General notes
1
1. General notes
1.1 Goods incoming
Upon receipt of the goods, they should be inspected immediately for external damage. Defects in the pa-
ckaging must be reported to the carrier immediately and acceptance must be refused.
Should the product be damaged after unpacking, this must be immediately reported in writing to thermo-
control. The complaint can be accepted no later than 5 days after receipt of the goods.
The delivery documents show whether additional transport insurance has been taken out. If this is the case,
thermo-control must be informed immediately so that the damage can be asserted against the insurance
company.
1.2 Inhalt
All thermocouples are delivered with a transport protection. This serves to protect the ceramic tubes against
mechanical stress during transport.
(1) Thermoelement
(2) Plaxiglas Transportrohr ∅30 mit Kleinansch Aufsatz
(3) Dicht- und Zentrierring
(4) Spannring Aluminium
For new parts, a Certicate of Calibration for each thermocouple for the built-in thermocouple and a Cer-
ticate of Conformity in a DIN A4 envelope are afxed to the inside of the box with a CERTIFICATE sticker.
1.3 Anwendbare Produkte
Die folgende Gebrauchsanleitung ist generell für Vakuum-Thermoelemente mit Kleinansch-Anschlüssen
gültig.
thermo-control
Körtélyessy GmbH
Vacuum thermocouples with small flange fitting
General notes
2
1.4 Prozessanschluss
Die Maße des sogenannten Kleinansches sind nach ISO 2861 geregelt. In der Norm wird der maximal zu-
lässige Druck mit 1.5bar angegeben. Ein sicherer Betrieb der Verbindung bei Drücken von 5bar ist, basierend
auf empirischen Daten aus mehr als 35 Jahre, mit infachen Spannklammern durchaus möglich.
Für den Betrieb der Kleinanschverbindung bei Drücken von 10bar sollte jedoch ein Stüzuring sowie massive
Spannring aus Edelstahl verwendet werden. Hierzu bieten wir ein spezielles Hochdruckset an.
2,5
min. 10
15°
d3
d1 max.
d2
2,8
Nennweite d1 d2 d3
16 20 17.2 30
25 28 26.2 40
40 44.5 41.2 55
50 61 52.2 75
thermo-control
Körtélyessy GmbH
Vacuum thermocouples with small flange fitting
General notes
3
1.5 Transport protection
The products are secured with different means during transport. The correct handling of disassembling the
transport protection guarantees the safety of the product.
In essence, two methods are in use:
• Securing with plexiglass tube and lling material
• Securing with stainless steel tube and PVC net hose
1.5.1 Transport protection with Plexiglass tube and lling material
Thermocouples with small ange or threaded connections are shipped in a Ø30mm Plexiglas tube. In the
plexiglass tube, the ceramic tubes of the thermocouple are xed against movement by a lling material,
usually corundum or walnut shell granules. The open end of the tube is provided with a blue cap.
Please remove the protection using following procedure:
• Remove the blue cap
• Completely remove / pour lling material out of the Plexiglas tube
• Pull the thermocouple out of the Plexiglass tube
Important note:
Not following above procedure will damage the thermocouple protection tube.
1.5.2 Transport protection with stainless steel tube and PVC mesh hose
This method is used for thermocouples with holding tube with a metallic transport tube. The tube has a
diameter of Ø18mm and covers the ceramic protective tubes. The ceramic tubes are covered with a PVC
mesh hose to protect them from shocks. The hose can protrude a few centimeters out of the transport tube
and is usually colored blue.
The transport tube is removed by pulling out in the direction of the longitudinal axis of the thermocouple.
Lateral movements or rotations can lead to breakage of the ceramic tubes and thus to the loss of the guarantee.
thermo-control
Körtélyessy GmbH
Vacuum thermocouples with small flange fitting
General notes
4
1.6 Certicate of calibration
Based on the type of product the certicate of calibration can be issued in two variations.
• Standard calibration based on Gold and Palladium x-point measurements against ASTM E230/E230M
with correction values from 500°C to 1500°C in 100K steps.
• Coil calibration in accordance to AMS 2750 from 150°C to 1320°C in 130K steps
thermo-control
Körtélyessy GmbH
Vacuum thermocouples with small flange fitting
General notes
5
1.7 Certicate of conformity
This certicate contains all production details which have been added to the serial number.
This includes:
• Batch number of the sealing mat used
• Used blank (process connection with potted ceramic protection tubes)
• Test data and result of the helium leak test
thermo-control
Körtélyessy GmbH
Vacuum thermocouples with small flange fitting
Product overview
6
2. Product overview
2.1 Process tting with ISO small ange
The standard is an ISO 2861 DN 25 small ange. Likewise, versions with DN16 or DN40 are possible.
Conguration table:
8 - PPXXZZ - LLLLAA
PP – Pressure range: vacuum tight and
pressure proof
05 – up to 5bar
10 – up to 10bar(*)
XX – Number of thermocouple (TP)
01 – 1 TP + empty tube
02 – 1 TP + 2 empty tubes
03 – 2 TP + empty tube
04 – 3 TP + empty tube
ZZ – Type thermocouple wire
01 – PtRh10% - Pt (Type S)
02 – PtRh13% - Pt (Type R)
03 – PtRh30% - PtRh16 (Type B)
04 – NiCr – Ni (Type K)
05 – NiCrSi – NiSi (Type N)
LLLL – Nominal length [mm]
0400 – 400 mm
to
1600 – 1600 mm
In 100 mm steps
AA– Fitting
KF16 – Small ange DN 16
KF25 – Small ange DN 25
KF40 –Small ange DN 40
Example: 8-050301-0600KF25
Thermocouple for vacuum systems up to 5 bar atmospheric pressure with 2 x Type S thermocouples + 1
empty test tube, with a nominal length of 600 mm and ISO 2816 small ange DN25.
A protective tube serves as a test tube into which a test thermocouple can be inserted. As a result, this
thermocouple can be checked for any deviations at any time. Also, if the thermocouple is installed in the
oven, the measurement can be performed. Due to the separate guidance of the thermocouples, the test
measurement does not affect the built-in thermocouples. In addition, the thin-walled construction makes
the thermocouple more tolerant of faster insertion speeds.
(*)Important note
Using the small ange tting at pressures above 5 bar special seal rings and clamps
need to be used to ensure a safe production.
thermo-control
