komodo KDPTBCMPSHRA User manual

PORTABLE CAMPING
SHOWER
KDPTBCMPSHRA

2

3
• Read all instructions and safety warnings before using this product.
• Familiarise yourself with the controls of this product before first use.
• To ensure a long product life, follow the maintenance instructions specified in this user
guide
• Only use water within the temperature range of 10-50°C in the unit.
• This product contains small parts that may be a choking hazard.
• Do not leave appliance unattended. Switch the unit off and disconnect from the water
source when not in use.
• Do not use the shower with water from the ocean,muddy/dirty areas, pool water or
river water.
• Ensure the charger port is closed tightly before placing pump in water to avoid
damage.
• Ensure that the base of the pump is fully submerged in water before operation.
• When the device is being operated by children, ensure adult supervision is given.
• Recharge the pump using a power source with an output of 5V/0.5-2A. Using improper
voltage may result in damage to the motor and possible injury to the user.
• If this product or its power cord shows any signs of damage, cease use immediately
and contact help.Kogan.com for support.
• Before use, ensure that all screws are fully tightened.
• Keep the shower away from heat sources such as portable heaters or fires.
• Ensure the device does not freeze and is not exposed to freezing temperatures.
Freezing will damage the motor and power cord.
• This product does not contain any user serviceable parts, do not disassemble, or modify
this product in any way.
SAFETY & WARNINGS

4
Battery
• It’s recommended to charge the battery to 40%-50% (approximately 1 hour of charging)
after each use to maintain optimum battery health and prolong battery life.
• Charge the unit before using for the first time.
• If not in use, recharge the battery at least every 3 months.
• Do not charge with power exceeding 5V / 0.5-2A.
• Store away from high temperatures and flammable or explosive goods. Only charge at
room temperature. Avoid charging in a hot environment.
• Only use the charger cable provided with the unit.
• Do not charge the battery overnight or overcharge. Disconnect from the charger once
the battery is fully charged.

5
1
Pump
9
Outlet connector
2
Power switch
10
O-ring
3
Charging socket
11
Shower head
4
Socket cover
12
Shower head holder
5
Filter
13
Hook
6
Filter cover
14
Suction cup
7
Hose
15
USB charging cable
8
Inlet connector
OVERVIEW
1
2
4
3
5
6
7
8
9
10
11
12
13
14
15

6
1. Attach the inlet connector to the pump and
tighten by turning clockwise.
2. Insert the O-ring into the outlet connector.
3. Attach the outlet connector to the shower
head and tighten by turning clockwise.
Note:To avoid leakage, ensure all connections
are securely tightened.
ASSEMBLY

7
1. Immerse the pump into clean water.
2. Press the power button to the turn the pump
ON/OFF.
3. Secure the shower head in place using the
shower head holder and either the supplied
hook or suction cup.
OPERATION
IMPORTANT:
• Do not remove the pump from
water while in operation. Power
off the pump before removing
from water.
• Ensure the shower head is
securely mounted before use.

8
Charging the Pump
To protect the battery, the pump will automatically stop when voltage drops below 2.7V.
The battery will need to be charged before resuming operation.
1. Remove the pump from water and ensure it
is dry.
2. Open socket cover by turning anti-clockwise.
3. Insert the supplied USB charging cord into
the charging socket.
4. Connect the USB charging cord into a USB power adapter or a USB port in your
vehicle or computer. Note: Ensure the power supply does not exceed 5V/0.5-2A.
Charging indicator status:
• RED LED: Battery is being charged.
• BLUE LED: Battery is fully charged.
Notes:
• Do not turn the pump on while it is
charging.
• To avoid damage to the battery, ensure
the charging voltage does not exceed the
power rating marked on the unit

9
Remove the Shower Head
1. Stop the device by pressing the power
switch.
2. Disconnect the hose from the pump and
shower head. Drain any water from the
hose.
3. Remove the O-ring from the outlet
connector and store safely.
CLEANING & CARE

10
Cleaning the Filter
1. Remove the filter cover.
2. Clean the filter and filter cover with water
and a neutral detergent.
3. Replace the filter and filter cover.

11
Volt
3.7V
Maximum electric flow
2.0A
Water flow
4.0L/min
Power supply
Built-in lithium battery
Capacity of battery
2200mAh
Operating time
45~60min
Charging output
5V, 0.5-2A
Charging time
Approx. 2.5hr (varies depending on charger)
Disposal
This marking indicates that this product should not be disposed with other
household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources.
SPECIFICATIONS

12
Need more information?
We hope that this user guide has given you
the assistance needed for a simple set-up.
For the most up-to-date guide for your product,
as well as any additional assistance you may require,
head online to help.kogan.com
