JVC Everio GZ-R315BE Operating and maintenance manual

Basic User Guide
CAMCORDER
GZ-R315BE
GZ-R315DE
GZ-R315RE
GZ-R315WE
GZ-R310SE
Dear Customers
Thank you for purchasing this JVC product.
Before use, please read the Safety Precautions and Cautions on p. 2 and p. 15 to
ensure safe use of this product.
B5A-1186-01
EN
.
Detailed User Guide
For more details on operating this
product, please refer to the “Detailed
User Guide” at the following website.
o
http://manual3.jvckenwood.com/index.html/
.Mobile User Guide
When you are outside, refer to
the “Mobile User Guide”.
Mobile User Guide can be
viewed with standard browser
for Android tablet and iPhone.
o
http://manual3.jvckenwood.com/mobile/eu/

Safety Precautions
IMPORTANT (for owners in the U.K.)
Connection to the mains supply in the
United Kingdom.
DO NOT cut off the mains plug from
this equipment.
If the plug fitted is not suitable for the
power points in your home or the cable is
too short to reach a power point, then
obtain an appropriate safety approved
extension lead or consult your dealer.
BE SURE to replace the fuse only with an
identical approved type, as originally
fitted, and to replace the fuse cover.
If nonetheless the mains plug is cut off be
sure to remove the fuse and dispose of the
plug immediately, to avoid possible shock
hazard by inadvertent connection to the
mains supply.
If this product is not supplied fitted with a
mains plug then follow the instructions
given below:
DO NOT make any connection to the
Larger Terminal coded E or Green.
The wires in the mains lead are coloured
in accordance with the following code:
.
Blue to N
(Neutral) or Blac
k
Brown to L (Live)
or Red
If these colours do not correspond with the
terminal identifications of your plug,
connect as follows:
Blue wire to terminal coded N (Neutral) or
coloured black.
Brown wire to terminal coded L (Live) or
coloured Red.
If in doubt — consult a competent
electrician.
CAUTIONS:
0
To prevent shock, do not open the
cabinet. No user serviceable parts
inside. Refer servicing to qualified
personnel.
0
When you are not using the AC adapter
for a long period of time, it is
recommended that you disconnect the
power cord from AC outlet.
CAUTION:
A built-in lithium-ion battery is inside the
unit. When discarding the unit,
environmental problems must be
considered and the local rules or laws
governing the disposal of these batteries
must be followed strictly.
NOTES:
0
The rating plate and safety caution are on
the bottom and/or the back of the main unit.
0
The serial number plate is on the bottom
of the main unit.
0
The rating information and safety caution
of the AC adapter are on its upper and/
or lower sides.
WARNING:
The camcorder with battery installed
should not be exposed to excessive heat
such as direct sunlight, fire or the Iike.
CAUTION:
The mains plug shall remain readily
operable.
0
Remove the mains plug immediately if
the camcorder functions abnormally.
CAUTIONS:
0
Be sure to use the supplied AC adapter.
0
Do not use the supplied AC adapter with
other devices.
CAUTION:
To avoid electric shock or damage to the
unit, first firmly insert the small end of the
power cord into the AC Adapter until it is
no longer wobbly, and then plug the larger
end of the power cord into an AC outlet.
.
2EN

Do not point the lens directly into the sun.
This can cause eye injuries, as well as
lead to the malfunctioning of internal
circuitry. There is also a risk of fire or
electric shock.
CAUTION!
The following notes concern possible
physical damage to this unit and to the
user.
Carrying or holding this unit by the LCD
monitor can result in dropping the unit, or
in a malfunction.
Do not use a tripod on unsteady or unlevel
surfaces. It could tip over, causing serious
damage to the unit.
CAUTION!
Connecting cables (Audio/Video, etc.) to
this unit and leaving it on top of the TV is
not recommended, as tripping on the
cables will cause this unit to fall, resulting
in damage.
.
Information on Disposal of Old
Electrical and Electronic Equipment
and Batteries (applicable for
countries that have adopted separate
waste collection systems)
Products and batteries with the symbol
(crossed-out wheeled bin) cannot be
disposed as household waste.
Old electrical and electronic equipment
and batteries should be recycled at a
facility capable of handling these items
and their waste byproducts.
Contact your local authority for details in
locating a recycle facility nearest to you.
Proper recycling and waste disposal will
help conserve resources whilst
preventing detrimental effects on our
health and the environment.
Notice: The sign “Pb” below the symbol
for batteries indicates that this battery
contains lead.
SOME DO’S AND DON’TS ON THE SAFE
USE OF EQUIPMENT
This equipment has been designed and
manufactured to meet international safety
standards but, like any electrical equipment,
care must be taken if you are to obtain the
best results and safety is to be assured.
DO read the operating instructions before
you attempt to use the equipment.
DO ensure that all electrical connections
(including the mains plug, extension leads and
interconnections between pieces of
equipment) are properly made and in
accordance with the manufacturer’s
instructions. Switch off and withdraw the mains
plug when making or changing connections.
DO consult your dealer if you are ever in
doubt about the installation, operation or
safety of your equipment.
DO be careful with glass panels or doors on
equipment.
DON’T continue to operate the equipment if
you are in any doubt about it working
normally, or if it is damaged in any way —
switch off, withdraw the mains plug and
consult your dealer.
DON’T remove any fixed cover as this may
expose dangerous voltages.
DON’T leave equipment switched on when
it is unattended unless it is specifically stated
that it is designed for unattended operation
or has a standby mode. Switch off using the
switch on the equipment and make sure that
your family knows how to do this.
Special arrangements may need to be made
for infirm or handicapped people.
DON’T use equipment such as personal
stereos or radios so that you are distracted
from the requirements of road safety. It is
illegal to watch television whilst driving.
DON’T listen to headphones at high volume,
as such use can permanently damage your
hearing.
DON’T obstruct the ventilation of the
equipment, for example with curtains or soft
furnishings. Overheating will cause damage
and shorten the life of the equipment.
EN 3

DON’T use makeshift stands and NEVER fix
legs with wood screws — to ensure complete
safety always fit the manufacturer’s
approved stand or legs with the fixings
provided according to the instructions.
ABOVE ALL
0
NEVER let anyone especially children
push anything into holes, slots or any other
opening in the case — this could result in
a fatal electrical shock;
0
NEVER guess or take chances with
electrical equipment of any kind — it is
better to be safe than sorry!
This product is licensed under the AVC
Patent Portfolio License for the personal
use of a consumer or other uses in which
it does not receive remuneration to (i)
encode video in compliance with the AVC
standard (“AVC Video”) and/or (ii) decode
AVC Video that was encoded by a
consumer engaged in a personal activity
and/or was obtained from a video provider
licensed to provide AVC Video. No
license is granted or shall be implied for
any other use.
Additional information may be obtained
from MPEG LA, L.L.C.
See http://www.mpegla.com
Make a backup of important recorded
data
JVC will not be responsible for any lost
data. It is recommended to copy your
important recorded data to a disc or other
recording media for storage once every 3
months.
M/D on the unit denotes the month and
year of production.
.
This unit is equipped with Water
proof, Dust proof, Drop proof and
Freeze proof.
Water proof: Equivalent to IEC
Standard publication 529 IPX8
and IPX6 (30 minutes at depths
up to 5 m (16.4 ft))
Dust proof: Equivalent to IEC
Standard publication 529 IP5X
Drop proof: This camera clears
company testing compliant with
"MIL-STD-810F Method; 516.5
Shock: dropping onto plywood 3
cm thick from a height of 1.5 m"
Freeze proof: Allowable
operating temperatures: −10 °C
to +40 °C
Note: Temperatures between
−10 °C and 0 °C temporarily
lower battery performance,
reducing the time available for
recording.
Precautions for waterproof function
0
Malfunction due to misuse by the
customer is not covered by warranty.
0
Before use in water, be sure to read and
understand the “Detailed User Guide”.
0
Close the terminal cover firmly until it
clicks and confirm that the red sign
completely goes off.
0
Make sure that there is no damage to and
no foreign material adhered to the
packing inside the cover.
0
Use the camcorder in marine water and
fresh water not deeper than 5 m or for not
more than 30 minutes.
0
The waterproof cannot be guaranteed if
the camcorder is subject to impact such
as dropping.
0
Do not jump or dive into water holding the
camcorder.
0
Do not use the camcorder in strong water
flows such as in rapids or under
waterfalls. The strong water pressure
may impair the waterproof performance.
0
Do not soak the camcorder in hot springs
or water of 40 °C or higher.
4EN

Fogging inside the Lens
Models with waterproof function are airtight.
When the temperature rises during
recording, condensation can occur inside
the lens due to the internal humidity.
During recording
To prevent the temperature of this unit from
rising, we recommend that you use the unit
in the following ways.
A
Avoid frequent exposure to direct
sunlight.
Record under the shade or use an
umbrella. Best if you could keep a wet
towel cover the unit.
B
The use of a tripod is recommended.
Long hours of recording while holding the
unit in your hands will cause the
temperature of the unit to rise.
C
It is better to leave the terminal cover open
while recording.
However, the waterproof, dust-proof and
shockproof features do not function in this
condition. Do take note of the environment
when using the camera. (Do not use a wet
towel.)
D
Make sure to turn off the power when you
are not recording.
The power turns off when the LCD monitor
is closed.
During charging
It is recommended to charge the unit in a low
humidity environment.
The moist air inside the unit can cause
condensation.
We recommend that you charge the unit in a
room where humidifier is not in use, and in
an air-conditioned room during summer.
When fogging occurs inside the lens
Open the terminal cover to reduce the
temperature, close the LCD monitor and
leave the camera as it is for a while.
.
Open the terminal cover.
Protecting the Lens
This unit does not come with a lens cover and
lens cap.
However, there is a protective glass in front
of the lens to protect the lens.
0
It is recommended to put the camera in a
cloth bag when carrying it around.
0
If the protective glass is dirty, wipe clean
using a commercially available cleaning
cloth.
.
Lens protective glass
EN 5

Contents
Safety Precautions ................................. 2
Verifying the Accessories ...................... 6
Names of Parts and Functions ............... 7
Date and Time Setting ........................... 8
Open the terminal cover (SD card cover) ...... 9
Getting Started
Charging the Battery ............................ 10
Inserting an SD Card ........................... 11
Recording
Video Recording .................................. 12
Video Quality ....................................... 13
Playback
Playing Back/Deleting Files on this Unit ..... 14
Further Information
Troubleshooting/Cautions .................... 15
Recordable Time/Specifications .......... 20
Verifying the Accessories
AC Adapter
UIA312-0520 Power Cord Adapter Cable QAM1580-001
USB Cable
(Type A - Micro Type B)
.
...
AV Cable
E3A-0085-00 Core Filter (for AV Cable) Basic User Guide (this manual)
.
..
0Please consult your JVC dealer or the nearest JVC service center when purchasing
a new AV cable.
6EN

Names of Parts and Functions
.
0
1
345
9
8
2
a
b
7
6
AStereo Microphone
BLCD Monitor
CCHARGE (Charging) Lamp (p. 10)
DPOWER/ACCESS (Power/Access)
Lamp
EZoom/Volume Lever (p. 12, 14)
FSTART/STOP (Video Recording)
Button (p. 12)
GTerminal Cover (SD Card Cover)
HSD Card Slot (p. 11)
IReset Button
JHDMI Mini Connector
KAV Connector
LUSB Connector
EN 7

Date and Time Setting
1Open the LCD monitor.
.
0The unit turns on. When the LCD
monitor is closed, the unit turns off.
2Tap [OK] when [SET DATE/
TIME!] is displayed.
.
SET DATE/TIME!
OK
3Set the date and time.
.
201512 10 00
24 TIME
DATE
SAVE
DATE & TIME
0When the day, month, year, hour, or
minute item is tapped, 3 and 2 will
be displayed.
Tap 3 or 2 to adjust the value.
0Repeat this step to input the day,
month, year, hour, and minute.
4After setting the date and
time, tap [SAVE].
5Select the region where you
live and tap [SAVE].
0Time difference between the
selected city and the GMT
(Greenwich Mean Time) is
displayed.
0Tap 0 or 1 to select the city name.
.
GMT
SAVE
DATE & TIME/AREA
8EN

Open the terminal cover (SD card cover)
AOpen the LCD monitor.
BSlide down the terminal cover
lock and slide the cover aside
CLift the cover slowly.
oTo close
.
Not properly closed if the red mark is visible!
Leave the LCD monitor open first.
AFlip down the cover slowly while making sure the gray waterproof seal fits into
the opening at the terminals.
BPress the entire cover against the camcorder with equal force and firmly attach
the cover completely.
CSlide the cover until it clicks into place.
(The cover is not properly closed if the red mark at the terminal cover lock is
visible.)
CAUTION
0Do not apply excessive force when opening or closing the terminal cover.
0Do not open or close the terminal cover with wet or dirt/sand-covered hands.
0Do not allow any dirt, lint, hair, sand, and other foreign substances to
accumulate between the waterproof seal and the case.
0Never damage or scratch the waterproof seal and terminal cover. Doing so
can result in leaks. If the seal is damaged, contact your nearest JVC Service
Center for a replacement. (Charges apply.)
0Read the “Detailed User Guide” carefully before using the camcorder under
water or in places exposed to water droplet.
(Rear)
EN 9

Charging the Battery
A battery is built into the camcorder.
.
To AC Outlet
(110 V to 240 V)
AC Adapter
(Provided)
Adapter Cable
(Provided)
Charging Lamp
AB
C
D
1Open the terminal cover (p. 9)
2Connect adapter cable to AC adapter.
3Plug in the AC adapter to AC outlet (110 V to 240 V).
4Connect the other side to USB socket on the unit.
CAUTION
0At the time of purchase or in case of the battery is not used for a long period
of time, the charging time will be longer than usual. The camera does not turn
on if the remaining battery power is low. In this case, charge the battery for
more than 40 minutes before turning on the power.
0Charging time: Approx. 6 h 10 m (when charging at 25°C)
0The battery cannot be charged outside the room temperature range of 10°C
to 35°C. The CHARGE lamp does not light up when the battery is not being
charged. If the temperature increases or decreases during charging, the
CHARGE lamp will blink slowly and charging will stop. In this case, remove
the AC adapter, press the Reset button and wait until the room temperature
is within the above stated range before charging again.
0You can record or play back videos during charging. (However, the charging
time will be longer than usual. In addition, the remaining battery power may
decrease according to conditions.) If the internal temperature rises when
using the unit, stop the charging temporarily. (The CHARGE lamp goes off.)
0If malfunctions (such as overvoltage) occur, charging will stop. In this case,
the CHARGE lamp blinks quickly as a notification.
0When the recording time becomes extremely short even when the battery is
fully charged, the battery needs to be replaced. For details on replacing the
built-in battery (subject to a fee), consult the nearest JVC service center.
0
For details on other charging methods, please refer to the “Detailed User Guide”.
10 EN

Inserting an SD Card
Insert a commercially available SD card before recording.
.
*
Insert an SD card.
Before inserting the SD card,
close the LCD monitor to turn off
this unit.
(Rear) Label
Open the terminal cover.
oTo remove the SD card
Push the SD card inward once, then pull it out straight.
NOTE
Operations are confirmed on the following SD cards.
Manufacturer Panasonic, TOSHIBA, SanDisk
Video A
Class 4 or higher compatible SD card (2 GB)/
Class 4 or higher compatible SDHC card (4 GB to 32 GB)/
Class 4 or higher compatible SDXC card (64 GB to 128 GB)
0When recording with video quality [UXP], Class 6 or
higher is recommended.
Still Image BSD card (256 MB to 2 GB) / SDHC card (4 GB to 32 GB) /
SDXC card (64 GB to 128 GB)
0Using SD cards (including SDHC/SDXC cards) other than those specified
above may result in recording failure or data loss.
0This unit is not guaranteed to operate with all SD cards, even when using the
ones specified above. Some SD cards may not work due to specification
changes, etc.
0To protect the data, do not touch the terminals of the SD card.
0When using an SDXC card, check its compatibility with the OS of your
computer by referring to the Detailed User Guide.
0Do not use a miniSD card or microSD card (even if the card is inserted in an
adapter). It may cause malfunction to the camcorder.
EN 11

Video Recording
You can record without worrying about the setting details by using the P (Intelligent
Auto) mode. Settings such as exposure and focus will be adjusted automatically to
suit the shooting conditions.
Before recording an important scene, it is recommended to conduct a trial recording.
.
H
P
A
C
A
TW
Check if the recording
mode is Avideo.
If the mode is Bstill image,
tap Bon the touch screen,
then tap Ato switch.
Start recording.
Press again to stop.
Zooming
(Wide angle)
(Telephoto) Zoom Lever
If the mode is HManual, tap Hon
the touch screen, then tap Pto
switch.
Check if the recording mode
is P.
0
You can also tap 6 on the touch screen to record. To stop recording, tap
7 . In addition, you can also tap D to zoom.
oAttaching the Core Filter
Attach the core filter to the AV Cable as shown in the illustration. The core filter
reduces interference when this unit is connected to other devices.
.
3 cm
To be connected to this unit
Release the
stopper.
Wind once
12 EN

oIndications during video recording
.
MENU
≪PLAY
0:00:00 [0:54]
REC
Recording in Progress
Recording-Standby
Battery Indicator
Recording Media
Image Stabilizer
Video Quality
Remaining Recording
Time
Scene Counter
Still Image
Recording Button
NOTE
0The estimated recording time of the supplied battery is approximately 2 hour
50 minutes of actual recording and up to 5 hours 10 minutes of continuous
recording.
0Do not remove SD card when the POWER/ACCESS lamp is lighted. The
recorded data may become unreadable.
0With [AUTO POWER OFF] operation, the camera automatically turns off if no
operation is performed for 5 minute, in order to conserve power. (The unit
enters into standby mode when the AC adapter is used.)
0The angle of view may change when the image stabilizer is turned on or off.
0When recording underwater, the internal mechanical noise (such as zooming
sound) may be easily picked up and recorded. This is not a malfunction.
Video Quality
This unit can perform recording in high definition (1920x1080).
Default setting of [VIDEO QUALITY] is XP.
oTo change the setting
ATap [MENU].
BTap [RECORD SETTING].
CTap [VIDEO QUALITY].
DTap the desired video quality.
AVCHD
(1920x1080)
UXP Higher video quality
XP
(Default) .
EP
More recording time
* For the approximate video recording time, refer to p. 20.
EN 13

Playing Back/Deleting Files on this Unit
Select and play back the recorded videos or still images from an index screen (thumbnail
display).
.
T
W
VOL.
＋
Tap on the files to delete.
Tap R.
To delete unwanted files
Turn up the
volume
Turn down
the volume
Volume adjustment
during playback
Tap uto return to the video
index screen.
Tap on the file to play back.
Tap “SET”.
Tap Eto return to the
recording mode.
Tap Fon the touch screen
to select the playback mode.
Tap eto pause playback.
Tap “OK”.
Tap “EXECUTE” when the
confirmation message appears.
Tap Aor Bto select the video
or still image mode.
A Imark appears on the selected file.
To remove the Imark, tap again.
DELETE
SEL ALL REL ALL SET QUIT
oTo capture a still image during playback
APause the playback with e.
BPress the START/STOP button or tap the A on the LCD.
NOTE
0While this unit may be used with the LCD monitor reversed and closed, the
temperature rises more easily. Leave the LCD monitor open when using this
unit.
0The power may turn off to protect the circuit if the temperature of this unit rises
too much.
14 EN

Troubleshooting/Cautions
Troubleshooting
If you encounter problems with this unit,
check the following before requesting
service.
1. Refer to the “Troubleshooting”
section in the “Detailed User Guide”.
If you have difficulties operating the
unit, refer to the detailed
descriptions in the “Detailed User
Guide”.
http://manual3.jvckenwood.com/
index.html/
2. This unit is a microcomputer-
controlled device. Electrostatic
discharge, external noise and
interference (from a TV, a radio, etc.)
might prevent it from functioning
properly.
In such a case, reset the unit.
ARemove all the cables from this
unit.
BPress the "Reset button" located
inside of the terminal cover.
(Before pressing the reset button,
close the LCD monitor to turn off
this unit.)
CReattach the AC adapter, open
the LCD monitor and this unit
powers on automatically.
3. If the above do not solve the problem,
consult your nearest JVC dealer or
JVC service center.
Built-in Battery
This unit is equipped with a built-in lithium-
ion battery. Before using this Unit, be sure
to read the following cautions:
0
To avoid hazards
…
do not burn.
…
do not modify or disassemble.
…
do not expose this Unit to temperatures
exceeding 60 °C, as this may cause the
built-in battery to overheat, explode or
catch fire.
0
To prevent damage and prolong
service life
…
do not subject to unnecessary shock.
…
charge within the temperature range of
10°C to 35°C. Cooler temperatures
require longer charging time, or in some
cases stop charging at all.
Warmer temperatures prevent complete
charging, or in some cases stop
charging at all.
…
store in a cool, dry place. Extended
exposure to high temperatures will
increase natural discharge and shorten
service life.
…
keep a 30% battery level ( i ) if the
battery is not to be used for a long period
of time.
In addition, fully charge and then fully
discharge the battery every 6 months,
then continue to store it at a 30% battery
level (
i ).
…
remove the AC adapter from the unit
when not in use, as some machines use
current even when switched off.
…
do not drop intentionally or subject to
strong impact.
Recording Medium
0
Be sure to follow the guidelines
below to prevent corruption or
damage to your recorded data.
0
Do not bend or drop the recording
medium, or subject it to strong
pressure, jolts or vibrations.
0
Do not splash the recording medium
with water.
0
Do not use, replace, or store the
recording medium in locations that are
exposed to strong static electricity or
electrical noise.
0
Do not turn off the camcorder power
during shooting, playback, or when
otherwise accessing the recording
medium.
0
Do not bring the recording medium
near objects that have a strong
EN 15

magnetic field or that emit strong
electromagnetic waves.
0
Do not store the recording medium in
locations with high temperature or
high humidity.
0
Do not touch the metal parts.
0
When erasing data using the
camcorder, the data won’t be erased
completely. When handing over your
camcorder and/or SD card, you are
recommended to erase all of the data by
either performing “FORMAT” or
“FACTORY PRESET” operation on this
unit, using commercially available
software, or by physically destroying the
camcorder.
LCD Monitor
0
To prevent damage to the LCD
monitor, DO NOT
…
push it strongly or apply any shocks.
…
place the camcorder with LCD monitor
on the bottom.
0
To prolong service life
…
avoid rubbing it with coarse cloth.
While the LCD monitor screen has more
than 99.99% effective pixels, 0.01% of
the pixels may be bright spots (red,
blue, green) or dark spots. This is not a
malfunction. The spots will not be
recorded.
Main Unit
0
For safety, DO NOT
…
open the camcorder’s chassis.
…
disassemble or modify the unit.
…
allow inflammables, water or metallic
objects to enter the unit.
…
disconnect the power supply while the
power is on.
…
place naked flame sources, such as
lighted candles, on the apparatus.
…
leave dust or metal objects adhered to
the power plug or an AC wall outlet.
…
insert any objects in the camcorder.
0
Avoid using the unit
…
in places subject to soot or steam such
as near a cooking stove.
…
in places subject to excessive shock or
vibration.
…
near a television set.
…
near appliances generating strong
magnetic or electric fields (speakers,
broadcasting antennas, etc.).
…
in places subject to extremely high (over
40 °C) or extremely low (under -10 °C)
temperatures.
0
DO NOT leave the unit
…
in places of over 50°C
…
in places where humidity is extremely
low (below 35 %) or extremely high
(above 80 %) with the terminal cover
open.
…
in direct sunlight.
…
in a closed car in summer.
…
near a heater.
…
in high places such as on a TV. Leaving
the unit in high places while a cable is
connected may result in a malfunction if
the cable is caught and the unit falls onto
the floor.
16 EN

0
To protect the unit, DO NOT
…
drop the unit or strike it against hard
objects.
…
subject it to shock or excessive vibration
during transportation.
…
keep the lens directed at extremely
bright objects for long periods.
…
expose the lens to direct sunlight.
…
swing it excessively when using the
hand strap.
…
swing the soft camcorder case
excessively when the camcorder is
inside it.
…
cover camcorder with a towel, cloth and
so on.
0
To prevent the unit from dropping
0
Fasten the grip belt securely.
0
When using the camcorder with a
tripod, attach the camcorder to the
tripod securely.
If the camcorder drops, you may be injured
and the camcorder may be damaged.
When a child uses the unit, there must be
parental guidance.
Dear Customer, [European Union]
This apparatus is in conformance with
the valid European directives and
standards regarding electromagnetic
compatibility and electrical safety.
European representative of
JVC KENWOOD Corporation is:
JVC Technical Services Europe GmbH
Konrad-Adenauer-Allee 1-11
61118 Bad Vilbel
GERMANY
Remember that this unit is
intended for private consumer
use only.
Any commercial use without proper
permission is prohibited. (Even if you
record an event such as a show,
performance or exhibition for
personal enjoyment, it is strongly
recommended that you obtain
permission beforehand.)
Trademarks
0AVCHD and AVCHD logo are
trademarks of Panasonic
Corporation and Sony Corporation.
0HDMI (High-Definition Multimedia
Interface) and HDMI logo are either
registered trademarks or
trademarks of HDMI Licensing, LLC
in the United States and/or other
countries.
.
0Manufactured under license from
Dolby Laboratories. Dolby and the
double-D symbol are trademarks of
Dolby Laboratories.
0SDXC logo is a trademark of SD-3C,
LLC.
0Windows® and Windows Vista®
are either registered trademarks or
trademarks of Microsoft Corporation
in the United States and/or other
countries.
0Apple, Mac, Mac OS, OS X, iMovie,
iPhoto, iPhone and Safari are
trademarks of Apple Inc., registered
in the U.S. and other countries.
0Intel and Intel Core are trademarks
or registered trademarks of Intel
Corporation or its subsidiaries in the
United States and other countries.
0Google™, Android™, YouTube™,
YouTube logo and Chrome™ are
trademarks and/or registered
trademarks of Google Inc.
0Other product and company names
included in this instruction manual
are trademarks and/or registered
trademarks of their respective
holders.
0Marks such as ™ and ® have been
omitted in this manual.
EN 17

MEMO
18 EN

MEMO
EN 19

Recordable Time/Specifications
Approximate Video Recording Time
Quality SDHC/SDXC Card
4 GB 8 GB 16 GB 32 GB 64 GB 128 GB
UXP 20 m 40 m 1 h 20 m 2 h 40 m 5 h 40 m 11 h 30 m
XP 30 m 1 h 1 h 50 m 3 h 50 m 8 h 10 m 16 h 20 m
EP 1 h 40 m 3 h 30 m 7 h 14 h 28 h 50 m 57 h 50 m
0The recordable time is only a guide. The actual recording time may be longer or
shorter than the time indicated above.
Camera
Power supply Using AC adapter: DC 5.2 V
Power
consumption 2.2 W (when [MONITOR BRIGHTNESS] is set to [3] (standard))
Rated Current Consumption: 2A
Dimensions 60 mm x 59.5 mm x 122 mm
(W x H x D: excluding grip belt)
Weight Approx. 288 g
The specifications and appearance of this product are subject to changes for
further improvement without prior notice.
For more information, please refer to the Detailed User Guide.
http://manual3.jvckenwood.com/index.html/
JVC KENWOOD Corporation
3-12, Moriyacho, Kanagawa-ku, Yokohama-shi, Kanagawa, 221-0022, Japan
©2015 JVC KENWOOD Corporation EU 1115TOH-SW-MT
20 EN
