Ironton 46174 User manual

12V LITHIUM-ION DRILL/DRIVER
OWNER’S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item#: 46174

Page of 13
2
Thank you very much for choosing an IRONTON product! For future reference, please complete
the owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual
to become familiar with this product before you begin using it.
This machine is designed for certain applications only. The distributor cannot be responsible for
issues arising from modification. We strongly recommend this machine not be modified and/or
used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the machine until you have first contacted the
distributor to determine if it can or should be performed on the product.
For technical questions please call 1-800-222-5381.
SPECIFICATIONS+
!
• Item #:-------------------------- 46174
• Motor Input:------------------- 12V DC
• No Load Speed:--------------- 0-350/0-1300 RPM, Reversible
• Chuck Size:------------------- 3/8” (10mm)
• Torque Settings:--------------- 13
• Max. Torque:------------------- 250 in.-lbs
• Battery: ----------- ------------ 12 Volt, Lithium-Ion
• Charger Input:----------------- 120V~/ 60Hz
• Charging time:---- ------------ 3-5 hours
• Net weight: -------------------- 2.2 lbs
Includes: 1 -Battery, Charger and 1 Double-ended Screwdriver Bit
GENERAL SAFETY RULES
WARNING: Read and understand all warnings, cautions and operating instructions before
using this equipment. Failure to follow all instructions listed below may result in electric shock, fire
and/or serious personal injury.
SAVE THESE INSTRUCTIONS
WORK AREA SAFETY
• Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
• Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Power tools create sparks, which may ignite the dust or fumes.
• Keep bystanders, children, and visitors away while operating a power tool. Distractions can
cause you to lose control.
PERSONAL SAFETY
• Stay alert, watch what you are doing and use common sense when operating a power tool. Do
not use tool while tired or under the influence of drugs, alcohol, or medication. A moment of
inattention while operating power tools may result in serious personal injury.

Page of 13
3
• Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat, or hearing protection for appropriate conditions will reduce
personal injuries.
• Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. Air vents
may cover moving parts and should be avoided.
• Avoid accidental starting. Ensure the switch is in the off position before plugging in. Carrying
power tool with your finger on the switch or plugging in power tools that have the switch on
invites accidents.
• Remove any adjusting keys or wrenches before turning the power tool on. A wrench or
key that is left attached to a rotating part of the tool may result in personal injury.
• Do not overreach. Maintain proper footing and balance at all times. Loss of balance can cause
an injury in an unexpected situation.
• If devices are provided for connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related
hazards.
• Do not use a ladder or unstable support. Stable footing on a solid surface enables better
control of the tool in unexpected situations.
• Keep tool handles dry, clean and free from oil and grease. Slippery handles cannot safely
control the tool.
TOOL USE AND CARE
• Secure the workpiece. Use clamp or other practical way to hold the workpiece to a stable
platform. Holding the workpiece by hand or against your body is unstable and may lead to loss
of control.
• Do not force the power tool. The tool will perform the job better and safer at the feed rate for
which it is designed. Forcing the tool could possibly damage the tool and may result in personal
injury.
• Use the correct power tool for the job. Don’t force the tool or attachment to do a job for which
it is not designed.
• Do not use tool if switch does not turn it on or off. Any tool that cannot be controlled with
the switch is dangerous and must be repaired or replaced by an authorized service center.
• Turn power tool off, and disconnect the plug from the power source and/or battery pack from
the power tool before making any adjustments, changing the accessories, or storing the tools.
Such preventive safety measures reduce the risk of an accidental start up which may cause
personal injury.
• Store idle tool out of reach of children and other inexperienced persons. It is dangerous
in the hand of untrained users.
• Maintain power tools with care. Check for proper alignment and binding of moving parts,
component breaks, and any other conditions that may affect the tool’s operation. A guard or any
other part that is damaged must be properly repaired or replaced by an authorized service
center to avoid risk of personal injury.
• Use recommended accessories. Using accessories and attachments not recommended by
the manufacturer or intended for use on this type tool may cause damage to the tool or result in
personal injury to the user. Consult the operator’s manual for recommended accessories.

Page of 13
4
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
• Feed the workpiece in the correct direction and speed. Feed the workpiece into a blade,
cutter, or abrasive surface against the direction of the cutting tool’s direction of rotation only.
Incorrectly feeding the workpiece in the same direction may cause the workpiece to be thrown
out at high speed.
• Never leave the tool running unattended, turn the power off. Do not leave the tool until it
comes to a complete stop.
BATTERY TOOL USE AND CARE
• Ensure the switch trigger is in the off position before inserting battery pack. Inserting the
battery pack into power tools that have the switch on invites accidents.
• Recharge only with the charger specified by the manufacturer. A charger that is suitable for
one type of battery pack may create a risk of fire when used with another battery pack.
• Use battery tools only with specified battery pack. Use of any other battery packs may
create a risk of injury and fire.
• Avoid storing battery pack in a container with other metal objects, such as nails, coins,
clips, keys, screws, or other small metal objects that can make a connection from one
terminal to another. Always protect the battery terminals when battery pack is not being used.
Connecting the battery terminals together may cause burns or a fire.
• Under abusive conditions, liquid may be ejected from the battery. Avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation or burns.
•Battery tools do not need to be plugged into an electrical outlet, therefore, they are always
in operation condition. Be aware of possible hazards when not using your battery tool or when
changing accessories. Following this rule will reduce the risk of electric shock, fire or personal
injury.
WARNING: USE OF THIS TOOL CAN GENERATE AND DISBURSE DUST OR OTHER
AIRBORNE PARTICLES, INCLUDING WOOD DUST, CRYSTALLINE SILICA DUST AND
ASBESTOS. Direct particles away from face and body. Always operate tool in a well-ventilated
area and provide for proper dust removal. Use dust collection system wherever possible.
Exposure to the dust may cause serious and permanent respiratory or other injury, including
silicosis (a serious lung disease), cancer, and death. Avoid breathing the dust, and avoid
prolonged contact with the dust. Allowing dust to get into your mouth or eyes, or lay on your skin
may promote absorption of harmful material. Always use properly fitting NIOSH/OSHA approved
respiratory protection appropriate for dust exposure, and wash exposed areas with soap and water.
SERVICE
• Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
• Service your power tool periodically. When cleaning a tool, be careful not to disassemble
any portion of the tool since internal wires may be misplaced or pinched.

Page of 13
5
WARNING: READ AND UNDERSTAND ALL WARNINGS, CAUTIONS AND OPERATING
INSTRUCTIONS BEFORE USING THIS EQUIPMENT. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious personal injury.
SAVE THESE INSTRUCTIONS
SPECIFIC SAFETY RULES FOR CORDLESS DRILLS
WARNING: DO NOT LET COMFORT OR FAMILIARITY WITH PRODUCT (GAINED
FROM REPEATED USE) REPLACE STRICT ADHERENCE TO PRODUCT SAFETY RULES. If
you use this tool unsafe or incorrectly, you can suffer serious personal injury!
WARNING: Hold tool by insulated gripping surfaces when performing an operation where
cutting tools may contact hidden wiring or its own cord. Contact with a “live” wire will make exposed
metal parts of the tool “live” and shock the operator!
• Do not leave the tool running. Operate the tool only when hand-held .
• Be Aware that this tool is always in an operating condition , because it does not have to be
plugged into an electric outlet.
• When operating the tool from an elevated position , be aware of people or things beneath
you.
• Always hold the tool firmly in your hands before switching the tool “ON” . The reaction to
the torque of the motor as it accelerates to full speed may cause the tool to twist .
• Wear eye and hearing protection. Always use safety glasses with side shields. Unless
otherwise specified, everyday glasses provide only limited impact resistance, they are not safety
glasses. Use only certified safety equipment; eye protection equipment should comply with
ANSI z87.1 standards. Protective hearing equipment should comply with ANSI s3.19 standards.
• Protect your lungs . Wear a face or dust mask if the operation is dusty. Following this rule will
reduce the risk of personal injury.
• Always disconnect battery pack from tool or place the switch in the locked or off position
before any assembly, adjustments or changing of accessories. Following this instruction will
reduce the risk of serious personal injury.
• Do not place battery tools or their batteries near fire or heat. This will reduce the risk of
explosion and possibly personal injury.
• Never use a battery which has been dropped or received a sharp blow. A damaged battery
is subject to explosion. Properly dispose of a dropped or damaged battery immediately.
• Use designated battery pack (Ironton™ - Item# 46173) and charger for this tool. Use of
any other batteries may result in a risk of fire.
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS FOR CHARGER AND BATTERY
• Save These Instructions. This manual contains important safety and operating instructions for
your battery charger.

Page of 13
6
• Before Using the Battery Charger, read all instructions and cautionary markings on (1) Battery
Charger, (2) Battery, and (3) Product using battery.
• Use only the charger which accompanied your product or direct replacements as listed in this
manual. Do not substitute any other charger.
• Do not recharge battery in damp or wet environments. Do not expose battery pack to water
or rain.
• Do not operate charger with damaged cord or plug. Replace immediately.
• Do not operate charger if it has received a sharp blow, been dropped or otherwise damaged
in any way. Take it to a qualified serviceman.
• Do not disassemble charger or battery pack. Take it to a qualified serviceman when service
or repair is required. Incorrect reassembly may result in a risk of electric shock or fire.
• Do not charge battery pack when temperature is below 50 degrees F (10 degrees C) or above
104 degrees F (40 degrees C). Store tool and battery pack in a location where temperature will
not exceed 122 degrees F (50 degree C). This is important to prevent serious damage to the
battery cells.
• Place charger on flat non-flammable surface and away from flammable materials when
re-charging the battery pack.
• To reduce risk of electric shock, unplug charger from outlet before attempting any
maintenance or cleaning.
• If operating time has become excessively shorter, stop operating immediately. It may result
in a risk of overheating, possible burns and even an explosion.
• Battery leakage may occur under extreme usage or temperature conditions. Avoid contact
with skin and eyes. If liquid comes in contact with your skin, wash immediately with soap and
water. If liquid gets into your eyes, wash them out with clear water for at least 10 minutes, and
then seek medical attention right away.
• Do not attempt to use a step-up transformer, an engine generator or DC power receptacle.
• Do not short the battery pack. Do not touch the terminal with any conductive material. Avoid
storing battery pack in a container with other metal objects such as nails, coins, etc. Always
protect the battery terminals when battery pack is not used.
• Do not charge battery pack inside a box or container of any kind. The battery must be
placed in a well ventilated area during charging.
• Do not allow anything to cover or clog the charger vents.
• Do not incinerate the battery pack even if it is severely damaged or is completely worn out.
The battery pack can explode in a fire.
• Disconnect Charger from the power source when not in use. This will reduce the risk to
electric shock or damage to the charger if metal pieces should fall into the opening. It also will
help prevent damage to the charger during a power surge.
WARNING: A battery short can cause a large current flow, overheating, possible burns
and even a breakdown.
WARNING: 120 volts are present at charging terminals, do not probe with conductive
objects. Electric shock or electrocution may result. Do not allow any liquid to get inside
charger. Electric shock may result.

Page of 13
7
IMPORTANT BATTERY INFORMATION: DISPOSING OF THE BATTERY
• Your batteries are LITHIUM-ION rechargeable batteries. Certain Local, State and
Federal laws prohibit disposal of these batteries in ordinary trash.
• Consult your local waste authorities for your disposal/recycling options.
• More information regarding battery disposal in U.S. and Canada is available at;
http://www.rbrc.org/index.html, or by calling 1-800-822-8837 (1-800-8BATTERY).
SAVE THESE INSTRUCTIONS
KNOWING YOUR CORDLESS DRILL (FIG 1)
1. Keyless Chuck
2. Torque Ring
3. 2-Speed Gear Switch
4. Trigger Switch
5. Reversing Switch
6. LED Work Light
7. Battery Pack
8. Metal Belt Clip
UNPACKING AND CONTENT
IMPORTANT: Due to modern mass production techniques, it is unlikely the tool is faulty or
that a part is missing. If you find anything wrong, do not operate the tool until the parts have
been replaced or the fault has been rectified. Failure to do so could result in serious
personal injury.
CONTENTS IN PACKAGE
Description Q'TY
Drill 1
Charger 1
Screwdriver Bit 1
Operator's Manual 1

Page of 13
8
OPERATION
WARNING: To reduce the risk of serious personal injuries, read and follow all
important safety warning and instructions before using this tool.
WARNING: Always be sure that the tool is switched off before insertion or removal
of the battery pack.
INSTALLING OR REMOVING THE BATTERY PACK
(FIG 2)
• To install the battery pack, slide the battery pack (1)
into the bottom of the tool housing (2) all the way
until it locks in place with a click, as shown in FIG 2.
Lightly pull on the battery to ensure it is locked into
place and will not accidentally fall out of the tool,
causing an injury.
• To remove the battery pack, pull the battery pack away from the tool while depressing the
locking tab (3).
CHARGING THE BATTERY (FIG 3)
NOTE: Always check that the power supply corresponds to the voltage on the ratings plate.
• Plug the charger adaptor (1) into a 120 Volt AC
Power Source. The green light on the charger
stand (3) will illuminate, indicating the charger is
powered.
• Slide the battery (2) all the way into the charger
stand (3) until it locks in place with a click, as
shown in FIG 3. The red light on the charger stand
will illuminate, indicating that the battery is
charging.
• The red light will go off after charging is complete.
• Batteries may become warm while charging. This is normal.
• If battery is hot after continuous use in the tool, allow it to cool down to room temperature
before charging. This will extend the life of your batteries.
NOTE: It takes approximately 3-5 hours to charge up a completely discharged battery.
WARNING: Always disconnect the battery pack from the tool or place the switch in
the locked or off position before any assembly, adjustments or changing accessories.

Page of 13
9
TRIGGER SWITCH ACTION
• Turn the drill on by depressing the trigger switch (4-FIG 1).
• Depressing the switch further will produce more speed and torque.
• Use the Reversing Switch (5-FIG 1) to change the direction of rotation of the drill.
• The Reversing Switch has three positions: Forward, Reverse, and Off (middle).
• Always check the rotation before beginning your work.
TWO-SPEED GEAR SWITCH (FIG 4)
• Slide the speed gear switch (A) to choose between
position 1 for low speed range (0-350 RPM) and
position 2 for high speed range (0-1,300 RPM).
• The low speed range has more power and torque.
Use the low speed range for high power and
torque applications.
• The high speed range is for fast drilling or driving
applications.
LED WORK LIGHT
Your tool has a built-in LED work light (6-FIG 1) to illuminate the work area. When you turn on the
tool, the work light will automatically turn on.
ELECTRIC BRAKE
This drill is equipped with an electric brake. Like the torque settings, an electric brake provides
you with another element of control during various operations. If the tool consistently fails to
quickly stop after trigger switch release, have a qualified serviceman examine the tool.
CHUCK (FIG 5)
• Your drill is equipped with a single sleeve keyless
chuck (1), so you can quickly change bits with no
extra tools required.
• To install bits, place the reversing switch in the Off
(middle) position. Rotate the chuck body
counter-clockwise to open the chuck jaws (2) to a
point where the opening is slightly larger than the
bit size you intend to use. Insert the bit. Tighten
the chuck jaws by rotating the chuck body
clockwise to secure the bit in place.

Page of 13
10
NOTE: Always make sure that bits are seated firmly between the
chuck jaws. Never attempt to operate a bit that is wobbly, unstable,
or broken.
• To remove bits, place the reversing switch in the Off (middle) position. Loosen the chuck jaws
by rotating the chuck body counter-clockwise. Remove the bit.
WARNING: Make sure the drill bit is inserted straight into the chuck jaws. Do not
insert the drill bit into the chuck jaws at an angle and tighten. This could cause the drill bit
to be thrown from the drill, resulting in possible serious personal injury.
CLUTCH (TORQUE) SETTINGS
• During screw driving applications, you can adjust the maximum torque that the drill will produce.
• This feature can be used to prevent the stripping and breaking of screws, or to set a series of
screws to a depth that fits your project.
• Set the clutch ring (2-FIG 1) to settings from 1 (lightest) to 13 (heaviest). Setting 13 ( ) is direct
drive (torque is not limited) and used primarily for drilling operations.
• In general, you will find the lower settings more useful with smaller screws and the higher
settings more useful for larger screws.
APPLICATION
GENERAL SCREWDRIVING
1. Clamp your workpiece.
2. Drill pilot holes for larger screws or when driving screws into hardwoods.
3. Exert enough pressure to start the screw and keep it turning. Do not force the screw. Let the
tool do the work.
4.Use a speed that will not strip the screw head or break the screw. Maintain your balance.
GENERAL DRILLING
1. Clamp your workpiece. Use torque setting 13 then exert enough pressure to start the drill bit
and keep drilling. Do not force or stall the bit. Don’t bend or twist the bit. Let the tool and the
drill bit do the work.
2. Maintain your balance and be prepared for binding and for bit breakthrough.
WARNING: Forcing a drill bit, bending or twisting the bit, or failure to maintain
balance in case of binding and breakthrough can result in serious personal injury.
3. Chattering or vibration may indicate you need a finer bit or higher speed. If the bit overheats or
clogs, it may indicate you need a coarser bit or slower speed setting. Replace bits when they
become dull. Dull bits will produce poor results and may overheat the drill.
4. Use a coating of light oil when drilling into metal to help cool the bit, increase drilling action
and extend drill bit life.

Page of 13
11
MAINTENANCE
CLEANING
Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use. Use clean clothes to
remove dirt, dust, oil, grease, etc.
WARNING: Do not at any time let brake fluids, gasoline, petroleum-based products,
penetrating oils, etc., come in contact with plastic parts. Chemicals can damage, weaken or
destroy plastic, which may result in serious personal injury.
Electric tools used on fiberglass material, wallboard, spackling compounds, or plaster are subject to
accelerated wear and possible premature failure because the fiberglass chips and grindings are
highly abrasive to bearings, brushes, commutators, etc. Consequently, we do not recommend using
this tool for extended work on these types of materials. However, if you do work with any of these
materials, it is extremely important to clean the tool using compressed air.
LUBRICATION
This tool is permanently lubricated at the factory and requires no additional lubrication.

Page of 13
12
DIAGRAM AND PARTS LIST!
NO.+
Description+ +
Qty+
++
NO.+
Description+ +
Qty+
1
Chuck screw
1
13
Screw ST2.9x16
8
2
Keyless chuck
1
14
Rear cover ring
1
3
Front cover of torque ring
1
15
Hex screw M4
2
4
Back cover of torque ring
1
16
Carrying strap
1
5
Torque ring
1
17
Switch
1
6
Screw M4x16
4
18
Battery pack
1
7
Front cover of housing
1
19
Battery connecting dock
1
8
Gear box & motor
1
20
LED work light
1
9
Speed selector
1
21
Left half of housing
1
10
Right half of housing
1
22
Belt clip
1
11
Screw ST2.9x10
1
23
screw
1
12
Name plate
1
24
Rotation selector
1
For replacement parts and technical questions, please call 1-800-222-5381.
!
!

Page of 13
13
TWO-YEAR WARRANTY
!
This product is warranted free from defects in material and workmanship for 2 years after date of
purchase. This limited warranty does not cover normal wear and tear or damage from neglect or
accident. The original purchaser is covered by this warranty and it is not transferable. Prior to
returning your tool to store location of purchase, please call Toll-Free Help Line for possible
solutions.
THIS PRODUCT IS NOT WARRANTED IF USED FOR INDUSTRIAL OR COMMERCIAL
PURPOSES. ACCESSORIES INCLUDED IN THIS KIT ARE NOT COVERED BY THE 2-YEAR
WARRANTY.
BATTERY INCLUDED IS WARRANTED FOR ONE (1) YEAR AFTER DATE OF PURCHASE.
WARNING
Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains
chemicals known to the State of California to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and other masonry products, and
• Arsenic and chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce your
exposure to these chemicals: work in a well-ventilated area, and work with approved safety equipment,
such as those dust masks that are specially designed to filter out microscopic particles.
Distributed by
Northern Tool + Equipment Co., Inc.
Burnsville, Minnesota 55306
NorthernTool.com
Made in China
