SERVICE MANUAL
AUDIO/VIDEO CONTROL RECEIVER
No.21160
Oct. 2002
COPYRIGHT 2002 VICTOR COMPANY OF JAPAN, LTD.
RX-8022PSL
RX-8022PSL
Contents
Safety precautions --------------------------------------------------------1-2
Disassembly method -----------------------------------------------------1-3
Adjustment method -------------------------------------------------------1-9
Self-diagnose function-----------------------------------------------------1-10
Description of major ICs -------------------------------------------------1-12~31
Area suffix
A --------------- Australia
MENU
231
564
89
7/P
0+10 10
BOOST FRONT•L
MENU
ENTER
FRONT•R
BASS
DIMMER
TEST CENTER SUBWFR
DIGITALEQ SBACK•L SBACK•R
SURR•L SURR•R
MUTING
CH/ LEVEL TV VOL
PLAY
STOP
/REW
DOWN – TUNING – UP
FF/
EXIT
VOLUME
CATV/DBS
CONTROL
TV/VIDEO
REC
PAUSE
SLEEP
PAUSE
SET
RETURN FMMODE 100+
CONTROL
RM-SRX8020J REMOTE CONTROL
CATV/DBS VCR1 TV AUDIO
DSP
OFF
DVD MULTIDVD
USB
CD
CDR
TAPE/MD
TV/DBS VIDEO PHONO
FM/AM
VCR1 VCR 2
SURROUND
SURR/DSP ANALOG/DIGITAL
A/V CONTROL RECEIVER
INPUT
DIRECT
ANALOG
TEXT
DISPLAY
SOUND
CONTROL
DOWN UP
EFFECT SETTING
DIGITAL
EQ
TV SOUND/DBSVIDEOVCR 2VCR 1DVDDVD MULTI
INPUT
ANALOG/DIGITAL
DSP
S-VIDEO VIDEO
VIDEO
L—AUDIO—R
SURROUND
SUBWOOFER OUT ON/OFF
SPEAKERS ON/OFF
FM/AM TUNING FM/AM PRESET FM MODE
MEMORY
PHONES
1
STANDBY
USB AUDIO
SURROUND/DSP
OFF
FM/AMUSB AUDIOTAPE/MDCDRCDPHONO
LEVEL
ADJUST
RX-8022P
AUDIO/VIDEO CONTROL RECEIVER
ANALOG DIRECT
BASS BOOST
MASTER VOLUME
2
SOURCE NAME
SOUCE NAME
STANDBY/ON
INPUT ATT
PUSH OPEN

RX-8022PSL
1-2
1. This design of this product contains special hardware and many circuits and components specially for safety
purposes. For continued protection, no changes should be made to the original design unless authorized in
writing by the manufacturer. Replacement parts must be identical to those used in the original circuits. Services
should be performed by qualified personnel only.
2. Alterations of the design or circuitry of the product should not be made. Any design alterations of the product
should not be made. Any design alterations or additions will void the manufacturer`s warranty and will further
relieve the manufacture of responsibility for personal injury or property damage resulting therefrom.
3. Many electrical and mechanical parts in the products have special safety-related characteristics. These
characteristics are often not evident from visual inspection nor can the protection afforded by them necessarily
be obtained by using replacement components rated for higher voltage, wattage, etc.Replacement parts which
have these special safety characteristics are identified in the Parts List of Service Manual. Electrical
components having such features are identified by shading on the schematics and by ( ) on the Parts List in
the Service Manual.The use of a substitute replacement which does not have the same safety characteristics
as the recommended replacement parts shown in the Parts List of Service Manual may create shock, fire, or
other hazards.
4. The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be
separated from live parts, high temperature parts, moving parts and/or sharp edges for the prevention of
electric shock and fire hazard. When service is required, the original lead routing and dress should be
observed, and it should be confirmed that they have been returned to normal, after re-assembling.
5. Leakage currnet check (Electrical shock hazard testing)
After re-assembling the product, always perform an isolation check on the exposed metal parts of the product
(antenna terminals, knobs, metal cabinet, screw heads, headphone jack, control shafts, etc.) to be sure the
product is safe to operate without danger of electrical shock.
Do not use a line isolation transformer during this check.
Plug the AC line cord directly into the AC outlet. Using a "Leakage Current Tester", measure the leakage
current from each exposed metal parts of the cabinet, particularly any exposed metal part having a return
path to the chassis, to a known good earth ground. Any leakage current must not exceed 0.5mA AC (r.m.s.).
Alternate check method
Plug the AC line cord directly into the AC outlet. Use an AC voltmeter having, 1,000 ohms per volt or more
sensitivity in the following manner. Connect a 1,500 10W resistor paralleled by a 0.15 F AC-type capacitor
between an exposed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal part,
particularly any exposed metal part having a return path to
the chassis, and meausre the AC voltage across the resistor.
Now, reverse the plug in the AC outlet and repeat each
measurement.Voltage measured any must not exceed 0.75 V
AC (r.m.s.).This corresponds to 0.5 mA AC (r.m.s.).
1.This equipment has been designed and manufactured to meet international safety standards.
2. It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
3. Repairs must be made in accordance with the relevant safety standards.
4. It is essential that safety critical components are replaced by approved parts.
5. If mains voltage selector is provided, check setting for local voltage.
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE
!
Burrs formed during molding may
be left over on some parts of the
chassis. Therefore, pay attention to
such burrs in the case of
preforming repair of this system.
In regard with component parts appearing on the silk-screen printed side (parts side) of the PWB diagrams, the
parts that are printed over with black such as the resistor ( ), diode ( ) and ICP ( ) or identified by the " "
mark nearby are critical for safety.
(This regulation does not correspond to J and C version.)

1-3
RX-8022PSL
Remove the four screws Aattaching the top cover
on both sides of the body.
Remove the three screws Bon the back of the body.
Remove the top cover from behind in the direction of
the arrow while pulling both sides outward.
1.
2.
3.
Disassembly method
Removing the top cover (See Fig.1)
Prior to performing the following procedure, remove
the top cover.
Remove the power cord stopper from the rear panel
by moving it in the direction of the arrow.
Remove the thirty seven screws E & F & G & H
attaching the each board to the rear panel.
Remove the three screws Iattaching the rear panel
on the back of the body.
1.
2.
3.
Removing the rear panel (See Fig.4)
Prior to performing the following procedure, remove
the top cover.
Cut off the tie bands.
Disconnect the harness from the connector CN416
(on the video audio board), CN206 (on the video
board) and CN244 (on the S video board) (see fig.8).
Disconnect the card wire from the connector CN400
on the audio board and CN402 on the power supply
board.
Remove the three screws Cfixing the upper surface
of the front panel, and four screws Dfixing the
bottom.
Detach the front panel assembly toward the front.
Remove the screw X attaching the earth wire (see fig.
19).
1.
2.
3.
4.
5.
6.
Removing the front panel assembly
(See Fig.2 and 3)
Prior to performing the following procedure, remove
the top cover.
Disconnect the harness from the connector CN393
on the compu link board.
Remove the three screws Eattaching the compu link
board to the rear panel.
1.
2.
Removing the compulink board
(See Fig.2 and 4)
Fig.1
Fig.2
Fig.3
Fig.4
A (both sides)
B
Top cover
CC
Power
supply board
Audio
board
CN400
CN402
CN393
Main
board
FFF FE G
FIIHI
Cord stopper
Front panel assembly
Front panel assembly
D
Rear panel
Tie band
Compu
link board

RX-8022PSL
1-4
Prior to performing the following procedure, remove
the top cover and rear panel.
Cut off the tie bands.
Disconnect the harness from the connector CN393
on the compu link board (see fig.2).
Disconnect the harness from the connector CN721,
CN723 on the main board and CN722 on the Cch
amp. board.
Remove the two fasteners fixing the small board to
the audio input board and video board.
Draw out the DVD board upwards, disconnecting the
connector CN501, CN243, CN205, CN381 and
CN361 on the DVD board.
1.
2.
3.
4.
5.
Removing the DVD board (See Fig.5 and 6)
Prior to performing the following procedure, remove
the top cover, rear panel and DVD board.
Remove the tuner board from the connector CN101
on the audio board.
Remove the audio input board from the connector
CN301 on the audio board.
Disconnect the harness from the connector CN416
and remove the video audio board from the
connector CN303 on the audio board.
Disconnect the harness from the connector CN206
and remove the video board from the connector
CN201 on the audio board.
Disconnect the harness from the connector CN244
and remove the S video board from the connector
CN241 on the audio board.
Remove the DSP board from the connector CN601
on the audio board.
1.
2.
3.
4.
6.
7.
Removing the each board of the tuner, the
audio input, the video audio, the video, the
S video and the DSP (See Fig.7 to 10)
Fig.5
Fig.6
Fig.8
Tie band
CN723
Tuner board
CN721
CN722
(on the Cch
amp. board)
DVD board
Main
board
CN361
CN381 CN243
CN501
CN205
Fig.7
Audio input board
Audio input board
&
Video board
Fastener
Small board
Video board S Video board
Video audio board DSP board
DVD board
CN244
(on the S
video board)
CN206
(on the
video board)
CN416
(on the video audio board)

1-5
RX-8022PSL
Removing the audio board
(See Fig.11 and 12)
Prior to performing the following procedure, remove
the top cover, rear panel, DVD board, tuner board,
audio input board, video audio board, video board, S
video board and DSP board.
Disconnect the harness and card wire from the
connector CN931 /CN932 and CN400 on the audio
board.
Cut off the tie band, if needed.
Disconnect the connector CN71(on the power supply
board) and CN81(on the audio board) and remove the
relay board.
Disconnect the harness from the connector CN831 on
the main board.
Remove the three screws Jand screw Kattaching the
audio board.
1.
2.
3.
4.
5.
Removing the speaker board (See Fig.11)
Prior to performing the following procedure, remove
the top cover and rear panel.
Disconnect the harness from the connector CN931/
CN932 on the audio board.
Disconnect the harness from the connector CN813
and CN814 on the main board.
1.
2.
Fig.11
Power
supply
board
Relay board
Audio board
Speaker board
CN71
CN81
K
CN814
CN813
CN931
/CN932
Power
transformer
J
Tie band
CN831
CN400
Main board
Fi
g
.12
Audio board
Fig.10
Fig.9
CN303
CN201 CN241
Audio board
CN301
CN101
CN601
Connection between the audio board and each board
CN101
CN301
CN303
CN201
CN241
CN601
Tuner board (CN111)
Audio input board (CN311)
Vidoe audio board (CN313)
Video board (CN200)
S video board (CN240)
DSP board (CN587)

RX-8022PSL
1-6
Prior to performing the following procedure, remove
the top cover.
Remove the card wire and cut off the tie bands.
Disconnect the harness from the connector CN721,
CN723, CN813, CN814, CN831 and CN881 on the
main board.
Disconnect the harness from the connector CN722
on the Cch amp. board (see fig.5).
Disconnect the harness from the connector CN811
on the power trans1 board.
Remove the screw K, after removing the relay board
if needed (see fig.11).
Remove the two screws Land the six screws M
attaching the main board.
Remove the two screws Nattaching the heat sink to
the main board.
Disconnect the connector of each amp. board.
1.
2.
3.
4.
6.
7.
8.
9.
Removing the main board
(See Fig.13 to 15)
Prior to performing the following procedure, remove
the top cover, main board and each amp. board.
Remove the four screws Tattaching the two
brackets to the heat sink and remove the two
brackets.
1.
Removing the Heat sink (See Fig.16)
Prior to performing the following procedure, remove
the top cover and main board.
Remove the two screws Oattaching the Cch amp.
board and remove the Cch amp. board.
Remove the two screws Pattaching the Lch amp.
board and remove the Lch amp. board.
Remove the two screws Qattaching the Rch amp.
board and remove the Rch amp. board.
Remove the two screws Rattaching the RLch amp.
board and remove the SLch amp. board.
Remove the two screws Sattaching the RRch amp.
board and remove the SRch amp. board.
1.
2.
3.
4.
5.
Removing the each amp. board of Cch,
Lch, Rch, RLch and RRch (See Fig.16)
Fig.13
Main board (reverse side)
Heat sink
Main board
RRch amp. board
Lch amp. board
Rch amp. board
Cch amp. board
RLch amp. board Heat sink
T
T
Fig.14
Fig.15
Main board
CN881
CN831
CN814
CN721
CN706
CN705
CN702 CN701 CN703
CN722
CN723
CN813
L
L
K
MM
Tie band
Tie band
Card wire CN811
Fig.16
N
Power
trans1
board
Heat sink
Bracket Bracket
P (Lch)
O (Cch) Q (Rch) S (RRch)
R (RLch)

1-7
RX-8022PSL
Prior to performing the following procedure, remove
the top cover and relay board.
Cut off the tie band if needed.
Disconnect the card wire from the connector CN402
on the power supply board.
Disconnect the harness from the connector
CN55/CN56 on the power trans1 board (see fig.17).
Remove the three screws Wattaching the power
supply board and pull out the power supply board
removing the hook.
Unsolder the three solder parts on the power supply
board.
1.
2.
3.
4.
5.
Removing the power supply board
(See Fig.18)
Prior to performing the following procedure, remove
the top cover.
Removed the two screws Gattaching the voltage
selector board to the rear panel (see fig.4).
Remove the screw Hattaching the power/fuse board
to the rear panel (see fig.4).
Remove the screw Vattaching the power/fuse board.
Unsolder the eight solder parts on the power/fuse
board.
1.
2.
3.
4.
Removing the power/fuse board
(See Fig.17)
Prior to performing the following procedure, remove
the top cover.
Removed the two screws Gattaching the voltage
selector board to the rear panel (see fig.4).
Unsolder the six solder parts on the voltage selector
board.
1.
2.
Removing the voltage selector board
(See Fig.17)
Prior to performing the following procedures, remove
the top cover.
Disconnect the harness from the connector CN55
/CN56 and CN811 on the power trans1 board.
Unsolder the seven solder parts on the power trans2
board.
Remove the four screws Uattaching the power
transformer.
1.
2.
3.
Removing the power transformer
(See Fig.17)
Fig.18
Headphone jack
Headphone jack board
Tie band
Solder part
(on the
reverse side)
Hook
Tie band
W
W
Power supply board
CN402
Fig.17
Power
supply board
CN55/CN56
CN811
Power
transformer
U
Solder part
Solder part
(on the reverse side)
Solder part
V
Power/fuse board
Power cord
Power
trans1 board
Power
trans2 board
Voltage
selector board
W
Solder part
(on the reverse side)
Under this board

RX-8022PSL
1-8
Removing the system control board,
power switch board and switch board
(See Fig.1 to 3)
<Front panel assembly>
Prior to performing the following procedure, remove
the top cover and front panel assembly.
Pull out the volume knob on the front side of the front
panel assembly and remove the nut attaching the
system control board.
Remove the two screws Aattaching the power
switch board on the front panel assembly(inner side).
And disconnect the harness from the connector
CN430 on the power switch board.
Remove the two screws Battaching the switch board
on the front panel assembly(inner side). And
disconnect the harness form the connector CN432
on the switch board.
Remove the harness from the three hooks a.
Remove the eight screws Cattaching the operation
switch panel from the inner side of the front panel
assembly.
Release the four joints on the front panel assembly
(inner side) by pushing the joint tabs inward.
Remove the operation switch panel toward the front.
Release the two hooks battaching the system
control board.
Disconnect the card wire from the connector CN410
and CN412 on the system control board.
1.
2.
3.
4.
5.
6.
7.
8.
Prior to performing the following procedure, remove
the top cover, front panel assembly and power supply
board.
Disconnect the harness form the connector CN881
on the main board (see fig.13).
Remove the nut fixing the headphone jack.
Drawn out the headphone jack board in the direction
of an inner side.
1.
2.
3.
Removing the headphone jack board
(See Fig.18 and 19)
Fig.1
Fig.3
Nut
Volume knob
System control board
CN410
Hook bHook b
Operation switch panel
CN412
Fig.2
Front panel assembly (inner side
)
Power switch board
CC
A
Joint Joint Joint Joint
B
CN430
CN432 Switch board C
Hook a
Fig.19
Nut
Bracket
Earth wire
Front panel
assembly
(inner side)
Headphone
jack
X

1-9
RX-8022PSL
Adjustment method
<Adjustment method>
1.Set the volume control to minimum during this adjustment.(No signal & No load)
2.Set the surround mode OFF.
2.Turn VR787 and VR788 fully counterclockwise to warm up before adjustment.
If the heat sink is already warm from previous use the correct adjustment can not be made.
3.For L-ch,connect a DC voltmeter between B2204 and B2205 (Lch)
And,connect it between B2213 and B2214(Rch).
4.30 minutes later after power on, adjust VR787 for L-ch, or VR788 for R-ch so that the DC voltmeter
value has 1mV~10mV.
1.Tuner range
FM 87.5MHz~108.0MHz
AM(MW) 531 kHz to 1 602 kHz (at 9 kHz intervals)
530 kHz to 1 600 kHz (at 10 kHz intervals)
Tuner section
Power amplifier section
B2213, B2214
VR787 (Lch)
VR788 (Rch)
Heat sink
Rch amp. board
Adjustment of idling current
Measurement location B2204-B2205(Lch) , B2213-2214(Rch)
Adjustment part VR787(Lch) , VR788(Rch)
Attention
This adjustment does not obtain a correct adjustment value immediately after the amplifier is
used (state that an internal temperature has risen).
Please adjust, after you turn off amplifier and internal temperature falls.
* It is not abnormal though the idling current might not become 0mA even if it is finished to turn variable
resistance (VR787,VR788) in the direction of counterclockwise.
B2204, B2205
Lch amp. board

RX-8022PSL
1-10
Self-diagnose function
1. Detection of abnormal power supply and voltage
When the power is turned ON, if an abnormality is detected during the signal input at the A/D port (IC901,
pin 2-5, 7) for one second continuously, the status will become STANDBY mode immediately.
When the power is turned ON again, detection of abnormal power supply and voltage will not be carried out
during the first 4 seconds.
Given below is a list of threshold values at the detection of abnormalities.
2. Initial setting on ship
To gain the initial setting on ship, put the power plug in the socket while pressing "DOWN" key and "UP" key
together simultaneously, then turn the power ON.
3. Test mode
To enter the test mode, put the power plug in the socket while pressing "EFFECT" key and "UP" key together
simultaneously, then turn the power ON.
Workings of test mode:
All FLs are turned ON for 3 seconds. (the FLs, which are divided in two groups, are turned ON alternatively)
A Faster volume UP/DOWN operation can be achieved with the remote controller.
When the power is turned OFF, the test mode will be released.
The FL display returns to normal after the three seconds. Then the STANDBY LED is turned ON (flashing
ON and OFF for each one second) to show the present status being a test mode.
Pin 2
Micro-computer+5V
Pin 3
Digital+5V
Pin 4
Analog+5V
Pin 5
+12V
Pin 7
Tuner+9V
At abnormal state
(Low voltage)
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
Analog value
0 - 2.2V
At normal state
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
Analog value
2.2 - 2.8V
At abnormal state
(High voltage)
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V
Analog value
2.8 - 5.0V

1-11
RX-8022PSL
Information on VERSION of system microcomputer (IC901)
Example : 2002/2/20 9th ROM
Display the local version (IC581)
Example : Ver_1.00
Display the local creation date
Example : 2002/2/10
Display the DSP version (IC511)
Example : DSP Rev41
Display the input sources
However, since it is the source of DIR processing, actual source may be
contradicted.
Example : ANALOG08
Display the input Fs
Example : Fs48kHz
Display the input format
Example : PCM
Display the input channel
Example : 2/0.0
S0001
200202209
4. Self-diagnose
V
0
D
A
D
D
D
D
D
D
U
F
F
F
F
N
U
P
A
A
D
D
D
A
M
N
U
1
2
2
2
3
2
3
2
3
N
D1
D2
D3
D4
D5
D6
D7
e
2
S
N
I
I
I
I
I
I
N
s
s
s
s
G
N
C
C
C
T
T
T
A
P
G
N
/
/
/
/
/
/
/
/
/
G
r
/
P
A
G
G
G
G
G
G
L
L
M
3
3
S
S
S
C
E
L
0
0
0
0
0
1
1
2
2
0
R
L
I
I
I
I
I
I
O
3
4
4
9
D
O
-
-
-
G
D
O
.
.
.
.
.
.
.
.
.
D
1
2
e
O
T
T
T
T
T
T
C
2
4
8
6
A
C
E
E
E
A
C
0
0
0
0
0
0
0
0
0
A
.
/
v
G
A
A
A
A
A
A
K
k
k
k
k
T
K
X
S
S
T
K
T
0
1
4
x
L
L
L
L
L
L
H
H
H
H
A
A
L
D
A
0
0
1
x
1
2
3
4
5
z
z
z
z
M
D
t
M
To enter the self-diagnose mode, put the power plug in the socket while pressing "SETTING" key and "UP" key
together simultaneously, then turn the power ON.
While the working status is being displayed, the each item can be switched with the UP/DOWN key
operation.
When the power is turned OFF, the self-diagnose mode will be released.
During the self-diagnose mode, the STANDBY LED is turned ON (flashing ON for one second then OFF for
three seconds).
FL transient display will be carried out as follows. When the transient display is not carried out,
normal display/workings are carried out.

RX-8022PSL
1-12
XCC56367PV150 (IC501) : DSP
MENORY EXPANTION AREA
PERIPHERAL
EXPANSION AREA
24-BIT
DSP56300
Core
EXTAL
RESET
PINIT/NMI
MODA/IRQA
MODB/IRQB
MODC/IRQC
MODD/IRQD
YAB
XAB
PAB
DAB
DDB
YDB
XDB
PDB
GDB
PM_EB
PIO_EB
XM_EB YM_EB
18
ADDRESS
10
CONTROL
24
DATA
TRIPLE
TIMER HOST INTERFACE SHI INTERFACE
DAX
(SPDIF Tx.)
INTERFACE
ADDRESS
GENERATION
UNIT
SIX CHANNELS
DMA UNIT
INTERNAL
DATA
BUS
PLL
CLOCK
GENARAT
PROGRAM
INTERRUPT
CONTROLLER
PROGRAM
DECODE
CONTROLLE
PROGRAM
ADDRESS
GENERATOR
PROGRAM
RAM
/INSTR.
CACHE
3Kx24
PROGRAM
ROM
40K x 24
Bootstrap
X MEMORY
RAM
13K x 24
ROM
32K x 24
Y MEMORY
RAM
7K x 24
ROM
8K x 24
DATA ALU
24 x 24 + 56->56-BIT MAC
TWO 56-BIT ACCUMULATORS
BARREL SHIFTER JTAG
OnCE
24BITS BUS
POWER
MNGMNT
EXTERNAL
DATA BUS
SWITCH
DRAM &
SRAM BUS
INTERFACE
&
I-CACHE
EXTERNAL
ADDRESS
BUS
SWITCH
ESAI_1
ESAI
INTERFACE
4
1 2 16 8 4 6 5
D6
D5
D4
D3
GNDD
VCCD
D2
D1
D0
A17
A16
A15
GNDA
VCCQH
A14
A13
A12
VCCQL
GNDQ
A11
A10
GNDA
VCCA
A9
A8
A7
A6
GNDA
VCCA
A5
A4
A3
A2
GNDA
VCCA
A1
108
107
106
105
104
103
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
80
79
78
77
76
75
74
73
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
SCK/SCL
SS#/HA2
HREQ#
SDO0/SDO0_1
SDO1/SDO1_1
SDO2/SDI3/SDO2_1/SDI3_1
SDO3/SDI2/SDO3_1/SDI2_1
VCCS
GNDS
SDO4/SDI1
SDO5/SDI0
FST
FSR
SCKT
SCKR
HCKT
HCKR
VCCQL
GNDQ
VCCQH
HDS/HWR
HRW/HRD
HACK/HRRQ
HOREQ/HTRQ
VCCS
GNDS
ADO
ACI
TIO0
HCS/HA10
HA9/HA2
HA8/HA1
HAS/HA0
HAD7
HAD6
HAD5
HAD4
VCCH
GNDH
HAD3 HAD2 HAD1 HAD0
RESET#
VCCP
PCAP
GNDP
SDO5_1/SDI0_1
VCCQH
FST_1
AA2
CAS#
SCKT_1
GNDQ
EXTAL
VCCQL
VCCC
GNDC
FSR_1
SCKR_1
PINT/NMI#
TA#
BR#
BB#
VCCC
GNDC
WR#
RD#
AA1 AA0
BG#
A0
37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72
MISO/SDA MOSI/HA0 TMS TCK TDI TDO SDO4_1/SDI1_1 MODA/IRQA# MODB/IRQB# MODCIRQC# MODD/IRQD# D23 D22 D21 GNDD VCCD D20 GNDQ VCCQL D19 D18 D17 D16 D15 GNDD VCCD D14 D13 D12 D11 D10 D9 GNDD VCCD D8 D7
144 143 142 141 140 139 138 137 136 135 134 133 132 131 130 129 128 127 126 125 124 123 122 121 120 119 118 117 116 115 114 113 112 111 110 109
1. Pin layout
2. Block diagram
Description of major ICs

1-13
RX-8022PSL
PORT A ADDRESS BUS
A0-A17
VCCA(3)
GNDA(4)
PORT A DATA BUS
D0-D23
VCCD(4)
GNDD(4)
PORT A BUS CONTROL
AA0-AA2/RAS0-RAS2
CAS
RD
WR
TA
BR
BG
BB
VCCC(2)
GNDC(2)
INTERRUPT AND
MODEL CONTROL
MODA/IRQA
MODB/IRQB
MODC/IRQC
MODD/IRQD
RESET
PLL AND CLOCK
EXTAL
PINIT/NMI
PCAP
VCCP
GNDP
QUIET POWER
VCCQH(3)
VCCQL(4)
GNDQ(4)
SPDIF TRANSMITTER(DAX)
ADO[PD1]
ACI[PD0]
TIMER 0
TIO0[TIO0]
OnCE ON-CHIP EMULATION/JTAG PORT
TDI
TCK
TDO
TMS
PARALLEL HOST PORT(HD108)
HAD(7:0)[PB0-PB7]
HAS/HA0[PB8]
HA8/HA1[PB9]
HA9/HA2[PB10]
HRW/HRD[PB11]
HDS/HWR[PB12]
HCS/HA10[PB13]
HOREQ/HTRQ[PB14]
HACK/HRRQ[PB15]
VCGH
GNDH
SERIAL AUDIO INTERFACE (ESAI)
SCKT[PC3]
FST[PC4]
HCKT[PC5]
SCKR[PC0]
FSR[PC1]
HCKR[PC2]
SDO0[PC11]/SDO0_1[PE11]
SDO1[PC10]/SDO1_1[PE10]
SDO2/SDI3]PC9]/SDO2_1/SDI3_1[PE9]
SDO3/SDI2[PC8]/SDO3_1/SDI2_1[PE8]
SDO4/SDI1[PC7]
SDO5/SDI0[PC6]
SERIAL AUDIO INTERFACE (ESAI_1)
SCKT_1[PE3]
FST_1[PE4]
SCKR_1[PE0]
FSR_1[PE1]
SDO4_1/SDI1_1[PE7]
SDO5_1/SDI0_1[PE6]
VCCS(2)
GNDS(2)
SERIAL HOST INTERFACE (SHI)
MOSI/HA0
SS/HA2
MISO/SDA
SCK/SCL
HREQ
Port B
Port C
Port E
Port D
3. Signal groupings

RX-8022PSL
1-14
44 - 34
12 - 22
11 - 1 23 - 33
1. Pin layout
AK4586VQ (IC571) : DIR & CODEC
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
I/O
O
I
I
-
-
-
O
O
I/O
I/O
O
I
I
I
O
O
O
I
I
I/O
I
I
I
I
O
O
-
-
I
O
O
O
O
O
O
O
O
I
I
-
-
-
I
I
I
I
I
I
I
I
Symbol
XTO
XTI
EXTCLK
TVDD
VDSS
DVDD
TX
MCKO
LRCK
BICK
SDTO
SDTI1
SDTI2
SDTI3
INT0
INT2
CDTO
CAD1
CDTI
SDA
CCLK
SCL
CSN
CAD0
DZF2
OVF
AVSS
AVDD
VREFH
VCOM
DZF1
LOUT3
ROUT3
LOUT2
ROUT2
LOUT1
ROUT1
LIN
RIN
PCDD
R
PVSS
RX4
SLAVE
RX3
TST
RX2
I2C
RX1
PDN
Function
X'tal output pin
X'tal input pin
External master clock input pin
Output buffer power supply pin, 2.7V~5.5V
Digital Ground pin, 0V
Digital power supply pin, 4.5V~5.5V
Transmit channel (through data) output pin
Master clock output pin
Input/Output channel clock pin
Audio serial data clock pin
Audio serial data output pin
DAC1 audio serial data input pin
DAC2 audio serial data input pin
DAC3 audio serial data input pin
Interrupt 0 pin
Interrupt 1 pin
Control data output pin in 4-wire serial control mode
Chip address 1 pin in I2C bus control mode
Control data input pin in 4-wire serial control mode
Control data input/output pin in I2C bus control mode
Control data clock pin in 4-wire serial control mode
Control data clock pin in I2C bus control mode
Chip select pin in 4-wire serial control mode
Chip address 0 pin in I2C bus control mode
Zero input detect 2 pin
Analog input overflow detect pin
Analog ground pin, 0V
Analog power supply pin, 4.5V~5.5V
Positive voltage reference input pin, AVDD
Common voltage output pin, AVDD/2
Zero input detect 1 pin
DAC3 Lch analog output pin
DAC3 Rch analog output pin
DAC2 Lch analog output
DAC2 Rch analog output pin
DAC1 Lch analog output pin
DAC1 Rch analog output pin
Lch analog input pin
Rch analog input pin
PLL power supply pin, 4.5V~5.5V
External resistor pin
Pll ground pin, 0V
Receiver channel 4 pin (internal biased pin)
Slave mode pin
Receiver channel 3 pin (internal biased pin)
Test pin
Receiver channel 2 pin (internal biased pin)
Control mode select pin
Receiver channel 1 pin internal biased pin)
Power-Down & Reset pin
2. Pin function

1-15
RX-8022PSL
3. Block diagram
DAC DATTLPF
DAC DATTLPF
DAC DATTLPF
DAC DATTLPF
DAC DATTLPF
DAC DATTLPF
ADC HPF
ADC HPF MCLK
SDOUT SDOUT
TX
MCKO
XTO
XTI
BICK
LRCK
SDIN1
SDIN2
SDIN3
LIN
RIN
LOUT1
ROUT1
LOUT2
ROUT2
LOUT3
ROUT3
BICK
LRCK
SDIN1
SDIN2
SDIN3
RX1
RX2
RX3
RX4
CSN CCLK CDTI CDTO
Audio
I/F
Clock
Recovery
DAIF
Decoder
DEM
Input
Selector
uP I/F X'tal
Oscillator
Clock
Generator
3. Block diagram
IS63LV102410K-X (IC512, IC513, IC514) : CMOS SRAM
DECODER
A0-A16
I/O0-I/O7
CE
OE
WE
VCC
GND
COLUMN I/O
CONTROL
CIRCUIT
128K X 8
MEMORY ARRAY
I/O
DATA
CIRCUIT
1. Pin layout 2. Pin function
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
A0
A1
A2
A3
CE
I/O0
I/O1
Vcc
GND
I/O2
I/O3
WE
A4
A5
A6
A7
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
A16
A15
A14
A13
OE
I/O7
I/O6
GND
Vcc
I/O5
I/O4
A12
A11
A10
A9
A8
Symbol
A0-A16
CE
OE
WE
I/O1-I/O7
Vcc
GND
Function
Address Input
Chip Enacble Input
Output Enable Input
Write Enable Input
Bidirectional Ports
Power
Ground

RX-8022PSL
1-16
MB90088 (IC203) : Display controller
28
27
26
25
24
23
22
21
20
19
18
17
16
15
1
2
3
4
5
6
7
8
9
10
11
12
13
14
AVss
YOUT
VOUT
COUT
CS
SIN
SCLK
TEST
BOUT
ROUT
GOUT
VOB
XD
EXD
YIN
VIN
CIN
AVcc
IOUT
VOC
Vcc
EXS
XS
HSYNC
VSYNC
EXHSYN
EXVSYN
Vss
Dot CLK
OSC
CGROM
Output
Control
Video Signal
OSC
Analog SW
4FSC CLK
OSC
VRAM
Display Memory
Control
NTSC/PAL
Signal OSC
H/V Separate
Serial Input
Control
SCLK
SIN
COUT
YOUT
VOUT
VOB
VOC
IOUT
GOUT
ROUT
BOUT
EXD
XD
EXS
XS
CIN
YIN
VIN
CS
VSYNC
HSYNC
EXVSYN
EXHSYN
Each Block
Each Control, Data
Each Block
1.Pin layout
2.Block diagram

1-17
RX-8022PSL
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
pin
no Symbol I/O Function
YIN
VIN
CIN
AVcc
IOUT
VOC
Vcc
EXS
XS
HSYNC
VSYNC
EXHSYN
EXVSYN
Vss
EXD
XD
VOB
GOUT
ROUT
BOUT
TEST
SCLK
SIN
CS
COUT
VOUT
YOUT
AVss
I
I
I
I
I
I
I
I
I
I
I
-
-
-
-
O
O
O
O
O
O
O
O
O
O
O
Lux signal Input terminal for Superinpause indication
Composite video signal input terminal for Superinpause indication
Contrast signal input terminal for Superinpause indication
Analog power supply terminal
Color (Lux) signal output terminal
Character output terminal
Power supply terminal
Clock generator outside circuit terminal for color burst
Horizontal signal output terminal
Vertical signal output terminal
EXT horizontal signal input terminal
EXT vertical signal input terminal
GND
Dot clock generator outside circuit signal terminal for indication
Character & background signal output terminal
Color signal (Green, Red, Blue)
Test signal input terminal
Shift clock input terminal for serial transmission
Serial data input terminal
Chip select terminal
Contrast signal output terminal
Composite video signal output terminal
Lux signal output terminal
Analog GND terminal
3.Functions
1 2 3 4 5 6 7 8
16 15 14 13 12 11 10 9
IN1A GND1 IN2B V CTL2 IN2A GND3 IN3B
LBIAS TYPE CLAMP TYPE
CLAMP TYPE
H
L
H
L
H
IN1B CTL1 OUT1 GND2 OUT2 OUT3 CTL3 IN3A
NJM2285V-W (IC202) : 2-input 3-channel video switch
+

RX-8022PSL
1-18
2. Pin Function
Pin
No. Symbol I/O Function Function
I/O
Symbol
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
FM IN
AM MIX
FM IF
AM IF
GND
TUNED
STEREO
VCC
FM DET
AM SD
FM VSM
AM VSM
MUTE
FM/AM
MONO/ST O
I
I/O
O
O
I
O
I
I
I
O
O
III
II
This is an input terminal of FM IF
signal.
This is an out put terminal for AM
mixer.
Bypass of FM IF
Input of AM IF Signal.
This is the device ground terminal.
When the set is tuning, this terminal
becomes "L".
Stereo indicator output. Stereo "L",
Mono: "H"
This is the power supply terminal.
FM detect transformer.
This is a terminal of AM ceramic filter.
Adjust FM SD sensitivity.
Adjust AM SD sensitivity.
When the signal of IF REQ of IC121(
LC72131) appear, the signal of FM/AM
IF output. //Muting control input.
Change over the FM/AM input.
"H" :FM, "L" : AM
Stereo : "H", Mono: "L"
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30 OSC BUFFER
AM OSC
REG
AM RF
AFC
AM AGC
O
I
O
I
I
I
AM Local oscillation Signal output.
This is a terminal of AM Local
oscillation circuit.
Register value between pin 26 and pin28
desides the frequency width of the
input signal.
AM RF signal input.
This is an output terminal of voltage
for FM-AFC.
This is an AGC voltage input terminal
for AM
O
O
I
O
AM detection output.
FM detection output.
Mpx input terminal
O
O
I
Left channel signal output.
Right channel signal output.
Input terminal of the left channel post
AMP.
Input terminal of the right channel
post AMP.
I
O
Mpx Left channel signal output.
Mpx Right channel signal output.
L OUT
R OUT
L IN
R IN
RO
LO
IF IN
FM OUT
AM DET
1. Block Diagram
ALC
BUFF
AM
OSC
REG
AM
MIX FM
RF.AMP
AGC
AM IF DET
SD
COMP AM
S-METER
FM
S-METER
FM IF PM
DET
S-CLRVE AM/FM
IF-BUFF TUNING
DRIVE
GND VCC
STEREO
DRIVE
MUTE
DECODER
ANIT-BIRDIE
STEREO
5N
SW
P-DET
PILOT
DET
FF
19k
FF
19k
FF
38k
VCO
384KHz /
2/
LS
30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
1234678910 11 12 13 14 15
5
LA1838(IC102) : FM AM IF AMP&detector, FM MPX decoder

1-19
RX-8022PSL
1. Pin layout
1
2
3
4
5
6
7
8
9
10
11
22
21
20
19
18
17
16
15
14
13
12
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
SDIN
XT
GND
LPFOUT
LPFIN
PD
VCC
FMIN
AMIN
IFCONT
IFIN
Pin
No.
1
2
3
4
5
6
7
8
9
10
11
Pin
No.
12
13
14
15
16
17
18
19
20
21
22
Symbol
XT
FM/AM
CE
DI
CLOCK
DO
FM/ST/VCO
AM/FM
LW
MW
SDIN
Symbol
IFIN
IFCONT
AMIN
FMIN
VCC
PD
LPFIN
LPFOUT
GND
XT
Function
X'tal oscillator connect (75kHz)
LOW:FM mode
When data output/input for 4pin(input) and
6pin(output): H
Input for receive the serial data from
controller
Sync signal input use
Data output for Controller
Output port
"Low": MW mode
Open state after the power on reset
Input/output port
Input/output port
Data input/output
Function
IF counter signal input
IF signal output
Not use
AM Local OSC signal output
FM Local OSC signal input
Power suplly(VDD=4.5-5.5V)
When power ON:Reset circuit move
PLL charge pump output(H: Local OSC
frequency Height than Reference frequency.
L: Low Agreement: Height impedance)
Input for active lowpassfilter of PLL
Output for active lowpassfilter of PLL
Connected to GND
X'tal oscillator(75KHz)
I/O
I
O
I
I
I
O
O
O
I/O
I/O
I/O
I/O
I
O
-
I
I
-
O
I
O
-
I
Reference
Driver Phase
Detector
Charge Pump
Unlock
Detector
Universal
Counter
Swallow Counter
1/16,1/17 4bit
12bit
Programmable
DriverS
Swallow Counter
1/16,1/17 4bit
Data Shift Register & Latch
Power
on
Reset
C2B
I/F
1/2
782 11 13
21
17
6
5
4
3
15
16
22
118
19
20
12
2. Block diagram
3. Pin function
LC72136N (IC121) : PLL frequency synthesizer

RX-8022PSL
1-20
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Symbol
XTI
V
DD C
DGNDC
V
DD
DGND
D+
D-
V
BUS
DGNDU
PLYBCK
SSPND
ZERO
TEST3
TEST2
TEST1
TEST0
VccR
AGNDR
V
OUT R
AGND
V
COM
Vcc
V
OUT L
AGNDL
VccL
AGNDP
VccP
XTO
I/O
IN
-
-
-
-
I/O
I/O
IN
-
OUT
OUT
OUT
IN
IN
IN
IN
-
-
OUT
-
-
-
OUT
-
-
-
-
OUT
Function
Crystal Oscillator Input.
Digital Power Supply for Clock Generator, +3.3V.
Digital Ground for Clock Generator.
Digital Power Supply, +3.3V.
Digital Ground.
USB Differential Input/Output Plus.
USB Differential Input/Output Minus.
USB Bus Power (This pin NEVER consumes the USB bus power).
Digital Ground for USB Transceiver.
Playback flag, active LOW. (LOW: playback, HIGH: idle).
Suspend flag, active LOW. (LOW: suspend, HIGH: operational).
Zero flag, (LOW: Normal, HIGH: ZERO).
Test pin 3. Connect to digital ground.
Test pin 2. Connect to digital ground.
Test pin 1. Connect to digital ground.
Test pin 0. Connect to digital ground.
Analog Supply for R-channel, +5V.
Analog Ground for R-channel.
Analog Output for R-channel.
Analog Ground.
Common for DAC.
Analog Supply, +5V.
Analog output for L-channel.
Analog Ground for L-channel.
Analog Supply for L-channel, +5V.
Analog Ground for PLL.
Analog Supply for PLL, +5V.
Crystal Oscillator Output.
Note:
(1) 3.3V tolerant.
(2) Schmitt trigger input with internal pull-down, 5V tolerant.
3.Pin function
1.Pin layout
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
XTI
V
DDC
DGNDC
VDD
DGND
D+
D-
VBUS
DGND
PLYBCK
SSPND
ZERO
TEST3
TEST2
XTO
VccP
AGNDP
VccL
AGNDL
VOUTL
Vcc
VCOM
AGND
VOUTR
AGNDR
VccR
TEST0
TEST1
(1)
(2)
(2)
(2)
(2)
(2)
PCM2702ED-X (IC410) : USB D/A converter
USB I/F 8x
Oversampling
Digital Filter Multi-level
Delta-Sigma
Modulator
USB clock
generator
Crystal OSC Power supply
DAC
DAC
Low-pass
Filter
Low-pass
Filter
D+
D-
VBUS
DGNDU
VDDC
DGNDC
XTI XTO VCC AGND VDD DGND
VOUTL
VOUTR
ZERO
FIFO
SPACT Audio clock
generator
VCOM
System Clock
audio
data
USB packet
data
WRCLK
MCLK
RDCLK
VDDP DGNDP
PLYBCK
SSPDN
VccL AGNDL VccR AGNDR
2. Block diagram
