ISE W288 ECO User manual

Operating Instructions
Washing Machine
ISE W288 ECO

Dear ISE customer!
Welcome to the family of ISE customers.
We hope that you will have many years of use from your new
machine.
The machine has many features. To make the most of its
functions, we recommend that you read the operating
instructions before using the machine. The operating
instructions include information on how you can help protect
the environment.
Operating Instructions
Washing Machine
ISE W288 ECO

4
Before using your machine for
the first time
4
Transport protection
4
Packing material
4
Washer door
4
Language selection
4
Checking water hardness
5Safety instructions
5
General
5
Installation
5
Overflow guard function
5
Transport/Winter storage
5
Recycling
6Child safety
6
Keep an eye on children!
6
Child safety catch
7
Description of the washing
machine
7Detergent compartment
8Advice and tips before washing
8
Sorting your laundry
8
Clothing
8
Laundry labels
8
Laundry label symbols
9
Hot water connection
9
Coloured cotton
9
Unbleached linen
9
Wool
9
Rayon fibres and synthetic fibres
9
Reducing allergic reactions
9
Save time and energy
9
High water level
9
Economy and efficiency
10
Detergents
10
Dyeing fabrics
11Washing
11
Sort your laundry.
11
Turn on the main power switch
11
Open the washer door and load
the washing
11
Add detergent and fabric softener,
as required
12
Select the programme
15
Select options
18
Close the washer door and press
the Start/Stop button
18
Once the program has finished
19Settings
19
You can change the following
settings:
19
Child-safe
19
Door opening
19
Language
19
Temperature
19
Extra rinses
20
Hot water
21Care and cleaning
21
Cleaning the trap and the drainage
pump
21
Cleaning the detergent
compartment
21
Cleaning the outside of the
machine
21
Cleaning the inside of the machine
to avoid unpleasant smells
22
Rinse holes under the agitator
22
If you have hard water
23Troubleshooting
23
The washer door will not open
23
The machine will not start
23
After power failure
23
Wet washing still in the machine
24
Error messages
2
Contents

25Technical information
25
Information on energy labelling
26
Information for test institute
26
Technical data
27Transport protection
28Installation
28
Positioning the washing machine
28
Adjusting the feet
28
Connection to water supply
28
Drainage connection
29
Electrical installation
30Service
30
Before contacting the service
division
32Quick guide
3
Contents

Transport protection
Remove any transport protection devices before
installing the machine. See the "Transport
protection" chapter.
Packing material
Please sort waste materials in accordance with
local guidelines.
Washer door
• The washer door cannot be opened until the
machine is connected to the electricity supply.
• To open the door manually, see "The washer
door will not open" in the "Troubleshooting"
chapter.
• The machine cannot be started when the door
is open.
• To open the washer door while a programme
is running, see "Close the door and press the
Start/Stop button" in the "Washing" chapter.
Language selection
You will be prompted to select the display
language when you have connected your machine
and start it for the first time. Do as follows:
1. Turn the programme selector to choose from:
US English, AU English, Svenska, Dansk,
Norsk, Suomi, Français, Deutsch, Italiano,
Espanol, Русский, Nederlands, EU English.
2. Press Start/Stop once to save the setting.
Checking water hardness
The quantity of detergent needed depends,
amongst other things, on how hard the water is.
See the detergent pack for details. Phone your
local water company to check the water hardness
in your area.
NOTE!
Each machine is tested before leaving the
factory. A small amount of water may remain in
the drain pump, though this does not affect
quality or damage the machine.
See Quick guide on the last page
4
Before using your machine for the first time

General
•Read the operating instructions and keep them
in a safe place.
• Installation of water and electricity, if required,
should be carried out by a qualified
professional.
• The machine should only be used for washing
items as described in these instructions. It is
not intended for dry cleaning.
• Use only detergent intended for machine
washing!
• Remove any transport protection devices
before using the machine. See the "Transport
protection" chapter.
• Repairs and maintenance relating to safety or
performance must be carried out by a qualified
professional.
•Damaged mains cables must only be replaced
by a qualified electrician.
• The machine is not designed to be used by
persons (even children) that are physically or
mentally handicapped or lack experience and
knowledge. Such persons must receive
instruction in how to use the machine from the
person responsible for their safety.
• Children must be watched to ensure they do
not play with the machine.
• In the enclosed plastic bag you will find a tool
for opening the washer door in emergencies.
Installation
See the "Installation" chapter.
Overflow guard function
If the machine’s water level rises above the normal
level, the overflow guard function begins to pump
water out and shuts off the water intake. If the
water level has not dropped within 60 seconds,
the program is terminated.
Transport/Winter storage
If the machine is to be transported or stored in
unheated premises where the temperature can
fall below freezing, do as follows:
• Empty the filter and the drainage pump. See
the "Care and cleaning" chapter.
• Shut off the water to the washing machine,
loosen the supply hose to the intake valve and
let the water run out from the valve and hose.
• After emptying the pump, a small amount of
water may remain in the machine. This does
not affect quality or damage the machine.
Recycling
This machine is manufactured and labelled for
recycling. In order to prevent injuries, the machine
must be made unusable once the decision has
been taken to dispose of it. Contact your local
authority for information about where and how
your machine can be recycled correctly.
5
Safety instructions

Keep an eye on children!
• Always close the washer door and start the
programme immediately after you have added
detergent.
• Do not allow small children to use or play with
the washing machine.
• Store detergent and fabric softener out of the
reach of children.
• You can activate the Child-safe start option to
prevent children from starting the machine.
Child safety catch
1. Turn off the machine using the main power
switch.
2. Press and hold the Door opening button and
switch on the machine with the main power
switch. Then press the Door opening button 5
times within 10 seconds.
3. Select the "Child-safe" setting by turning the
programme selector.
4. Press the Door opening button once.
5. Turn the programme selector and choose
"Child-safe On" or "Child-safe Off".
6. Press the Door opening button once to save
the setting.
7. Press Start/Stop to return to the programme
menu.
You can temporarily deactivate Child-safe start
by pressing the Super Rinse button and the minus
button under Delayed Start at the same time.
Child-safe start will be deactivated for 3 minutes.
6
Child safety

1 2 3 4
75,6
1. Main power switch
2. Detergent compartment
3. Programme panel
4. Serial number plate (on inside of washer door)
5. Drainage pump cover
6. Drainage pump (behind cover)
7. Washer door
Detergent compartment
1. Pre-wash
2. Main wash
3. Main wash liquid detergent.
4. Fabric softener
2 3
1 4
7
Description of the washing machine

Here are some tips that may help you before
washing.
Sorting your laundry
Sort items according to:
• how soiled they are
• colour
• material
Clothing
1. Do up zips and close Velcro straps so that they
don’t harm fabrics.
2. New coloured items may contain excess dye
and should therefore be washed separately
the first few times.
3. Turn delicate items inside out. This reduces
the risk of burling and fading.
4. Empty pockets and wash them inside out if
possible.
Laundry labels
Look at the item's laundry label. The table below
shows suitable wash programmes for different
materials and wash loads. Using modern washing
machines and detergents, for example compact
detergents, you can usually wash at lower
temperatures. It is a good idea to use trial and
error to find out what produces the best results.
Laundry label symbols
Examples of washing instructions and recommended programmes. Always follow the washing instructions
for each garment.
ProgramMaterialLaundry labels
Everyday wash 60 °C to 95 °CCotton, linen, white and light-coloured items.
Quick 60 °CCotton, linen, cotton/polyester. Light and dark-coloured
garments.
Easy Care 40 °CAcrylic, viscose, modal, acetate, polyester, polyamide
and elastane. Light and dark-coloured garments.
Wool/hand wash 30 °C to 40 °CWool, silk and other very delicate garments
or
8
Advice and tips before washing

Hot water connection
Hot water intake has a positive effect on grease
stains and certain pigment stains, such as oil, soot
and coffee. Note however that difficult protein
stains with albumen content (blood, milk, meat
and fish) first need to be soaked in cold water as
they are difficult to dissolve at temperatures above
40 °C. For the best washing results we
recommend the Super wash option and
pre-soaking the stained items in cold water before
washing them in the machine.
Coloured cotton
Coloured cotton items with the washing instruction
60 °C should be washed at 60 °C for the first time
in order to remove any excess dye. If you do not
do so, there is a risk that the colour will run. Use
detergent without bleach in order to preserve the
colour of the fabric.
Unbleached linen
Unbleached linen fabrics should be washed at 60
°C, using detergent containing no bleach or optical
whiteners. Heavily-soiled linen can occasionally
be washed at higher temperatures, but not too
often because the heat can destroy the linen’s
shine and strength.
Wool
These fabrics are labelled either machine wash
or hand wash. The Wool/hand wash programme
is at least as gentle as washing by hand.
Wool is especially sensitive to processes such as
washing.
If you do not wish to spin dry, you can squeeze
out the water using terry towels. In this case select
No spin.
To find out how to choose this setting, see the
"Washing" chapter. However, most garments can
withstand a short spin. Choose a short spin by
selecting a spin speed of 800 rpm or less.
Rayon fibres and synthetic fibres
Materials made of rayon fibres, such as viscose,
and some synthetic fibres are very delicate and
require much space so as not to crease. Only half
fill the drum when washing and choose a spin
speed of 800 rpm or lower.
NOTE!
Viscose and acetates are fragile when wet.
Reducing allergic reactions
The washing machine has a Super Rinse option.
Use this for people with sensitive skin, such as
those with allergies and small children.
Save time and energy
Use the Everyday wash programme to save time
and energy. This programme has a shorter main
wash than Standard cotton, but is often sufficient
for lightly soiled washing.
High water level
If you want more water for the main wash and
rinses, you can use the High water level option.
High water level is used automatically in the
Wool/Hand programme.
Economy and efficiency
You can save a lot of energy by not using higher
temperature programs than necessary.
• Select Quick if you just need to freshen up
shirts or exercise clothes, for example. This
will save both water and energy.
• If you select a fast spin speed, this reduces
energy consumption when drying in a tumble
dryer or drying cabinet.
• Always wash with a full load when using the
Heavy, Everyday wash and Standard cotton
programmes.
• Avoid pre-washing. Modern machines and
detergents clean effectively without
pre-washing. Pre-washing is only necessary
for heavily soiled washing.
9
Advice and tips before washing

Detergents
Eco-labelled detergents are less harmful to the
environment.
Detergent overdosing does not give better
washing results; it merely causes a greater impact
on the environment.
Try to use less detergent, and increase only if you
are not satisfied with the results.
Dyeing fabrics
If you want to dye fabrics in the machine, select
the Everyday wash programme with the Super
Rinse option. Select temperature according to the
dye manufacturer’s recommendations.
Choose a low spin speed if the fabric to be dyed
is a blended material such as
polyester/cotton.
NOTE!
Add the dye directly to the washing drum – not
to the detergent compartment. After dyeing, you
should run the machine empty using the same
program. Use the normal amount of detergent.
NOTE!
Due to environmental concerns, we discourage
the use of strong chemicals.
When using agents for bleaching or stain
removal, there is a risk of rust (corrosion) and
discolouration of the machine.
10
Advice and tips before washing

1Sort your laundry.
See the "Advice and tips before washing"
chapter.
Place underwired bras in a laundry net.
Empty pockets. Coins, nails and the like can
cause damage to the machine and fabrics. See
the "Advice and Tips" section before washing.
2Turn on the main power switch
3Open the washer door and load
the washing
If the washer door is closed, press the Door
opening button (key symbol). The door opens
once all water has drained from the machine.
Load the washing. The wash programme chart
shows how much washing can be washed with
each programme.
4Add detergent and fabric
softener, as required
The detergent packaging will have
recommendations for how much detergent you
should use. The machine holds 8 kg of washing.
If you only have a small amount of laundry in the
machine, you can reduce the amount of detergent
used.
Follow the manufacturers' recommendations as
regards which type of detergent is suitable for
which temperature.
Powder detergent
Pour the powder into the compartment for the
main wash, and pre-wash as well if desired.
Liquid detergent
When using liquid detergent, follow the detergent
manufacturer’s recommendations. We
recommend always using a wash ball with very
thick liquid detergent.
Wash ball or net
If you use a wash ball or net, place it directly in
the drum and select a programme without
pre-wash.
NOTE!
Detergent overdosing does not give better
washing results; it merely causes a greater
impact on the environment.
Try using less detergent, and increase only if
you are not satisfied with the results.
Fabric softener
Pour the fabric softener into the compartment with
the symbol. Follow the recommendations on
the fabric softener packaging.
NOTE!
Do not fill above the compartment’s maximum
fill level. Otherwise fabric softener will run in too
early, which impairs the washing effect.
11
Washing

5Select the programme
You select a programme by turning the
programme selector. The selected
programme is shown in the display. Now use the
option buttons to select any options. See chapter
"Select options".
1. Auto
This program automatically adjusts the length of
the main wash and the number of rinses to the
amount and type of laundry loaded in the
machine.
2. Time program
This program adjusts itself to the specified time
frame or finish time. When using this program, it
is however important to select a temperature and
time suited to how soiled the laundry is. The spin
speed can be selected freely.
Specify the desired programme time by pressing
+ or - on the Time button. The symbol for the
programme lights beside the selected time. You
can choose a programme time between 30
minutes and 3 hours. If you choose a 30-minute
programme time the maximum wash temperature
will be 30 °C
3. Heavy
Programme for heavily soiled laundry, with dirt
that needs to be fully dissolved before the main
wash. A pre-wash is used to do this. The machine
adapts the programme time and water
consumption to the load size.
4. Standard cotton
Program for normally to heavily soiled laundry,
whites and colors. You can select the temperature
freely, so follow the washing instructions for each
garment. 60 °C is a good temperature for heavily
soiled cotton garments, as well as for garments
worn next to the skin. Select 40 °C if the laundry
is less soiled. The spin speed can be selected
freely. The machine adapts the program time and
water consumption to the load size.
5. Everyday wash
A standard programme for lightly to moderately
soiled laundry. The temperature can be selected
freely, so follow the washing instructions for each
garment. Garments worn next to the skin ought
to be washed at 60 °C. Very lightly soiled laundry
often comes clean already at 40 °C. The spin
speed can be selected freely.
6. Quick
Fast program for laundry that just needs
freshening up. The program can be run at any
temperature, so follow the washing instructions
for each garment. The lower the selected
temperature, the shorter the program time.
Garments worn next to the skin ought to be
washed at 60 °C. The spin speed can be selected
freely.
7. Easy Care
Programme for synthetic, mixed fibre and easy
care cotton. The programme has a high water
level and as such is also suitable for cushions,
quilted jackets and the like. Read the washing
instructions carefully and remember, for example,
that fabric softener must not be used with the
membranes found in some outer garments. A
washing temperature up to 60 °C and a spin
speed up to 1200 rpm can be selected.
12
Washing

8. Synthetics
Programme for delicate garments made of
synthetic fibre, mixed fibre, rayon and easy care
cotton. The maximum temperature is 60 °C, but
follow the washing instructions for each garment.
Many synthetics will come clean at 40 °C.
Garments worn next to the skin ought to be
washed at 60 °C. The maximum spin speed is
800 rpm.
9. Wool/hand wash
A gentle laundry programme for wool, silk and
garments that should be washed by hand. The
highest temperature is 30 °C. This programme
has a short spin. The maximum spin speed is 800
rpm.
10. Rinse
This program performs one cold rinse cycle +
spin. Suitable for laundry that just needs to be
dampened and for cleaning cloths and mops.
11. Spin
Used to just spin the wash.
12. Drain
Used when you only want to drain the water from
the machine.
13
Washing

Programme chart
Programme time
(approx. hrs and
min.)
Energy consump-
tion
(approx. kWh)
Water consump-
tion
(approx. liter)
Max. load
( kg)
Spin Speed
rpm
Number of
RinsesTemp. °C
Pre-
washProgram
1)
1. Auto
2. Time program
2:452,28581800595X
3. Heavy 2:401,17581800560X
3:201,1065818003602)
4. Standard cotton 2:570,6765818003403)
1:401,260818003605. Everyday wash
0:450,4254,018002406. Quick
1:200,5504,012002402)
7. Easy Care
1:200,4302,58003408. Synthetics
0:500,5702,58003309. Wool/hand wash
0:200,1154,01800110. Rinse
0:150,104,0180011. Spin
0:0112. Drain
1) Short programme for test institutes, max. 1/2 load.
2) Test programme for cold water connection in accordance with EN 60456. For large volumes of detergent we recommend removing the insert and adding detergent
directly to the detergent compartment.
3) 40 °C programme for test institutes. The 40 °C option must be selected.
The above table presents a few examples of the energy, water and time consumption of a few different programme settings. Consumption
can vary depending on water pressure, water hardness, water supply temperature, room temperature, load weight and content, variations
in the power supply and selected options. In the examples provided here the rinse setting is set to Normal and no options are selected.
If you use large amounts of detergent, such as non-compact powder, and find that the amount you want to use does not fit in the compartment,
you can remove the insert and dose directly in the compartment. We recommend that all test institutes remove the insert for large volumes
of detergent.
14
Washing

6Select options
You can select options to adjust the wash
programme to suit your own specific
requirements. The available options depend on
the selected programme. If the option is available
for the selected programme, the symbols lights
up when you press the button.
The machine will remember the options you select
for each programme (with one exception –
Delayed Start). You can still change the selected
options the next time you select the programme
in question.
Temperature
• Select the temperature by pressing the -/+
buttons until the desired temperature is
displayed.
• You can select temperatures between Cold (-)
and 90 °C. If you select Cold, the washing
temperature will be the same as that of the
water entering the machine. For Wool/hand
wash you cannot choose a temperature higher
than 40 °C. For Time program and Easy Care
the maximum temperature is 60 °C.
Spin
• Select the spin speed by pressing the -/+
buttons until the desired spin speed is
displayed.
• You can select speeds between 400 and 1800
rpm, 0 (no spin) or No D(no drain). The
maximum spin speed varies according to the
programme selected. The speed is shown in
the display.
•0 , means that the programme does not
include a spin cycle and ends by draining.
• No D, No drain means that the programme
does not include a spin cycle and ends with
the water from the final rinse still in the
machine. The washing will remain covered by
the water from the final rinse, stopping it from
getting creased. If you have selected "No
drain", once the programme has ended you
must select the Spin or Drain programme to
drain the water from the machine before you
open the washer door.
15
Washing

Delayed start
When you select Delayed Start, the machine will
start 1-24 hours after you press the Start/Stop
button. This option cannot be used with Time
program.
• Select Delayed Start by pressing the + button
under the time display. Delayed Start is shown
for three seconds.
• By pressing the + and - buttons under the time
display you can delay the start in whole hours
up to a maximum of 24 hours. The symbol for
Delayed Start lights up beside the number of
hours.
• Press Start/Stop, and the machine counts
down 1 hour at a time and starts after the
selected delay.
If you change your mind and want to cancel
Delayed Start, you must press and hold Start/Stop
for three seconds.
NOTE!
Remember to press the Start/Stop button to start
the programme.
NOTE!
Make sure the detergent compartment is
completely dry before you add detergent,
otherwise there is a risk that the detergent will
clump before the machine starts.
Super rinse
Use the Super Rinse option if you want to increase
the number of rinses. The maximum number of
rinses is seven, and the number of rinses varies
depending on the selected programme.
Recommended for persons with extremely
sensitive skin and/or in areas with very soft water.
• Select Super Rinse by pressing the button
under the symbol.
• The symbol above the button lights when this
option is activated.
High water level
Use High water level if a garment's laundry label
shows this symbol. High water level means that
additional water is used during the main wash and
rinse cycles.
• Select High water level by pressing the button
under the symbol.
• The symbol above the button lights when this
option is activated.
NOTE!
The machine takes in the additional water for the
high water level about 15 minutes after the main
wash has started.
Anti crease
Anti crease means that the drum will rotate for
three seconds per minute for two hours once the
wash programme has finished. This feature
prevents the garments from lying in the same
position and getting creased if you are unable to
remove them immediately.
•Select Anti crease by pressing the button under
the symbol.
• The symbol above the button lights when this
option is activated.
Super wash
Super wash can be selected to better dissolve
difficult stains and heavy soiling on clothing. This
option adds a cold pre-wash and the wash time
in cold water is extended by approximately six
minutes. The main wash time is also extended.
• Select Super wash by pressing the button
under the symbol.
• The symbol above the button lights when this
option is activated.
16
Washing

Pre-soak
If the washing is stained with blood, for example,
we recommend a presoak. The washing will soak
in cold water for two hours before the wash
programme starts.
• Select Presoak by pressing the button under
the symbol.
• The symbol above the button lights when this
option is activated.
17
Washing

7Close the washer door and
press the Start/Stop button
NOTE!
A few seconds after you start a programme the
washing machine will begin to fill with water from
both the hot and the cold supplies. If for some
reason no hot water is available, the machine
waits for one minute and then fills with cold water
only. The wash drum does not start to rotate until
it begins to fill with water.
Time remaining
The time remaining is shown in hours and
minutes. Once a programme is selected, the
estimated programme time is displayed. This may
differ from time to time depending on the
temperature of the water entering the machine
and the size of the load. If the programme time is
longer than the previous wash with the same
programme, "0:01" will be displayed until the
programme finishes. This is normal! The next time
you use the programme under similar conditions,
the estimated programme time will be more
accurate.
To add or remove washing after the
program starts
If you want to add or remove items after the
programme has started, you can stop the
programme by pressing and holding the Door
opening button (key symbol) for three seconds.
When you restart the machine, add any extra
detergent needed and close the washer door. The
machine continues automatically from the point
where the programme was interrupted.
Stopping or changing a programme
You can stop a programme by pressing the
Start/Stop button for three seconds. "Stop"
appears in the display. To restart the machine,
select a new programme, add any extra detergent
needed and press the Start/Stop button.
NOTE!
Do not open the detergent compartment while
the machine is running.
8Once the program has finished
The text "Done" is shown on the display for
2 minutes. The machine then turns off.
The washer door opens automatically once the
programme has finished. If you want to deactivate
the automatic door opening function, see the
"Selecting settings" section.
• Remove the load.
If you have small children or pets at home, close
the washer door once you have removed the
laundry.
18
Washing
