει στην
Ευρωπαϊκή Ένωση και άλλες Ευρωπαϊκές χώρες με συστήματα χωριστής
συλλογής απορριμμάτων).
Το σύμβολο αυτό, που απεικονίζεται πάνω στο προϊόν και σε τυχόν εξαρτήματα του
ή στο εγχειρίδιο οδηγιών του ή στη συσκευασία του, δείχνει ότι οι ηλεκτρικές και
ηλεκτρονικές συσκευές, μετά το πέρας της λειτουργίας τους, δεν θα πρέπει να
απορρίπτονται μαζί με τα αστικά απόβλητα. Αντίθετα θα πρέπει να παραδίδονται σε
κατάλληλα σημεία συλλογής για την ανακύκλωση των ηλεκτρικών και ηλεκτρονικών
συσκευών.
Διασφαλίζοντας τη σωστή απόρριψη αυτού του προϊόντος, συνεισφέρετε στην
πρόληψη πιθανών αρνητικών συνεπειών στο περιβάλλον και την ανθρώπινη υγεία,
οι οποίες θα μπορούσαν να προκληθούν από την μη ενδεδειγμένη απόρριψη του
προϊόντος.
Η ανακύκλωση, επαναχρησιμοποίηση και άλλες μορφές αξιοποίησης των παλαιών
ηλεκτρικών και ηλεκτρονικών συσκευών βοηθούν στη διαφύλαξη των φυσικών πόρων
και στην προστασία του περιβάλλοντος.
Για περισσότερες πληροφορίες σχετικά την ανακύκλωση αυτού του προϊόντος,
παρακαλούμε επικοινωνήστε με τις τοπικές δημοτικές αρχές, την υπηρεσία
αποκομιδής αστικών αποβλήτων ή το κατάστημα από το οποίο αγοράσατε το
συγκεκριμένο προϊόν.
Για περισσότερες πληροφορίες, μπορείτε να επικοινωνείτε με το Συλλογικό Σύστημα
Εναλλακτικής Διαχείρισης Αποβλήτων Ηλεκτρικού και Ηλεκτρονικού Εξοπλισμού
“Ανακύκλωση Συσκευών Α.Ε.” (www.electrocycle.gr).

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
-IV-
Declaration of Conformity
Hereby, Intracom S.A. Telecom Solutions declares that the products
OmniBASTM & WiBASTM are CE marked in compliance with the essential
requirements and other relevant provisions of the Radio Equipment Directive
2014/53/EU, Eco Design Directives 2009/125/EC, 2010/30/EU and with the
requirements of the RoHS directive 2011/65/EU.
The full text of the EU declaration of conformity is available at the
following URL: http://emc.intracom-telecom.com/en/start.htm
∆ήλωση Συμμόρφωσης
Με την παρούσα, ηIntracom Α.Ε. Τηλεπικοινωνιακών Λύσεων δηλώνει ότι
τα προϊόντα OmniBASTM & WiBASTM φέρουν την σήμανση CE
συμμορφούμενο προς τις απαιτήσεις και τις λοιπές διατάξεις των οδηγιών
Radio Equipment Directive 2014/53/EU, Eco Design Directives
2009/125/EC, 2010/30/EU καθώς και με τις απαιτήσεις της οδηγίας RoHS
2011/65/EU.
Το πλήρες κείμενο της δήλωσης συμμόρφωσης (EU) είναι διαθέσιμο στην
ακόλουθη διεύθυνση URL: http://emc.intracom-telecom.com/en/start.htm

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
1
Table of Contents
1. Introduction.........................................................................................................................3
About this Document..........................................................................................................3
Safety Precautions.............................................................................................................5
2. Materials ..............................................................................................................................9
OSDR...............................................................................................................................10
Antennas..........................................................................................................................11
Mounting Kits ...................................................................................................................12
Cables..............................................................................................................................15
Cable Glands and Holder ................................................................................................. 18
Power Injectors.................................................................................................................19
SFP..................................................................................................................................21
Ancillaries.........................................................................................................................22
Others..............................................................................................................................23
3. Before Starting the Installation ........................................................................................ 24
3.1. Radio Unit View................................................................................................................25
3.2. Radio Unit Cabling ...........................................................................................................28
Gigabit ETH cable for service Traffic, Inband Management and Powering ....................... 29
Fiber Optic cable for service Traffic and Inband Management / Gigabit Ethernet (S-FTP)
cable for service Powering ...............................................................................................37
3.3. Installation Tools ..............................................................................................................45
3.4. Site Prerequisites.............................................................................................................47
4. Installation Procedures..................................................................................................... 51
4.1. Radio Unit and Antenna ...................................................................................................52
Sectoral and Parabolic Antenna.......................................................................................52
Panel Antenna..................................................................................................................65
4.2. Radio Unit Grounding Cable.............................................................................................76
4.3. Radio Unit Ethernet (S-FTP) Cable ..................................................................................77
4.4. Power Injector..................................................................................................................82
4.5. Radio Unit Optical Cable (Optional)..................................................................................83
4.6. Radio Unit Cable Holder...................................................................................................88
Appendix A: Adaptation Kit Installation.............................................................................. 91
Pole Installation................................................................................................................91
Appendix B: Mounting Kit Wall Installation......................................................................... 94
Wall Installation................................................................................................................94
Appendix C: Power Injector Installation.............................................................................. 96
Outdoor DC PoNE............................................................................................................97
Outdoor AC PoNE..........................................................................................................105

Table of Contents
2
Indoor AC POE...............................................................................................................112
Appendix D: Cables Termination....................................................................................... 114
Ethernet Cable ...............................................................................................................115
Grounding Cable............................................................................................................120
AC Power Supply Cable................................................................................................. 123
Appendix E: Sectoral Antenna Pole Space Requirements............................................... 126
10.5 GHz Antenna..........................................................................................................126
26/28/32 GHz Antenna...................................................................................................128
Appendix F: Receptacles Pin Out...................................................................................... 130
Radio Unit ...................................................................................................................... 130
Outdoor DC PoNE.......................................................................................................... 132

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
3
1. Introduction
About this Document
Scope of
Document The scope of this document is to provide detailed instructions on the
installation and cabling of OSDR (Outdoor Software-Defined Radio platform)
wireless product.
This document applies for installation of all available operation
modes: PtMP Hub(1), PtMP TS(2) and PtP Node(3).
Target
audience This document is addressed to certified technicians with wireless equipment
knowledge and skills concerning the following:
•Outdoor Radio Unit Installation (pole installation).
•Antenna installation.
•Preparation & Termination of: Ethernet & Grounding cables.
•Laying and Installation of: Ethernet, Fiber Optic & Grounding cables.
•Testing Ethernet cables using Ethernet cable testers.
Reference
manuals The reference manuals are listed below:
Item
Description
1
Lightning & Surge Protection for Intracom Telecom Radios – Installation
Practices.
2
OSDR Product Catalog.
3
OSDR System Description.
4
Lightning & Surge Protector (LSP) Datasheet.
5
WiBASTM-Connect Installation.
6
OSDR Commissioning.
Continued on next page
(1) WiBASTM OSDR Hub.
(2) WiBASTM OSDR Terminal Station (TS). For WiBASTM-Connect refer to item 5 of the Reference
manuals.
(3) OmniBASTM-OSDR.

1. Introduction
4
About this Document, Continued
Conventions This document applies to the following conventions:
•Arial Bold blue fonts are used for order codes.
•Arial Blue underline fonts are used for document references.
•Arial Bold black fonts are used for indicating important information or
paragraph header.
This symbol means DANGER. The purpose of this symbol is to warn
you that any wrong action can cause bodily injury or even death.
This symbol means CAUTION. The purpose of this symbol is to
prevent you from performing an action that might result in damage of
the equipment.
The purpose of this symbol is to protect you from unauthorized entry
to the site and damage your equipment.
A note calls your attention to important supplementary information.
A hint denotes helpful piece of advice or practical suggestion.

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
5
Safety Precautions
RF EXPOSURE
Locally applicable national and international RF safety requirements must be
adhered to when installing the OSDR / antenna system.
Please refer to local regulatory authorities for advice on compliance.
As guidance, for an OSDR 10.5 / 26 / 28 / 32 GHz:
According to EN 50385 and the relative EU Directives (1999/519/EC -
general public environment & 2004/40/EC – occupational environment) the
OSDR / antenna, should be installed in a location such that it is not possible
for workers or members of the public, in the normal course of their work or
everyday activities, to gain access closer in front of the antenna than the
specified distances in the table below.
The values of the table are given for OSDR at max power and max gain 60
cm terminal antenna.
BAND (GHz) DISTANCE (meters)
WORKER PUBLIC
PtMP
Hub PtMP TS or PtP Node PtMP Hub PtMP TS or PtP Node
26 / 28 / 32 0.5 2.55 1 5.1
10.5 1.25 2.5
Continued on next page

1. Introduction
6
Safety Precautions, Continued
General
•Do not install or operate this system in the presence of flammable gases or
fumes. Operating any electrical instrument in such an environment is a
safety hazard.
•Outdoor units and antennas should be installed ONLY by experienced
installation professionals who are familiar with local building and safety
codes and, wherever applicable, are licensed by the appropriate
government regulatory authorities. Failure to do so may void the product
warranty and may expose the end user or the service provider to legal and
financial liabilities.
•INTRACOM S.A. TELECOM SOLUTIONS and its resellers or distributors
are not liable for injury, damage or violation of regulations associated with
the installation of outdoor units or antennas.
•Appropriate labeling should exist at points with high risk of contact with
hazardous voltage.
•A list with emergency phone numbers (e.g. medical assistance numbers)
should be hung at easy-to-view positions.
•Also, recommended are for safety purposes, a fire detection system and
fire extinguishers (installed at easy-to-access points) inside the installation
premises.
•This equipment must be permanently earthed for protection and functional
purposes.
•Changes or modifications to this equipment not expressly approved by
INTRACOM S.A. TELECOM SOLUTIONS or the party responsible for
compliance could void the user's authority to operate the equipment.
Working on the Building’s Roof
During stormy weather, do not perform any mechanical assembling or
antenna installation / alignment works on the building’s roof.
The metal structure of towers / masts is prone to lightning.
Equipment Access
Only trained, authorized personnel should have access to the
installed equipment.
The equipment premises is intended to be installed in restricted access.
Continued on next page

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
7
Safety Precautions, Continued
Proper Grounding Installation & Equipotential Bonding
Never power on OSDR equipment unless you have completed the
grounding installation.
There is risk of equipment failure and / or electrical shock.
Ensure that:
•The grounding system measures an appropriate path resistance as specified
by local regulations.
•An appropriate grounding bar (or terminal) exists at the proximity of each
equipment installation position.
•The equipment is intended to be installed in location only where the
equipotential bonding has been applied.
Local AC Power Source
Ensure that:
•Safety requirements require a single pole circuit-breaker to be employed
between the local power DC source and outdoor AC PoNE.
•The circuit breaker must disconnect the mains phase of the AC power.
•For circuit breaker requirements refer to Circuit breakers on page 49.
Local DC Power Source
Ensure that:
•Safety requirements require a single pole circuit-breaker to be employed
between the local power DC source and outdoor DC PoNE.
•The circuit-breaker must control (open / close) the negative (-) V pole of the
power supply.
•The positive pole (+) V of the Local DC Power Source, which the wire of DC
power cable is terminated on, is grounded.
•
For circuit breaker requirements refer to Circuit breakers on page 49.
AC & DC Power Supply Cables
Ensure that:
•Power source cables must be tested for short circuits, open circuit or wrong
wiring before installed.
•The ground wire of the AC power source cable must be connected to the
protective earth (ground) point of the mains electricity installation.
Continued on next page

1. Introduction
8
Safety Precautions, Continued
Proper Connection of Power Injector
Never connect the Gigabit Ethernet (S-FTP) cables coming from the OUT
receptacle of power injector to network switches / routers / laptops.
There is risk of network devices failure due to potential power that is carrying
inside the cable.
Connect the OUT receptacle of power injectors to electrical GbE port of radio
unit as described in current manual.
Proper Radio Unit Power Up
Do not plug / unplug:
The Ethernet cable to / from the radio unit when the power injector
operates (powering through power injector).
There is risk of radio unit failure.
Always ensure that the power supply source / power injector is OFF before
plugging / unplugging.
Laser Radiation
When using SFP, then the OSDR is a CLASS 1 laser product.

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
9
2. Materials
Scope This chapter describes all the available materials for OSDR installation.
Topics The chapter includes the following topics:
Description
Page
OSDR 10
Antennas 11
Mounting Kits
12
Cables 15
Cable Glands and Holder 18
Power Injectors 19
SFP 21
Ancillaries 22
Others
23

2. Materials
10
OSDR
Radio unit
Oder Code Description
OSDR-OB-U-DSDS-SB
Full outdoor software defined radio, 10.5/26/28/32
GHz, FDD, GbE.
Operation Modes: PtMP Hub, PtMP TS, PtP Node.

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
11
Antennas
Antenna types
#
Description
A Antenna, sectoral 900, integrated,
26/28/32 GHz.
Includes:
•Mounting kit.
•Greasing paste.
•Installation leaflet.
B Antenna, sectoral 900, integrated,
10.5 GHz.
Includes:
•Mounting kit.
•Greasing paste.
•Installation leaflet.
C Antenna, parabolic, 0.3 m, integrated,
10.5/26/28/32 GHz.
Includes:
•Mounting kit.
•Greasing paste.
•Installation leaflet.
D Antenna(1), panel, 10.5 GHz.
For installation requires the following
order codes:
•OSDR-ANT-MNT (mounting kit).
•GRS-PST (greasing paste).
For antennas order codes please refer to item 2 of Reference
manuals on page 3.
(1) Extra bolts and leaflet concerns only WiBASTM-Connect installation.

2. Materials
12
Mounting Kits
Mounting kit for
panel antenna
Oder Code Description
OSDR-ANT-MNT Pole/Wall mounting kit for panel antenna 10.5 GHz (pole
diameter 48 mm up to 60 mm).
Pole adaptation
bracket for
panel antenna
Oder Code
Description
INST-ADAPT Pole adaptation bracket for panel antenna 10.5 GHz (pole
diameter 61 mm up to 120 mm).
OSDR-ANT-MNT is required for mounting
panel antenna 10.5 GHz.
# Items Description Qty Details
A Hose clamp. 2 For pole diameter 101 mm up to 120 mm.
B Hose clamp. 2 For pole diameter 61 mm up to 100 mm.
C Bracket. 1 Pole adaptation bracket.
D Washers. 4 M8 washers (DIN125A), stainless.
E Screws. 4 M8x25 hex-headed screw (DIN933),
stainless.
Continued on next page

Outdoor Software Defined Radio (OSDR) platform
Installation & Cabling Manual - Edition 3.0
13
Mounting Kits, Continued
Hooks for panel
antenna
Oder Code
Description
OSDR-PL-ANT-KIT
Hooks for panel antenna 10.5 GHz.
Pole mounting
bracket for
outdoor DC
PoNE
Oder Code Description
INST-PONE-PL
Mounting bracket for pole installation of PONE-OD-DC
power injector (pole diameter 50 to 120 mm / steel hose
clamp diameter 64 to 140 mm).
Pole mounting
bracket for
outdoor AC
PoNE
Oder Code Description
INST-PONE-PL2
Mounting bracket for pole installation of PONE-OD67-AC
power injector (pole diameter 50 to 120 mm / steel hose
clamp diameter 64 to 140 mm).
2 x screws and lock washers are used. The
third set (screw and lock washer) is for spare
purpose.
Continued on next page

2. Materials
14
Mounting Kits, Continued
Pole hose
clamps
Stainless steel hose clamp for pole installation of ETH-SRG-OD68 lightning
surge protector (one ETH-SRG-OD68 requires 2 clamps).
The following table shows the available hose clamps:
Item Order Code Description
A ST-CL64-140 ∅64-140 mm, width = 14.2 mm.
For
∅
48-100 mm pole diameter.
B ST-CL102-178 ∅102-178 mm, width = 14.2 mm.
For
∅
75-149 mm pole diameter.
C ST-CL172-248 ∅172-248 mm, width = 14.2 mm.
For
∅
150-229 mm pole diameter.
D ST-CL242-318 ∅242-318 mm, width = 14.2 mm.
For
∅
230-300 mm pole diameter.
