SECOMAT Laundry dryer 75–200
Operating instructions
V.2017.00

Legal notice
These operating instructions were published by
Krüger +Co. AG
Winterhaldenstrasse 11
CH-9113 Degersheim
T 0848 370 370
[e-mail]
www.krueger.ch
Allrights,includingthatoftranslation,reserved.Reproductionofanykind,e.g.photocopying,
storage on microfilm or capture in electronic data processing systems, requires the written
agreement of the publisher. Reprinting, in part or in whole, is prohibited. These operating
instructions correspond to the technical state of the product at the time of printing. We
reserve the right to modify the technology and equipment.
© Krüger +Co. AG
These operating instructions contain important information regarding initial use
and handling. Please observe them in full even when you pass the device on to a
third party, and store them for reference at a later date.


3Legal notice
5Key
6Introduction
7Safety notices
8Operating instructions
Intended use
Description of system
Transport
Storage
Installation
9Fitting the washing line
10 Operation
Function keys
Starting up
Choosing the appropriate
drying programme
11 Dehumidifying
Manual mode
Optional additional heating
12 Cleaning
Disposal
13 Faults
14 Technical data
15 Mounting SECOMAT 75
17 Mounting SECOMAT
100/150/200
Table of contents


Key
1Exhaust opening with slats
2Operating unit
3Flufilter
4Intake opening
5Water drain with ¾-inch thread
6Reset button (behind filter opening)
1
2
63
4
5


Congratulations on purchasing our product.
Please read the operating instructions in full before using the dryer. Pay particular atten-
tion to all safety notices. Our device is EMC-tested and satisfies the requirements of the
current European and national guidelines. CE conformity has been demonstrated, and the
manufacturer holds the corresponding declarations.
If you have any questions, do not hesitate to contact our technical support team:
Tel. [phone] or [phone]
Fax [phone]
[e-mail]
www.krueger.ch
Dear customer


WARNING! Dangerous for children and others!
This appliance can be used by children aged from 8 years and above and persons with re-
duced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without supervision.
1. The device may only be installed in line with the national connection conditions.
2. Never place fingers or objects in the device openings. Risk of injury!
3. Always switch the device o when it is not being used. Do not allow the electric cable to
come into contact with a hot surface.
4. Disconnect the mains plug in the event of faults and before cleaning and maintenance.
5. Never disconnect the plug from the socket by pulling the mains cable or by touching
with wet hands.
6. Never pull the device by the mains cable.
7. Do not pull the mains cable over sharp edges and be sure not to pinch it.
8. Do not start up the device (disconnect mains plug immediately)
If damaged.
If you suspect a defect after the device has been dropped or similar. In these cases,
have the device checked by a (refrigeration) specialist and repaired if necessary.
If the mains cable is damaged. In this case, the manufacturer, the manufacturer’s
customer service or another qualified specialist must replace it.
9. Never use the device in standing water! Before stepping into a puddle, first disconnect
the device or unscrew the fuse.
10. Do not place heavy objects on the device and do not sit on it.
11. We assume no liability for any damage if the device is used for anything other than
its intended function or is incorrectly operated or not properly repaired. Your warranty
claim ceases to apply in such cases.
Safety notices


Operating instructions
Intended use
This device is designed specifically for drying laundry. The room-dehumidifying function
can also be used to keep rooms dry.
Description of system
The SECOMAT produces dry air that it blows onto the laundry by means of a ventilator.
The items of laundry release humidity into the ambient air. The damp air is absorbed by the
device and passes over the cooled surface of the cooling unit, where the steam condenses.
The condensed air is then taken to a container or siphon outlet via the collecting tray. The
dry air is warmed back up to the original room temperature in the warm part of the cooling
unit before being blown out via the ventilator.
Transport
Always transport the device upright. This prevents damage to the compressor and damage
in transit.
Storage
If you do not intend to use the device for a long time, you must clean the water bucket and
housing before taking into storage. It is then best to pack the device in its original box.
Installation
1. Mount the fixing rail supplied to the wall 55 centimetres below the drying rack.
2. Hang the device from this rail and secure it against accidental removal with screws to
the left and right.
3. Make sure the device is correctly aligned vertically and horizontally. Use a spirit level to check.
4. Keep a safety clearance of 8 centimetres from any flammable materials. The mains plug
must still be easily accessible after mounting.
Room temperature of normal version: min. +10°C, max. +30°C
Room temperature of version with additional heating: min. +5°C, max. +30°C
If water is collected in the bucket, it must be emptied regularly. Depending on the temperature
and humidity of the air, the bucket may fill once or twice a day. Water damage will occur if
the bucket is not emptied.
Attaching the hose
1. Fit the connecting piece (straight or angled) to the thread on the bottom of the device.
2. Pull the hose over the connecting piece.
3. Insert the end of the hose into the outlet pipe (preferably siphoned).
Where possible, lead the water away directly.


To achieve optimum drying results, please mount the washing line as follows:
Wrong
The washing is hanging across the dryer, obstructing the air flow and making the washing
hanging behind dry much more slowly.
Good
The air can circulate and reach even the items at the back.
Optimal
The radial line system developed by Krüger is perfect for the condensation drying method
and achieves the shortest drying times.
Make sure there is at least 0.5 metre between the outlet opening and the nearest piece of
washing.
Fitting the washing line
Minimum distance
to washing 0.5m
Minimum distance
to washing 0.5m
0.5m
0.5m


Function keys
1Standby with red fault indicator
P1 Low washing drying level
P2 Medium washing drying level
P3 High washing drying level
P4 Room dehumidifying (blue LED display)
Starting up
1. Close windows and doors
2. Check that the cleaned filter is inserted correctly
3. 1Press standby
4. P1 P2 P3 Select programme selector key for dryness level
Choosing the appropriate drying programme
The programme can be selected to suit your needs.
P1 low washing drying level
Short drying time, the laundry retains residual humidity and is therefore easy to iron.
P2 medium washing drying level
Medium drying time, the laundry is dry but may still retain some residual humidity.
P3 high washing drying level
Longer drying time, the laundry is bone dry and can be folded immediately.
The air humidity in the drying room depends on the season. During the dry winter months,
the device may turn o too soon. In this case, please switch to a higher level (P2 or P3).
During the damp summer months, the device may stay on for longer than necessary. In this
case, please select a lower drying level (P2 or P1).
The laundry dryer operates fully automatically. In other words, it dehumidifies for as long
as the humidity in the room is above the set level of dryness. As soon as the desired level
of humidity has been reached, dehumidification is interrupted. If the room humidity rises
again, the device automatically switches back on. This process is repeated as often as
Operation
1P1 P2 P3 P4


necessary until the desired level of dryness has been reached. The device then switches
o permanently. If you want to turn the device on again, you have to restart it by hand.
Dehumidifying
P4 The room dehumidifying function can be switched on and o independently of the
laundry drying function using the room dehumidifying button. When the function is activat-
ed, the blue LED display flashes. If the room dehumidifier function is active and the laundry
dryingfunctionisswitchedon,thenthiscontrolsthedehumidifierfunction.Oncethelaundry
drying programme is complete, the unit automatically reverts to the dehumidifier function.
This function remains active until it is switched o manually.
Manual mode
The manual mode can be used to dry one or a few items of washing. If you press and hold
down one of the three function keys stated below for 5 seconds, automatic mode is activated
for a defined time:
P1 Manual mode for 30 minutes
P2 Manual mode for 60 minutes
P3 Manual mode for 90 minutes
When manual mode is activated, the LED on the relevant function key flashes. Once the defined
time has passed, the device switches o and manual mode is automatically deactivated.
Optional additional heating
In very cold drying rooms, the additional heating function can be used to enhance the drying
function (see technical data on page 68). When you purchase the H model, this additional
heating function has already been installed by the factory. It can be retrofitted to the normal
version for an extra charge.
If room temperature is less than +14°C, the additional heating switches on automatically
and helps to heat up the dry air. If room temperature reaches +16°C, the heating element
switches o automatically. The heating capacity is adjusted according to the volume of air.


Cleaning
Cleaning the device:
1. Wipe the housing with a damp cloth.
2. Pull the air filter up and out of the device (hold on the left and right side).
3. Dust the air filter with a brush and insert again.
Internal cleaning is needed if the device is very dirty. This maintenance work must be
undertakenbyarefrigerationspecialist. Failuretoundertakethemaintenancework required
may result in a device defect. Defects caused by failure to undertake maintenance work are
excluded from warranty claims – especially if the filter has not been cleaned, resulting in the
device overheating. To ensure a long service life and trouble-free operation, we recommend
taking out a maintenance contract.
Disposal
The dehumidifier is filled with a refrigerant. It therefore requires special disposal. Please
contact your dealer or the local waste disposal facility.


Before contacting the fault service team, please consult the following questions:
If the device is not running
Is the mains plug correctly plugged in?
Is the electric box’s fuse OK?
Is the mains cable OK?
If the device is running constantly
Are the doors and windows closed?
Can humidity be originating from other sources?
Has the correct drying programme been selected (see page 64: Choosing the
appropriate drying programme)
If the device is providing unsatisfactory dehumidification
Is the air circulating in the room?
Are the intake and exhaust openings unobstructed?
Is the room temperature too high or too low (see page 62)?
Is the filter clean?
Is there at least 0.5 metre between the outlet opening and the first piece of washing?
Are only a few or single items of washing hanging up? (see page 65: Manual mode)
Blinken der roten LED
If the red fault lamp is flashing, the device is interlocked. Each fault has its own flash code.
In other words, depending on the type of error, the lamp will flash at a dierent frequency.
Establish the fault code and take a note of it before pressing the reset button (see page 59,
no. 6) behind the filter. If the interlock cannot be reset despite several attempts, please
contact the fault service team. Tell them the error code as well as the article no. and serial
no. that can be found on the identification plate on the front left-hand side of the device.
This will help to considerably improve troubleshooting.
Faults


Technical data
Technical data
SECOMAT 75 100 150 200
Model without additional heating
Quantity of laundry
according to standard*
7.5 kg 10.0kg 15.0 kg 20.0kg
Energy eciency class AAAA
Drying capacity
according to standard*
1.36kg/h 2.98kg/h 3.17kg / h 3.08 kg/h
Drying time according
to standard*
5h 36min 3h 24min 4h 36min 6h 18min
Sound pressure level
according to standard*
64 dB(A) 71 dB(A) 69 dB(A) 65 dB(A)
Dim. W×H×D (mm) 565 × 620×330 655×670×395 655 ×670×395 655×670× 395
Weight 39kg 47kg 47kg 47 kg
Voltage 230 V /50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz
Power consumption
without additional
heating**
345 W 989 W 989 W 989 W
Current consumption
without additional
heating**
1.5 A 4.3 A 4.3 A 4.3 A
Fuse protection
(slow-blow)
6.0 A 10.0 A 10.0 A 10.0 A
Refrigerant (CFC free) R134a R407c R407c R407c
Model with additional heating
Voltage 230 V /50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz
Max. heating capacity 1350 W 1350 W 1350 W 1350 W
Max. power
consumption***
1695 W 2340 W 2340 W 2340 W
Max. current
consumption
7.5 A 10.3 A 10.3 A 10.3 A
Fuse protection
(slow-blow)
10.0 A 13.0 A 13.0 A 13.0 A
Start-up temperature +14° C +14° C +14° C +14° C
Cut-o temperature +16° C +16° C +16° C +16° C
* Energy testing method for ambient air laundry dryers (HSLU Lucerne School of Engineering and Architecture,
Horw/Lucerne)
** at +20° C/60% relative humidity
*** varies depending on the volume of air


Mounting
SECOMAT 75


¾-inch condensation
connection


Mounting
SECOMAT 100/150/200


¾-inch condensation
connection




