KONICS KRN1000 SERIES User manual

© Copyright Reserved KONICS Co., Ltd. i
USER MANUAL

ii © Copyright Reserved KONICS Co., Ltd.

Preface
© Copyright Reserved KONICS Co., Ltd. iii
Preface
Thank you for purchasing KONICS product.
Please familiarize yourself with the information contained in the Safety Precautions section
before using this product.
This user manual contains information about the product and its proper use, and should be kept
in a place where it will be easy to access.

User Manual Guide
iv © Copyright Reserved KONICS Co., Ltd.
User Manual Guide
Please familiarize yourself with the information in this manual before using the product.
This manual provides detailed information on the product's features. It does not offer any
guarantee concerning matters beyond the scope of this manual.
This manual may not be edited or reproduced in either part or whole without permission.
A user manual is not provided as part of the product package.
Visit our web site (www.konics.com) to download a copy.
The manual's content may vary depending on changes to the product's software and other
unforeseen developments within KONICS, and is subject to change without prior notice.
Update notice is provided through out homepage.
We contrived to describe this manual more easily and correctly. However, if there are any
corrections or questions, please notify us these on our homepage.

User Manual Symbols
© Copyright Reserved KONICS Co., Ltd. v
User Manual Symbols
Symbol
Description
Supplementary information for a particular feature.
Failure to follow instructions can result in serious injury or death.
Failure to follow instructions can lead to a minor injury or product damage.
An example of the concerned feature's use.
※1 Annotation mark.

Safety Precautions
vi © Copyright Reserved KONICS Co., Ltd.
Safety Precautions
Following these safety precautions will ensure the safe and proper use of the product and
help prevent accidents, as well as minimizing possible hazards.
Safety precautions are categorized as Warnings and Cautions, as defined below:
Warning Failure to follow the instructions may lead to a serious injury
or accident.
Caution Failure to follow the instructions may lead to a minor injury
or accident.
Fail-safe device must be installed when using the unit with machinery that may cause
serious injury or substantial economic loss. (e.g. nuclear power control, medical equipment,
ships, vehicles, railways, aircraft, combustion apparatus, safety equipment, crime/disaster
prevention devices, etc.)
Failure to follow this instruction may result in personal injury, fire, or economic loss.
The unit must be installed on a device panel before use.
Failure to follow this instruction may result in electric shock.
Do not connect, repair, or inspect the unit while connected to a power source.
Failure to follow this instruction may result in electric shock.
Check the terminal numbers before connecting the power source.
Failure to follow this instruction may result in fire or burning the unit.
Lithium battery is used in the unit. Do not disassemble or burn the unit.
Failure to follow this instruction may result in explosion.
Do not touch the unit and terminals after cut off the power within 30 sec.
Failure to follow this instruction may result in electric shock.
Ground PE terminal individually and ground cable should be over AW G16 (1.25 mm2).
Failure to follow this instruction may result in electric shock.
Do not insert any objects at the openings of the unit.
Failure to follow this instruction may result in electric shock or personal injury.
Do not disassemble or modify the unit. Please contact us if necessary.
Failure to follow this instruction may result in personal injury, fire, or economic loss.
Do not use the unit outdoors.
Failure to follow this instruction may result in shortening the life cycle of the unit, or electric
shock.
When connecting the power input and relay output cables, use AWG20 (0.05mm2) cables
and make sure to tighten the terminal screw bolt above 0.74N.m to 0.90N.m.
Failure to follow this instruction may result in fire due to contact failure.
Use the unit within the rated specifications.
Failure to follow this instruction may result in shortening the life cycle of the unit, or fire.

Safety Precautions
© Copyright Reserved KONICS Co., Ltd. vii
Do not use loads beyond the rated switching capacity of the relay contact.
Failure to follow this instruction may result in insulation failure, contact melt, contact failure,
relay broken, or fire.
When connecting magnet contact as relay contact output load, attach a surge absorber at
contact coil.
Failure to follow this instruction may result in product malfunction.
Do not use water or oil-based detergent when cleaning the unit. Use dry cloth to clearn the
unit.
Failure to follow this instruction may result in electric shock, or fire.
Do not use the unit where flammable or explosive gas, humidity, direct sunlight, radiant heat,
vibration, or impact may be present.
Failure to follow this instruction may result in fire or explosion.
Keep dust and wire residue from flowing into the unit.
Failure to follow this instruction may result in fire or product damage.
Check the polarity before connecting cables.
Failure to follow this instruction may result in fire or explosion.
Check the polarity of the measurement input contact before wiring the temperature sensor.
Failure to follow this instruction may result in fire or explosion.
Check the connection diagram of this manual before supplying power.
Failure to follow this instruction may result in fire.
Do not touch terminal during dielectric or insulation resistance test.
Failure to follow this instruction may result in electric shock.
Use insulation transformer and noise filter power for too much noise from the power. Attach
noise filter on the grounded panel, etc. Use short cables for noise filter output part and
power terminal of the unit.
Failure to follow this instruction may result in product damage, malfunction by surge.
If power line and input signal line are close each other, install line filter for noise protection
at power line and use shielded input signal line.
Do not control the alarm output or measure the data during firmware update. Failure to
follow this instruction may result in malfunction. Alarm output, contact input, data
measurement do not operate normally.
After completing firmware update, check the complete message and turn OFF to ON the
power.
All parameter setting values are reset after firmware update. It may not operate as same
way with before updating operation.
Use voltage output of transmitter power output only for transmitter power. Failure to follow
this instruction may result in output module damage.
Do not press the touch screen by sharp or hard objects with excessive force.
To prevent inductive noise, separate cables of the unit from high-voltage line, power line.
Do not install inductive noise or power line closely. It may cause measurement error.
Install the unit at well-ventilated place to prevent over-heat and give space over 30mm
against wall.
Install the unit vertically.

Safety Precautions
viii © Copyright Reserved KONICS Co., Ltd.

Table of Contents
© Copyright Reserved KONICS Co., Ltd. ix
Table of Contents
Preface .............................................................................................................................iii
User Manual Guide ......................................................................................................... iv
User Manual Symbols ...................................................................................................... v
Safety Precautions .......................................................................................................... vi
Table of Contents ............................................................................................................ ix
1Product Introduction................................................................................. 11
1.1 Features............................................................................................................. 11
1.2 Components and accessories ...........................................................................12
1.2.1 Components ............................................................................................... 12
1.2.2 Accessories ................................................................................................ 12
1.3 Ordering information..........................................................................................13
1.4 Unit description ..................................................................................................14
1.4.1 Front part.................................................................................................... 14
1.4.2 Rear part .................................................................................................... 15
2Specifications............................................................................................17
2.1 KRN1000 ...........................................................................................................17
2.2 Input/Output .......................................................................................................18
2.3 Input type and range..........................................................................................20
3Dimensions................................................................................................21
3.1 KRN1000 ...........................................................................................................21
3.2 Panel cut-out......................................................................................................21
4Connections ..............................................................................................23
4.1 KRN1000 ...........................................................................................................23
4.2 Input/Output circuit.............................................................................................24
5Installations ...............................................................................................25
5.1 Environment.......................................................................................................25
5.2 Installation Method.............................................................................................26
5.3 USB to Serial driver ...........................................................................................27
5.3.1 Driver installation........................................................................................ 27
5.3.2 Check the driver ......................................................................................... 28
6Screen........................................................................................................29
6.1 Initial booting screen..........................................................................................29
6.2 Screen description .............................................................................................30
6.2.1 Status display part ...................................................................................... 30
6.2.2 Measurement value display part ................................................................ 32
6.2.3 Graph ......................................................................................................... 33
6.2.4 Pop-up menu.............................................................................................. 37
6.2.5 Virtual keyboard ......................................................................................... 38
6.2.6 Color........................................................................................................... 40

Table of Contents
x © Copyright Reserved KONICS Co., Ltd.
7Menu...........................................................................................................41
7.1 Display ...............................................................................................................42
7.1.1 History ........................................................................................................ 42
7.1.2 File History ................................................................................................. 44
7.1.3 Group Setting ............................................................................................. 45
7.1.4 Touch Calibration........................................................................................ 46
7.2 Status .................................................................................................................47
7.2.1 Alarm List.................................................................................................... 47
7.2.2 Event List.................................................................................................... 48
7.2.3 AO/DI Status............................................................................................... 48
7.3 Input CH Info......................................................................................................49
7.3.1 Input/Display............................................................................................... 49
7.3.2 Input Option ................................................................................................ 53
7.3.3 Alarm .......................................................................................................... 58
7.3.4 User Unit..................................................................................................... 60
7.4 Option Info. ........................................................................................................61
7.4.1 Alarm Output .............................................................................................. 61
7.4.2 Digital Input................................................................................................. 62
7.4.3 RS422/485 ................................................................................................. 63
7.4.4 Ethernet/USB ............................................................................................. 64
7.5 System Info........................................................................................................66
7.5.1 Date/Time ................................................................................................... 66
7.5.2 Reservation ................................................................................................ 67
7.5.3 Device......................................................................................................... 69
7.5.4 File.............................................................................................................. 70
7.5.5 Log In.......................................................................................................... 71
7.5.6 System Info. ............................................................................................... 72
7.6 Memory Info.......................................................................................................73
7.6.1 Memory Management ................................................................................ 73
7.6.2 Internal Memory ......................................................................................... 74
7.7 Screen Capture..................................................................................................75
7.8 Log OFF/Power OFF .........................................................................................76
8Integrated device management program (DAQMaster) .........................77
8.1 Overview ............................................................................................................77
8.2 Features.............................................................................................................78
8.3 Dedicated features for KRN1000 ......................................................................79
8.3.1 Record Backup........................................................................................... 80
8.3.2 Check backup data..................................................................................... 81
9Troubleshooting ........................................................................................83
9.1 Error message ...................................................................................................84

1Product Introduction
© Copyright Reserved KONICS Co., Ltd. 11
1Product Introduction
1.1 Features
KRN1000 is paperless recorder with LCD method to save recording data at SD / USB memory.
It displays trend graph, bar graph, or digital figures at TFT Color LCD.
Via RS422/485, Ethernet or USB device communication, it is available to set parameters,
transfer data as data logger functions for user convienent.
It supports several communication method and various input/output functions. It also provides
easy and convient graphic user interface (GUI) applying graphic display.
5.6-inch color TFT LCD (640×480) touchscreen display with excellent readability and
intuitive control interface
Supports 27 input types (thermocouple, RTD, analog voltage and current[shunt])
4 / 8 / 12 / 16 input channel models available
Various communication methods (RS422/485, Ethernet, USB) standard
25 to 250 ms high-speed sampling, 1 to 3600 s recording cycle
200 MB internal memory and external memory support (SD/USB up to 32 GB)
Store and backup internal data to external memory (SD/USB)
9 different graph types available
Various option input/output available: digital input (contact/non-contact), alarm output,
transmitter power output
Compact, space-saving design (rear length: 69.2 mm)

1 Product Introduction
12 © Copyright Reserved KONICS Co., Ltd.
1.2 Components and accessories
1.2.1 Components
KRN1000
Rear cover User manual
Brackets: 4 Resistance (250Ω)
Before using KRN1000, check the components.
If any component is left out or damaged, contact our company or seller.
KONICS service center: [phone] to 7
1.2.2 Accessories
Communication converter
SCM-38I
(RS232C to RS485 converter) SCM-US48I (USB to RS485 converter)
Use Autonics SCM-38I or SCM-US48I as communication converter.
SCM-38I (RS232C/RS485 converter) and SCM-US48I (USB/RS485 converter) are same
appearance.
LCD Touchscreen Paperless Recorder

1Product Introduction
© Copyright Reserved KONICS Co., Ltd. 13
1.3 Ordering information
KRN1000 - 04 0 1
-
0 S
①②③④⑤⑥
Category
Description
①Item KRN1000 Paperless recorder
②Input channels
04 4 channels
08 8 channels
12 12 channels
16 16 channels
③Option input/output
0 None
1 Alarm relay output 8 channels
2 Alarm relay output 6 channels
+ Digital input 2 channels
3 Alarm relay output 6 channels
+ 24VDC power output for transmitter
4 Alarm relay output 4 channels + Digital input 2 channels
+ 24VDC power output for transmitter
④Communication output 1 RS422/485 + Ethernet + USB Device
⑤Power supply 0 100-240VAC 50/60Hz
⑥Case S Standard panel installation type

1 Product Introduction
14 © Copyright Reserved KONICS Co., Ltd.
1.4 Unit description
1.4.1 Front part
1. Power indicator: Power turns ON and the red LED turns ON.
2. Screen: Measrued value is displayed as trand graph, bar bar graph, digital figures. (Refer to
‘6 Screen’)
3. Front cover: Open the front cover. There are power switch and, USB Host/Device, SD card
slot.
4. Power switch: Turn ON/OFF the power of KRN1000.
5. USB host port: Connect the USB memory.
It recognizes up to 32GB. When using extension cable, cable length should be up to 1.5m.
6. USB device port: Used for parameter settings.
7. SD card slot: SD card memory slot. It supports up to 32GB.
8. Stylus pen: Used for touching screen.
Do not connect the other USB devices except USB memory at USB host port.
1
3
2
4
6
7
5
8

1Product Introduction
© Copyright Reserved KONICS Co., Ltd. 15
1.4.2 Rear part
1. Sensor input terminal: Connects universal input.
2. Ethernet port: Connector for ethernet cable. It communicates Modbus TCP.
3. RS422/485 port: Connects RS422/485 for Modbus RTU communication.
4. Option input/output port: Connects for option input/output (digital input (non-contact/ contact),
alarm output, power for transmitter).
5. Power input: Power connection (100-240VAC 50/60Hz)
1
2
3
4
5

1 Product Introduction
16 © Copyright Reserved KONICS Co., Ltd.

2Specifications
© Copyright Reserved KONICS Co., Ltd. 17
2Specifications
2.1 KRN1000
Power supply 100-240VAC 50/60Hz
Allowable voltage range 85 to 110% of rated voltage
Power consumption Max. 23VA
Screen
Display method 5.6 inch TFT Color LCD
Resolution 640×480 pixels
Adjusting
brightness 3-level (Min/Standard/Max)
Input method Touch screen (Pressure sensitive type)
Number of input channels 4 / 8 / 12 / 16 channels
Universal input※1Temperature sensors (thermocouple, RTD),
Analog (voltage, current (shunt))
Sampling period 1 to 4-CH: 25ms/125ms/250ms,5to 16-CH: 125ms/250ms
(internal sampling period is average movement filter and alarm output
operation unit time)
Recording period 1 to 3600 sec
Internal memory Approx. 200MB
External memory SD / USB memory max. 32GB
Dielectric strength 2300VAC 50/60Hz for 1 min (between power terminals and case)
※Except ethernet and USB device
Vibration Mechanical 10 to 60Hz 4.9m/s
2
in each X, Y, Z direction for 1 hour
Malfunction 10 to 60Hz 1m/s
2
in each X, Y, Z direction for 10 min
Insulation resistance Over 20MΩ (at 500VDC megger)
Noise immunity Square shaped noise by noise simulator (pulse width 1µs) ±2kV
Time accuracy Within ±2 min/year (available up to 2099)
Protection structure IP50 (front part)
Environm
ent※2
Ambient
temperature 0 to 50℃, storage: -20 to 60℃
Ambient
humidity 35 to 85%RH, storage: 35 to 85%RH
Approval
Weight※3Approx. 1290 to 1400g (approx. 590 to 700g)
※1. For more information of universal input, refer to ‘2.2 Input/Output’.
※2. Environment resistance is rated at no freezing or condensation.
※3. The weight includes packaing. The weight in parenthesis is for unit only.

2 Specifications
18 © Copyright Reserved KONICS Co., Ltd.
2.2 Input/Output
Type
Input/Output
type
Description
Universal input
Input type
RTD JPt100Ω, DPt100Ω, DPt50Ω, Cu100Ω, Cu50Ω
(supplied current: approx. 190µA)
Thermocouple
B, C (W5), E, G, J, K, L, L (Russia), N, P, R, S, T, U
Analog
Voltage: ±60mV, ±200mV, ±2V, 1-5V, ±5V,
-1V-10V
Current: 0-20mA, 4-20mA (measureable when
using 250Ωshunt resistance)※1
Input
impedance Voltage (V): Approx. 205kΩ
RTD, Thermocouple, Voltage (mV): Min. 200kΩ
Display
accuracy※2
RTD
Warm-up time: Max. 30 min
At room temperature (25±5℃): ±0.1% F.S.±1-digit
Out of room temperature: ±0.2% F.S.±1-digit
Thermocouple
Analog
Resolution
16-bit
Option
input/output※3
Digital input
No-contact
input
ON: Residual voltage max. 1V
OFF: Leakage current max. 0.1mA
Contact input ON: Max. 1kΩ, OFF: Min. 100kΩ,
Short-circuit: Approx. 4mA
Alarm relay
output
Capacity 250VAC 3A,30VDC 3A, 1 Form A (resistive load)
Life cycle
Mechanical: Min. 20,000,000 operations
Electrical: 100,000 operations
(3A 250V AC, 3A 30V DC)
Power output
for
transmitter※4
24±2VDC, Max. 60mA
Built-in over current protection circuit
Comm.
output※5
RS422/485
Modbus RTU
※It is recommended to use shielded cable overAWG 24.
Ethernet
IEEE802.3 10 BASE-T /
IEEE802.3U 100 BASE-TX (Modbus TCP)
USB Device USB V2.0 Full Speed (Modbus RTU)
※1. Current measurement and connection examples
Connect 250Ωshunt resistance and set analog input type 0-20mA(shunt) / 4-20mA (shunt).
It is available to measure 0-20mA/ 4-20mA current.
Universal input
shunt resistance connection
method

2Specifications
© Copyright Reserved KONICS Co., Ltd. 19
※2. ◎At room temperature (23℃± 5℃)
RTD Cu50Ω (-200≤T≤200): (±0.1% F.S. or ±1.5℃, select the higher one) ±1-digit
RTD DPt50Ω (-200≤T≤500): (±0.1% F.S. or ±1.5℃, select the higher one) ±1-digit
Thermocouple R, S, C, G type (0≤T≤100): (±0.1% F.S. or ±4.0℃, select the higher one)
±1-digit
Thermocouple U, T type (-100≤T≤400): (±0.1% F.S. or ±2.0℃, select the higher one)
±1-digit
Thermocouple B type, below 400℃: There is no accuracy standards.
All thermocouples, below -100℃: (±0.3% F.S. or ±4.0℃, select the higher one) ±1-digit
◎Out of room temperature range
RTD Cu50Ω (-200≤T≤200): (±0.2% F.S. or ±3.0℃, select the higher one) ±1-digit
RTD DPt50Ω (-200≤T≤500): (±0.2% F.S. or ±3.0℃, select the higher one) ±1-digit
※3. Input/Output is different by option. Refer to ‘1.3 Ordering information’.
※4. For supplying power for transmitter, it is recommened to use shield cable to reduce noise.
※5. RS422/485, ethernet, USB device communication outputs are not used at the same time.
※If sensor input line is longer, it is recommended to use shield cable to reduce noise.
Before the wiring, turn OFF the unit.
Be sure that the polarity of power for transmitter. If not, it may cause product damage.
When supplying the over voltage at sensor input, it may cause product damage.

2 Specifications
20 © Copyright Reserved KONICS Co., Ltd.
2.3 Input type and range
Input type Display
Temperature range
℃℉K
Thermocouple
K (CA)
TC-K
-200.0 to 1350.0
-328.0 to 2462.0
73.2 to 1623.2
J (IC)
TC-J
-200.0 to 800.0
-328.0 to 1472.0
73.2 to 1073.2
E (CR)
TC-E
-200.0 to 800.0
-328.0 to 1472.0
73.2 to 1073.2
T (CC)
TC-T
-200.0 to 400.0
-328.0 to 752.0
73.2 to 673.2
B (PR)
TC-B
100.0 to 1800.0
212.0 to 3272.0
373.2 to 2073.2
R (PR)
TC-R
0.0 to 1750.0
32.0 to 3182.0
273.2 to 2023.2
S (PR)
TC-S
0.0 to 1750.0
32.0 to 3182.0
273.2 to 2023.2
N (NN)
TC-N
-200.0 to 1300.0
-328.0 to 2372.0
73.2 to 1573.2
C (TT)
※
1
TC-C
0.0 to 2300.0
32.0 to 4172.0
273.2 to 2573.2
G (TT)
※2
TC-G
0.0 to 2300.0
32.0 to 4172.0
273.2 to 2573.2
L (IC)
TC-L
-200.0 to 900.0
-328.0 to 1652.0
73.2 to 1173.2
L (Russian type)
※3
TC-L_R
0.0 to 600.0
32.0 to 1112.0
273.2 to 873.2
U (CC)
TC-U
-200.0 to 400.0
-328.0 to 752.0
73.2 to 673.2
Platinel
Ⅱ
TC-P
0.0 to 1350.0
32.0 to 2462.0
273.2 to 1623.2
RTD
Cu50Ω
CU50
-200.0 to 200.0
-328.0 to 392.0
73.2 to 473.2
Cu100Ω
CU100
-200.0 to 200.0
-328.0 to 392.0
73.2 to 473.2
JPt100Ω
JPT100
-200.0 to 600.0
-328.0 to 1112.0
73.2 to 873.2
DPt50
Ω
DPT50
-200.0 to 600.0
-328.0 to 1112.0
73.2 to 873.2
DPt100
Ω
DPT100
-200.0 to 850.0
-328.0 to 1562.0
73.2 to 1123.2
Analog
Voltage
-60.00-60.00mV
±60mV
Resolution: 10µV
-99999 to 99999
(display range depends on the
decimal point position.)
-200.00-200.00mV
±200mV
Resolution: 10µV
-2.000-2.000V
±2V
Resolution: 1mV
1.000-5.000V
1-5V
Resolution: 1mV
-5.000-5.000V
±
5V
Resolution: 1mV
-1.00-10.00V
-1V-10V
Resolution: 10mV
Current
(shunt)
0-20mA 0-20mA
(shunt)
—
4-20mA 4-20mA
(shunt)
—
※1. C (TT): Same as exisitng W5 (TT) type temperature sensor.
※2. G (TT): Same as existing W (TT) type temperature sensor.
※3. Russian L type temperature sensor is divided from general purpose L type.
