Jetta JETBOOK 9060 User manual

On - Line Manual

The FCC wants you to know...
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
Any changes or modifications made to this equipment may void the user’s
authority to operate this equipment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
● All external cables connecting to this basic unit must be shielded. For cables
connecting to PCMCIAcards, see the option manual or installation instructions.

Federal Communications Commission (FCC)
PART 68 Warning
This equipment complies with Part 68 of the FCC Rules. On the bottom of the
computer is a label that contains, among other information, the FCC Registration
Number and Ringer Equivalence Number (REN) for this equipment. You must,
upon request, provide this information to your telephone company.
FCC Part 68 Registration Number: 6CTTAI – 25876 – FB – E
REN: 0.8B
The REN is useful to determine the quantity of devices you may connect to your
telephone and still have all of those devices ring when your number is called. In
most, but not all areas, the sum of the REN’s of all devices should not exceed five
(5.0). To be certain of the number of devices you may connect to your line, as
determined by the REN, you should call your local telephone company to
determine the maximum REN for your calling area.
If your MODEM causes harm to the telephone network, the local Telephone
Company may discontinue your service temporarily. If possible, they will notify
you in advance. However, if advanced notice isn’t practical, you will be notified
as soon as possible. You will be informed of your right to file a complaint with the
FCC.
Your telephone company may make changes in its facilities, equipment,
operations, or procedures the could affect the proper functioning for your
equipment. If they do, you will be notified in advance to give you an opportunity
to maintain uninterrupted telephone service.
CANADIAN DOC NOTICE
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the Radio Interference Regulation of the
Canadian Department of Communications.
"Le présent appareil numérique n’èmet pas de bruits radioélectriques dépassant
les limites applicables aux appareils numériques de la class B prescrites dans le
Règlement sur le brouillage radioélectrique édicté par le ministère des
Communications du Canada"

Macrovision License of Notice
This product incorporates copyright protection technology that is protected by
method claims of certain U.S. patents and other intellectual rights owned by
Macrovision Corporation, and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse engineering or disassembly is
prohibited.
Dolby License of Notice
Manufactured under license from Dolby Laboratories.

Chapter 1
Front with the display closed
Right side
Left side
Back side
Underside
Front with the display open
System window and LED control

Finding Your Way Around
This chapter presents a "grand tour" of your computer with illustrations to guide
you along your way. It serves as a reference when you need to locate specific
parts of the computer.
Front with the display closed
The Diskette drive allows you to use either high-density or double-density
3.5-inch diskettes.
The Display latch keeps the display panel closed and locked. To open the display
panel, slide the latch to the right and raise the panel.
The Diskette drive release button ejects a diskette from the diskette drive.
The Front panel lights provide information about various system functions. The
front panel controls perform several functions, depending on the position of the
AP/Lock/Audio CD.

Front panel controls
AP/Lock/Audio CD
The AP/Lock/Audio CD has three different positions:
ϖWhen the switch is in AP mode, the buttons act as hot
keys and launch a predefined program of your choice.
ϖWhen the switch in Lock mode, the four front panel
control buttons (stop/eject, play/pause, previous track,
next track) are disabled.
ϖWhen the switch is in Audio CD mode, the front panel
buttons can control playing the CD. For more
information on using the front panel buttons to play a
CD.
NOTE: You can play an Audio CD even when the computer is off by
sliding the AP/Lock/Audio CD to CD mode. The front panel control
buttons can be used to control playing the CD.

Power and battery indicator lights
The on/off light glows green when the computer is on, or when the
computer is off and the AP/Lock/Audio CD is set to CD.
Mail button
The link to New mail express.
The link to mail express.
The link to Internet express.
CD Player controls
With the computer off or no, slide the AP/Lock/Audio CD to the right to
enable the front panel CD player controls. In CD mode, the front panel
control buttons have the following functions:
The stop/eject button stops the disc if it is playing, or opens the CD-ROM
driver tray.
The play/pause button starts playing the current track in the CD-ROM
driver, or pauses a track that is already playing.
The previous track button returns to the beginning of the preceding track
(for CDs) on the disc.
The next track button skips to the beginning of the following track (for
CDs) on the disc.
The speaker volume control adjusts the stereo the speaker volume.
Press and hold the left side to decrease the volume until the desired
volume is reached. Press and hold the right side to increase the volume
until the volume is reached.

Right side
The 3.5 mm Headphone jack lets you connect stereo headphones or other audio-output device, such as external speakers. Connecting
headphones or other devices to this jack automatically disables the
internal speakers.
The 3.5 mm Microphone jack lets you connect an external monaural
microphone or other audio-input device.
The PC Card eject buttons allow easy removal of PC Cards.
The two-stacked CardBus-ready PCMCIA-compatible PC Card slots
allow you to install additional devices. Each slot can accommodate a
Type II PC Card. Both slots are able to install a Type III PC Card.
CAUTION: Keep foreign objects out of the PC Card slots. A pin or
similar object that accidentally put into a slot can damage the
computer's circuitry.
The DC IN socket is where you plug in the AC adapter.
The PS/2TM port allows you to connect an optional PS/2 compatible
mouse or external keyboard..
The USB (Universal Serial Bus) ports allow you to connect USB
peripherals to your computer, such as a keyboard, pointing device or
monitor.

Left side
The manual eject button enables you to manually eject a disc from the CD-ROM
drive.
The CD-ROM drive allows you to install and run programs from application
CD-ROMs. You can also use it to play audio CDs.

Back side
The Security lock slot allows you to attach an optional computer cable
lock to secure the computer to a large, heavy object, such as your desk.
The IEEE 1394 port standard devices.
DEFINITION: USB is a peripheral expansion standard that supports a
data- transfer rate of up to 12 Mbps. USB peripherals has a single
standard for cables and connectors.
The USB standard allows you to install and remove USB devices while
the computer is on. Switching devices without turning off the computer
is called "hot swapping."
The RJ-45 LAN port (for LAN model), the jack lets you use a modular
RJ-45 LAN cable to connect the internal built-in LAN card to a LAN
system.
The RJ-11 Modem port , the jack lets you use a modular phone cable to
connect the internal built-in modem to a standard telephone outlet.
CAUTION: Do not use a pencil press the Shutdown button. Pencil lead
can break off inside the computer and damage it. Instead, use a slim
object such as a straightened paper clip.

The Parallel port lets you connect a parallel printer, or other parallel
device, including ECP- compatible devices.
The VGA display port allows you to connect an external monitor.
DEFINITION: ECP (Extended Capabilities Port) is a parallel port
standard for PCs that support bi-directional communication between
the PC and attached devices (such as a printer).
The TV -Out port allows you to connect a Television set to this port to
view the Notebook’s display output on your TV.

Underside
The Memory slot cover protects the extension memory module.
The Battery provides DC power to the computer.
The Battery release latch secures the battery to the computer and prevents it
from falling out.
The Battery latch lock is the double lock for the battery. It prevents the battery
release latch moving to undesired position cause battery falling out.

Front with the display open
LCD screen:
Your Notebook’s VGA display is one of models
-1024 x 768 XGA TFT color LCD, display area 13.3”
-1024 x 768 XGA TFT color LCD, display area 14.1”
-1024 x 768 XGA TFT color LCD, display area 15.0”
-1400 x 1050 SXGA+ TFT color LCD, display area 15.0”
DEFINITION: TFT (Thin Film Transistor) is a type of LCD flat-panel
display screen in which each pixel controlled by from one to four
transistors. Screens with TFT technology (sometimes called
active-matrix LCDs) provide the best resolution of all the flat-panel
displays.

The Power button turns the computer on and off, or let system enter lower power
mode (Standby, Hibernation) depends on power management setting in OS.
The Lid switch can be used to control LCD back light on/off or let system enter
into suspend mode of lower power depends on power management setting in OS.
The System window informs you of the Notebook’s current operating status at a
glance.
The Keyboard provides all the functionality of a full-size keyboard.
The front panel provides a palm rest to assist you in maintaining proper posture
while using the computer.
The function keys, when used with the Fn key, activate various system functions,
such as LCD brightness control.
The Touch Pad is a pressure sensitive pointing device that provides all the
features of a mouse. Although its operation differs from a mouse, its function is
quite the same; to move the cursor around the screen.
The Touch Pad buttons have essentially the same function as mouse buttons.
The stereo Speakers let you hear the computer's audio output such as system
alarms associated with your software and music from audio CDs.
The Front panel controls allow convenient use of the CD player, or can launch
your favorite programs.

System window and LED control
Display icons on system window
● Caps Lock/Num Lock/Scroll Lock/Pad Lock: indicators for keyboard operation
or key-lock mode
● CDROM+HDD/PCMCIA/FDD: indicators for activities of devices
● AC power/Charge/Full: indicators for status ofAC power and battery charge
status
● Battery status: indicates the status of battery pack and other specific definitions
Definition of icons
Icon Definitation System Windows Display
Caps lock Caps Lock State of Keyboard
Scroll Lock Scroll Lock State of Keyboard
Num Lock Num Lock State of Keyboard
Pad Lock Pad Lock State of Keyboard, when
Pad Lock is on, the embedded
keypad will be active
CD-ROM/HDD Reflect the activity of CD-ROM or
HDD
FDD Reflect the activity of internal FDD
(External FDD will not support this
function)
PCMCIA Reflect the activity of PCMCIA

Definitions of battery status
Icon Definitation System Windows Display
AC power Reflect the AC power state
Icon is off: Power source is not
existed.
Icon is on: Power source is existed.
Icon is glitter: The AC adapter not
enough 60 watt.
Charge icon Icon is blinking when battery
installed and in charging.
Blinking rate: turn on 0.5sec/turn off
0.5sec.
Full icon Only turn on battery capacity is
100%. And Charge icon will turn off.
No any battery No battery frame. No any battery icon will be
showed.
Bad cell No battery frame. No any battery icon will be
showed.
Over
temperature Battery frame is solid, show right and left bar. Charge& Full icon turn
off.
Battery power is
low Battery frame is solid on. Show one bar.
Battery power is
critical low
(0%~5%)
Only battery frame is blinking (once
per second).
Battery gas
gauge Battery frame is solid on One bar: capacity 6% to 30%
Battery frame is solid on
Two bar: capacity 31% to 74%
Battery frame is solid on
Three bar: capacity 75% to 100%

Chapter 2
Making sure you have everything
Selecting a place to work
Setting up your computer
Connecting the AC adapter
Charging the Battery
Connecting a printer
Adding memory
Connecting a mouse
Using the computer for the first time
Turn on the computer
Adjusting brightness and contrast (Hot keys)
Using the Track point
Setting the date and time
Setting up your printer
Customizing the desktop
Registering your computer

Getting Started
This chapter provides tips for working comfortably, describes how to connect
components, and explains what to do the first time you use your notebook
computer.
Making sure you have everything
Before doing anything else, consult the Quick Start card to make sure you
received everything. If any items are missing or damaged, notify your dealer
immediately.
Selecting a place to work
Your computer is portable and designed to be used in a variety of circumstances
and locations.
Creating a computer-friendly environment
Place the computer on a flat surface, which is large enough for the computer and
any other items you need to use, such as a printer. Leave enough space around
the computer and other equipment to provide adequate ventilation and prevent
overheating.
To keep your computer in prime operating condition, protect your work area from:
● Dust, moisture, and direct sunlight.
● Liquids and corrosive chemicals.

Setting up your computer
Setting up your computer may include:
● Connecting the AC adapter
● Charging the battery
● Connecting a printer
● Upgrading your computer by installing more memory
● Connecting a mouse
Connecting the AC adapter
Your computer contains a rechargeable battery pack, which needs to be charged
before you can use it the first time.
The AC adapter enables you to power the computer from an AC outlet and to
charge the computer's batteries. A status light on the AC adapter glows when the
device is in use.
To connect AC power to the computer:
1. Connect the power cable to the AC adapter.
2. Plug the AC adapter into the computer's DC IN socket.
