JVL Echo Installation instructions

To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
Table of contents
2
TABLE OF CONTENTS
Safety Information............................................................................................................................................................3
1. General Description....................................................................................................................................................4
2. Flash Memory Card Replacement..........................................................................................................................6
3. Game Box Replacement.............................................................................................................................................7
4. Game Box Fans Replacement...................................................................................................................................8
5. Coin Mechanism Replacement.................................................................................................................................9
6. Coin Sensor Replacement.......................................................................................................................................10
7. Monitor Unit Replacement.....................................................................................................................................11
8. Bill Acceptor Replacement.....................................................................................................................................12
9. I/O Board Replacement...........................................................................................................................................14
10. Counter Replacement............................................................................................................................................15
11. Power Pad Assembly Replacement..................................................................................................................16
12. Upper Glass Replacement....................................................................................................................................17
13. Upper Glass Lights PCB Replacement.............................................................................................................18
14. Amplier PCB Replacement................................................................................................................................19
15. Power Supply Replacement................................................................................................................................20
16. Main Fan Replacement..........................................................................................................................................21
17. Service Lights PCB Replacement.......................................................................................................................22
18. Wi-Fi Adapter Replacement................................................................................................................................23
19. Modem Replacement............................................................................................................................................24
Appendix A.......................................................................................................................................................................26
Appendix B.......................................................................................................................................................................60
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
Safety information
3
SAFETY INFORMATION
1. Read Instructions: Read instructions before proceeding with the installation and operation of
the product.
2. Heed Warnings: Follow all warnings on the product and in the operating instructions.
3. Overloading: Do not overload wall outlets or extension cords. This can result in re or electric
shock.
4. Object and Liquid Entry: Never push foreign objects into this product through openings as
they may touch dangerous voltage points that could result in a re or electric shock.
5. Servicing: It is dangerous to service this product yourself. Refer to qualied service personnel.
6. Replacement Parts: When replacement parts are required, use only replacement parts speci-
ed by the manufacturer.
7. Safety Check: Upon completion of any service or repairs to this product, ask the service techni-
cian to perform safety checks to determine that the product is in proper operating condition.
Additional Safety Information for the User
Verify Line Voltage Before Use: Your JVL machine has been designed for use with 115/230V
60/50Hz AC current. Connection to another line voltage can create a safety hazard.
If you have any questions about the voltage requirements, contact your local distributor.
WARNING:
To prevent re or shock hazard, do not expose this appliance to rain or moisture. It has been de-
signed for indoor operation only.
The appliance is not suitable for installation in an area where a water jet would be used. The appli-
ance must not be cleaned by a water jet.
If the supply cord is damaged, it must be replaced by a special cord available from the manufac-
turer or its service agent, or the same type as the original.
Changes or modications not expressly approved by JVL Labs could void the user’s authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital de-
vice, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to correct the interference at his own
expense.
If you require any assistance, please contact Technical Support at 1-800-296-6657.
The information in this manual is subject to change without notice. JVL and JVL logo are registered trademarks of JVL Labs.
Product names mentioned herein are for identication purposes only and may be trademarks and/or registered trade-
marks of their respective companies. © 2008 JVL Labs. All rights reserved.
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
General description
4
1. GENERAL DESCRIPTION
ECHO is a countertop with following features:
• 22 inch LCD screen that delivers a true HD entertainment experience
• LCD screen featuring red accents and a glossy piano nish
• Four speakers, a subwoofer and a high quality tri-band acoustic system
• Reliable storage with a high capacity SD card
• A large spill-resistant power-pad for optimal gaming performance
• Large capacity for coins and bills
• Separate access for money and electronics redenes security and serviceability
• Wi-Fi and USB connectivity
• 3 degree lockable turntable, designed especially for touch screen applications
Here are the main components of this countertop:
Dimensions: 22”W x 21” H x 15” D
Weight: 38lbs
Coin Box Capacity: 1.6L
Mars Bill Acceptor (or other) 700 bills
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
General description
5
Operator Information:
After opening back door, you will have access to the Setup Button.
Set Up Button
Back Door Sensor
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
Flash memory card replacement
6
2. FLASH MEMORY CARD REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unscrew one Hex Nut #8-32. Lift the Inner Box to release the latches then tilt the top of the box
towards you to gain access to the SD Memory card slot (see Fig. 6 on page 30 and Fig. 7 on page
31 for details).
7. Press onto the existing SD Memory card to eject it from its socket. Replace it with the new one
(see Fig. 7 on page 31 for details).
8. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
Game box replacement
7
3. GAME BOX REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unplug all connectors from the CPU Box. These connectors are:
• USB upgrade cable
• Power Pad cable
• Touch screen cable
• I/O Board cable
• Network cable
• LVDS cable
• Audio cable
See Fig. 8 on page 31 for details
7. Unscrew one Hex Nut #8-32. Lift the Inner Box upwards to release the latches then rotate the
CPU box to gain access to the AC cable connector (see Fig. 6 on page 30 and Fig. 9 on page 32 for
details).
8. Disconnect the DC Harness from the CPU Box. Remove the CPU Box from themachine
(see Fig. 10 on page 32 for details).
9. Press onto the SD Memory card to eject it from the existing CPU Box. Insert the memory card
into the new CPU Box (see Fig. 11 on page 33 for details).
10. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
(1) HNS-CT09-723
(2) HNS-CT09-704
(3) HNS-CT09-716
(4) HNS-CT09-713
(5) HNS-CT09-727
(6) HNS-CT09-780
(7) HNS-CT09-730
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
8
4. GAME BOX FANS REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unplug all connectors from the CPU Box. These connectors are:
• USB upgrade cable
• Power Pad cable
• Touch screen cable
• I/O Board cable
• Network cable
• LVDS cable
• Audio cable
See Fig. 8 on page 35 for details
7. Unscrew one Hex Nut #8-32. Lift the Inner Box upwards to release the latches then tilt the top
of the box towards you to gain access to the AC cable connector (see Fig.6 on page 30 and Fig. 9
on page 32 for details).
8. Disconnect the AC cable from the CPU Box. Remove the CPU Box from the machine (see Fig. 10
on page 32 for details).
9. Unscrew two machine screws #6-32 x 1/4” (see Fig. 12 on page 33 for details).
10. Disconnect the two fan cables from the CPU Board. Remove the Fan Holder bracket from the
CPU Box (see Fig.13 on page 34 for details).
11. Unscrew four screws, remove the old fans, and install the new fans. Make sure the fans’ orien-
tation is correct; airow should be directed onto the CPU and Mobile Graphics chip (see Fig. 14 on
page 35 for details).
12. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
(1) HNS-CT09-723
(2) HNS-CT09-704
(3) HNS-CT09-716
(4) HNS-CT09-713
(5) HNS-CT09-727
(6) HNS-CT09-780
(7) HNS-CT09-730
Game box fans replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
9
5. COIN MECHANISM REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Lift the Coin Acceptor Lock upwards and tilt the Coin Acceptor towards you (see Fig. 15 on page
36 for details).
5. Unplug the Coin Acceptor (if electronically controlled) and remove it from the countertop
(see Fig. 16 on page 36 for details).
6. Replace the old Coin Acceptor with the new one.
7. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Coin mechanism replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
10
6. COIN SENSOR REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Lift the Coin Acceptor Lock upwards and tilt the Coin Acceptor towards you (see Fig. 15 on page
36 for details).
5. Unplug the Coin Acceptor (if electronically controlled) and remove it from the countertop
(see Fig. 16 on page 36 for details).
6. Unplug the Coin Sensor connector (see Fig. 17 on page 37 for details).
7. Unscrew two machine screws #8-32 x 1/4”. Remove the Coin Acceptor Bracket from the ma-
chine (see Fig. 18 on page 38 for details).
8. Unscrew two machine screws #4-40 x 1/4” and replace the old JVL Sensor PCB with the new one
(see Fig. 44 on page 52 for details).
9. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Coin sensor replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
11
7. MONITOR UNIT REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unplug the following connectors from the CPU Box:
• LVDS cable
• Touch screen cable
See Fig. 20 on page 39 for details
7. Unscrew one Hex Nut #8-32 and free the Touch Screen USB cable from the clamp (see Fig. 21 on
page 39 for details).
8. Disconnect the Monitor Door Stopper Cable from the Monitor by unscrewing one machine
screw #8-32 x 3/8”(see Fig. 22 on page 40 for details).
Attention, the Monitor Assembly has to be secured at this moment, as it will fall if not properly
handled.
9. Remove the Monitor assembly by lifting upwards. Replace with the new one.
10. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
(6) HNS-CT09-780
(3) HNS-CT09-716
Monitor unit replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
12
8. BILL ACCEPTOR REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unplug the following connectors from the CPU Box:
• LVDS cable
• Touch screen cable
See Fig. 20 on page 36 for details
7. Unscrew one Hex Nut #8-32 and free the Touch Screen USB cable from the clamp (see Fig. 21 on
page 39 for details).
8. Disconnect the Monitor Door Stopper Cable from the Monitor by unscrewing one machine
screw #8-32 x 3/8”(see Fig. 22 on page 40 for details).
9. Remove and set aside the Monitor assembly by lifting upwards.
10. Disconnect the following connectors from the amplier PCB:
• Upper Tweeters connector (1)
• Mid-range speakers connector (2)
• Subwoofer speakers connector (3)
• CPU Box audio cable connector (4)
• Power cable connector (5)
See Fig. 23 on page 44 for details
11. Unscrew one Hex Nut #8-32 and disconnect the Bill Acceptor Ground cable from the stud
(PEM) (see Fig. 24 on page 41 for details).
12. Remove the Bill Cassette (see Fig. 25 on page 41 for details).
13. Remove the Bill Acceptor Cover by sliding it upward (see Fig. 26 on page 42 for details).
14. Unscrew one Machine Screw #8-32 x 3/8” (see Fig. 27 on page 42 for details).
15. Slide the Bill Acceptor and bracket upwards and remove by tilting them towards you to gain
access to Bill Acceptor connector (see Fig. 28 on page 43 for details).
16. Disconnect the BA Harness connector from the Bill Acceptor (depending on the type of Bill
Acceptor).
17. Set aside the Bill Acceptor with Bill Acceptor bracket.
(6) HNS-CT09-780
(3) HNS-CT09-716
Bill acceptor replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
13
18. Unscrew four Hex Nuts #8-32 to detach the Bill Acceptor from the Bill Acceptor bracket. Re-
place the old Bill Acceptor with the new one (see Fig. 29 on page 44 for details).
19. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Bill acceptor replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
14
9. I/O BOARD REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unplug all connectors from the I/O Board:
• Service Lights cable connector
• Fan cable connector
• I/O Board USB cable connector
• BA Harness connector
• I/O Board Power cable connector
• Counter cable connector
• Door Switch cable connector
• Upper Glass Illumination cable connector
• Reject Button Illumination cable connector
See Fig. 30 on page 44 for details.
Note. Cash harness part numbers vary depending on the type of coin acceptor and bill acceptor.
7. Unscrew two Machine Screws #4-40 x 3/16’’ and remove the existing I/O Board (see Fig. 31 on
page 45 for details).
8. Carefully remove the Dallas Key and place it into the new I/O Board (see Fig. 32 on page 45 for
details).
9. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
(1) HNS-CT09-708
(2) HNS-CT09-719
(3) HNS-CT09-713
(4) See note
(5) HNS-CT09-702/712
(6) HNS-CT09-714
(7) HNS-CT09-703
(8) HNS-CT09-724
(9) HNS-CT09-708
I/O board replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
15
10. COUNTER REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Disconnect the Counter Cable connector (6) from the I/O Board (see Fig. 30 on page 44 for
details).
7. Unscrew two Machine Screws #4-40 x 3/16”and lift the I/O Board upwards to remove the Coun-
ter Cable, located underneath the board (see Fig. 31 on page 45 for details)
8. Unscrew one Machine Screw M3 x 6 and replace the old counter with the new one (see Fig. 33
on page 46 for details).
9. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Counter replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
16
11. POWER PAD ASSEMBLY REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
Following two steps are for security purposes only (not to let coin from cashbox get into ma-
chine).
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew six Tapping Screws #8 x 3/8” and carefully pull the Power Pad Assembly upwards to
gain access to the Power Pad USB cable (see Fig. 34 on page 47 for details).
5. Disconnect the Power Pad USB cable connector from the Joystick Board (see Fig. 35 on page 47
for details).
6. (Optional) If equipped with the RFID Board, disconnect the RFID cable connector from the Joy-
stick Board (see Fig. 36 on page 48 for details).
7. Replace the old Power Pad Assembly with the new one.
8. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Power pad assembly replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
17
12. UPPER GLASS REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Unscrew four Tapping Screws #8 x 3/4”(see Fig. 37 on page 48 for details).
6. Replace the Upper Glass with the new one.
7. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Upper glass replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
18
13. UPPER GLASS LIGHTS PCB
REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew two Machine Screws #8-32 x 1-1/4”and open the monitor to gain access to all elec-
tronic components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Unscrew four Tapping Screws #8 x 3/4”(see Fig. 37 on page 48 for details) and set aside the Up-
per Glass.
6. Disconnect the cable from the PCB (see Fig. 38 on page 49 for details)
7. Pull the Upper Glass Lights PCB towards you and press onto the snaps to release the PCB. You
may need to use a at head screwdriver to push the PCB from behind (see Fig. 39 on page 49 for
details).
8. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Upper glass lights PCB replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
19
14. AMPLIFIER PCB REPLACEMENT
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew 4 Machine Screws:
(Two- #8-32 x 1-1/4” and two #8-32 x 3/8”) and open the monitor to gain access to all electronic
components (see Fig. 3 on page 28 and Fig. 4 on page 29 for details).
5. Press on the snaps of the Inner Cover to unlock them. Tilt the cover towards you, and then slide
the Inner Cover upwards. Move it along the Monitor Stopper Cable and set it aside (see Fig. 5 on
page 30 for details).
6. Unscrew one Hex Nut #8-32, slide the Amplier Shield upwards and pull to release.
This lifted position will allow you easy access to connectors (see Fig. 40 on page 50 for details).
7. Unplug the following connectors from the Amplier PCB:
• Upper Tweeters connector (1)
• Mid-range speakers connector (2)
• Subwoofer speakers connector (3)
• CPU Box audio cable connector (4)
• Power cable connector (5)
See Fig. 41 on page 50 for details
8. Unscrew two Machine Screws #4-40 x 3/16”(see Fig. 42 on page 51 for details) and replace the
old Amplier PCB with the new one.
9. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Amplier PCB replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200

Copyright © 2011 JVL Labs All Rights Reserved
20
15. POWER SUPPLY REPLACEMENT
NOTE: You will need a short Philips head screwdriver.
1. Turn o the countertop and disconnect the AC power supply.
2. Open the lock and tilt the top of the Back Door towards you to remove it completely (see Fig. 1
on page 26 for details).
3. Remove the freely installed Cashbox by lifting upwards, then pulling it towards you (see Fig. 2
on page 27 for details).
4. Unscrew two Machine Screws #8-32 x 3/8 ”, and move the Coin Out Tray out of the way by push-
ing it to the left (see Fig. 43 on page 51 for details).
5. Unscrew three Machine Screws #8–32 x 1/4 ” (see Fig. 44 on page 56 for details).
6. Tilt and position the Power Supply Assembly as shown in Fig. 45 on page 53 to remove it from
the countertop. Disconnect AC and DC cables from the old Power Supply Board.
7. Unscrew 4 Machine Screws #6-32 x 3/8”(see Fig. 46 on page 53 for details)
8. Replace the old Power Supply with the new one.
9. Reassemble the countertop by following the previous steps in reverse order.
NOTE: For part numbers see Appendix B
Power supply replacement
To Purchase This Item, Visit BMI Gaming | www.bmigaming.com | [phone] | +1.561.391.7200
