DSC 1000
DIGITAL
SIMPLY CINEMA
SERVICE MANUAL
®
The DSC 000 Controller is shown here.

ENGLISH
DSC 1000 CONTROLLER
SPECIFICATIONS
DVD player
Pickup: Semiconductor laser, wavelength 650nm
Signal system: NTSC / PAL
Video signal horizontal resolution: More than 480 lines (DVD)
Video signal-to-noise ratio: More than 60 dB (DVD)
Audio frequency response: DVD (PCM): 20Hz ~ 22kHz (+/- .0dB)
(Stereo) CD (PCM): 20Hz ~ 20kHz (+/- .0dB)
Audio signal-to-noise ratio: More than 80 dB (PCM)
Total harmonic distortion:: Less than 0.0 % (PCM)
Dynamic range: DVD (PCM): More than 85 dB (EIAJ, 2kHz)
CD: More than 85 dB (EIAJ)
F Tuner
System: PLL quartz-locked digital synthesizer system
Tuning range: 87.50 ~ 08.00 MHz
Antenna terminals: 75 ohms, unbalanced
Intermediate frequency: 0.7 MHz
Video Outputs
Component Video Output: Y: Vp-p/75 Ohms, sync negative polarity
Cr: 0.7 Vp-p/75 Ohms
Cb: 0.7 Vp-p/75 Ohms
CVBS Video: Vp-p 75 ohms
S-video: Y: Vp-p 75 ohms
C: PAL 0.3 Vp-p 75 ohms / NTSC 0.286 Vp-p 75 ohms
Audio line Outputs
Audio L/R: Vrms, kilohms
General
Power requirements: AC 230 V, 50 Hz
Power consumption: 20 W
Dimensions (WxHxD): 43 x 75 x 352 mm, 7" x 3" x 4"
Weight: 8.5 kg, 8.7 lb.
* Designs and specifications are subject to change without notice.
JBL continually strives to improve its products by introducing design refinements into existing models without notice. For
this reason, the DSC 000 systems may differ in some respects from the published specifications and descriptions, but will
always equal or exceed the original specifications unless otherwise stated.
CONSUMERS SHOULD NOTE THAT NOT ALL HIGH DEFINITION TELEVISION SETS ARE FULLY COMPATIBLE WITH THIS
PRODUCT AND MAY CAUSE ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN CASE OF 525 OR 625 PROGRESSIVE
SCAN PICTURE PROBLEMS, IT IS RECOMMENDED THAT THE USER SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS REGARDING OUR TV SET COMPATIBILITY WITH THIS MODEL 525p
AND 625p DVD PLAYER, PLEASE CONTACT OUR CUSTOMER SERVICE CENTER.

1
SERVICING PRECAUTIONS
NOTES REGARDING HANDLING OF THE PICK-UP
1. Notes for transport and storage
1) The pick-up should always be left in its conductive bag until immediately prior to use.
2) The pick-up should never be subjected to external pressure or impact.
2. Repair notes
1) The pick-up incorporates a strong magnet, and so should never be brought close to magnetic materials.
2) The pick-up should always be handled correctly and carefully, taking care to avoid external pressure and
impact. If it is subjected to strong pressure or impact, the result may be an operational malfunction
and/or damage to the printed-circuit board.
3) Each and every pick-up is already individually adjusted to a high degree of precision, and for that reason
the adjustment point and installation
screws should absolutely never be touched.
4) Laser beams may damage the eyes!
Absolutely never permit laser beams to enter the eyes!
Also NEVER switch ON the power to the laser output part (lens, etc.) of the pick-up if it is damaged.
5) Cleaning the lens surface
If there is dust on the lens surface, the dust should be cleaned away by using an air bush (such as used
for camera lens). The lens is held by a delicate spring. When cleaning the lens surface, therefore, a cot-
ton swab should be used, taking care not to distort this.
6) Never attempt to disassemble the pick-up.
Spring by excess pressure. If the lens is extremely dirty, apply isopropyl alcohol to the cotton swab. (Do
not use any other liquid cleaners, because they will damage the lens.) Take care not to use too much of
this alcohol on the swab, and do not allow the alcohol to get inside the pick-up.
Storage in conductive bag
NEVER look directly at the laser beam, and don’t let contact
fingers or other exposed skin.
Magnet
How to hold the pick-up
Conductive Sheet
Cotton swab
Pressure
Pressure
Drop impact

2
NOTES REGARDING COMPACT DISC PLAYER REPAIRS
1. Preparations
1) Compact disc players incorporate a great many ICs as well as the pick-up (laser diode). These compo-
nents are sensitive to, and easily affected by, static electricity. If such static electricity is high voltage,
components can be damaged, and for that reason components should be handled with care.
2) The pick-up is composed of many optical components and other high-precision components. Care must
be taken, therefore, to avoid repair or storage where the temperature of humidity is high, where strong
magnetism is present, or where there is excessive dust.
2. Notes for repair
1) Before replacing a component part, first disconnect the power supply lead wire from the unit
2) All equipment, measuring instruments and tools must be grounded.
3) The workbench should be covered with a conductive sheet and grounded.
When removing the laser pick-up from its conductive bag, do not place the pick-up on the bag. (This is
because there is the possibility of damage by static electricity.)
4) To prevent AC leakage, the metal part of the soldering iron should be grounded.
5) Workers should be grounded by an armband (1MΩ)
6) Care should be taken not to permit the laser pick-up to come in contact with clothing, in order to prevent
static electricity changes in the clothing to escape from the armband.
7) The laser beam from the pick-up should NEVER be directly facing the eyes or bare skin.
Resistor
(1 Mohm) Conductive
Sheet
Resistor
(1 Mohm)
Armband

3
ESD PRECAUTIONS
Electrostatically Sensitive Devices (ESD)
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components com-
monly are called Electrostatically Sensitive Devices (ESD). Examples of typical ESD devices are integrated cir-
cuits and some field-effect transistors and semiconductor chip components. The following techniques should
be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off
any electrostatic charge on your body by touching a known earth ground. Alternatively, obtain and wear a
commercially available discharging wrist strap device, which should be removed for potential shock reasons
prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ESD devices, place the assembly on a conductive sur-
face such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ESD devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static"
can generate electrical charges sufficient to damage ESD devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESD
devices.
6. Do not remove a replacement ESD device from its protective package until immediately before you are
ready to install it. (Most replacement ESD devices are packaged with leads electrically shorted together by
conductive foam, aluminum foil or comparable conductive materials).
7. Immediately before removing the protective material from the leads of a replacement ESD device, touch the
protective material to the chassis or circuit assembly into which the device will by installed.
CAUTION : BE SURE NO POWER IS APPLIED TO THE CHASSIS OR CIRCUIT, AND OBSERVE ALL
OTHER SAFETY PRECAUTIONS.
8. Minimize bodily motions when handing unpackaged replacement ESD devices. (Otherwise harmless motion
such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can gen-
erate static electricity sufficient to damage an ESD device).

DSC1000 Component list
Item Parts No. Qty SPECIFICATION Remarks(English)
1380-B0DSC100-8000 1Chassis
2380-ADSC1000-8500 1Top cover
3380-CDSC1000-0500 1Back panel
4332-3DSCPT04-0000 1Loader support
5332-3DSCPT05-0000 1Power button support
6332-3DSCPT06-0000 2Len support
7332-3DSCPT07-0000 1Heat-sink support
8385-01459545-5200 1Heat-sink
9385-00161235-5200 2Heat-sink, for SMPS D17 D18
10 385-00501935-5200 1Heat-sink, for SMPS Q16
11 385-VD31ZPA2-5000 1Aluminium alloy front panel
12 332-7DSCPT11-0000 2Net cover on front panel
13 330-ADSCPT12-0000 1Baffle for tray door
14 600-000H0205-0020 1Amplifier speaker output label
15 385-00282810-0000 1Heat-sink, for MainBoard U4
16 332-10MV7200-0000 2Decorate lamp holder MV7200
17 500-09130126-0000 1Insulated underlay for AC cord 130×126mm
18 500-10202011-0010 1Insulated underlay for SMPS 20×20×11mm
19 331-1000RE01-8000 1Button
20 331-1000RE02-8000 1Power button
21 330-2000RE03-8000 1Disc tray door
22 331-8000RE04-8000 1Len for tray door
23 331-8000RE05-8000 1Len for VFD VFD
24 330-ADSCRE06-0000 1Left baffle
25 330-ADSCRE07-0000 1Right baffle
26 331-5VD28016-7000 1Power indicator lampshade
27 331-3000RE12-0000 1Volume knob
28 331-4DSC1000-4000 4Pedestal bronzing,size same as DVD 25,specify color
29 350-0DSC1000-0000 4Pedestal underlay same as DVD25
30 332-200SZ003-0200 1IR receiver head frame SZ003
28×28×10mm
DSC1000-RE01
DSC1000-RE02
DSC1000-RE03
DSC1000-RE04
DSC1000-RE05
DSC1000-RE12
DSC1000-PT03
DSC1000-PT04
DSC1000-RE08
DSC1000-PT12
DSC1000-H02
DSC1000-RE07
DSC1000-PT11
DSC1000-PT09
DSC1000-RE06
METAL PART
PLASTIC PART
DSC1000-PT05
DSC1000-PT06
DSC1000-PT07
DSC1000-PT08, 145×95×45mm
DSC1000-PT01
16X12X35mm
50X19X35mm
DSC1000-PT02
Harman Consumer Group Components JBL DSC1000/230

DSC1000 Component list
31 350-00202006-0200 2VFD soft pad VFD 20mm×20mm×6mm
32 331-7C035040-0010 2Alumium fastener cover pyrocondensation cannula F3×40mm
33 500-70000000-0000 1Plastic fastener fasten the power cord
34 332-40000000-0000 6Screw map
35 500-02000000-0030 2Lead nip
36 500-01025015-0001 23M double glue 3M 25×15mm
37 332-20007008-0000 11 PCB plastic frame PCB F7×8.6mm
38 500-09002024-0000 1Talc piece for SMPS Q6 F20×24mm
39 350-00161101-2600 3Diathermanous Selenium Rubber place on Amp Board
AU1 AU2 AU3 16×11×1mm
40 331-90033702-Q200 1Shade for volume knob F33×F7×0.2mm
41 500-10200702-0000 2Sponge with double glue 20×7×2mm
42 555-A01000RC-0010 1 set Remote control
43 162-J00TJC13-0200 1JBL speaker jack TJC1-3 JBL TJC1-3 Red 032C with JBL logo
44 162-J00TJC13-0100 1JBL speaker jack TJC1-3 JBL TJC1-3 Whtie with JBL logo
45 162-J00TJC13-0500 1JBL speaker jack TJC1-3 JBL TJC1-3 Green 361C with JBL logo
46 162-J00TJC13-0300 1JBL speaker jack TJC1-3 JBL TJC1-3 Cool Grey 7C with JBL logo
47 162-J00TJC13-0600 1JBL speaker jack TJC1-3 JBL TJC1-3 Process Blue C with JBL logo
48 331-90146258-0500 1VFD filter VFD for VFD 146×25.8mm
49 500-05022050-0000 1Pyrocondensation cannula cover magnetism annulus of AC cord f22×50mm
50 205-0JSHM248-1000 1Magnetism annulus M248 for AC cord
51 313-AGDSC100-0001 1Laser precausion mark stick on loader
52 313-AGDSC100-0002 1Laser precausion guide stick on loader
53 500-01012060-0010 2Viscose band 12×60mm
54 160-E0050250-0A00 15 pin, long 250mm, two ends with 2.0mm space
connector, different link sides connect loader and mainboard
55 160-E0060320-0A00 16 chip, long 320mm, two ends with 2.0mm space
connector, different link sides connect loader and mainboard
56 160-E0020040-0A00 12 pin, long 40mm, one end with 2.54mm space
connector connect front panel board and power switch
57 160-E0090230-0A00 19 pin, long 230mm, two ends with 2.0mm space
connector, same link sides connect front panel board and mainboard
CONNECT CABLE
Harman Consumer Group Components JBL DSC1000/230

DSC1000 Component list
58 160-E0100160-0A00 110 pin, long 160mm, one end with 2.0mm connector and another end with 2.54mm connector, different link
sides connect power supplier board and mainboard
59 160-E0050180-0A00 15 pin, long 180mm, one end with 2.0mm connector and another end with 2.54mm connector, same link
sides connect power supplier board and amplifier board
60 160-EG020180-0A00 12 pin, long 180mm, two ends with VH-3Y connector,
different link sides connect power supplier board and amplifier board
61 161-16070100-0000 1
16 pin, long 50mm, 1.0mm space, flat cable, same link
sides connect mainboard and amplifier board
62 161-24070050-0000 111 pin, long 70mm, 1.25mm space, flat cable, same
link sides connect mainboard and tuner model
63 160-E0050340-5A00 15 pin with shield, long 340mm, two ends with 2.0mm
space connector, same link sides connect front panel board and mainboard
64 160-E0020600-2A00 12 pin, long 600mm, one end with VH-3Y connector connect power supplier board and power switch
65 160-E0240170-JA00 124 pin, long 170mm, 0.5mm space, flat cable, different
link sides connect loader and mainboard
66 160-E0030060-3A00 13 pin, long 60mm, two ends with 2.54mm space
connector, same link sides connect power supplier board and front panel board
67 162-A0000350-0000 1Power cord with 350mm fixture, with magnetism
annulus EU version
68 162-A0000042-0000 11 pin with 42 line, one end with alumium fastener connect A point with B point of Q6 on SMPS
69 206-0000DV34-2202 1LOADER SANYO DV34
70 555-A01000RC-0010 1Remote control DSC1000
71 170-APS5EA07-0000 1Power switch (20mm) PS5E-A-078
204-001E803A-0300 TFCF1E803A, for EU version,
73 300-C1239CPV-0002 1Mainboard 1239C-PV1
74 300-O01241C-0002 1Amplifier board 1241C
75 300-D001242C-0002 1Front panel board 1242C
76 300-K001354C-0001 1Remote control board 1354C
FM tuner model1
WHOLE PART
ASSEMBLED PCB
72
Harman Consumer Group Components JBL DSC1000/230
