Koeppl CL10-2 User manual

Type CL-2 = Compact-Light
MOTORGERÄTEFABRIK
94163 ENTSCHENREUTH
 (0 99 07) 89 10-0 - Fax [phone]
www.koeppl.com [e-mail]
The basis for working with the 2-wheel tractor type Compact-Light is that you read, under-
stand and follow this operating manual and that for the
attachments as well as the engine
manufacturer’s operating manual.
You may not commence with the operation before having done
so
.
Rev. date / Edition
12.11.2012 - No. 02-2012
Für künftige Verwendung aufbewahren!
Retain for future reference!
Operating manual
for
2-wheel tractor
Compact-Light = CL-2
CL10-2 / CL13-2 SNOW / CL14-2

Page 2
Version 02-2012
Notes
Compact-Light
Translation of the original operating manual
Translation of the original operating manual

Page 3
Version 02-2012
Table of contents
Compact-Light
Table of contents
Table of contents .................................................................................................................................. 3
Foreword ...............................................................................................................................................
Appropriate use .................................................................................................................................... 5
General safety instructions .................................................................................................................. 6
1. Possible hazards in dealing with the 2-wheel tractor .............................................................................. 6
2. Explanation of the safety symbols used ............................................................................................................ 6
3. azards due to accessories ............................................................................................................................. 7
4. Noise / vibration values ................................................................................................................................... 7
5. Sources of danger .......................................................................................................................................... 8
6. Lighting devices on single-axle tractors ............................................................................................................ 9
7. Operator position, danger area ........................................................................................................................ 9
8. Requirements for the operating personnel ...................................................................................................... 11
9. Personal protective equipment....................................................................................................................... 11
10. Safety measures at the place of work ............................................................................................................ 12
11. General safety instructions ............................................................................................................................ 12
12. Protective devices ......................................................................................................................................... 13
13. Leaving the 2-wheel tractor ................................................................................................................ 14
14. Safety of attached devices ............................................................................................................................ 14
15. Brakes ......................................................................................................................................................... 15
16. Engine ......................................................................................................................................................... 15
17. Tyres, screwed connections........................................................................................................................... 15
18. Operating devices ......................................................................................................................................... 15
Transport ............................................................................................................................................ 16
1. Tractor size / machine dimensions ................................................................................................................. 16
2. Technical data .............................................................................................................................................. 17
3. Transport ..................................................................................................................................................... 18
Operation ............................................................................................................................................ 19
1. Commissioning ............................................................................................................................................. 19
2. Steering shaft adjustment ............................................................................................................................. 20
3. Starting the 2-wheel tractor ............................................................................................................... 21
4. Shifter .......................................................................................................................................................... 22
5. Power take-off engagement/disengagement ................................................................................................... 23
6. Engine ......................................................................................................................................................... 24
7. Throttle lever ............................................................................................................................................... 25
8. Active steering.............................................................................................................................................. 26
9. Rapid-change device flange ........................................................................................................................... 28
10. Parking foot ................................................................................................................................................. 29
11. Operating hour meter ................................................................................................................................... 30
Faults .................................................................................................................................................. 31
1. Faults and their remedy ................................................................................................................................ 31
Maintenance ....................................................................................................................................... 33
1. ydraulic drive ............................................................................................................................................. 33
2. Power take-off drive ..................................................................................................................................... 36
3. Wheel drive .................................................................................................................................................. 36
4. Engine ......................................................................................................................................................... 38
5. Drive wheels, wheel motors .......................................................................................................................... 38
6. Attached devices .......................................................................................................................................... 39
7. General ........................................................................................................................................................ 39
8. Safekeeping and storage ............................................................................................................................... 39
9. Maintenance schedule ................................................................................................................................... 40
Appendix ............................................................................................................................................. 1
1. Lubricants / adhesives .................................................................................................................................. 41
EU Conformity Declaration ................................................................................................................. 2

Page
Version 02-2012
Foreword
Compact-Light
Foreword
Before putting the Compact-Light 2-wheel tractor into operation, it is absolutely
essential to read and follow the instructions regarding appropriate use, the operat-
ing manual and the safety instructions as well as the operating manuals for the at-
tached devices that will be operated with the 2-wheel tractor!
The guarantee only applies in the case of proper operation!
Dear customer, you have made the right choice!
Although the available choice is large, you have decided on a 2-wheel tractor.
We are particularly pleased about that. We will do our best to satisfy you for many
years to come.
We hope you will be our best advertisement from now on.
The following points distinguish our product:
• The appliance is very well balanced, you can work without effort.
• It is equipped with an outstanding engine.
• Maintenance costs are hence very low.
• The operation is simple and effective.
• The supply of spare parts is guaranteed and takes place promptly.
• Optimum customer service is at your disposal at all times.
The Compact-Light 2-wheel tractor is the result of decades of experience and can
therefore be used practically and continuously.
The company is constantly working on the further development of all of its
machines and appliances. We therefore reserve the right to make changes to the
form, technology, weight and equipment of the scope of supply. Please understand
that no claims can be derived from the specifications and illustrations contained in
this manual.
IF YOU HAVE ANY REQUESTS FOR IMPROVEMENT, PLEASE LET US
KNOW!

Page 5
Version 02-2012
Appropriate use
Compact-Light
Appropriate use
The 2-wheel tractor type Compact-Light, in conjunction with the respective original
attached device, is designed exclusively for normal use and work in agriculture and forestry,
such as the mowing of grass and meadows as well as the performance of winter services:
-for snow hoeing, snow clearing, mowing, flail mowing, all-purpose mowing, hay mak-
ing, sweeping and the scattering of sand and fertiliser
• The conditions specified in the quotation and in the confirmation of order are decisive. Any
other use is construed as being inappropriate. The manufacturer shall not be liable for any
damages resulting from this; the user alone bears the risk.
• This work is permitted only if the engine sizes, wheel sizes and environmental conditions
are suitable.
• The 2-wheel tractor (Type Compact-Light) may be used, maintained and repaired
only by persons who are familiar with this work and who have been instructed about the
hazards.
• The 2-wheel tractor may not be used on steep slopes.
• Unauthorised conversions and alterations to the 2-wheel tractor are forbidden for safe-
ty reasons!
• Relevant regulations governing the prevention of accidents as well as the generally accepted
regulations governing health and safety at work and road traffic rules must be complied
with.
Important!
The operating, service and maintenance conditions for the 2-wheel tractor specified in
this operating manual are prerequisites for appropriate use and must be strictly adhered
to.
Warning!
If the machine is used for any other purpose than that stated above or is driven with a
higher power than is permitted, this can result in:
• dangerous situations for people and
• damage to property.
Warning!
The manufacturer is not aware of any inappropriate or prohibited uses of the machine. The
improper attachment of additional devices or the attachment of additional devices and
parts not purchased from the company exclude liability for any resulting damage.

Page 6
Version 02-2012
General safety instructions
Compact-Light
General safety instructions
1. Possible hazards in dealing with the 2-wheel tractor
In the case of incorrect operation or misuse, there is a danger of
• injury to or death of the operator,
• damage to the 2-wheel tractor and other property belonging to the user,
• impairment of efficient working with the 2-wheel tractor
All persons who are involved with the start-up, operation, service and maintenance of the 2-
wheel tractor must
• be appropriately qualified,
• observe and follow this operating manual precisely!
It’s your safety that is at stake !
2. Explanation of the safety symbols used
The following symbols are used in this operating manual:
Warning!
This symbol indicates important safety information in this operating manual.
This symbol indicates a possibly dangerous situation. Serious injuries may result from failing to
follow the instructions. Read the following instructions carefully and also inform other operating
personnel.
Caution!
This symbol indicates a possibly dangerous situation.
Slight injuries may result from failing to follow the instructions.
Important!
This symbol denotes safety tips and other useful information.
Wear safe
ty glasses
Wear protective
gloves
Wear safety shoes
Read and follow the
operating manual and
safety instructions
before putting into
operation!
Switch off the engine and
re
move the spark plug cap
before repair, mainte-
nance and cleaning!
Wear ear protectors
Never reach into the
crushing danger zone if
parts can
still move there
Warning of a hot
surface
Switch off the mowing attachment
and the engine before working on
the cutting tool

Page 7
Version 02-2012
General safety instructions
Compact-Light
Snow hoe warning notices
3. Hazards due to accessories
Attached devices, mowing devices and any other additional devices used must not disable the
safety devices of the 2-wheel tractor.
4. Noise / vibration values
Caution!
Long periods of exposure to noise and vibrations lead to damage to health. Wear ear pro-
tectors and adapt your working hours.
Noise information (sound power level EN ISO 3744) - emissions
Noise information (sound pressure level EN ISO 11201) - immissions
Vibrations (hand/arm vibrations DIN 45675 Part 8) - immissions
The A-weighted sound power level and the A-weighted emission sound pressure level of the
2-wheel tractor, without additional devices, at the operator's ear are
Version Sound power level
[dB(A)]/[rpm] Sound pressure level [dB(A)]/[rpm] Vibrations [m/s²]
CL10 98,8 87,3 4,2
CL13 98,2 86,8 4,4
CL14 98,9 88,4 4,6
- Wear ear protectors
Emissions of a noise level can lead to disturbances of acoustic signals. Other vehicles may
not be noticed – particular caution is required!
Depending on the attached device, an increase in the sound pressure level of up to 4.5 dB(A) is
to be expected - exact data is given in the respective operating manual.
• Measurements took place in the open air, based on EN ISO 3744 (sound power level) and
EN ISO 11201 (sound pressure level).
• The measuring instrument used: NOR 116 sound level meter, Norsonic, Norway - complies
with the IEC 651 and 804 class 1 standard.
• Engine speed = highest engine operating speed
• Radius of the semicircular measurement area = 4 m.
Read the opera
t
ing
manual before
putting into
operation.
Eliminate blockages only after the rotary
grinder and chopper wheels have come to a
standstill and only with the aids provided.
Danger of being caught up, wound in,
drawn in or trapped.
Keep a sa
fe distance
.
Danger due to parts
being flung when the
engine is running.
Keep a safe distance.
Danger of being
caught up, wound in,
drawn in or trapped.
Keep a safe distance.
Danger due to
rotating tools.
Switch the engine off
and wait until the
tools come to a halt

Page 8
Version 02-2012
General safety instructions
Compact-Light
2. Vibration measurements took place in accordance with EN 1033.
Measuring devices
Vibration measuring instrument: CASTLE GA 2003 HARM
Operating conditions
• Fuel tank approx. 50 % full.
• Steering shaft adjusted to the body height of the operator.
• Appliance run-in and at operating temperature.
• Measured on the steering shaft in accordance with EN 12733.
• Engine speed = highest engine operating speed
5. Sources of danger
The 2-wheel tractor may be used on both commercial and private properties in ac-
cordance with road traffic laws.
• Check that the unit is safe to operate and to be used in traffic each time before putting it into
operation!
• Observe the generally applicable regulations for safety and the prevention of accidents in
addition to the instructions in this operating manual!
• When using the 2-wheel tractor on public roads, the stipulations of the respective na-
tional road traffic laws (in Germany: StVZO) in their current versions apply.
• Familiarise yourself with all devices and controls as well as their functions before starting
work. Make sure that all protective devices have been attached properly! Doing so during
the work assignment is too late!
• The user is responsible for the safety of third parties in the working area!
• It is forbidden to enter or remain in the working and danger area of the 2-wheel trac-
tor!
• Before starting up, check the immediate vicinity - children!
• Ensure that your field of view and the lighting conditions are adequate!
• The driver should wear tight-fitting clothes. Avoid loose-fitting clothes. Wear sturdy shoes!
• Do not leave the engine running in closed rooms – the exhaust gases are harmful to health
and may under certain circumstances lead to death!
• Be careful when handling fuel – increased risk of fire! Never refill the fuel tank in the prox-
imity of open flames, igniting sparks and hot engine parts. Do not smoke when refuelling!
• Before refuelling, switch off the engine and remove the ignition key (if one exists). Do not
refuel in closed rooms – risk of explosion!
• Use a suitable pouring aid (e.g. a funnel). If possible, refuel only in the open air with the
engine switched off and cold.
• Do not spill fuel – risk of fire!
• If you have spilt fuel, clean all parts and push the motor mower away from this place before
starting it.
• Do not inhale petrol vapours – risk of cancer due to benzene content; use lead-free and ben-
zene-free petrol if possible – refer also to the engine manufacturer’s operating manual!
• In order to avoid the risk of fire, keep the tractor clean!
• Be careful when handling brake fluids and battery acid – they are toxic and caustic!
• Switch off the engine and pull off the spark plug cap before performing maintenance and
cleaning work.
• Particular caution is necessary when coupling or uncoupling attached tools to or from the
tractor!
• Make sure that all protective devices have been attached properly!
• Observe permissible axle loads, overall weights and transport dimensions!

Page 9
Version 02-2012
General safety instructions
Compact-Light
6. Lighting devices on single-axle tractors
Distinction must be made here as to whether the single-axis tractor
• is guided by a pedestrian via the steering shafts or,
• is driven from a sulky (single-track trailer) or
• is driven from a trailer.
In the dark, or when necessitated by the weather, single-axle tractors guided by pedestrians via
the steering shafts require at least a single, non-dazzling lamp with a white light, which must
be affixed to the left-hand side (UK: right-hand side) or carried by hand so that its light is clear-
ly visible to oncoming traffic (from the front) or overtaking traffic (from the rear) (Article 50,
paragraph 2, German Highway Code and Article 17, paragraph 5, German Highway Code).
If a single-axle tractor with a trailer is transported on a public road, no operating permit is re-
quired up to a design-related top speed of 6 km/h. The name and place of residence of the keeper
of the vehicle must be displayed by a sign on the trailer. A driving licence is not required, how-
ever. The driver of the vehicle must be qualified to drive it. Lighting devices etc. must be present.
7. Operator position, danger area
The operator position on the 2-wheel tractor is located at the two steering shafts (controls)
behind the 2-wheel tractor.
Fig. 1. Operator position.
Direction of
travel
Engine
Rapid-change flange
Operator position
Safety stop lever
with wheel and power take-off drive
Parking foot
operating position
Steering shaft
height-adjustable
Steering lever
Engine cowling
optional
Working headlight
optional
Twist-grip
Forward/reverse

Page 10
Version 02-2012
General safety instructions
Compact-Light
It is forbidden to enter the danger area (B) during work.
This area begins in the middle of the wheel axle and extends to the sides and to the front by vary-
ing distances, depending on the attached tool.
Where
• Snow hoe b s = 25 m b v = 25 m
• Snow plough blade b s = 10 m b v = 10 m
• Mowing bars b s = 10 m b v = 10 m
• AZM-S b s = 2 m b v = 5 m
• AZM-A b s = 25 m b v = 25 m
• Belt haymakers b s = 10 m b s = 10 m
• Flail mowers b s = 20 m b v = 20 m
• Sweeping machine b s = 5 m b v = 5 m
Also refer to the operating manuals for the respective attached devices!
Working on slopes with a gradient higher than 25% or in uneven terrain
On slopes with a gradient of over 40% or in uneven terrain, the device can slip or tip over; the
danger zone is extended by the possible slipping or tipping area of the machine.
• Check the terrain before starting work.
• Select the correct tyres: twin tyres, additional iron slope wheels, spiked rollers…
• Use the maximum possible track and axle width.
• Check the tyre pressures.
• Safety shoes type S2 with non-slip soles are absolutely necessary. Work with crampons if
necessary.
• Keep persons clear of the danger area.
• Adapt your working speed to the surroundings.
• Keep a constant watch on the lie of the terrain.
• Pay attention to the weather – increased risk of accident in wet weather
• Danger due to forced posture over long periods when working in difficult terrain – take suf-
ficient breaks!
Danger area B

Page 11
Version 02-2012
General safety instructions
Compact-Light
8. Requirements for the operating personnel
The minimum age for operators is 16 years.
Only authorised persons may work with the 2-wheel tractor type Compact-Light.
No operating permit and no driving licence is required for single-axle traction and working ma-
chines guided by pedestrians via steering shafts. If the visibility makes it necessary, at least one
non-dazzling white light is to be attached at the front and at the rear on the left-hand side (UK:
right-hand side).
If a single-axle tractor and trailer is transported on a public road, no operating permit is required
up to a design-related top speed of 6 km/h. The name and place of residence of the keeper of the
vehicle must be displayed by a sign on the trailer. A driving licence is not required, however. The
driver of the vehicle must be qualified to drive it. Lighting devices etc. must be present.
The operator is responsible for the safety of third parties in the working area.
The responsibilities for different activities on and with the 2-wheel tractor must be clearly
defined and adhered to. Unclear competences are a safety risk.
The user must:
• make the operating manual available to the operator and
• ensure that the operator has read and understood it.
9. Personal protective equipment
For operation
Wear type S2 safety shoes.
wear work clothes that offer sufficient protection against the sun.
You should wear suitable ear protectors when working.
For cleaning
Wear sturdy safety gloves (leather) to protect against sharp objects (attached devices).
For grinding the mowing blades
Wear safety goggles
> 25%< 25%
Fig. 2. Working on slopes
Check the angle of inclination
of the terrain with a spirit level
Up to 80%
100 cm
25 cm = 25%
W
a
Terrain

Page 12
Version 02-2012
General safety instructions
Compact-Light
10. Safety measures at the place of work
• When starting the engine, the traction and attached device drives must be disengaged (i.e.
the safety stop lever is not depressed; see fig. 2, page 13).
• The driving speed must always be adapted to the environmental and load conditions. Avoid
sudden turns when driving up, down or across a slope. Never disengage the clutch and/or
shift gear on slopes.
• Couple trailers and attached devices according to the regulations. The driving, steering,
braking capability and tipping behaviour will be affected by attached devices. Therefore
make sure that steering and braking capabilities are sufficient and adapt your working speed
to the respective environmental conditions!
• Persons fitted with a cardiac pacemaker must not touch electrically conducting parts of the
ignition system when the engine is running.
• Before starting to drive, check the brakes and their function.
• Remove objects from the work area (e.g. planks, cables, stones etc.).
• Keep hands and feet away from moving parts during operation.
• Ensure that the work area is sufficiently well illuminated.
• Drive at a right angle to the slope, never up or down the slope!
• Never disengage the clutch and/or shift gear on slopes.
• Never leave the operator position during work.
• Do not alter or repair supporting and safety-relevant parts (frame, axles etc.).
• In the case of damage to the appliance, switch it off immediately. Remove the spark plug
cap and have the damage repaired!
• If the appliance is to be used for mowing crops that are classified as foodstuffs, parts which
come into contact with the foodstuffs must not be lubricated with machine oil or grease or
protected against rust.
• Avoid sudden turns when driving up, down or across a slope.
• Driving downhill in neutral is forbidden! The appliance could roll away under its own
weight.
• If there is a danger of slipping on a sloping terrain, an accompanying person must hold the
2-wheel tractor with a rod or a rope. The accompanying person must remain above the
vehicle at a safe distance from the working tools.
11. General safety instructions
• Watch out for fuel and oil leaks and eliminate them if necessary.
• Check screws, nuts and bolts regularly for tightness and tighten them if necessary – after the
first time of use and if circumstances demand.
• Lubricate all sliding or moving parts (e.g. Bowden cables etc.) with a little grease or lubri-
cating oil, especially after cleaning with a high pressure cleaner.

Page 13
Version 02-2012
General safety instructions
Compact-Light
Fig. 3. Safety stop lever – stop position.
Safety stop lever
‘stop’ position
Robin EX40 engine
Ignition switch
12. Protective devices
The 2-wheel tractor is equipped with a safety stop lever on the steering shaft (left), which
disengages the traction drive or power take-off drive when released – i.e. the engine continues to
run, but the machine and the attached device stop (for stop position see fig 3). The engine can be
switched off only by the ignition key (if there is one) or by the engine stop switch.
The safety stop lever serves as an emergency stop switch in dangerous situations where fast
switch-off is required. It swivels automatically into the ‘STOP’ position when released.
Stop the 2-wheel tractor immediately if there are any malfunctions of the safety stop lever.
Have malfunctions rectified immediately!
Warning!
The engine runs on due to the centrifugal ma!
Tools running on – danger of injury!
• In order to start the machine, the Bowden cable shifter must be placed in the 0 position and
the safety stop lever must be placed in the stop position - see fig. 3.
• During operation of the 2-wheel tractor the safety stop lever must be depressed –
operating position.
• It is forbidden by to leave the safety stop lever/ V-belt tensioning lever in the operat-
ing position when the machine is to be cleaned, maintained or left – e.g. in order to clean
the snow hoe. First bring the machine to a halt, switch off the engine and then clean the tool.
It is forbidden
to tie down the safety stop lever / tensioning lever or
to bind it with adhesive tape!
Motor Rato
SNOW
1- Place the throttle lever first in the SLOW po-
sition  and then in the STOP position.
2- Remove the safety key  .
Also refer to the engine manufacturer’s
operating manual!
Fig. 4. Switching the engine off.
Twist-grip
forward/reverse + speed



Page 1
Version 02-2012
General safety instructions
Compact-Light
The protective devices
• have been installed for the safety of the operator and,
• must not under any circumstances be modified, removed or circumvented by means of mod-
ifications to the 2-wheel tractor.
The safety stop lever serves as an EMERGENCY-OFF switch which is to be released in dan-
gerous situations where fast switch-off/stopping is required. It then returns automatically to the
‘STOP’ position.
13. Leaving the 2-wheel tractor
• Set the 2-wheel tractor down on the ground, switch off the engine and remove the ig-
nition key (if there is one).
• When leaving the 2-wheel tractor, secure it against rolling away and use by unauthor-
ised persons by means of wheel chocks.
• Never leave the 2-wheel tractor unattended if the engine is still running.
• Never leave the operator position at the steering shaft when driving.
• Close the petrol tap when parking the 2-wheel tractor!
14. Safety of attached devices
Fundamental rule:
Check that the unit is safe to operate and to be used in traffic each time before putting it into op-
eration!
• There is a risk of injury when coupling attached devices. Be especially careful!
• Attached devices may only be attached when the engine is switched off and the PTO drive
is disengaged.
• Secure the 2-wheel tractor and the attached devices against rolling away (parking
brake, wheel chocks).
• Attach the transport lock and safety device and place them in the protective position.
• Connect the attached devices according to regulations and fasten them only to the pre-
scribed fittings.
• It is not permitted to ride on the attached device of the tractor during work or
transport.
• Observe permissible axle loads, overall weights and transport dimensions!
• Check and attach transport equipment (lighting, warning devices, protective devices).
• Switch the appliance off immediately in the case of damage; remove the ignition key of the
2-wheel tractor if there is one (only with electric starter) and have the damage re-
paired.
• Place protective and safety devices in the protective position again after the repair work is
completed. Only then is operation allowed again.
• Check the protective devices and working devices for wear.
• There are crushing and cutting zones on externally powered parts (e.g. hydraulics.
• It is forbidden to enter or remain in the working, rotating and swivelling area!
Keep a safe distance!
• Before starting work, remove all foreign bodies from the area to be worked. Beware of for-
eign bodies during operation!
• Before starting work, remove all foreign bodies from the area to be worked. Beware of for-
eign bodies during operation!
• Be particularly careful when working on steep paths and on slopes – danger of tipping over!

Page 15
Version 02-2012
General safety instructions
Compact-Light
Drive at a right angle to the slope if possible.
• Disengage the device drive (power take-off) when driving outside the working area. The
2-wheel tractor must be raised into the transport position.
• Never work on the attached device when the engine is running; switch the engine off in or-
der to carry out such work.
• Persons must not stand between the tractor and the attached device if the tractor is not
secured against rolling away by means of wheel chocks.
• Observe the generally applicable regulations for safety and the prevention of accidents in
addition to the instructions in this operating manual.
• The mating surfaces of the rapid-change flange on the basic device and on the attached de-
vice must be clean; they must be cleaned if necessary.
• The mating surfaces must be greased with special long-life grease (see appendix).
• If protective devices and working tools are subject to wear they should be inspected at regu-
lar intervals and replaced if necessary!
15. Brakes
• The appliance is braked by load-holding valves.
• Adjustment and repair work on the load-holding valves may be carried out only by special-
ist workshops.
16. Engine
• Do not leave the engine running in a closed room – danger of poisoning!
• Always switch the ignition off and close the petrol tap when turning the engine off!
17. Tyres, screwed connections
• When working on the wheels, ensure that the tractor is parked safely and secured against
rolling away!
• Repairs to the tyres may be carried out by specialists using suitable mounting tools!
• There is a risk of explosion if the tyres are over-inflated!
• Check the tyre pressures regularly!
• Check the wheel motor bolts for tightness after the first 10 hours of operation and then all
every 8 hours of operation.
18. Operating devices
• Check the function of the brakes before starting to drive!
• Shift down in good time before driving downhill!
• Switch off the tractor immediately if malfunctions occur in the steering or brakes. Have
malfunctions rectified immediately!

Page 16
Version 02-2012
Transport
Compact-Light
Transport
In order to avoid damage to the machine and life-threatening injuries when transporting the ma-
chine, it is essential to pay attention to the following points:
• Transport work may be carried out only by persons who are qualified for such work, ob-
serving the safety instructions.
• The machine may be raised only at the points intended for the purpose and without attached
devices.
• When transporting on a trailer, it is essential to secure the machine against slipping and roll-
ing away. Always switch off the engine.
• Use suitable ramps for loading and unloading.
• Never transport the engine with the fuel tank or the fuel tap open. Refer also to the motor
manufacturer’s operating manual!
• Follow the national road traffic regulations when driving on public roads.
• Also read the chapter ‘General safety instructions’.
1. Tractor size / machine dimensions
Tyres a
[mm] b [mm] c [mm] g [mm]
4.00 x 8 AS 1.220 1.112 269 602
Compact-Light = CL.
a
b
c
g
Forwards

Page 17
Version 02-2012
Transport
Compact-Light
2. Technical data
CL10-2 CL1 -2 CL13-2
SNOW
Driving speed
Wheels 4.00 x 8 AS
Forwards
Reverse
0 – 6 km/h
0 – 3 km/h
0 – 6 km/h
0 – 3 km/h
0 – 6 km/h
0 – 3 km/h
No. of gears/
Settings
Infinite
forward/reverse
Infinite
forward/reverse
Infinite
forward/reverse
Power take-off speed, max. approx. 1.050 rpm approx. 1.050 rpm approx. 1.050 rpm
Power take-off
engagement /disengagement yes yes yes
Rapid-change device flange Standard Standard Standard
Engine
Robin
Petrol
EX27
6,6 kW
9,0 HP
Robin
Petrol
EX40
10,3 kW
14,0 HP
Rato
Petrol
390 SNOW
9,5 kW
13,0 HP
Active steering Standard Standard Standard
Wheels 4.00 x 8 AS Standard Standard Standard
Iron slope wheels Standard Standard Standard
Weight [kg]
without tyres and
without attached device 122 128 128
Tyre type Tyre size Track width Pressure
Field tyres 4.00 x 8 AS
4.00 x 10 AS
5.00 x 10 AS
60 cm
61 cm
71 cm 1,5 bar
Wide tyres AS 16x 6.50 x 8 AS
18 x 9.50 - 8 AS
20 x 8 - 10 AS
77 cm
83 cm
84 cm 1,5 bar
Turf tyres 18 x 9.50 - 8 84 cm
Lamella tyres
Snow tyres 4.00 x 8 61 cm 1,5 bar
Optionally with caterpillar drive
Filling quantities
Hydraulic system
Mobil DTE 10 Excel 68
alternatively oil*
according to D N 51524-3 ( SO VG68)
CAUT ON!
use only zinc-free oils
approx. 1.9 l
Internal combustion engine see operating instructions
* if alternative oils are used, an oil change must be carried out after every 25 hours of operation.

Page 18
Version 02-2012
Transport
Compact-Light
3. Transport
The 2-wheel tractor is delivered ready for operation.
Unpacking
• Remove the cardboard box and the film.
The generally recognised and applicable regulations for safety and the prevention of acci-
dents must be adhered to when transporting the 2-wheel tractor!
• Ensure that all protective devices are properly attached.
• Ensure that no protective devices have been damaged or rendered inoperable during
transport.
• Check and attach transport equipment (lighting, warning devices, protective devices).
• If protective devices and working tools are subject to wear they should be inspected at regu-
lar intervals and replaced if necessary!
• Place protective and safety devices in the protective position again after transport. Only
then is operation allowed again.
• Check the protective devices and working devices for wear.
• Never transport the engine with the fuel tank or the fuel tap open. Refer also to the engine
manufacturer’s operating manual!
Fig. 5. Compact-Light CL.

Page 19
Version 02-2012
Operation
Compact-Light
Operation
In order to avoid damage to the machine and life-threatening injuries when putting the
machine into operation, it is essential to pay attention to the following points:
You must have read and understood:
• the engine manufacturer’s operating manual,
• the operating manual for the respective attached device and
• the operating manual for the 2-wheel tractor,
in particular chapter 1, ‘Safety and protective devices’.
You may not operate the 2-wheel tractor before having done so.
1. Commissioning
Warning!
Exhaust gases contain carbon monoxide!
They are highly toxic if inhaled and can lead to death.
Important!
During the first 20 hours of operation (the running-in period) the engine and the hydraulic
system should not be operated up to their performance limits.
After about 10 hours of operation, check that all screws, bolts and control parts on the
basic machine and attached devices are tight.
Important!
At temperatures under + 0° C you must allow the hydraulic drive to warm up for approx. 3
minutes at a low engine speed so that the oil can reach operating temperature and the drive can
function without problems. During this time
•the ‘Direction of travel’ twist-grip must be in the neutral / 0 position.
•the safety stop lever must be depressed.
The oil pump runs and the oil warms up.
After about 3 hours of operation, check that all screws, bolts and control parts on the basic ma-
chine and attached devices are tight.
The following items must be checked before putting into operation for the first time:
• Check the engine oil – see the engine manufacturer’s operating manual.
• Check the hydraulic oil.
• Check all safety devices.
• Check whether there is sufficient fuel in the fuel tank.
• Check that all screws, bolts and controls on the 2-wheel tractor and the attached de-
vice are tight!
• Remove all tools and foreign parts from the machine.
• Adjust the steering shaft to the operator’s body size and in accordance with the purpose of
use.

Page 20
Version 02-2012
Operation
Compact-Light
2. Steering shaft adjustment
In order to be able to work optimally, you must adjust the steering shaft to suit your body size.
This adjustment is child’s play:
• Stand in front of the 2-wheel tractor.
• You should be able to stand in a relaxed position in front of the 2-wheel tractor with
slightly bent elbows. If that is not the case the steering shaft needs to be adjusted.
Adjusting the steering shaft: (See fig. 6)
• Press lever C downwards until the steering shaft is released from the latch.
• Hold the lever C and adjust the height.
• The steering shaft can be locked further up or further down by releasing and latching lever
C.
• You are now finished with the adjustment of the steering shaft.
Fig. 6. Steering shaft adjustment .
Lever C
Lever C
