KAKADU 45L Transit Fridge User manual

™
OWNERS MANUAL
Part No. 10001052
FRIDGE OR FREEZER
45 LITRE
TRANSIT FRIDGE

2
General Information & Safety Instructions.......3
Assembly and Parts ........................................4
Getting Started................................................5
Operating your Fridge/Freezer ........................6
Temp Control/General Operation ....................8
Using with Solar Panel or Generator.............11
Tips, Maintenance & Service.........................12
Troubleshooting.............................................13
Error Code .....................................................14
Specications................................................14
Warranty Details ............................................16
CONTENTS

3
Read This Manual Thoroughly Before First
Use, even if you are familiar with this type
of product. The safety precautions enclosed
herein reduce the risk of re, electric shock
and injury when correctly adhered to. Keep
the manual in a safe place for future reference,
along with purchase receipt and carton. If
applicable, pass these instructions on to the
next owner of the appliance.
Always follow basic safety precautions and
accident prevention measures when using an
electrical appliance, including the following:
ELECTRICAL SAFETY & CORD HANDLING
Correct voltage: Make sure your local outlet
voltage and circuit frequency corresponds to
the voltage indicated on the appliance rating
label.
NOTE: INTENDED USE: This is a portable
product, designed for private use. It is
exclusively designed for use in cars, caravans
and other vehicles including mobile homes,
campervans, rail cars and boats. It is designed
to cool food and beverages and to be set up in
dry, weather protected areas. It is not intended
for stationary extended use as e.g. a second
fridge at home.
Safe connection: Insert the plug rmly into a
properly earthed AC mains or 12V DC socket,
Do not alter the plug.
Protect from moisture: To protect against
electric shock, do not immerse the cable, plug
or the appliance itself in water or other liquid.
Ensure your hands are dry before handling the
plug or switching on the appliance. Do not use
it on wet surfaces.
NOTE: Installation of AC in boats should be
carried out by a qualied electrician.
Protect the power cable. Do not kink or
damage the power cable. Do not wrap it
around the appliance. Do not pull the unit by
the cable. Do not use the cable as a handle,
close a door on the cable or pull the cable
around sharp edges or corners. Keep the
cable away from heated surfaces.
Never touch uninsulated cables with bare
hands.
This applies especially to handling AC cables.
For installations in boats: If the device is AC
mains operated, it is important that the system
is protected by a fuse and an earth leakage
protection device.
Always ensure that the correct voltage is
applied to the Fridge/Freezer. The voltage is
stated on the Fridge/Freezer’s data plate.
Never obstruct vents to the Fridge/Freezer’s
compressor.
Defrost the Fridge/Freezer on a regular
basis.
Never use hard or sharp implements to
remove ice from the cooling compartment.
Never use abrasive or solvent based
materials when cleaning the cooling
compartment.
Do not use any electrical appliances inside
the cooling compartment.
NOTE: This appliance is not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should be
supervised to ensure that they do not play with
the appliance.
Do not expose to rain.
This appliance is suitable for camping use.
GENERAL INFO AND SAFETY INSTRUCTIONS

4
ASSEMBLY AND PARTS
1
3
2
4
5
8
7
6
SINGLE ZONE FRIDGE OR FREEZER
1. Internal Basket
2. Control Panel
3. Single Lid
4. Carry Handle
5. Air Flow Vent
6. Power Input Panel
7. AC Power Cable (Page 7.)
8. DC Power Cable (Page 7.)

5
GETTING STARTED
INSTALLATION
After unpacking the Fridge/Freezer check that no
parts are missing. Place the unit in a dry place
which is protected against splashing water. Do not
place directly adjacent to sources of heat such as
heating, gas ovens, hot water pipes or under the
blazing sun.
It is important that your appliance is installed and
operated in accordance with these instructions
to guarantee its performance, efciency and
operation.
APPLICATION & OPERATIVE
COOLING RANGE
The cooling compartment has varying temperature
zones. The values indicated on the digital display
are related to the middle of the cabinet.
The 45L Transit Fridge or Freezer is designed to
either refrigerate or freeze food. The Dairy Section
(small compartment at rear) will only chill food, will
never freeze. The Fridge/Freezer may be used for
outdoor use such as for camping purposes.
If you wish to refrigerate medicines, rst check
to ensure the Fridge/Freezer’s cooling capacity
meets the demands of the respective medicines.
The Fridge/Freezer is designed to operate in
ambient temperatures between 14F and 131F in
a maximum air humidity of 90% and can operate
continuously at an angle of 30° maximum.
NOTE: The normal operation of the appliance
requires heat to be radiated away from the
condenser located at the end of the cabinet.
Adequate airow is required around the
compressor at all times. (Fig. 1).
The cooling system has been designed to operate
correctly when the appliance is positioned on
angles up to 30 degrees. It is recommended that
the time the unit is exposed to angles over 30
degrees is limited to a maximum of four (4) hours
continuous operation. (Fig. 2).
Fig. 1
Fig. 2
30O
30O

6
OPERATING YOUR FRIDGE/FREEZER
POWER REQUIREMENTS
The Fridge/Freezer is designed to operate on
AC or DC voltage.
AC input 110-120V AC at 60Hz to AC adaptor
(e.g. electrical power point)
DC input 12V or 24V DC (e.g. car cigarette
lighter or car battery)
If the Fridge/Freezer is operating when the
vehicle ignition is switched OFF, the Fridge/
Freezer will switch OFF automatically unless
vehicle is tted with dual battery system.
The Fridge/Freezer will automatically switch
back ON when the vehicle is re-started and
the power source voltage reaches the Battery
Monitor cut-in setting.
OPERATING WITH 12/24V DC
Plug the 12V/24V DC power cable into the
DC POWER socket (Fig 3.) on the end of the
Fridge/Freezer and then connect to the vehicle
cigarette lighter socket or suitable 12V or 24V
DC power source.
The Fridge/Freezer will automatically turn
on, there is no requirement to switch the
appliance on.
The display will automatically show the current
internal cabinet temperature.
For optimum performance and efciency, it is
important that the Fridge/Freezer has a reliable
DC power source available. Direct connection
to the battery is recommended and reduces
the risk of voltage dropping too low for the
appliance.
Use only the DC power cable supplied with the
Fridge/Freezer.
Important: If a DC extension cable is required
we recommended use of a AWG11 Twin
Sheath Two Core cable with direct connection
to the positive and negative battery terminals
with 15A inline fuse protection.
12/24V DC Power Requirements
If your Fridge/Freezer is cutting out prematurely, it
could be due to:
1. The battery voltage protection being set
too high on the Battery Monitor (refer to page
9/10).
2. DC power cable and/or connections are not
suitable to carry the required current. Check
the power cable and all connections and
adjust the Battery Monitor on the control panel
if required.
The Fridge/Freezer is equipped with a
multilevel Battery Monitor that protects your
vehicle battery against excessive discharging
when the Fridge/Freezer is connected to 12V
or 24V DC power source.
Important: When using the Fridge/Freezer
with DC power supply, we recommend setting
the Battery Monitor to LOW if Fridge/Freezer
not running off crank battery.
NOTE: A battery charger may only be
connected to the battery when the Fridge/
Freezer has been disconnected from the DC
power source.
Re-connect fridge after charger has been
connected.Over-voltage may cause damage to
the electronics of the Fridge/Freezer.
Your Fridge/Freezer is equipped with reverse
polarity protection. It protects your Fridge/
Freezer against reverse battery connection and
short circuit.
As a protection for your battery, the Fridge/
Freezer switches OFF automatically if the
power source voltage is insufcient. Fridge will
only restart when voltage reaches cut in level.
NOTE: It is important that the correct cable
size and gauge is used for the installation of
the DC supply as over distance the voltage
can decrease if the incorrect cable size and
gauge cable is being used.
Always consult a qualied automotive
electrician when using a DC extension cable.

7
OPERATING YOUR FRIDGE/FREEZER
DC Power Cable
(Can be Cigarette connection or Merit
connection by removing/replacing red twist
cap (Fig.4)
OPERATING WITH AC ADAPTOR
Plug the AC power adaptor & cable into the
Fridge power socket (Fig. 3) on the end of the
Fridge/Freezer and then connect to a suitable AC
power source.
The Fridge/Freezer will automatically turn
on, there is no requirement to switch the
appliance on.
The display will automatically show the
current internal cabinet temperature.
CAUTION: Do not touch cables, plugs or
switches with wet hands or when your feet
are in contact with water! If you operate your
Fridge/Freezer on board a boat by means of
a shore connection to a AC power source,
the power connection must include an earth
leakage RCD residual current device.
Fig. 3
Fig. 4

8
When your Fridge/Freezer is rst connected
to the AC or DC power input the appliance
will automatically switch on and the LCD
control panel will display the current cabinet
temperature, battery monitor and Eco setting
as well as the current input voltage.
The Temperature Controller provides the
ability to set the desired temperature level and
display the current cabinet temperature. The
electronic controller has been programmed to
maintain an average of the set temperature.
The compressor will start up when the internal
cabinet temperature increases 3F to 4F
degrees above the set temperature and will
run until the temperature is 3F to 4F degrees
below the set temperature.
BATTERY DISPLAY
Voltage is measured at the input connection on
the side of the appliance.
Battery Display 12V 24V
9.6V or less 21.3V or less
9.7V to 10.3V 21.4V to 22.4V
10.6V to 11.0V 22.7V to 23.5V
11.1V to 11.7V 23.6V to 24.6V
11.8V to 12.4V 23.7V to 25.7V
12.5V or above 25.8V or above
*Values are for reference only and may be subject to
change depending on conditions and power supply.
TEMP CONTROL/GENERAL OPERATION

9
CONTROL OPERATION
1. Power On/Off Button
2. Settings Button
3. Temp Decrease Button
4. Temp Increase Button
5. Temp Display
6. Battery Protection Display
7. Compressor Speed Display
Power – O and On
1. Press power button & fridge will go into
standby mode then switch off after 5 seconds
2.Press the power button & fridge will re-start
with previously selected settings
Eco Function – Setting
1. Press the SETTINGS button to change the
compressor between ECO & MAX
Cabinet Temperature – Setting
1. Adjust Temperature by pressing the + button to
increase temp and the - button to decrease temp
Note: Maximum temperature settings are from
0F to 68F
2. Temperature display will ash when
selecting temperature & return to solid display
when showing actual internal temperature
Battery Monitor – Setting
1. Adjust by pressing & holding the SETTINGS
button for 3 seconds until battery monitor
setting ashes. Press SETTINGS button to
change settings
12V DC Input Cut Out Cut In
HIGH 11.3V 12.6V
MEDIUM 10.1V 11.4V
LOW 9.6V 10.9V
24V DC Input Cut Out Cut In
HIGH 24.3V 25.7V
MEDIUM 22.3V 23.7V
LOW 21.6V 23.0V
1
2
7
6
3
45

10
BATTERY MONITOR – SETTING
1. Adjust the setting by pressing the Battery
Protection button until desired setting is
highlighted on display
12V DC Input Cut Out Cut In
HIGH 11.3V 12.6V
MEDIUM 10.1V 11.4V
LOW 9.6V 10.9V
24V DC Input Cut Out Cut In
HIGH 24.3V 25.7V
MEDIUM 22.3V 23.7V
LOW 21.6V 23.0V
CONTROL OPERATION

11
USING WITH SOLAR PANEL OR GENERATOR
USING WITH SOLAR PANELS
The power consumption and efciency of
your Fridge/Freezer makes it ideal to be used
in conjunction with solar panels to provide
recharging of the DC power source. Solar
panels will provide charge into the battery
during the daylight hours even while the
appliance is operating.
As the output from solar panels changes
depending on the level of sunlight and
intensity, your Fridge/Freezer cannot be
connected directly to the solar panels. The
appliance must be connected to a suitable DC
battery and then the solar panels connected to
the battery.
We recommend the use of the quality
regulated portable solar panel kits from 60 to
250 watts for use with your Fridge/Freezer.
DO NOT CONNECT THE FRIDGE/FREEZER
DIRECTLY TO THE SOLAR PANEL AS IT
WILL NOT WORK. CONNECTION MUST BE
VIA THE BATTERY.
USING PORTABLE GENERATORS
It is important that the correct generator size
is used with your Fridge/Freezer. An incorrect
generator or voltage output may result in
reduced performance or damage to your
Fridge/Freezer which may void your appliance
warranty.
If connecting directly to an AC generator,
ensure that only a digital or inverter type
generator is used. These provide a more
reliable and constant AC output power
source and are specically designed for use
with electronic and other power sensitive
appliances.
Most generators are tted with a DC power
output socket - DO NOT connect your
fridge directly to the DC power output of the
generator as this will result in damage to your
Fridge/Freezer and void warranty.
When charging the battery using a digital or
inverter type generator, we recommend only
using a ‘smart battery charger’ that is fully
automatic, spark proof and reverse polarity
protected. The battery charger is connected
directly to the AC power output socket of the
generator.

12
TIPS AND SUGGESTIONS
Fresh and frozen foods should not be stored
right beside each other in the cabinet. Doing
so may cause a fresh food to freeze and/or
spoil.
When the appliance is being set at 32F or
lower temperatures, do not store glass bottles
or liquids such as milk, juices or soft drinks in
the unit as these may freeze and shatter, leak
or burst.
Items such as fruit and vegetables should
be stored closer to the top of the cabinet as
this area is normally slightly warmer. This will
reduce the risk of spoiling and ensures that
damage is not caused by being crushed by
heavier items.
To improve the efciency of your Fridge/
Freezer it is better to have the cabinet as
full as possible at all times. A full cabinet
will provide lower power consumption over
24 hours than a half empty one. When the
cabinet is full there is little air space between
the goods so the cold air is trapped, but when
there is lots of air the coldness cannot be
captured and held. On a trip it is a good idea
to replace nished products with bottles of
water or similar. This will ll the empty spaces
and allow the coldness to remain within the
cabinet.
Frequent door opening will allow warm air
to enter the cabinet. Keep the number of
times you open the door to a minimum where
possible.
When located in the rear of a car or trailer, it
is recommended that the appliance be kept
away from direct sunlight to reduce the risk
of increased heat. It should also be provided
with suitable ventilation to guarantee efcient
power consumption and performance. You
must remember that when a vehicle is parked
in the sun that on a day where the ambient
temperature is 86F, the interior of the vehicle
can reach 131F.
MAINTENANCE & SERVICE
Your Fridge/Freezer will be delivered cleaned
from the factory – you nevertheless should
clean prior to initial use. Take a cloth which
has been slightly moistened with lukewarm
water. Pay attention that no water drops
into the seals and possibly damages the
electronics. Dry off the Fridge/Freezer with a
cloth after cleaning. Clean your Fridge/Freezer
periodically and as soon as it is dirty.
ATTENTION:
DO NOT use solvents or agents with sand or
acid parts for cleaning your Fridge/Freezer.
DO NOT use brushes, graters or hard sharp
tools to clean your Fridge/Freezer.
Before cleaning, the power cable should be
disconnected and the Fridge/Freezer switched
OFF.
Clean the Fridge/Freezer inside and out with
a damp cloth. For stubborn dirt, use some
sodium bicarbonate dissolved in lukewarm
water.
After washing, rinse with clean water and dry
carefully.
When storing your Fridge/Freezer for a long
period of time, DO NOT fully close the lid.This
will prevent mould and odours.
For additional queries, service and maintenance
please email our After Sales Support
[email protected]
They will provide you with expert advice on further
information you may require.
DISPOSAL
When it comes to the end of its working life, your
Fridge/Freezer should be disposed of responsibly
to ensure that it does not contaminate the
environment. It would be advisable to contact your
local council for advice on the disposal of this unit.
TIPS, MAINTENANCE & SERVICE

13
ISSUE POSSIBLE SOLUTIONS
The Fridge/Freezer will not turn on
Check the unit is switched ON – Press the power button to turn on
Check the power source (voltage may be too low)
Check the power cable and all connections from the power source
to Fridge/Freezer
The contents of the fridge are freezing The temperature has been set too low, therefore increase the temperature
setting.
Poor refrigeration performance
Too much food has been put inside the unit
Temperature of the food put inside the fridge is too high
Ensure lid is closed properly
Ensure power source has sufcient voltage
There is poor ventilation around the fridge
Ambient temperature is very high
Temperature is not set correctly
There is a “water ow” type of noise from inside
the unit This is normal, caused by the ow of refrigerant
There is a noise from the unit
Ensure unit is on a at level surface
Check for vibrations in surrounding objects
Fridge/Freezer does not work and display does
not illuminate
There is no voltage present in the 12V/24V cigarette lighter socket in your
vehicle. The ignition must be switched ON in most vehicles to apply current
to the cigarette lighter socket
No voltage present in the AC voltage socket. Try using another plug socket
The adaptor is defective.
Fridge/Freezer does not work and display does
not illuminate when operating from the 12V/24V
cigarette lighter socket with ignition switched ON.
The cigarette lighter socket fuse in vehicle is defective and must be replaced
The cigarette lighter socket in vehicle must be cleaned or the plug has not been
assembled correctly.
The display shows an error message (F1)
and the Fridge/Freezer does not cool
Connected to DC power source, the Fridge/Freezer has switched off.
This may be due to low voltage. Check Battery Monitor setting is on LOW.
Re-start vehicle to increase battery voltage level. Test and charge battery
The Fridge/Freezer has switched off due to an internal fault.
TROUBLE SHOOTING

14
SPECIFICATIONS
ERROR
CODE POSSIBLE CAUSE SOLUTION
F1 Low voltage to fridge
DC - Increase voltage of DC power source/Check all connections
AC - Replace defective 240V AC Power adaptor
F2 Condensor Fan Faulty Replace condensor fan
F3 Compressor over pressure Disconnect power to fridge for 20 minutes & attempt re-start
F4 Compressor not kicking in Replace compressor control module
F5 Over Temperature of the compressor & electronics Disconnect power to fridge for 20 minutes & attempt re-start
F7 Temperature Sensor Faulty Replace temperature sensor
Model 10001052
Capacity 45lt Single Zone
Weight 33lbs (empty)
Dimensions 27L x 14D x 18H (Inches) (Width includes handles)
Compressor LG BCA018L
Current Draw 60W MAX (12VDC), 30W MAX (24VDC)
Cooling Range 68F to 0F
Power Input 45W
Insulation PU Foam
Material Polypropylene
ERROR CODE INFORMATION

15
NOTES

LIMITED WARRANTY
1. This warranty will apply only if you have purchased from us or our authorized dealer, and will apply only to the
original purchaser who acquires the product for his or her own use.
2. WARRANTY PERIOD: we warrant that this product will be free from defects in materials and workmanship under
normal use as described in the published product documentation for 36 months and the integrated powerpack for
12 months from the date of original purchase (Limited Warranty).
3. WARRANTY: You are entitled to a replacement or refund for a major failure and compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if products
fail to be of acceptable quality and the failure does not amount to a major failure.
4. To the extent permitted by any applicable local law:
a. Our obligations under this Limited Warranty are limited to the repair, replacement or refund of covered parts
that prove defective under normal use during the Limited Warranty and does not extend to any claim for
damages that you or any other person may have for any loss (including without limitation consequential
damages or loss of profit, freight/shipping or travel costs), or damage howsoever caused whether or not such
loss or damage arises as a result of any defect in the product or from the failure or omission on our part to
comply with any obligation at law;
b. In replacing a defective product under the Limited Warranty, we may, at our discretion, substitute a model of
equivalent nature where the exact model is unavailable;
c. This Limited Warranty does not apply to damage caused by failure and damage caused by improper use
and abuse, fair wear and tear, accidents, misuse (including failure to follow instructions regarding care and
maintenance of the product), neglect, disassembly, alterations or external causes such as, but not limited
to, water damage, exposure to sharp objects, exposure to excessive force, anomalies in the electrical current
supplied to the product (if applicable), and extreme thermal or environmental conditions;
d. We may elect, at our discretion and as an alternative to repairing or replacing a defective part, to refund the
cost of the relevant product upon it being returned to us; and
e. This Limited Warranty does not extend to any products acquired for the purposes of re-supply, or for use in
manufacturing, or repair processes.
5. This warranty may be claimed by: returning the product to its place of purchase, with a detailed proof-of-purchase
clearly showing the date and detail of the purchase;
6. If you have any questions concerning this warranty policy, you may contact us in writing:
Adventure Operations, 71 Charles Ulm Place, Eagle Farm, 4009, QLD, Australia, or by
email: [e-mail] or visit our website: www.adventureoperations.com
TO THE EXTENT PERMITTED BY LAW, ADVENTURE TRADING AUSTRALIA PTY LTD, ITS SUBSIDIARIES AND ITS
VENDORS DISCLAIM ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
OR ANY SIMILAR STANDARD IMPOSED BY APPLICABLE LEGISLATION AND ADVENTURE TRADING AUSTRALIA PTY LTD
AND ITS SUBSIDIARIES’ RESPONSIBILITY TO REPAIR, REPLACE, OR OFFER A REFUND FOR DEFECTIVE PRODUCTS IS
THE SOLE AND EXCLUSIVE REMEDY PROVIDED TO ITS CUSTOMERS UNDER THIS DOCUMENT.
WARRANTY - For details see www.kakaduUSA.com/warranty
