Koolatron TotalChef Manual

CLEANING AND MAINTENANCE
1. To clean the glass board, use a damp cloth or sponge.
DO NOT use anything abrasive to clean and DO NOT place device into
the sink with water pouring directly on it.
2. To clean the control board, use a damp cloth.
TROUBLE SHOOTING
Problem
The cooker stops after
continuous use but emits
squeaky sound for
about 30 seconds.
Solution
• Check if the pan is being used properly.
• Check if the pan is centered on the glass board.
• Check if the diameter of the pan base is
at least 12cm.
Problem
The heating stopped
suddenly when in use.
Solution
• Check if the temperature surrounding
the device is too high.
• Check if the air vent hole is blocked.
Problem
The temperature cannot
be controlled while
the product is on.
Koolatron International
Unit C3 Knights Park, Knight Road, Strood, Rochester
Kent, ME2 2LS, United Kingdom
Telephone: [phone] • Fax: [phone]
Solution
• Check if the base of the pan used is
flat enough.
• Check if the central part of the pan is sunken.
• Check if the heat indicator light is on.
ERROR CODES
The following codes may appear in the display panel (6):-
E1 or E2 There is a problem with the electronic control.
Turn off the unit, wait a few minutes and start again.
E3 or E4 The unit is over-heating.
Turn off the unit, allow it to cool down and then recommence operation.
E5 Check the power supply, there is a lack of required voltage
E6 Check the power supply, the voltage is too high for the unit.

Thanks for purchasing our Total Chef Induction Hob . Please
take the time to read through the instructions provided. If you
have any questions or requests, please do not hesitate to
contact our customer service phone line at (0) 1634 29 7383.
TABLE OF CONTENTS
INTRODUCTION
The Total Chef Induction Hob contains a smooth heat-resistant
glass hob surface. The heating elements are located beneath
the glass. With this technology, there are many reasons to use
the Total Chef Induction Hob.
Safety - the temperature of the glass top remains low. With an
induction hob, the heat necessary for cooking the food is pro-
duced directly into the pan; the glass hardly heats up at all, as it
only receives the heat from the pan placed on it. If there is no
saucepan on the hob but the power is on, the surface will not
heat up until a suitable saucepan or pot is placed on the hob.
Precision cooking control - the Induction Hob contains cooking
zones so accurate it is possible to create a constant low temper-
ature for long periods of time, so that soups and casseroles can
simmer away without the likelihood of them sticking to the bot-
tom of the pan.
Induction hobs are also fast at being capable of reduced cook-
ing times, and because there is no heat wasted, they use con-
siderably less energy than other hobs.
This device is more economical than a conventional hob when
a pan is lifted off, the zone stops heating immediately.
•1• •2•
Introduction…………………….................…………...........………..2
Product Specifications………...………..…………………..………..3
Usage……………….......................................…..…………............4
Control Panels.......................………….......…..……………...…….5
Pan Selection………….......…..……………...……......................5-6
Safety Features…………………………........……….……....……...6
Cleaning and Maintenance……………………...…….…back cover
Error Codes……………………...…….…........................back cover
Trouble Shooting…………..…………..….......................back cover

CONTRAST OF ELECTRICITY AND GAS CONSUMED
Heating
Method
Rated
Power
Thermal
Efficiency
Time for
Boiling 1L
Water
Electricity
(gas)
Total
Chef
Induction
Hob
Liquid
Gas
1600W
1800W
2000W
93%
93%
93%
3min 18sec
3min 10sec
2min 20sec
0.078kw
0.11 kw
0.11 kw
53% 5min 9.895kw
NAME OF PARTS
USAGE
THERE ARE TWO WAYS TO COOK YOUR FOOD
1. Set by TEMPERATURE
- Turn unit on at mains power, power indicator (1) will illuminate.
- Press on/off switch (2).
- Press function button (3) once.
- Small light on left side (7) will illuminate.
- Select which TEMPERATURE you wish to cook at by pressing the low
or high button (4) or (8) and read off from the bottom row of settings (11).
- Food will cook at the temperature selected.
- You can change the temperature at any time with the low or high buttons.
2. Set by MODE
- Turn unit on at mains power, power indicator (1) will illuminate.
- Press on/off switch (2).
- Press function button (3) twice.
- Small light on right hand side (5) will illuminate.
- Select which MODE you wish to cook at by pressing the low or high
button (4) or (8) and read off the MODE from the top row of settings(10).
- Food will cook within the constraints of the mode you have selected and will
be automatically controlled to ensure that the heat is constant for that mode.
- The temperature reading underneath the Mode setting has no relevance
when cooking using Mode settings.
- You can change the required mode at any time with the low or high buttons.
TIMER
- When the unit is switched on the Timer can be operated.
- Depress the ‘timer’ button (9) for each minute you require – up to 99 minutes.
- Depressing and holding the timer button will speed up the indicator on
the Timer display (6) to your required time.
- The Timer will count down once you have left it on your desired setting.
- When timing has finished, the unit will bleep once and turn itself off.
Rated Power 2000W
Setting Range of Power 200--2000W
Setting Range of Temperature 70-240˚C
Rated Voltage 240V/50Hz
PRODUCT SPECIFICATIONS
•3• •4•

PAN SELECTION
1. The diameter of the bases of any applicable pans and containers (enamel,
matrix and stainless iron) should be between 12cm and 22cm, and the bases
must be flat.
2. Kinds of inapplicable pans and containers:
• Containers and pans made of aluminum, copper, pottery, porcelain or glass.
• Containers and pans, of which the bases are not flat enough.
SAFETY FEATURES
Do not hit the glass board. Do not use the Induction Hob near
water to prevent malfunctions.
Do not heat sealed containers
like cans, which may explode.
Do not use the Induction Hob
close to a heat source like a gas
cooker or stove.
Do not heat with empty pan. Place cooker at least 10 cm
from the wall.
After use of the Induction Hob,
please do not touch the glass
board.
Do not heat indirectly with paper
or cloth on the board in order
to avoid combustion caused by
excessive temperature of the pan base.
•5• •6•
bottom
Footed pan bottom
(1) Operating indicator – unit is ready to commence
(2) On/Off switch – used to turn unit on after unit is plugged into mains,
or to turn unit off at any time during operation.
(3) Function Button – press once for cooking with desired Temperature,
or press twice for cooking at desired Mode.
(4) High button – to move up temperature settings or Mode Settings
(5) Indicator light to show unit will cook in Mode settings
(6) Time display (also shows error messages – see below)
(7) Indicator light to show unit will cook at Temperature settings
(8) Low button – to move down temperature settings or Mode Settings
(9) Timer key – depress to achieve desired timer setting
(10) Mode indicator panel
(11) Temperature indicator panel
CONTROL PANEL
10
9 8 7 6 5 4 3 2
11 1
