Inverter Fusion i-TECH MIG150 User manual

i-TECH MIG150
Inverter MIG
Welding Machine
User Manual
Do not aempt to set up or operate this equipment unl you have read & fully
understood the contents of this manual. If you do not fully understand any of the
instrucons, please contact your supplier for further informaon & advice before
beginning any welding procedure.

Contents
1. General descripon.................................................................................. 1
2. Warranty .................................................................................................. 2
3. Safety........................................................................................................ 2
4. Main parameters...................................................................................... 3
5. Panel layout.............................................................................................. 4
6. Set up & operaon ................................................................................... 6
7. Cauon ................................................................................................... 11
8. Maintenance .......................................................................................... 11
9. Troubleshoong ..................................................................................... 12
1. General Descripon
 The i-TECH MIG150 welding machine is manufactured with advanced
inverter technology.
 IGBT technology enhances the reliability of the machine.
 It is capable of MIG and scratch start TIG welding.
 High duty cycles enable connuous welding for longer periods.
 Closed loop feedback control, constant voltage output, workable under
network voltage uctuaon within ± 15%.
 Adjustable welding voltage and circuit enable excellent welding
characteriscs.
 High no-load and slow wire feed funcons increase the success rate of arc
starng.
1

2. Warranty
1. Your i-TECH MIG150 welder is covered by a comprehensive 2 year return-to-
base parts & labour warranty.
2. Improper use, abuse or any aempt to repair the product by an unauthorised
third party will invalidate any warranty claim.
3. Any parts or consumables ed or used in conjuncon with the i-TECH MIG150
which aect the equipment operaon & which are deemed by Inverter Fusion
Ltd to be of inferior quality or not t for that purpose will be regarded as abuse
and will invalidate the warranty claim.
4. The claimant is responsible for all carriage, insurance and transportaon costs in
returning the product to Inverter Fusion Ltd.
5. Upon receipt and inspecon of the product, it will be repaired or replaced at the
discreon of Inverter Fusion Ltd. In the event of a chargeable repair, or a repair
being required that is not considered to be a warranty issue, the claimant will be
contacted for further instrucons.
6. Following the compleon of any authorised warranty claim work, the product
will be returned to the claimant at the cost of Inverter Fusion Ltd (UK only).
3. Safety
There are inherent safety issues whilst welding so please ensure you read this
manual carefully before commencing operaons and follow the safety guidelines
below to protect yourself and others from injury:
1. Whilst welding, ensure that you are working in a well venlated area to avoid
breathing in smoke & fumes.
2. Always wear a suitable welding mask/helmet, welding gloves & protecve
clothing whilst welding.
3. Never look at the welding arc when not wearing a welding mask or helmet.
4. Never touch the work piece with bare hands whilst it is sll hot.
5. When appropriate use a suitable welding screen or curtain to protect other
people.
6. Do not weld near ammable materials or combusble liquids or gases.
7. Ensure the earth return is connected appropriately to prevent danger of electric
shock.
8. Never touch moving parts on the machine, such as the fan, and ensure all doors,
panels and covers are closed and in place during operaon.
9. Magnec elds produced by the welder during operaon may aect cardiac
pacemakers — pacemaker users should consult a doctor before welding.
2

4. Main Parameters
Input Power Voltage 240 — 50/60Hz
Current Range 20—150 Amps
Open Circuit Voltage Range 22—31
Wire Feed Speed (m/min) 1—11
MIG Welding Wire (ø) 0.6—1.0mm
Duty Cycle @ 20°
35% @ 150 Amps
60%@ 120 Amps
100% @ 100 Amps
Power Factor 0.58
Eciency 80%
Protecon Class IP21
Weight 11kg
Dimensions 450mm x 203mm x 340 mm
3

5. Panel Layout
5.1. Front panel
Power on indicator LED
4
Voltage adjustment
Overheang warning LED
Euro welding torch
connector
Earth return
Wire speed adjustment

5.2. Back panel
5.3. Internal panel structure
Power on/o switch
Input power cable
Negave terminal Posive terminal
5
Shielding gas hose connector

6. Set Up & Operaon
Please ensure you follow these instrucons whilst seng up your i-TECH MIG150:
6.1. Power cable connecon
Connect the power input lead to a suitable 240v single phase plug.
6.2. MIG welding with gas
6.2.1. Set up
1. Connect the welding torch to the output socket on the front panel of the
machines and ghten it.
2. Connect the earth return to the negave (-) terminal on the front panel of the
machine.
3. Insert the dix plug on the wire feeder into the “GAS” output socket on the
internal panel and ghten it clockwise.
4. Fix the welding wire coil to the rack axis on the wire feeder, ensuring that the
groove in the wire feed wheel is aligned with the torch wire
feed hole.
5. Unfasten the tensioner on the wire-pressing wheel and feed the wire
into the appropriate groove in the wire feed roller, pressing it in securely but not
too ghtly. NOTE: ensure the correct roller is ed i.e. 0.8mm  wire needs a
0.8mm  groove on the roller.
6. Thread the wire into the welding torch manually and then press the wire feed
buon to feed it out of the end of the torch.
7. Connect the gas hose ghtly to the regulator on the gas bole.
6

6.2.2. Operaon
1. Switch the power on at the back of the machine — the LED power indicator will
light up and you will hear the fan start to work.
2. Open the gas cylinder valve and adjust the ow meter to the desired posion.
3. Turn the conversion switch on the front of the machine to the “MIG welding”
posion and adjust the voltage and wire feed speed appropriately.
4. Adjust the burnback control on the internal panel to ensure the required length
of wire protrudes out of the contact p aer welding.
5. Press the switch on the welding torch and begin welding.
6. The gas cuts o automacally one second aer the arc is stopped.
6.3. MIG welding without gas
6.3.1. Set up
1. Connect the welding torch to the output socket on the front panel of the
machines and ghten it.
2. Connect the earth return to the negave (-) terminal on the front panel of the
machine.
3. Insert the dix plug on the wire feeder into the “NO GAS” output socket on the
internal panel and ghten it clockwise.
4. Fix the welding wire coil to the rack axis on the wire feeder, ensuring that the
groove in the wire feed wheel is aligned with the torch wire feed hole.
5. Unfasten the tensioner on the wire-pressing wheel and feed the wire into the
appropriate groove in the wire feed roller, pressing it in securely but not too
ghtly. NOTE: ensure the correct roller is ed i.e. 0.8mm  wire needs a 0.8mm
 groove on the roller.
6. Thread the wire into the welding torch manually and then press the wire feed
buon to feed it out of the end of the torch.
7

6.3.2. Operaon
1. Switch the power on at the back of the machine — the LED power indicator will
light up and you will hear the fan start to work.
2. Turn the conversion switch on the front of the machine to the “MIG welding”
posion and adjust the voltage and wire feed speed appropriately.
3. Adjust the burnback control on the internal panel to ensure the required length
of wire protrudes out of the contact p aer welding.
4. Press the switch on the welding torch and begin welding.
6.4. Changing the feed roll groove
The feed roll groove is factory set for welding ller wires of 0.8-1.0mm diameter.
The feed roll groove must be changed if you use 0.6mm ller wire.
1. Open the feed roll using the pressure control lever.
2. Switch the machine on from the main switch.
3. Press the welding gun trigger and drive the feed roll in such a posion that the
locking screw is up and can be opened.
4. Switch o the machine using the main power switch.
5. Open the feed roll locking screw by approximately half a turn using a 2.0mm
Allen key.
6. Pull the feed roll from its sha.
7. Turn the feed roll and reinstall it, making sure that the screw is on the same
level as the sha.
8. Tighten the feed roll locking screw.
8

6.5. Threading the ller wire
1. Open the reel housing by pressing the opening buon and install the wire reel
so that it rotates counter-clockwise. You can use either a 5kg (200mm diameter)
or 1kg (100mm diameter) wire reel in the machine.
2. Aach the reel with a reel lock.
3. Unfasten the wire end from the reel, but keep hold of it.
4. Straighten the wire end for approximately 20cm and cut the wire in the
straightened secon.
5. Open the pressure control lever which then opens the feed gear.
6. Thread the wire through the wire’s rear guide to the gun’s wire guide.
7. Close the feed gear and fasten it with the pressure control lever. Make sure that
the wire runs in the feed roll groove.
8. Adjust the compression pressure with the pressure control lever so that it is no
higher than the middle of the scale. If the pressure is too high, it removes metal
fragments from the wire surface and may damage the wire. On the other hand,
9

if the pressure is too low, the feed gear slips and the wire does not run
smoothly.
9. Press the welding gun trigger and wait for the wire to come out.
10.Close the reel housing cover.
CAUTION: When driving the wire into the gun, do not point the gun at yourself or
others or put your hand in front of the p, since the cut wire is extremely sharp.
Keep ngers away from the feed rolls.
6.6. Reversing polarity (for gasless wire only)
Some ller wires are recommended to be welded with the gun in the negave (-)
pole. In this case, the polarity must be reversed. Consult the ller wire packaging
for the recommended polarity.
1. Disconnect the machine from the mains.
2. Bend the rubber cover of the earthing cable’s pole in such a way that the cable
can be disconnected.
3. Remove the nuts and washers. Note the correct order of the washers!
4. Interchange the cables.
5. Install the washers in place and close the ghtening nuts to spanner ghtness.
6. Put the rubber cover of the earthing cable’s pole rmly in place. The rubber
cover must always protect the earthing cable’s pole.
10

7. Cauon
7.1. Working environment
1. Welding should be carried out in a relavely dry environment with a humidity of
90% or less.
2. The temperature of the working environment should be -10°C to +40°C.
3. Avoid welding in the open air unless sheltered from sunlight and rain, and never
let rain or water inltrate the machine.
4. Avoid welding in dusty areas or where corrosive chemical gases are present.
5. Avoid MIG welding in environments with a strong airow.
7.2. Venlaon
The i-TECH MIG150 contains an inner fan which cools it eecvely, enabling it to
work steadily for longer periods. To enable the fan to work eciently, always
ensure that the louvers on the front panel are uncovered and unblocked and that
the minimum distance between the machine and other objects is 30cm.
7.3. Overheang protecon
If the machine has become overheated because of connuous welding for long
periods the overheat LED will light up and the overheat protecon system will begin
working, causing the machine to stop welding. If this occurs there is no need to
restart the machine — once it has cooled down the LED will go out and welding can
recommence.
8. Maintenance
1. Always use and store your i-TECH MIG150 in a clean, dry environment.
2. Regularly check that the cables and leads are in good condion.
3. Regularly check that the gas hose is in good condion and has no cracks.
WARNING
Improper use, abuse or any aempt to repair the product by an unauthorised
third party will invalidate any warranty claim.
Any parts or consumables ed or used in conjuncon with the i-TECH MIG150
which aect the equipment operaon & which are deemed by Inverter Fusion
Ltd to be of inferior quality or not t for that purpose will be regarded as abuse
and will invalidate the warranty claim.
11

9. Troubleshoong
Fault Cause Remedy
The power on
LED is not lit
No mains power
available
Ensure that the machine is connected
to a suitable live mains power source
& is switched on
The fuse in the plug is
no longer working Replace the fuse
The yellow LED
light is lit
The machine has
overheated because the
working duty cycle has
been exceeded
Stop welding for a while to allow the
machine me to cool down. Ensure
that the fan & output ducts are free
from obstrucon & that there is
adequate venlaon space around
the machine
No welding
output
Welding leads are
incorrectly ed
Check that the leads are ed to the
correct sockets & that the earth
return is connected to the work piece
MMA Welding
operaon is
errac or not as
required
Incorrect welding
current selected
Check that the current seng is
correct for the selected electrode
Faulty or damp
electrode Select an alternave electrode
Errac or
uncontrollable
MMA welding arc
Faulty electrode holder
or bad earth return
connecon
Check that the correct sized
components are ed & that the
electrode holder is in good condion.
Ensure that there is a good earth
return connecon with the work
piece
Incorrect wire feed
roller
Check correct size wire feed roller is
ed
MIG welding wire
feed errac
Incorrect feed roller
tension Check feed roller tension
Wire binding on reel Check wire will easily feed from roll
Nozzle blocked or wrong
size
Check correct size nozzle is ed in
torch
12

Heathpark Way, Heathpark Industrial Estate, Honiton, Devon, EX14 1BB
01404 549791
[e-mail] | www.inverterfusion.co.uk
Inverter Fusion Ltd @IFL_Welders
