Kolpin POLARIS RANGER 800 XP Series User manual
.
INSTALLATION INSTRUCTIONS
POLARIS RANGER
800 XP
4x4 6x6
POLARIS RANGER
800 XP
2
Kolpin Outdoors Inc.
205 N. Depot St.
Fox Lake, WI 53933
SAFETY INSTRUCTIONS
Warning: Failure to heed all safety and operating instructions and
warnings regarding use of this product can result in serious bodily
injury.
READ PROPERLY COMPLETE ASSEMBLY INSTRUCTIONS BEFORE STARTING OF ASSEMBLY
Install all parts indicated in assembly instructions. Failure to fully assemble
product before use could result in personal injury.
Assembly of product requires use of hand or power tools.
If you are not experienced in using these types of tools,
have product dealer do the install for you.
Some parts contain sharp edges, wear protective gloves if necessary.
Always keep your assembly area clean, uncluttered and well lit.
Keep visitors and children a safe distance away from the assembly area. Visitors should wear the
same safety equipment described above.
Never operate your UTV with the cab doors open. Failure to properly latch the
doors before moving the vehicle could result in serious injury.
Dress for safety. DO NOT wear loose clothing, gloves, neckties or jewelry if
using power tools to assemble this product.
Tight the front glass holders screws with attention, if you tight these screws too hard the front glass
may by crackle.
Insert all nut covers after you finish installation.
POLARIS RANGER
800 XP
3
Kolpin Outdoors Inc.
205 N. Depot St.
Fox Lake, WI 53933
MAINTANCE AND CLEANING
To clean polycarbonate surface use soapy water solution or other subtle means.
Dirt and dust wash by gently water stream and swipe only with wet or damp means in
the direction from top to bottom.
The recommended frequency of cleaning of polycarbonate part
is about 1 time per month or according to the actual degree of pollution.
Do not use detergents that could scratch the surface plates.
(abrasives, harsh fabrics, etc.)
Do not use solvents or alkaline detergents or cleaners with ammonia
(ammonium hydroxide).
Do not remove the impurities from the surface of the razor blades or other sharp items.
Do not clean cabine, when the polycarbonate plates are heated by the sun.
Do not use the squeegee, it could be scratched surface plates.
Do not clean the water current strength greater than 50 bar (WAP)
The manufacturer is not responsible for scratching the surface in case of failure to
comply with the above instructions.
All bolted connections of cab must be by user at regular intervals checked and
tightened.
POLARIS RANGER
800 XP
10
Kolpin Outdoors Inc.
205 N. Depot St.
Fox Lake, WI 53933
Detail views onto the roof holders.
METAL DOOR BASES (LEFT + RIGHT):
Uninstall the upper outer original screws from the rear safe cross on both sides.
Uninstall the bottom original screws from the rear UTV’s roller cage on both sides (in red ellipse).
POLARIS RANGER
800 XP
20
Kolpin Outdoors Inc.
205 N. Depot St.
Fox Lake, WI 53933
FRONT PANEL - (1-part):
Place the bottom metal windshield ledge onto the UTV’s body from the front side of the dashboard.
This ledge should lay on the UTV’s body on the rubber foam sealing.
Cut off the epdm according the dashboard
