Konic KDL43JT395A2 User manual

KDL43JT395A2

1

2

3

12
37
38
40
10
Media Menu 32
4

General Description
One Coaxial output
AV
5
One YPbPr input socket
Three HDMI inputs socket(HDMI 1.4)
One PC IN

Wall-mounted accessories(Optional)
Specifications And Accessories
PAL BG DK I
VGA support resolution
HDMI support resolution
640x480/800x600
2x8W
1920x1080
480P 570I/P 720I/P
KDL43JT395A2
75 W
43"
1920X1080
6
USB supported format
Media
MOVIE
COOK,MP2
MUSIC
File EXT.
Codec
Video Audio
.mpg
.avi
.ts
.mov
.mkv
.dat
.mp4
.vob
.rm/.rmvb
MPEG-1,MPEG-2
DivX,Xvid,MJPEG
MPEG-4,SP/ASP,H.263/H.264/H.265
MPEG-2,AVS,AVS+.HEVC
MPEG-4,SP/ASP,
H.263/H.264,HEVC
MPEG-1
MPEG-4 SP/ASP,H.263/H.264,HEVC
MPEG-1,MPEG-2
MPEG-2
RV30/RV40
MP3,WMA,
AAC,AC3,
PCM
.mp3/.wma/
.m4a/.aac MP3 / WMA / AAC
.jpg/.jpeg/
.bmp/.png
Progressive JPEG / Baseline JPEG / BMP /
Non-Interlaced / Interlaced
--
--

7
MENU
Source Select.
CH+
CH-
CH+/-:Select channel.
VOL+
VOL-
VOL+/-:Adjust Volume.
INPUT
AV IN: AV Input.
EARPHONE: Audio output fo external device.
RF: Connect to an antenna or cable TV system.
AUDIO:
HDMI1/HDMI2/HDMI3:
Connect the audio output connector on your computer.
5
8
9
10
3
1
HDMI2 HDMI3HDMI1
VGA
PC IN AV I N
5V 500mA
RF IN
DVB-S2 RF IN
DVB-T2
1
2
49 10
6
7
8
PC: Connect one end of the VGA cable to the computer 's VGA port, connect the other
end of the VGA cable to the VGA port on the TV, and tighten the screws clockwise at
both ends.
DVB- S2: Upgrade the original channel transmission capacity.

8
(Only DTV/ATV)
ENTER button
S·MODE button
P·MODE button
Press to select a sound mode.
Press to select a picture mode.

PVR setting
PVR
9

First Time Setup
RF AIR
RF CABLE
10
New Zealand

First Time Setup
11
Channel List
In the Antenna/Satellite/ATV press the OK key of the remote control,
display Channel List, press the yellow key to select DTV/Radio/Data/ATV.

12
33
Input Source
DTV
Cable
Satellite
ATV
AV
YPbPr
PC
HDMI1
HDMI2
HDMI3
Media
OK OK
DVB-C
PC:Connect one end of the VGA cable to the computer’s VGA port,connect
the other end of the VGA port on the TV,and tighten the screws clockwise at
both ends.

13

14

15

16

Auto Tuning
Photo 1 Photo 2
(1) Select option of Auto Tuning under the
sourcr of satellite and there will be different
operations you should know. As shown in
phorol,you can press OK to appear list and
choose one of satellite signal name under
circumstance of highlighted satellite option.
(2)The system provides three channel types
including free,scramble,all. You can set the
service type as DTV/Radio/All and scan mode
can be modified to preset/audio/blind screen
with right key. Click word of search and auto
tuning can start.
17

18
Satellite auto tuning setting
DVB-S manual tuning DVB-S
The concrete unicable setting includes userband/SRC Add.,frequency and position.
The userband have many options, such as 1/0, 2/1, 4/3, 7/6. The range of frequency
is wild and you can set according to your need. The position can change to A/B.

19
Press OK button to show satellite name list
and choose one when TV is in main manual
tuning. Scan mode can be modified to
preset/audio/blinnd screen. The system give
you three service type including free, scramble,
all. Please note that you are able to open/close
network scan. The unicable setting under
DVB-S manual tuning is same with auto tuning.
Satellite edit
(1)Choose one of satellite signal list and press OK button to enter setting interface. The orbit positions you can
select are just 019.2E and 019.2W.For LNB type, the system provides many options to fit your needs. You can
open one or close all about Diseqc. Diseqc1.0 can switch from LNB1 to LNB4. Diseqc1.1 can support LNB from
1 to 16. As motor, you should choose Diseqc kind and then set move position. You are able move audio from
east or west. If you don’t need it, you can set as stop.
The unicale setting is same with the circumstance of DVB-S auto tuning.
