Jammin SCRT10 User manual

1.Before Starting
2.While Operating
•Please read manual carefulyl (With a parent, guardian or a responsible adult if necessary).
•Any running area you choose must be dry. Do not run vehicle near any water or wet areas.
•Do not run on public streets. It is very easy to have the car run over or damaged by hitting obstacles
or other surfaces.
•Do not operate the car in tight confined places. The vehicle is very fast and will easily hit something.
•Do not run near people or animals. The car is very fast and could seriously injur someone.
•Do not operate the car at night. You will not be able to drive it safely.
3.Before Operating
•Make sure that all screws and nuts are properly tightened.
•Always use fresh batteries for your transmitter and receiver before running the car. If the radio does
not have full control of the car with steering, throttle and brake. Do not run it until corrected. Failure
to correct this will result in possible injury and damage to the car or property.
We strongly recommend using a failsafe. But remember failsafe does not protect if all power is lost
in vehicle.
•Please confirm the steering and throttle is at neutral position before operating.
4.Check Your Vehicle After Runing
•Turn OFF receiver first, then turn OFF transmitter. This will prevent the car from losing control.
•After running radio controlled car, it is necessary to perform routine maintenance.
5 Safety
IMPORTANT-READ THIS BEFORE RUNNING
•Please be careful when handling the vehicle. It will be hot after running. Pay close attention to
engine and pipe, it is extremely hot.
WARNING: To avoid a possible fire hazard, always unplug the battery. Do not leave your vehicle
unattended.
•On nitro vehicles engine must be shut down first before any radio equipment.

TOOLS NOT INCLUDED IN THE KIT
Cutter
Curved Scissors
91009 - LEXAN SCISSOR
Craft Knife
Precision Caliper
Needle Nosed Pliers
Equipment Needed
Included Items
Cross Wrench
1.5mm Allen Wrench
2mm Allen Wrench
2.5mm Allen Wrench
Turnbuckle Wrench
OVERVIEW
Components
Transmitter
Parts Bag
Receiver Servo
Radio Control Car
AA Batteries
( 12pcs )
AA Batteries
( 4pcs )
Glow Fuel
NITRO 20%
Fuel Bottle
10160 - 550cc
Starter Box
10244 - Dual 775 Motor
Body Reamer
10803 - BLACK
10804 - BLUE
10805 - PURPLE
Instant Cemment
10239 - CA
Screw Cement
10289 - THREAD LOCK
CA
Screw Cement
GEAR
GREASE
Gear Grease
10240 - GREEN GREASE
Glow Igniter
10215- Glow Heater
extra long with charger
10202 - Hump Pack 1700Mah
OPTIONAL

HNT-3 Transmitter
HNT-3 2.4GHz RADIO SYSTEM OVERVIEW
1.Transmitter Antenna
2.Servo Reverse Switches
4.Power LED
3.TX RF Module And Binding Button
5.Power Switch
6.Steering Dual Rate Trim LED
8.Fail Safe Button
10.Steering End Point Adjustment Knob
9.Throttle End Point Adjustment Knob
11.Steering Dual Rate Adjustment Button
12.Steering Trim
13.Throttle Trim
14.AUX Channel Switch
16.Throttle Trigger
15.Steering Wheel
Channels:3Ch
Frequency:2.4GHz
DC:12V/ 8 cell AA Type
Battery
Meas.:310*170*75mm
Net weight:530g
Specification:
1
2
3
4
5
6
7
9
11
12
14
15
16
13
8
10
17
17.Battery Cover
7.External Charging Jack
*Carefully read the instruction manual of your
radio controller before using and keep it in a
safe place as a reference introduction in the
future.
Receiver Connection Diagram Specification Data
•Transmitter
Channels: 3
Frequency: 2.4Ghz
Power DC: 9.6V - 12V
Measurement: 280 x 190 x 85mm
(Packing Meas.)
Net Weight: 510g
•Receiver
Channels: 3
Frequency: 2.4Ghz
Power DC: 4.8 - 5.6V
Net Weight: 13.5g
Auxiliary Channel
Throttle Channel
Steering Channel
Battery Port
Bind Button

CAUTION
• To use your Radio with your models correctly and safely, read this manual carefully and keep it in a
safe place for future reference.
Warning:
1. This product is only equipped for radio controlled cars;
2. The usage of this product should be approved by local law or regulations;
3. We will not be responsible for the damages caused by unauthorized modification, adjustment
or replacement of parts on this product;
4. The manual may be change without prior notice. Please contact us if you have any corrections
or clarifications that should be made in the manual;
• Before turning on the transmitter, make sure the transmitter batteries are fresh. The voltage of the
transmitter batteries is should never be lower than 9.6V, and please check and confirm that the servos
are all well and properly connected.
• Keep the radio system away from moist, high temperature and strong vibrations. Do not clean radio
with any solvent.
• Make sure antenna does not touch anything when power switch is turned on. Do not leave this radio
in reach of small children.
• Please use this product according to your local laws and regulations, we are not responsible for any
incidents or damages.
2.4Ghz Binding
BIND
•Binding your RX to Transmitter
Turn on the transmitter, then connect your speed control to the
battery, then push the bind button on the receiver while holding it
down turn on the switch on the speed control. The LED should turn
Green which means the binding is successful. After that, it’s un-
necessary to bind again.
Caution:
When binding make sure that the RX and TX is no more
than a yard or 3 feet from each other, also no other similar FHSS
system or device is being use within 10 yard of your RX and TX
or it could accidentally pair up or bind with your vehicle.
STEP 2
Power Switch (turn on)
STEP 1 RF-TEST (Press and hold)
• Reducing output power setting.
• Push the RF-TEST button, while holding it down turn on your transmitter,
the “ST-D/R” LED “RED” should light up. Now your output power of the
transmitter is reduce to a lower mode of 18dbm, which reduce the range
of the radio but save in battery consumption
.
•Now press the RF-TEST button again, the LED on the “ST-D/R should turn off, and
output power becomes normal 20dbm which can control your vehicle with more
range but more battery consumption.
LED
Reducing Power

AUX Channel Function (CH3)
•This switch control the transmitter’s third channel. A servo plugged in this Channel 3 will move to full travel in one
direction when the switch is in the “AUX” position, then move the switch to the “OFF” position the servo will move
in the opposite position . This channel can be use to turn on all sort of things in your vehicle. For example, lights,
on board camera etc..... l
Steering Dual Rates Setup
ST.D/R SW
•DEFINITION:
Steering Dual Rate (ST. DR): Is the adjustment that allows the dual rate value
(maximum servo travel) to be increased (INC) or decreased(DEC) with in a range
of 0% to 100% of the steering servo. This functions very useful in a race
conditions as it allows you to tailor the steering radius and sensitivity for the
current track conditions.
•ADJUSTMENT:
INC
DEC
ST.DR
1.Press and hold the “INC” (Increase) button until the LED on the “ST.DR” blinking green
into a blinking red indicating maximum turning radius or value of 100%.
2.Press and hold the “DEC” (Decrease) button until the LED on the ‘ST.DR” start blinking green
and goes to a blinking red LED indicating minimum turning radius or value 0%.
Steering End Point Adjustment (ST.EPA)
L R
L R
*After adjusting "D/R" to Max position then adjust
both "ST EPA" knob to the correct position as
picture shown.
Steering
Stopper
*The steering stopper may vary for different
brand models. Follow the steering stopper
set-up for max position. The steering servo
may be damaged if it is overload.
Use the "EPA" to adjust steering tie-rod to
the steering stopper.
Steering End Point Adjustment (EPA)
Left turn Right turn
Straight (neutral)
*L/R Steering end point adjustment
(ST. EPA)knob.
Max Max

CHECKING YOUR DUAL RATE
•To Check Your Dual Rate:
1. Turn your radio “ON” then turn “ON” your vehicle.
2. Check your steering on your radio by turning left and right several times.
3. Now turn your steering wheel all the way to the left or right whichever you choose
and hold it while pushing the “DEC” button ( see fig. 1) on the “ST-DR” and
hold it down, you should see that the wheel on your vehicle decrease in radius
(see fig. 2) and that the LED on “ST-DR” will start blinking Green and turn to a
blinking Red indicating it is at 0% or minimal steering radius
.
4. To increase the dual rate turn the wheel left or right all the way and hold it while
pushing the “INC” button this will increase the turning radius of the and the LED
on ST-DR will start blinking Green and turning to the FIRST Blinking Red indicating
that the“Dual Rate” is at 80%, Holding the increase button past the FIRST Blinking
Red will turn to Blinking Green again then to the SECOND Blinking Red indicating
your “Dual Rate” is at 100%. When running your vehicle try to run the “Dual Rate”
at maximum radius (100%). Then if you have too much steering then decease as
needed.
100%
0%
01 0 %
ST.DR
INC
DEC
ST.D/R
DEC
INC
ST. D/R
FIG. 1
0% 0%
10
0%
100%
1%00
100%
FIG. 2
FIG. 3
FLASHING

Steering Trim
Please turn on your transmitter, plug in your battery and turn on your esc while making the adjustment of these settings.
1.Connect the receivers, servos, and other components and then turn on the power switches of the transmitter and receiver.
2.Be sure the steering trim and throttle trim on the transmitter are at their neutral position.
3.When turning on your system make sure you turn on the transmitter first before turning on the receiver, while turning off the system
turn of receiver before turning off the transmitter.
•Steering Trim
Steering neutral adjustment can be made by moving the steering trim knob to the left or right.
•Finding Neutral position on the Steering
To find the center or neutral position on your transmitter, turn it on. Push the “ST-TRIM” left and notice the “ST-DR” will start flashing Green
then slowly turn to a flashing Red hold it there until you see a steady flashing Red, now you know you are at the end of left side trim. Now to
find the center or neutral position of the steering trim push the “ST-TRIM” to the right and hold it, you will notice that the “ST-DR” LED will start
flashing Green hold it their until you see that it will turn RED let go, now you are at center or neutral position, if you go past the RED light it
will start flashing GREEN again you are now off center or neutral and going toward the right.
•Racer Tip
Always check and be sure the servo is at it neutral position before installing a servo. Adjust the servo horn hole position and linkage so that
both are parallel. When a servo saver is used, place it as close to center position as possible. Be sure the steering trim on the transmitter is at
the neutral position.
•Trim Operation and Maximum Travel.
Changing the trim can effect the overall settings, when adjustments are made with the trims, please recheck your installation for maximum
servo travel. When Trim movement goes to extremes and your vehicle will not go straight.
That means if you make a lot of trim movement to get a servo to the neutral position, please reposition the servo horn or servo saver on the
servo and inspect your linkage installation.
1.When adjusting the ST-Trim button the ST-DR LED appears FLASHING GREEN.
2.When in the neutral position, the LED appears RED.
3.When in Max or Min position, LED appears FLASHING RED.
12
100%
0%
B
R
A
X
*Turn "BR" knob to set brake rate.
100%
*Turn "MAX" knob to maximize the throttle rate.
50%
100%
M
*We Suggest you to set the brake at 50%.
Too much brake may overheat and damage the
Electric Speed Controller and Motor.
Throttle End Point Adjustment (EPA)
LEFT RIGHT

Throttle Trim
•Throttle neutral adjustments can be made by moving the throttle trim to the left or the right.
•Racers Tip
When using a electronic speed control, please set the throttle trim to neutral and make adjustments to the speed control. On a gas powered
model, set the trim to the point where carburetor is fully closed in accordance with the engine instruction manual.
•Trim Operation and Travel
Trim adjustment will affect the overall servo travel, so please check the movement after the adjustment
When trim movement goes to extremes.
•That means if you have adjust the trim movement a lot to the neutral position, please recenter your servo horn closer to the neutral position
and inspect your throttle linkage.
FLASHING
•Finding Neutral position Throttle
1. Turn on transmitter
2. Push the “TH-TRIM” to the right (see Fig 5) and notice the “ST-DR” LED will start flashing Green (see Fig 6) then slowly turning to a flashing Red
hold it until you see a steady flashing Red, now you know you are at the end of the Forward trim.
3. To find the center or neutral position of the “TH-TRIM” push the “TH-TRIM” to the Left and hold it, you will notice that the “ST-DR” LED will start
flashing Green hold it their until you see that it will turn RED let go, now you are at center or neutral position, if you go past the RED light it
will start flashing GREEN again you are now off center or neutral and going toward the Reverse or Brake. If you past it don’t worry just push
it to the right a few click and you should be at neutral again.
HOW TO NEUTRAL THROTTLE TRIM
Fig 5
Fig 6
Right
Forward
Left
Reverse
Brake
Fail Safe
button
Fail Safe
Light
Fail Safe Process
1.Pair the transmitter and receiver before setting the fail safe(F/S) function. Turn on the transmitter power, then the receiver.
2.To set up fail safe(F/S) function with throttle servo is at neutral position, keep the throttle trigger at neutral position.
3.Press and hold the fail safe button on the transmitter for 5 second, until the fail safe LED light turn red. The fail safe(F/S) function is now
activated.
•The HNT-3 radio system features a built-in fail safe to
function automatically set the servo to default when the
transmitter loses signal due to interference.
For your safety ,we recommend you to active the fail safe
function.
CAUTION
•To avoid throttle servo position
must be at "neutral" when setting the fail safe(F/S) function.
• Fail safe is only good when you have power to the servo and
electronic speed control (ESC). Without power it can not go
back to neutral.
losing control of the car, the
Stop
(Neutral)
Fail Safe Setup

Handling Procedure For Batteries
•Battery Replacement
1) Remove the battery cover from the transmitter by sliding it in the direction of the arrow.
2) Remove the used batteries.
3) Load the new 8 AA size alkaline, or Nickel Metal Hydride (NimH) rechargeable batteries,
and pay very close attention to the polarity marking on the batteries.
4) Slide the battery cover back onto the case.
5) If you use rechargeable batteries OFNA make this charger 10210 it will charge your Transmitter
9.6v at 100mA and Receiver battery 4.8v-6v at 100mA at the same time.
•Caution
Always make sure you reinsert the batteries are in the correct polarity order. If the batteries are loaded
incorrectly, the transmitter may not work or can be damaged.
When the transmitter is not used for a long period of time remember to remove the batteries. If the batteries
do happen to leak, clean the batteries case and contacts thoroughly and make sure the contacts are free of
corrosion.
•Battery Disposal
Some countries and state require special handling of used batteries, please contact the agencies responsible
for recycling hazardous wastes in your local area.
•Battery low voltage alarm indicator. LED Power light will flash.
Handling Procedure For Batteries
10210 - DUAL CHARGER, 4.8V-6V/9.6V TRANSMITTER AND RECEIVER
NOTICE THE DIRECTION OF BATTERY COVER
(Not included)
Turning R/C Unit Off
ON
*Turn off the receiver first, then turn off the transmitter.
1
2
OFF
*If you switch off the transmitter first
before the receiver, you may lose control
of the R/C car.
CAUTION
FOR MORE SUPPORT PLEASE CALL US AT (949)586- 2910 OR CHECKOUT OUR WEBSITE
WWW.OFNA.COM .

40921
BUMPER & RADIO TRAY POST & BODY POST
40839
FRONT C HUB
40835
DIFF. CASE
40836
FRONT & REAR LOWER ARM
40837
FRONT UPPER ARM & ARM HOLDER
40840
FRONT & REAR GEAR BOX
37100
SHOCK ABSORBER
PLASTIC PARTS FOR USE

40944
REAR BUMPER
40943
FRONT BUMPER
40945
REAR BUMPER BRACE
37381
BALL END (4mm)
PLASTIC PARTS FOR USE
40541
RECEIVER BOX

40802
STEEL SPUR GEAR (46T)
SYMBOL USED THROUGHOUT THE INSTRUCTION MANUAL
Ensure
Free
Movement
Ensure Free
Movement
Apply
Grease
Apply Grease
Oil
Tighten
Tighten
Do Not
Over Tighten
Rotate
Direction Rotate
Direction
Contact
Adhesive
Contact Adhesive
wScre tCemen
BAG
1:1
Parts Bag Used Degrease With
Motor Spray Do Not
Over Tighten
Clockwise
Rotation
Anti-clockwise
Rotation
True-To-Scale
Apply Oil
Apply Screw
Cement
40841
FRONT KNUCKLEARM
40843
REAR UPRIGHT
40844
CENTER DIFF. MOUNT
40947
BODY POST & CENTER BRACE
40848
STABILIZER BALL END
40834
SERVO SAVER
PLASTIC PARTS FOR USE

1
2
3
ASSEMBLY OF THE FRONT AND REAR DIFF.
ASSEMBLY OF THE FRONT AND REAR DIFF.
ASSEMBLY OF THE CENTER DIFF.
Step 1 Step 2
Step 1 Step 2
Step 1
4x4 mm
40009
40009
37450
10x15mm
Ball Bearing
94034
4x4mm
Set Screw
30780
2x12.8mm Pin .....x4
.....x4
.....x4
.....x2
40009
P6 O-Ring
30780
Oil
Oil
*Build two differentials for front and rear.
.....x16
30776
4x10mm Washer
30773
4mm
Cross Pin .....x4
40011
2.6x10mm
40805
30776
94046
2.6x10mm
Flat Head Screw
.....x8
94034
4x4mm
Set Screw
30780
2x12.8mm Pin .....x2
.....x2
.....x2
.....x1
40009
P6 O-Ring
Tighten the diff screws in this order.
1
4
3
2
40808
40808
37450
37450
40835
40805
40803
30780
40805
37450
10x15mm
Ball Bearing
Tighten
30773
Build two differentials for front and rear.
4x4 mm
40835
40009
40807
37450
40805
30780
Apply silicone oil to the differential
during assembly.
Step 2
Oil
30780
40805
40009
40807
37450
40802
Oil
FRONT
10233 - 5000WT
REAR
10232 - 3000WT

4
5
6
ASSEMBLY OF THE CENTER DIFF.
ASSEMBLY OF THE FRONT GEAR CASE
ASSEMBLY OF THE FRONT SHOCK STAY
Step 1 Step 2
Step 1 Step 2
.....x8
30776
4x10mm Washer
30773
4mm
Cross Pin .....x2
40011
2.6x10mm
30773
40805
30776
.....x4
Tighten the diff screws in this order.
1
4
3
2
3x35mm
3x10mm
•Adjust the backlash with shims.
Apply
Grease
Srwce
e etCmn
38254
12x15x0.25mm Shim .....x2
37430
5x11mm Ball Bearing
.....x2
94043
3x35mm Hex Screw
.....x2
94003
3x10mm Hex Screw
.....x2
94003
3x10mm
Hex Screw
.....x2
38254
38254
40804
37430
37430
40840
40806
4x4mm
40840
40813
94046
2.6x10mm
Flat Head Screw
94034
4x4mm Set Screw .....x1
1:1
Tighten
Down
•Notice the direction of
the front lower arm holder.
3x10mm
40870
•Apply silicone oil to the differential
gear during assembly.
CENTER
10233 - 5000WT

7
8
9
ASSEMBLY OF THE FRONT LOWER ARMS
ASSEMBLY OF THE FRONT UPPER ARMS
ASSEMBLY OF THE KNUCKLE ARMS
Step 3
Step 1
Step 2
Step 4
3x8mm
3x12mm
40813
40837
40825
40837
40841
40818
37360
40818
40840
37390
37430
37430
40875
40839
40818
40836
40825
40836
40837
40826
40838
30403
94035
3x8mm
Set Screw
.....x2
94004
3x12mm
Hex Screw
.....x2
37430
5x11mm Ball Bearing
.....x4
37220
King Pin Bushing .....x4
Do Not
Over Thigten
Do Not
Over Thigten
•Approx. 8.5mm
Ensure
Free
Movement
• Notice the direction of the front lower arm
holder in rear.
Up
Counterclockwise mark.
Ensure
Free
Movement
Ensure
Free
Movement
40825
3x53mm Arm Shaft .....x2
94004
3x12mm
Hex Screw
.....x2
.....x2
30403
6mm Ball
40824
3x32mm Arm Shaft .....x2
Step 1
37390
2x10.8mm Pin
.....x2
Step 2
40837
40837
3x12mm
40837
40824 Ensure
Free
Movement
Ensure
Free
Movement
40824
Assemble both right and left sides.
•A 3x8mm set screw
is used to adjust
ride-height.
40818

10
11
12
ASSEMBLY OF THE FRONT SUSPENSION ARMS
Assemble both right and left sides.
ASSEMBLY OF THE FRONT STABILIZER
•Makes two rods for left and right
hand-side.
ASSEMBLY OF THE FRONT STABILIZER
3x4mm
3x16mm
40823
3x16mm
3x8mm
40848
40848
30341
30403
2.5x8mm
3x3mm
40840
40817
40840
3x3mm
3x3mm
94001
3x4mm
Hex Screw
.....x2
94005
3x16mm
Hex Screw
.....x2
94005
3x16mm
Hex Screw
.....x2
94035
3x8mm
Set Screw
.....x2
.....x2
30403
6mm Ball
94033
3x3mm
Set Screw
.....x4
94044
2.5x8mm
Hex Screw
.....x2
Ensure
Free
Movement
Ensure
Free
Movement
Sc ewr
Cem nte
Srec w
Cement
•Approx. 2.5mm
Assemble both right and left sides.
40823
3x25.8mm Arm Shaft .....x2
•Insert drive shaft into cap joint
before assembly.

13
14
15
ASSEMBLY OF THE SERVO SAVER
ASSEMBLY OF THE SERVO SAVER AND THE STEERING TIE-ROD
•Approx. 0.5mm
Step 1 Step 2 Step 3
•Approx. 37.5mm
Step 1 Step 2
ASSEMBLY OF THE SERVO SAVER TO FRONT GEAR BOX
37360
37360
37360
40834
40834
40922
40810
40809
40834
37220
3x8mm
37220
3x8mm
40947
40812
3x8mm
40834
40827 (3x50mm)
37381
37381
3x8mm
3x8mm
3x8mm
40834
3x8mm
37220
King Pin Bushing .....x2
94002
3x8mm
Hex Screw
.....x2
94002
3x8mm
Hex Screw
.....x3
94040
3x8mm Washer
.....x2
40834
5x8x2.5mm
Plastic Bushing
.....x4
94002
3x8mm
Hex Screw
.....x2
Do Not
Over Tighten
Screw
C me ent
Servo saver spring preload.
Ensure
Free
Movement
crewS
Cem ten
40834
40834
40834
Do Not
Over Tighten
Ensure
Free
Movement
Ensure
Free
Movement
Ensure
Free
Movement

16
17
18
ASSEMBLY OF THE FRONT BODY POST
ASSEMBLY OF THE FRONT BODY STAY ONTO FRONT GEAR CASE
ASSEMBLY OF THE FRONT BUMPER
Step 1
94005
3x16mm
Hex Screw
.....x2
94006
3x18mm
Hex Screw
.....x2
Step 2
3x12mm
3x12mm
3x16mm
2.6x15mm
40947
40947
40947
40947
3x18mm
94041
3mm
Nylon Nut .....x2 3x16mm
3mm
40943
94004
3x12mm
Hex Screw
.....x4
94005
3x16mm
Hex Screw
.....x2
94054
2.6x15mm
Screw
.....x2
Assemble both right and left sides.
Tighten
