JIB DP25016B User manual

MODEL DP25016B
FOR YOUR SAFETY:
READ ALL INSTRUCTIONS CAREFULLY

Table of Contents
General safety instructions for Power Tools 1
Main specification 2
Unpacking and checking contents
List of loose parts in the box and bags
Getting to know your drill press
Assembly
Lubrication
Maintenance
Wire diagram
Trouble shooting
Repair parts
General safety instructions for Power Tools
1.KNOW YOUR POWER TOOL
Read and understand the ower's manual and labels affixed to the tool.Learn its application and
limitations as well as the specific potential hazards peculiar to this tool.
2.GROUND ALL TOOLS
This tool is equipped with an approved 3 conductor and a 3 prong grounding type plug to fit the
proper grounding type receptacle.
3.KEEP GUARDS IN PLACE
In working order and in proper adjustment and alignment.
4.WEAR PROPER APPAREL
Do not wear loose clothing,gloves,neckties,or jewelry (rings,wrist,watches) to get caught in moving
parts.Wear protective hair covering to contain long hair.Roll long sleeves above the elbow.
5.USE SAFETY GOGGLES
6.KEEP WORK AREA CLEAN
Cluttered areas and benches invite accidents.Floor must not be slippery due to wax or sawdust.
7.KEEP CHILDREN AWAY
-1-

Main Specification
Drill Capacity 16 mm / 5/8 in.
Chuck Capacity 16 mm / 5/8 in.
Swing 250 mm / 10 in.
Spindle Taper MT2
Spindle Travel 60 mm / 2-23/64 in.
Column Diameter 59.5 mm / 2-11/32 in.
Motor 120V/1ph/400W
Rack & Pinion Yes
Base Size 320*215 mm / 13-25/32 × 8-15/32 in.
Table Size 195*196 mm / 7-43/64 × 7-23/32 in.
Max. Distance Chuck to Table 300 mm / 11-13/16 in.
Max. Distance Chuck to Base 375 mm / 14-49/64 in.
Overall Height 850 mm / 33-15/32 in.
Range of spindle speeds
5 speeds
Motor Speed Spindle Speeds (min-1)
1700 min-1 620 1100 1720 2340 3100
Overall dimensions (L*M*H) 690 × 430 × 260mm / 27-11/64 × 16-59/64 × 10-15/64 in.
Net Weight 30kgs / 66 lbs
Unpacking and checking contents
1.Unpacking and checking contents
Separate all the parts from packaging materials and check each item make sure all items are accounted
for before discarding any packing material.
Item Description Qty
A Head Asm…………………………………………. 1
BColumn Support Asm……………………………. 1
C Owner's Manual…………………………………… 1
D Box of Loose Parts……………………………….. 1
E Bag of Loose Parts……………………………….. *
F Base…………………………………………………. 1
G Table/Support Arm………………………………… 1
2.Remove the protective oil that is applied to the table and column.Use any ordinary household
type grease and spot remover
3.Apply a coat of paste wax to the table and column to prevent rust.Wipe all parts thoroughly with
clean dry cloth.

-2-

690 × 430 × 260mm / 27-11/64 × 16-59/64 × 10-15/64 in.

List of Loose Parts in the box and bags
-3-

Getting to know your drill press
- 4-

Assembly
Refer to the figure install all parts correctly,
tighten the screw and bolts securelly
1 Base
2. Column/w Support Asm
3 M10*1.5-40Screw (4)
4 Head Asm
5 Table
6 Feed Handle
7 Clamp-Column Lock
8 Crank
-5-
- 5-

Lubrication
All of the BALL BEARING are packed with grease at the factory.They require no further lubrication.
Periodically lubricate the table elevation machanism,the SPLINES (grooves) in the spindle,and the
RACK (teeth of the quill),see "Getting to know your drill press."
Maintenance
Frequently blow out any dust that may accumulate inside the motor.
A coat of automotive type paste was applied to the table and column will help to keep the surfaces clean.
Wire diagram
Part No. Component/Object Manufacturer PCS
Motor Motor AC250V/1PH/400W 1
SB1 Magnetic Switch 250VAC/16A 1 KJD12
SB2
SB3 Push Button-Emergency Stop 250VAC/12A 1 HY57B
SB4 Micro Switch 250VAC/16A 1 KW-7-3B
SB5 Micro Switch 250VAC/16A 1 KW7
- 6-

Trouble Shooting
TROUBLE PROBABALE CAUSE REMEDY
Noisy Operation
1.Incorrect belt tension. 1.Adjust tension.
2.Dry Spindle. 2.Lubricate spindle.
3.Loose spindle pulley 3.Checking tightness of retaining nut on
pulley,and tighten if necessary.
4.Loose motor pulley 4.Tighten setscrews in pulleys.
Drill bit burns
1.Incorrect speed. 1.Change speed.
2.Chips not coming out of hole. 2.Retract drill bit frequently to clear chips.
3.Dull drill bit 3.Resharpen drill bit.
4.Feeding too slow 4.Faster the speed.
5.Not lubricated 5.Lubricate drill bit.
Drill bit leads off…
hole not round
1.Hard grain in wood or
lengths of cutting lips
and/or angles not equal
1.Resharpen drill bit correctly.
2.Bent drill bit 2.Replace drill bit.
Wood splinters on
underside
1.No "back up material" 1.Use "back-up material"
under workpiece.
Workpiece turn
loose from hand
1.Not supported or 1.Support working or clamp it.
clamped properly.
Drill bit binds in
workpiece
1.Workpiece pinching drill bit 1.Support working or clamp it.
or excessive feed pressure.
2.Improper belt tension. 2.Adjust temsion.
Excessive drill bit
runout or wobble
1.Bent drill bit 1.Use a straight drill bit.
2.Worn spindle bearings. 2.Replace bearings.
3.Drill but not properly 3.Install drill bit properly.
installed in chuck
4.chuck not properly installed. 4.Install chuck properly.
Quill Returns too
slow or too fast 1.Spring has improper tension. 1.Adjust spring tension.
Chuck will not stay
atached to spindle
if falls off when
trying to install it.
1.Dirty,grease,or oil on the 1.Using a household detergent clean the
tapered inside surface of chuck tapered surface of the chuck and spindle to
or on the spindles tapered remove all dirt,grease and oil.
surface.
-7-

Repair Parts
FIGURE1
FIGURE1 PARTS LIST
Key
No. Description Key No. Description
1 Knob 14 Bushing-Rubber
2 Screw-Pan Hd.M5*0.8-12 15 Ring-Retaining
3 Pulley-Motor 16 *Bearing-Ball 17mm
4 Screw-Hex Soc.Set M6*1.0-10 17 Spacer
5 Guard Pulley w/Lables 18 Insert Pulley (includes Key
6 *Bearing-Ball 12mm #15&20)
7 Shaft-Spindle 19 Pulley-Spindle
8 Chuck 20 Nut-Pulley
9 Key-Chuck 21 Belt-"V"5/16*31
10 Tube-Quill 22 Clamp Cord
11 Gasket-Quill 23 Screw-Pan Hd.M5*0.8-10
12 Ring-Retaining 24 Washer Foam
13 Screw-Wash.Hd.M6*1.0-12 25 *Lockwasher M6
*Standard Hardware Item --- May Be Purchased Locally
-8-

Repair Parts
FIGURE2
FIGURE2 PARTS LIST
Key
No. Description Key No. Description
1 Head w/Pointer&Trim 21 *Lockwasher-Ext.5mm
2 Motor 22 Screw-Pan Hd.M5*0.8-8
3 *Nut-Hex M8 23 Screw-Pan Hd.M5*0.8-12
4 *Washer M8*16*1.6 24 Switch Locking
5 Cord-Motor 25 Key-Switch
6 *Nut-Hex M10 26 Screw-Self Tap.Pan Hd
7 *Lockwasher M10 M4.2*1.4-9.5
8 Bracket-Motor 27 Cover-Switch Plate
9 Screw-Hex Hd.M8*1.25-20 28 Box-Switch
10 Support-Motor Bracket 29 Screw-Special Set
11 Pin-Roll 6*16 M8*1.25*18
12 knob-Motor Adjusting 30 Seat-Spring
13 Screw-Hex Soc.Set 31 *Nut-Hex M12*1.5-8
M8*1.25-8 32 Cap-Spring
14 Lock-Depth Screw 33 Spring-Torsion
15 Ring-Depth Stop W/Scale 34 Retainer-Spring
16 knob 35 Cord-Power
17 Rod 36 Hex"L"-Wrench 3mm
18 Hub-Pinion 37 Hex"L"-Wrench 4mm
19 Pin-Stop Owners Manual
20 *Connector-Wire (Not Illustrated)
*Standard Hardware Item --- May Be Purchased Locally
-9-

Repair Parts
FIGURE3
FIGURE3 PARTS LIST
Key No. Description
1 Support-Table w/Scale
2 Support-Lock Handle
3 Tube/Support
4 Base
5 Screw-Hex Hd.M8*1.25-20
6 Screw-Hex Hd.1/2-12*7/8
7 Table
