KOBE Range Hoods
Brillia Series
Model No.: ISX2430SQB-2 (30”)
ISX2436SQB-2 (36”)
ISX2442SQB-2 (42”)
INSTALLATION INSTRUCTIONS
AND OPERATION MANUAL

IMPORTANT
READ THIS FIRST
READ BEFORE INSTALLATION
1. Carefully check all contents of packages.
2. Thoroughly inspect the unit for any shipping damages, cosmetic
damages or defects.
3. Have a certified contractor/electrician test the unit before installation.
IF THERE IS ANY PROBLEM:
1. DO NOT INSTALL THE UNIT AND KEEP ALL ORIGINAL
PACKAGING MATERIAL.
2. Have your original invoice as proof of purchase and product serial
number ready.
3. Contact your merchant for product replacement due to shipping
damages, cosmetic damages or defects.
4. For all other issues, call 1-877-BUY-KOBE (289-5623), or e-mail to
[email protected] .
NO RETURN, NO REFUND, NO EXCHANGE IF:
1. PRODUCT HAS BEEN INSTALLED
2. KNOCK-OUT HOLES HAVE BEEN
PUNCTURED
3. MISSING ORIGINAL PACKAGING
MATERIAL AND/OR PARTS

[ENGLISH]
- READ AND SAVE THESE INSTRUCTIONS -
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS.................................................................................... 1
COMPONENTS OF PACKAGE.................................................................................................. 3
INSTALLATION.......................................................................................................................... 4
OPERATING INSTRUCTIONS................................................................................................... 8
MAINTENANCE........................................................................................................................10
SPECIFICATIONS ....................................................................................................................11
MEASUREMENTS & DIAGRAMS.............................................................................................12
PARTS LIST..............................................................................................................................13
CIRCUIT DIAGRAM..................................................................................................................15
TROUBLE SHOOTING.............................................................................................................16
WARRANTY .............................................................................................................................17
PRODUCT REGISTRATION .....................................................................................................19
- READ ALL INSTRUCTIONS CAREFULLY BEFORE STARTING -
ALL W IRING MU S T BE DONE B Y A PROFE SSION A L AND IN
ACCO RD ANCE W I TH NATI ONAL AND LOC AL ELEC TRICAL CO DES

1
IMPORTANT SAFETY INSTRUCTIONS
- PLEASE READ THIS SECTION CAREFULLY BEFORE INSTALLATION -
WARNING : TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL INJURY,
OBSERVE THE FOLLOWING:
1) Installation and electrical wiring must be done by qualified professionals and in accordance with all
applicable codes and standards, including fire-rated construction.
2) When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hidden
utilities.
3) Ducted fans must be vented to the outside.
a) Before servicing or cleaning unit, open the light panel and SWITCH POWER OFF AT SERVICE
PANEL.
b) Clean all grease laden surfaces frequently. To reduce the risk of fire and to disperse air properly,
make sure to vent air outside. DO NOT vent exhaust air into wall spaces, attics, crawl spaces or
garages.
NOTE - This warranty is void without an authorized agent’s receipt or if unit is
damaged due to misuse, poor installation, improper use, mistreatment,
negligence or any other circumstances beyond the control of KOBE
RANGE HOODS authorized agents. Any repair carried out without the
supervision of KOBE RANGE HOODS authorized agents will
automatically void the warranty.
- KOBE RANGE HOODS will not be held responsible for any damages to
personal property or real estate or any bodily injuries whether caused
directly or indirectly by the range hood.
WARNING : TO REDUCE THE RISK OF PERSONAL INJURY IN THE EVENT OF A RANGE
TOP GREASE FIRE:
1. Keep all fan, baffle/spacer/filter/oil tunnel/oil container and grease-laden surfaces clean. Grease
should not be allowed to accumulate on fan, baffle/spacer/filter/oil tunnel/oil container.
2. Always turn hood ON when cooking.
3. Use high settings on cooking range ONLY when necessary.
4. Do not leave cooking range unattended when cooking.
5. Always use cookware and utensils appropriate for the type and amount of food prepared.
6. Use this unit only in the manner intended by the manufacturer.
7. Before servicing, switch power off at service panel and lock service panel (if possible) to prevent
power from switching on accidentally.
8. Clean ventilating fan frequently.

2
What to Do In The Event Of a Range Top Grease Fire
• SMOTHER FLAMES with a tight fitting lid, cookie sheet, or metal tray, and then turn off the burner.
KEEP FLAMMABLE OR COMBUSTIBLE MATERIALAWAY FROM FLAMES. If the flames do not go
out immediately, EVACUATE THE AREAAND CALLTHE FIRE DEPARTMENT or 911.
• NEVER PICK UPA BURNING PAN – You May Get Burned.
• DO NOT USE WATER, including wet dishcloths or towels – a steam blast will result.
• Use an extinguisher ONLY if:
a) You have a Class A, B, C extinguisher and know how to operate it.
b) The fire is small and contained in the area where it started.
c) The fire department has been called.
d) You can fight the fire with your back to an exit.
What to Do If You Smell Gas
- Extinguish any open flame.
- Do not try to turn on the lights or any type of appliance.
- Open all doors and windows to disperse the gas. If you still smell gas, call the Gas Company and
Fire Department right away.
CAUTION
1) For general ventilation use only. Do not use to exhaust hazardous or explosive materials and vapors.
2) To reduce the risk of fire, use only metal ductwork. Sufficient air is needed for proper combustion and
exhausting of gases through the flue (chimney) to prevent back drafting.
3) Follow the heating equipment manufacturer’s guideline and safety standards such as thosepublished
by the National Fire Protection Association (NFPA), and the American Society for Heating,
Refrigeration and Air Conditioning Engineers (ASHRAE), and code authorities.
4) Activating any switch on may cause ignition or an explosion.
5) Due to the size and weight of this hood, installation by 2 persons is recommended.
ELECTRICAL SHOCK HAZARD – Can result in serious injury or death.
Disconnect appliance from electric power before servicing. If equipped,
the fluorescent light bulb contains small amounts of mercury, which must
be recycled or disposed of according to Local, State, and Federal Codes.

3
COMPONENTS OF PACKAGE
(Must keep all material for returns or refunds)
Glass Canopy Box (Box 1 of 3)
Range H
ood Box (Box 2 of 3)
{A} Glass Canopy {B} KOBE Range Hood
{C} Warranty Registration Card
{D} Quick Reference Guide
{E} Baffle Filter (2 pcs)
{F} Oil Tunnel
{G} Screw Package
{H} Flapper (2 pcs)
{B}
{C} {D}
{E} {F}
{G} {H}
Duct Cover Box (Box 3 of 3)
{I} Telescopic Stack
{J} Adjustable Duct Cover
{K} Aluminum Pipe
{I}
{J}
{K}
FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.koberangehoods.com OR
CONTACT KOBE RANGE HOODS AT [phone].
Hexagonal Screws
QTY: 4PCS
Round Screw Washer
QTY: 16PCS
Conical Screw Washer
QTY: 2
PCS
4mm x 8mm Screws
QTY: 18PCS

4
INSTALLATION
PLEASE READ ENTIRE INSTRUCTIONS BEFORE PROCEEDING
Calculation before Installation
To calculate installation, please refer to TABLE 1. (All calculation in inches.)
TABLE 1
A = Height of Floor to Ceiling
B = Height of Floor to Counter Top
(Standard: 36”)
C = Preferred Height of Counter Top to Hood
Bottom (Recommended 30” to 36”)
D = Height of Hood
E = Height of the Hood Installation
[A – (B+C)]
F = Height of Duct Cover
[E – D]
SAFETY WARNING
HOOD MAY HAVE VERY SHARP EDGES; PLEASE WEAR PROTECTIVE GLOVES IF
REMOVING ANY PARTS FOR INSTALLING, CLEANING OR SERVICING.
NOTE: BE CAREFUL WHEN USING ELECTRICAL SCREWDRIVER, DAMAGE TO THE HOOD MAY
OCCUR.

5
Preparation before Installation
NOTE: TO AVOID DAMAGE TO YOUR HOOD,
PREVENT DEBRIS FROM ENTERING THE
VENT OPENING.
•Decide the location of the venting pipe from the hood
to the outside (Figure 1).
•A straight, short vent run will allow the hood to
perform more efficiently.
•Try to avoid as many transitions, elbows, and long
runs as possible. Transitions, elbows and/or long
runs may reduce the performance of the hood.
•Temporarily wire the hood to test for proper
operation before installing.
•Important: Peel protective film off the hood and
duct covers, if any.
•Use duct tape to seal the joints between pipe
sections.
Hood I
nstallation
CAUTION: USE HAND TOOLS ONLY. DO NOT
OVER TIGHTEN SCREWS. IT MAY CAUSE DAMAGE TO
THE HOOD.
CAUTION : If moving the cooking range is
necessary to install the hood, turn off the power in
an electric range at the main electrical box. SHUT
OFF THE GAS BEFORE MOVING A GAS RANGE.
And use a protective covering to protect cooktop
and/or countertop from damage.
1. Mark centerlines of cook top or range on ceiling.
Use centerlines marked on ceiling to position the
range hood as shown in Figure 2.
2. Cut and remove ceiling drywall. Install 2” x 4” cross
framing lumber (not provided) between ceiling
joists.
3. The framing should be spaced 9-1/2” at the front
centerline and 7-3/4” on the sides. Refer to Figure
3.
4. Finish the ceiling surface. Be sure to mark the
location of the ceiling joists and cross framing
lumber.
5. Cut a 7-1/2” duct opening and approximately a 1”
wire access hole. Secure four hood mounting
screws (not provided) into the ceiling joint and cross
framing lumber, leaving 1/8” away from the cabinet
as shown on Figure 4. Make sure screws are driven
into the ceiling at the middle of joists and cross
framing lumber for maximum support and stability.
Figure 1
Figure 2
Figure 3
Figure 4

6
6. Adjust the telescopic stack with sixteen screws and
washer (pre-installed). Refer to Figure 5.
7. Align the telescopic stack to the mounting screws on
the ceiling and lock the telescopic stack in place.
Fasten the mounting screws as shown in Figure 6.
8. Slide the duct covers up the telescopic stack, and
temporary hold the duct covers up.
CAUTION : MAKE SURE THE TELESCOPIC
STACK IS SECURE BEFORE RELEASING.
9. Remove the four screws and washers from top of the
hood body. Position and install the glass canopy
onto the hood bodywith the fourscrews and washer.
10. Install the two flappers (provided) onto the exhaust.
Refer to Figure 7.
11. Align the hood with the telescopic stack and secure
the hood body onto the telescopic stack with sixteen
4mm x 8mm screw (provided). Refer to Figure 8.
CAUTION : MAKE SURE THE HOOD IS
SECURE BEFORE RELEASING.
Figure 5
Figure 6
Figure 7
Figure 8
Telescopic Stack Installation
Hood Installation

7
Wiring to Power Supply
THIS RANGE HOOD MUST BE PROPERLY
GROUNDED. MAKE SURE THIS IS DONE BY
QUALIFIED ELECTRICIAN IN ACCORDANCE WITH
ALL APPLICABLE NATIONAL AND LOCAL
ELECTRICAL CODES. BEFORE CONNECTING
WIRES, SWITCH POWER OFF AT SERVICE PANEL
AND LOCK SERVICE PANEL TO PREVENT POWER
FROM BEING SWITCHED ON ACCIDENTALLY.
12. Route house wiring into the ceiling as close to the
installation location as possible. Allow additional
length of wiring to drop down from the ceiling to the
electric box.
13. Connect the electrical wires according to color
(green to green, white to white, and black to black)
and cap with wire connectors. Green wire must be
grounded to reduce risk of electric shock.
Ductwork Installation
14. Use 6” round aluminum or steel pipe (not provided)
to connect the plastic
15. Place the two sections of the inner duct cover on the
telescopic stack and clip together. Secure it to the
top of the telescopic stack with two 4mm x 8mm
screws and conical screw washers (provided).
16. Place the two sections of the outer duct cover on the
telescopic stack and cliptogether. Slide it downward
so that it sits properly on the hood.
Final Assembly
17. Install the Baffle Filters.
18. Turn power ON in control panel. Check all lights and
fan operation.
19. Make sure to leave this manual for the homeowner.
Duct Cover Installation
