Kunft KWM5316 User manual

instructions manual
manual de instrucciones
manual de instruções
washing machine
KWM5316
7 Kg

2 3
KWM5316
EN
washing machine
Dear client,
Thank you for purchasing this product.
The quality of this appliance has been certied by several
laboratory tests. This instructions manual is provided
to simplify the use of the appliance as well as to guarantee
a safe use.
Please read carefully the instructions and safety measures
described in this manual.
We sincerely hope you will be satised when using
your new appliance.
INDEX
1. SAFETY INSTRUCTIONS...................................... 4
1.1. Power Supply ................................................. 5
1.2. Power Cord and Other Cables........................ 5
1.3. Humidity and Water ........................................ 6
1.4. Cleaning.......................................................... 6
1.5. General Precautions ....................................... 6
2. OPERATING INSTRUCTIONS............................. 12
2.1. Product Description....................................... 12
2.2. Product usage............................................... 12
2.3. Maintenance ................................................. 24
2.4. Troubleshooting ............................................ 27
3. TECHNICAL SPECIFICATIONS........................... 28
4. POST-SALE SERVICE......................................... 32
5. ENVIRONMENTAL PROTECTION ...................... 32

4 5
KWM5316
EN
washing machine
1. SAFETY INSTRUCTIONS
WARNING
Risk of Electric Shock
Do Not Open
Warning: to avoid the risk of electric
shock, do not remove the cover.
The interior does not contain any parts
that can be repaired by the user.
Ask for assistance from the Customer
Support Service.
Important Warnings
Before using your appliance read these ins-
tructions manual carefully and keep it in a
safe place as you may need to consult it in
the future.
Before turning on your appliance, and to
ensure a safe and correct operation, do not
use if:
- It has fallen to the ground;
- You notice any evidence of damage;
- Any anomaly occurs during its operation.
To avoid hazards or deterioration of your ap-
pliance through incorrect use it is advisable
to read these instructions thoroughly.
Your appliance should not be used for other
purposes than the ones intended and sole-
ly for household use. Any damage resulting
from using the appliance outside this scope,
any incorrect use, as well as any manual
modications to the product will not be co-
vered and automatically voids the warranty.
Assistance
In case of malfunction, take your appliance to
the Customer Support Service for assistance.
This appliance can be used by chil-
dren from the age of 8 and by pe-
ople with reduced physical, senso-
rial or mental capabilities and / or
lack of experience and knowledge
if they have been given instructions
on using the appliance safely and
if they understand the hazards in-
volved. Children may not play with
the appliance. Cleaning and main-
tenance must not be carried out by
children without supervision.
These instructions are also available
at www.suporteworten.pt
1.1. Power Supply
Make sure the main voltage is compatible with
the appliance’s. If this is not the case, please
consult the Customer Support Service.
1.2. Power Cord and Other Cables
Do not tangle the cord or pull it to discon-
nect the appliance. Also, keep the cord
away from warm surfaces.

6 7
KWM5316
EN
washing machine
Never use the appliance if it has a damaged
cable or socket.
Take it to the Customer Support Service for
replacement.
1.3. Humidity and Water
Do not use your appliance in humid places.
Do not allow the appliance to become wet
under any circumstances as this may be
dangerous. To avoid re hazard or electric
shock do not expose your appliance to humi-
dity or water. Furthermore, do not place your
appliance under water (e.g. for cleaning).
1.4. Cleaning
Before cleaning, be sure to switch off the ap-
pliance and remove the plug from the main
power supply. Always allow the unit to cool
down before cleaning.
To clean the exterior of the product, use a
dry soft cloth only.
1.5. General Precautions
• Please follow the instructions in the user
manual which will help you to properly ins-
tall and operate this product and enjoy its
advanced features. Please keep the ins-
tructions for future reference.
• Read all instructions before using the pro-
duct.
• Maintenance and service operations are
only to be carried out by authorized pro-
fessionals.
• Any damage caused by manual modica-
tions to the product is not covered by the
warranty.
• If this product is used for other purposes
than the ones originally intended, or if it is
not correctly connected, the product may
become damaged and the warranty will be
voided.
• For your safety, the information in this ma-
nual must be followed to minimize the risk
of re or explosion, electric shock, or to
prevent property damage, personal injury
or loss of life. Explanation of the symbols:
Warning!
This combination of symbol and signal word
indicates a potentially dangerous situation
which may result in death or serious injuries
unless it's avoided.
Caution!
This combination of symbol and signal word
indicates a potentially dangerous situation
which may result in slight or minor injuries
or damage to property and the environment.
Note!
This combination of symbol and signal word
indicates a potentially dangerous situation
which may result in slight or minor injuries.
Warning! Electric shock!
• If the supply cord is damaged, it must be

8 9
KWM5316
EN
washing machine
replaced by the manufacturer, Customer
Support Service or similarly qualied per-
sons in order to avoid a hazard.
• The new hose-sets supplied with the wa-
shing machine are to be used and that old
hose-sets should not be reused.
• Before any maintenance the device, un-
plug the washing machine from the mains.
• Always unplug the machine and turn off
the water supply after use. The max. in-
let water pressure is provided in pascals.
The min. inlet water pressure is provided
in pascals.
• For your safety, the power plug must be
inserted into an earthed three-pole socket.
Check carefully and make sure that your
socket is properly and reliably earthed.
• Make sure that the water and electrical
devices must be connected by a quali-
ed technician in accordance with the
manufacturer's instructions and local safe-
ty regulations.
Risk to children!
• Children of less than 3 years should be su-
pervised to ensure that they do not play
with washing machine.
• Animals and children may climb into the
machine. Check the machine before every
operation.
• Kids should be supervised that they do not
play with the washing machine.
• Glass door may be very hot during the ope-
ration. Keep kids and pets far away from
the machine during the operation very wet
rooms as well as in the rooms with explo-
sive or caustic gas.
• Remove all packages and transport
bolts before using the washing machine.
Otherwise, serious damage may result.
• Plug must be accessible after installation.
Risk of explosion!
• Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or dabbed
with combustible or explosive substances
(such as wax, oil, paint, gasoline, degrea-
sers, dry-cleaning solvents, kerosene, etc.)
This may result in re or explosion.
• Beforehand thoroughly rinse items of wa-
shing by hand.
Caution!
Installing the product!
• This washing machine is for indoor use
only.
• This washing machine isn't intended for
built-in using.
• The openings must not be obstructed by a
carpet.
• The washing machine shall not be instal-
led in a bathroom or very wet rooms, nor
in rooms with explosive or caustic gases.

10 11
KWM5316
EN
washing machine
• The washing machine with single inlet val-
ve only can be connected to the cold-water
supply. The washing machine with double
inlet valves should be correctly connected
to the hot water and cold-water supply.
• The plug must be accessible after installa-
tion.
• Remove all packages and transport
bolts before using the washing machine.
Otherwise, serious damage may result.
Risk of damaging washing machine!
• Your washing machine is for household
use only and is only designed for textiles
suitable for machine washing.
• Do not climb up and sit on top cover of the
washing machine.
• Do not lean against the washing machine
door.
• Cautions when handling the washing ma-
chine:
1. Transport bolts should be reinstalled in
the washing machine by a specialized
person.
2. Accumulated water must be drained out
of the washing machine.
3. Handle the washing machine carefully.
Never hold each protruded part on the
washing machine while lifting it. The
washing machine door cannot be used
as the handle during conveyance.
4. This washing machine is heavy. Trans-
port with care.
• Please do not close the door with excessi-
ve force. If you nd it difcult to close the
door, please check if the clothes are put in
or distributed well.
• It is forbidden to wash carpets.
Operating the washing machine
• Before washing the clothes for the rst
time, the washing machine must run for
one cycle without the clothes inside.
• Flammable and explosive or toxic solvents
are forbidden. Gasoline and alcohol etc.
Shall not be used as detergents. Please
only select the detergents suitable for ma-
chine washing, especially for drum.
• Make sure that all pockets are emptied.
Sharp and rigid items such as coin, broo-
ches, nails, screws or stones etc. may
cause serious damages to this washing
machine.
• Please check whether the water inside the
drum has been drained before opening its
door. Please do not open the door if there
is any water visible.
• Be careful not to get burn when the wa-
shing machine drains hot washing water.
• Never rell the water by hand during wa-
shing.
• After the programme is completed, please
wait for two minutes to open the door.

12 13
KWM5316
EN
washing machine
2. OPERATING INSTRUCTIONS
2.1. Product Description
1. Rigid, dry, and levelled surface
2. Avoid direct sunlight
3. Sufcient ventilation
4. Room temperature above 0° C
5. Keep far away from heat sources
Unpacking the washing machine
Warning!
• Packaging material (e.g. lms, Styrofoam) can be
dangerous for children.
• There is a risk of suffocation! Keep all packaging
far away from children.
1. Remove the cardboard box and Styrofoam
packing.
2. Lift the washing machine and remove the base packing. Make
sure the small triangle foam is removed with the bottom one
together. If not, lay the washing machine down on its side, then
remove the small foam from the unit bottom manually.
3. Remove the tape securing the power supply cord and drain hose.
4. Remove the inlet hose from the drum.
Removing the transport bolts
Warning!
• You must remove the transport bolts from the back of the washing
machine before using it.
• You will need the transport bolts again if you move the product, so
make sure you keep them in a safe place.
Please take the following steps to remove the
bolts:
1. Loosen the 4 bolts with a spanner and then
remove them.
2. Plug the holes with transport hole plugs.
3. Keep the transport bolts for future use.
Levelling the washing machine
Warning!
• The lock nuts on all four feet must be screwed tightly against the
housing.
1. Check if the legs are closely attached to the cabinet. If not,
please turn them to their original positions and tighten the nuts.
2. Loosen the lock nut by turning the feet until they are in close
contacts with the oor.
Note!
• The product line chart is for reference only, please refer to real
product a standard.
Accessories
Transport
hole plug
Supply hose
cold water
Supply hose
hot water
(optional)
Drain hose
support
(optional)
Owner’s
manual
2.2. Product usage
Installation area
Warning!
• Stability is important to prevent the washing
machine from moving!
• Make sure the washing machine does not stand on
the power cord.
Before installing the washing machine, the location characterized as
follows must be selected:
Water supply hose
Top cover
Control Panel
Power supply cord
Drum
Service lter
Drain hose
Detergent dispenser
Door

14 15
KWM5316
EN
washing machine
3. Adjust the legs and lock them with a spanner and make sure the
washing machine is steady.
Connecting the water supply hose
Warning!
• To prevent leakage or water damage, follow these instructions!
• Do not kink, crush, modify or sever the water inlet hose.
• For the model equipped with a hot valve, connect it to hot water
tap with hot water supply hose. Energy consumption will decrease
automatically for some programmes.
Connect the inlet pipe as indicated. There are two ways to connect
the inlet pipe.
1. Connection between ordinary tap and inlet hose.
Loosen the clamp nut and tighten the clamp nut’s four bolts. Press
the slide bushing and then connection it by inserting the inlet hose
into the connecting base
2. Connection between screw tap and inlet hose.
Tap with threads and inlet hose Special tap for washing machine
Connect the other end of inlet pipe to the inlet valve at the back of the
washing machine and fasten the pipe tightly clockwise.
water inlet valve water supply hose
Drain Hose
Warning!
• Do not kink or protract the drain hose.
• Position the drain hose properly, otherwise damage might result
due to water leakage.
There are two ways to place the end of drain hose:
1. Put it into the water trough
2. Connect it to the branch
drainpipe of the trough.
Note!
• If the machine has a drain hose support, please install it as follows.
Warning!
• When installing the drain hose, x it properly with a rope.
• If the drain hose is too long, do not force it into the washing machine
as it will cause abnormal noises.
Quick Start
Caution!
• Before using the washing machine, please make sure it's installed
properly.
• Before using the washing machine for the rst time, run it for one
cycle without the clothes inside.

16 17
KWM5316
EN
washing machine
Before Washing
Plug in Open tap Load Close door Add
detergent
Note!
• Detergent must be added to “Compartment I” after selecting pre-
washing for washing machines with this function.
Washing
Washing
Select
Programme
Select function
or default
Start up
Note!
• If the default setting is selected, step 2 can be skipped.
After Washing
When the cycle nishes, the message “End” is displayed.
Before Each Washing
• The working condition of the washing machine should be (0-40)° C. If
used under 0° C, the inlet valve and draining system may be damaged.
If the washing machine is worked at 0° C or less, then it should be
transferred to a room with a normal room temperature to ensure the
water supply hose and drain hose are not frozen before use.
• Please check the labels and the instructions on how to use the
detergent before wash. Use non-foaming or less-foaming detergent
suitable for machine washing properly.
Check the label Take the items out
of the pockets
Knot the long strips,
zip or button
Put small clothes
into the pillowcase
Turn easy-pilling
and long-pile fabric
inside out
Separate clothes
with different
textures
Warning!
• When washing a single item of clothing, the washing machine may
move / shake a lot and display a ‘great unbalance’ alarm. Therefore,
it is suggested to add one or two more clothes to be washed
together so that draining can be done smoothly.
• Don't wash clothes with kerosene, gasoline, alcohol and other
ammable materials.
■Detergent Dispenser
Pre-Wash detergent
Main Wash detergent
Softener
Pull out the dispenser
Caution!
• Detergent only need to be added in “case I” after selecting pre-
washing for washing machines with this function.
Programme Programme
Cotton Bulky / Bedlinen
Synthetic Baby Care
Mix Wool
Jeans Sport Wear
Spin Only Rapid 45'
Rinse & Spin Quick 15'
ECO 40-60 Intensive
20° C
Means must Means optional

18 19
KWM5316
EN
washing machine
Note!
• Before adding agglomerated or ropy laundry detergent or additive
to the detergent dispenser, we recommend using some water to
dilute it to prevent the inlet of the detergent dispenser from being
blocked and overowing while lling with water.
• Please choose a suitable detergent for the various washing
temperatures to get the best washing performance with less water
and energy consumption.
Control Panel
    
Note!
• The chart is for reference only. Please refer to real product as
standard.
1. On / Off
Press this button to switch the washing machine On / Off.
2. Start / Pause
Press this button to start or pause the washing cycle.
3. Option
Press this button to select an additional function. It will light up
when selected
4. Programmes
Press this button to select of the many available washing
programmes.
5. Display
The display shows the settings, estimated time remaining, options
and status messages for your washer. The display will remain on
through the cycle.
6. Drum Clean
Press this button to clean the drum and tube.
A: Display
B: Child lock
C: Door lock
D: Delay
E: Temperature
F: Pre-wash
G: Extra rinse
Option
Delay Delay
Set the Delay function:
1. Select a programme;
2. Press the Delay button to choose the time (the delaying time is
0-24 h.);
3. Press [Start / Pause] to commence the delay operation
Choose the Programme Setting time Start
Cancel the Delay function:
Press the [Delay] button until the display shows “oH”. This button
should be pressed before starting the programme. If the programme
has already started, switch off the programme and reset a new one.
Caution!
• If there is any break in the power supply while the machine is
operating, a special memory stores the selected programme and,
when the power is restarted, the programme will continue.

20 21
KWM5316
EN
washing machine
Programme Option Programme Option
Delay Extra
Rinse
Pre-
Wash Delay Extra Rinse
Pre-
Wash
Cotton Bulky /
Bedlinen
Synthetic Baby Care
Mix Wool
Jeans Sport Wear
Spin Only Rapid 45'
Rinse & Spin Quick 15’
ECO 40-60 Intensive
20° C
Optional
Extra Rinse The washing machine will undergo an extra rinse
cycle.
Pre Wash
The washing machine will run a prewash before the
main wash. Suitable to wash the supercial dust
on clothes. When selectin it, you will need to add
detergent to the Case (I).
Other Functions
Temp. Temperature regulation button (Cold, 20° C, 40° C,
60° C, 90° C)
Speed Speed regulation button:
1400:0-400-600-800-1000-1200-1400
Programme Default Speed
(rpm) Programme Default Speed (rpm)
1400 1400
Cotton 800 Bulky / Bedlinen 1000
Intensive 800 Baby Care 1000
Synthetic 800 Wool 600
Mix 1000 Sport Wear 800
Jeans 1000 Rapid 45' 800
ECO 40-60 - Quick 15' 800
20° C 1000 Rinse & Spin 1000
Spin Only 1000
Child Lock: To avoid mis operation by children.
Choose the
Programme Press Start
Press [Temp.]
and [Function] for 3 sec.
until you hear a beep.
Caution!
When the Child Lock (CL) feature is activated and the programme
starts, the child lock indicator will switch on and the CL and remaining
time on the display are alternately displayed every 0.5 s. Press the
other buttons and the child lock indicator will ash for 3 s. When the
programme nishes, “CL” and “END” will alternate for 10 s every 0.5
s and then the CL lights will ash for 3s.
• To release the Child Lock function, press and hold the two buttons,
even when the power is off, switch off the washing machine and the
program will end.
• The "Child Lock" will lock all buttons except the “Power button” and
“Child Lock” buttons.
• Please release the Child Lock function before selecting a
programme and the washing cycle starts.
Mute the buzzer
Speed
Choose the Programme Press the [Speed] button for
3 sec., the buzzer is mute.
To activate the buzzer function, press the button the button for 3
seconds. The setting will be kept until the next reset.
Caution!
• After Muting the buzzer function, the sounds will not be activated
any more.
Drum Clean After the washing machine runs to the cycle counting
period (counting cycle is 25 times), the “Drum Clean”
lamp will ash at the end of the last programme,
reminding the user to run the programme;

22 23
KWM5316
EN
washing machine
Release condition:
1. Press and hold the “Drum Clean” button for
3s. The Drum cleaner indicator remind will be
cancelled and the washing cycles will be recount
for another 25 cycles.
The counted cycles will be recounted when drum
clean program is nished.
Programmes
Programmes are available according to the laundry type.
Programmes
Cotton For hard-wearing textiles, heat-resistant textiles
made of cotton or linen.
Synthetic To wash synthetic items, like shirts, coats, blending.
While washing the knitting textiles, detergent
quantity shall be reduced due to its loose string
construction and easily forming bubbles.
Baby Care To wash baby’s clothes. It can make the baby’s
wear cleaner and make the rinse performance
better to protect the baby’s skin.
Rapid 45’ To washing few and not very dirty clothes quickly.
Mix To wash textiles made of cotton and synthetics.
Jeans Special programme to wash jeans.
Quick 15’ Extra short programme, suitable for lightly soiled
washes and small amounts of laundry.
Wool To wash hand or machine-washable wool or rich
wool textiles. Especially gentle wash programme
to prevent shrinkage, longer programme pauses
(textiles rest in wash liquor).
Spin Only Extra spin with selectable spin speed.
Rinse & Spin Extra spin with spin.
Sport Wear To wash sports clothes.
Bulky / Bedlinen To wash bulky clothes / bedlinen.
ECO 40-60 Default 40 ºC programme, not selectable, suitable
for laundry washing at about 40º C – 60º C.
Note!
• Reference to your product to select the programmes.
Washing Programmes Table
Programme Load (kg) Temp. (° C) Default Time
7.0 Default 7.0
Cotton 7.0 40 2:40
Intensive 7.0 40 3:48
Synthetic 3.5 40 2:20
Mix 7.0 40 1:20
Jeans 7.0 60 1:45
ECO 40-60 7.0 -- 3:23
20° C 3.5 20 1:01
Spin Only 7.0 -- 0:12
Bulky / Bedlinen 3.5 -- 0:20
Baby Care 7.0 40 1:48
Wool 2.0 60 1:43
Sport Wear 3.5 40 1:07
Rapid 45' 2.0 20 0:45
Quick 15' 2.0 40 0:45
Rinse & Spin 7.0 Cold 0.15
• Regarding EN 60456:2016 With (EU) No.1061/2010
The EU energy efciency class is: A+++
Energy test programme: Intensive; Speed: the highest speed;
Temp.: 60 / 40º C; Other settings as default.
Half load for 7.0 Kg machine: 3.5 Kg.
• Regarding EN 60456:2016/prA2019/2014, (EU)2019/2014,
(EU)2019/2023
EU energy efciency class: E
Energy test programme: ECO 40-60. Other settings as default.
Half load for 7.0 Kg machine: 3.5 Kg.
Quarter load for 7.0 Kg machine: 2.0 Kg.

24 25
KWM5316
EN
washing machine
Note!
• The parameters in this table are only for user's reference. The
actual parameters maybe different with the parameters in above
mentioned table.
2.3. Maintenance
Cleaning and Care
Warning!
• Before your maintenance starts, please unplug the machine and
close the tap.
Cleaning the cabinet
Proper maintenance on the washing machine can
extend its working life. The surface can be cleaned
with diluted non-abrasive neutral detergents when
necessary. If there is any water overow, use the wet
cloth to wipe it off immediately. No sharp items are
allowed.
Note!
• Formic acid and its diluted solvents or equivalent are forbidden,
such as alcohol, solvents or chemical products, etc.
Cleaning the drum
Rust inside the drum sue to metal items must be immediately
removed with chlorine-free detergents.
Never use steel wool.
Note!
• Don't put laundry in the washing machine during the drum cleaning.
Cleaning the door seal and glass
Wipe the glass and seal after each wash to
remove lint and stains. If lint builds up, it can
cause leaks.
Remove any coins, buttons and other objects
from the seal after each wash.
Cleaning the inlet filter
Note!
• Inlet lter must be cleaned if there is less water.
Washing the lter in the tap
1. Close the tap.
2. Remove the water supply hose from the tap
3. Clean the lter.
4. Reconnect the water supply hose.
Washing the lter in washing machine:
1. Screw off the inlet pipe from the backside
of the machine.
2. Pull out the lter with long nose pliers and reinstall
it back after being washed.
3. Use the brush to clean the lter.
4. Reconnect the inlet pipe.
Note!
• If the brush is not clean, you can pull out the lter washed separately;
• Reconnect, turn on the tap.
Clean the detergent dispenser
1. Press down the arrow location on softener cover inside the
dispenser drawer.
2. Lift the clip up and take out softener cover and wash all grooves
with water.
3. Restore the softener cover and push the drawer into position.
Pull out the
dispenser
drawer by
pressing A
Clean the
dispenser
drawer
under water
Clean inside
the recess
with an old
toothbrush
Insert the
dispenser
drawer

26 27
KWM5316
EN
washing machine
Note!
• Do not use alcohol, solvents or chemical products to clean the
machine.
Cleaning the drain pump filter
Warning!
• Be careful of the hot water!
• Allow detergent solution to cool down.
• Unplug the machine to avoid electrical shock before washing.
• Drain pump lter can lter the yarns and small foreign matters from
the washing.
• Clean the lter periodically to ensure the normal operation of
washing machine.
Open the lower
cover cap
Rotate 90º C
and pull out the
emergency drain
hose, and take
off the hose cape
After water
returns out, reset
the drain hose
Open the lter
by turning to the
counterclockwise
Remove
extraneous
matter
Close the lower
cover cap
Caution!
• Make sure the valve cap and emergency drain hose are reinstalled
properly; the cap plates should be inserted aligned with the hole
plates otherwise water may leak.
• Some washing machines don't have an emergency drain hose, so
steps 2 and 3 can be skipped. Rotate the lower cover cap directly to
make the water run into the basin.
• When the washing machine is in use and depending on the
programme selected, there can be hot water in the pump. Never
remove the pump cover during a wash cycle, always wait until
the washing machine has nished the cycle and is empty. When
replacing the cover, ensure it is securely re-tightened.
2.4. Troubleshooting
If the washing machine does not work or if it stops working mid-
operation, try to nd a solution to the problem. If you cannot nd one,
contact the Customer Support Service.
Description Reason Solution
Washing
machine
cannot start
Door is not closed
properly Restart after the door is closed
Check if the clothes
are stuck
Door can't be
opened Washer's safety protection design is
working
Disconnect the power
and restart the washing
machine
Water
leakage The connection between inlet pipe or
outlet hose is not tight
Check and fasten
the water pipes
Clean up the outlet hose
Detergent
residues
in the box
Detergent
is dampened
or agglomerated
Clean and wipe
the detergent box
Indicator
or display
does not light
Disconnect the
power. The PC board
or harness has a
connection problem
Check if the power is shut
down and the power plug
is connected correctly
Abnormal
noise Check if the xing (bolts) have been removed
Check it’s installed
on a solid and level oor
Description Reason Solution
Door does not
close properly Restart after the door is closed
Check if clothes are stuck
Water injecting
problem while
washing
Check if the water pressure is too low
Straighten the water pipe
Check if the inlet valve lter
is blocked
Overtime water
draining Check if the drain hose is blocked
Water overow Restart the washing machine
Others Please try again. Contact
the Customer Support Service
if the problem persists

28 29
KWM5316
EN
washing machine
Note!
• After performing the checks, restart the washing machine. If the
problem persists or the display shows other alarm codes, contact
the Customer Support Service.
3. TECHNICAL SPECIFICATIONS
Power Supply 220-240 V ~, 50 Hz (EU)
MAX. Current 10 A
Standard Water Pressure 0.005 MPa ~1 MPa
Model Washing
Capacity
Dimension
(W x D x Hmm) Net Weight Rated Power
MFN70-S1403/C31E-EU(NE) 7.0 kg 595 x 495 x 850 60 kg 2050 W
PRODUCT FICHE
Product che concerning to Regulation (EU) No 1061/2010
Trademark
Model identier MFN70
-S1403 / C31E
-EU(NE)
Rated capacity in kg of cotton laundry 7
Energy efciency class on a scale from A+++
(most efcient) to D (least efcient)
A+++
Energy consumption 174 kWh per year, based on 220 standard
washing cycles for the standard cotton programmes at 60° C and
40° C at full and partial load, and the consumption of the low-power
modes. Actual energy consumption will depend on how the washing
machine is used.
Energy consumption at standard 60° C cotton
programme at full load
0.91 kwh
Energy consumption at standard 60° C cotton
programme at partial load
0.69 kwh
Energy consumption at standard 40° C cotton
programme at partial load
0,61 kwh
Weighted power consumption on off mode 0.50 W
Weighted power consumption on left-on mode 1.00 W
Water consumption 9900 litres per year, based on 220 standard
washing cycles for the standard cotton programmes at 60° C and
40° C at full and partial load. Actual water consumption will depend
on how the washing machine Is used.
Spin-drying efciency class B on a scale from G (least efcient) to A
(most efcient)
Maximum spin speed 1400
Remaining moisture content 53%
1 Intensive 60° C programme' and the 'Intensive 40° C programme’
are the standard washing programmes to which the information in
the label and the che relates, that these programmes are suitable
to clean normally soiled cotton laundry and that they are the most
efcient programmes in terms of combined energy and water
consumption.
Programme time at standard 60° C cotton
programme at full load
240 min
Programme time at standard 60° C cotton
programme at half load
230 min
Programme time at standard 40° C cotton
programme at half load
230 min
Duration time of left-on mode -
Airborne acoustical noise emissions during washing
phase
62 dB
Airborne acoustical noise emissions during spinning
phase
79 dB
’built-in’ washing machine no
Energy test programme: Intensive 60 / 40º C. Speed: the highest
speed; Other settings as default.
Supplier's name or trademark:
Supplier's address (b):
Model identier: MFN70-S1403/C31 E-EU(NE)
General product parameters:
Parameter Value Parameter Value
Rated capacity (a) (kg) 7.0 Dimensions in cm Height 85
Width 60
Depth 50
EEIW (a) 91.0 Energy efciency class (a) E
Washing efciency index (a) 1.04 Rinsing effectiveness (g/kg) (a) 5.0

30 31
KWM5316
EN
washing machine
Energy consumption in kWh
per cycle, based on the ECO
40-60 programme. Actual energy
consumption will depend on how
the washing machine is used.
0.784 Water consumption in litre
per cycle, based on the ECO
40-60 programme. Actual water
consumption will depend
on how the washing machine
is used and on the hardness
of the water.
45
Maximum temperature inside
the treated textile (a) (°C) Rated capacity 39 Remaining moisture content (a) (%) Rated capacity 53
Half 35 Half 53
Quarter 24 Quarter 53
Spin speed (a) (rpm) Rated
capacity 1400 Spin-drying efciency class (a) B
Half 1400
Quarter 1400
Programme duration (a) (h:min) Rated
capacity 3:28 Type free-standing
Half 2:42
Quarter 2:42
Airborne acoustical noise
emissions in the spinning phase
(a) (dB(A) re 1 pW)
80 Airborne acoustical noise
emission class (a)
(spinning phase)
C
Off-mode (W) 0.50 Standby mode (W) 1.00
Delay start (W) (if applicable) 4.00 Networked standby (W)
(if applicable) N/A
Minimum duration of the guarantee offered by the supplier (b)
This product has been designed to release silver ions during the washing cycle No
Additional information:
Weblink to the supplier's website, where the information in point 9 of Annex II to Commission Regulation
(EU) 2019/2023 (1) (b) is found:
(a) for the eco 40-60 programme.
(b) changes to these items shall not be considered relevant for the purposes of Article 4(4) of Regulation
(EU) 2017/1369.
(c) if the product database automatically generates the denitive content of this cell the supplier shall
not enter these data.
Note!
• Programme setting for testing in accordance with applicable stan-
dard En60456 for wash.
• Programme setting for testing in accordance with applicable stan-
dard En50229 for wash and dry.
• When using the test programmes, wash the specied load using the
maximum spin speed.
• The actual parameters will depend on how the washing machine is
used, and maybe different with the parameters in above mentioned
table.
• The noise emissions during washing / spinning for the standard
washing cycle at full load.

32 33
KWM5316
EN
washing machine
4. POSTSALE SERVICE
KUNFT has designed this appliance in order to guarantee maximum
reliability. However, if a problem occurs do not attempt to open the
appliance - there is a risk of electrical shock. If you are not able to
solve the problem, please contact the Customer Support Service
of any Worten, Modelo or Continente store in order to be assisted.
Worten Equipamentos para o Lar provides a 2-year warranty for
manufacturing defects from the date of purchase of the appliance.
WARNING: any attempt to repair the appliance without contacting
the manufacturer or seller will void the warranty.
All users must be familiar with these instructions. Knowing what
could go wrong can help prevent problems from occurring.
5. ENVIRONMENTAL
PROTECTION
In order to protect the environment, we strive to reduce the volume of
packaging used, limiting it to three easily sorted materials: cardboard,
paper and plastic.
The appliance is manufactured using recyclable materials
after disassembled by a specialized company. Please
comply with local regulations concerning the recycling of
all materials.
Estimado cliente:
Gracias por adquirir este producto.
Este aparato ha sido sometido a diversas pruebas
que avalan su calidad. Este manual de instrucciones
está destinado a facilitar el uso del aparato y garantizar
un uso seguro.
Lea atentamente las instrucciones, así como las medidas
de seguridad descritas en este manual.
Esperamos sinceramente que esté satisfecho
con su nuevo aparato.

34 35
KWM5316
ES
lavadora
ÍNDICE
1. INSTRUCCIONES DE SEGURIDAD ................... 35
1.1. Alimentación ................................................. 36
1.2. Cable de alimentación y otros cables ........... 37
1.3. Humedad y agua........................................... 37
1.4. Limpieza........................................................ 37
1.5. Advertencias de seguridad............................ 38
2. MANUAL DE INSTRUCCIONES.......................... 44
2.1. Descripción del producto .............................. 44
2.2. Utilización del producto................................. 44
2.3. Mantenimiento .............................................. 57
2.4. Resolución de problemas ............................. 60
3. ESPECIFICACIONES TÉCNICAS ....................... 61
4. SERVICIO POSVENTA ........................................ 65
5. PROTECCIÓN MEDIOAMBIENTAL..................... 65
1.INSTRUCCIONESDE SEGURIDAD
ATENCIÓN
Peligro de electrocución
No Abrir
Atención: para evitar el riesgo de
electrocución, no abra esta unidad.
Su interior no contiene elementos que
puedan ser reparados por el usuario.
Acuda al Servicio de Atención al Cliente.
Avisos importantes
Antes de usar el aparato, lea atentamente
este manual de instrucciones y guárdelo en
un lugar seguro, pues puede tener que con-
sultarlo en el futuro.
Antes de encender el aparato, y a n de ga-
rantizar su utilización de forma correcta y
segura, no lo utilice si:
- Se ha caído al suelo;
- Nota alguna señal de daño;
- Se produce alguna anomalía durante su
funcionamiento.
Para evitar posibles peligros y el deterioro
del aparato debido a un uso incorrecto, se
recomienda que lea atentamente las ins-
trucciones.
Este aparato no deberá ser utilizado para
otros nes que no sean los previstos en el
manual y únicamente para uso doméstico.

36 37
KWM5316
ES
lavadora
En caso de que no sea compatible, consulte
al Servicio de Atención al Cliente.
1.2. Cable de alimentación y otros
cables
No enrolle el cable de alimentación ni tire de
él para desenchufar el aparato. Asimismo,
manténgalo alejado de supercies calien-
tes.
Nunca utilice este aparato si el cable o el
enchufe están dañados.
En su lugar, llévelo a un Servicio de Aten-
ción al Cliente para que proceda a su sus-
titución.
1.3. Humedad y agua
No utilice el aparato en lugares húmedos.
No deje que el aparato se moje en ningu-
na circunstancia, pues puede ser peligroso.
Para evitar el peligro de incendio o descarga
eléctrica, no exponga el aparato al agua o la
humedad. Asimismo, no sumerja el aparato
(por ejemplo, para limpiarlo).
1.4. Limpieza
Antes de proceder a la limpieza del aparato,
apáguelo y desconecte el cable de la cor-
riente. Deje siempre que el aparato se en-
fríe antes de efectuar cualquier operación
de limpieza.
Para limpiar el exterior del producto, utilice
únicamente un paño suave y seco.
Cualquier daño derivado del uso del aparato
fuera de este ámbito de aplicación, cualquier
uso incorrecto, así como cualquier modica-
ción manual del producto, no estará cubierto
y anulará automáticamente la garantía.
Asistencia
En caso de avería, acuda al Servicio de
Atención al Cliente.
Este aparato podrá ser utilizado
por niños de ocho años o más y
por personas con discapacidad fí-
sica, sensorial o mental, o perso-
nas con falta de experiencia o co-
nocimientos, siempre que cuen-
ten con supervisión o se les haya
proporcionado instrucciones para
usar este aparato de un modo se-
guro, y entiendan los riesgos que
conlleva. Los niños no deben ju-
gar con el aparato. La limpieza y
mantenimiento no deben ser rea-
lizados por niños sin supervisión.
Estas instrucciones también están
disponibles en www.suporteworten.pt
1.1. Alimentación
Compruebe que el voltaje de la red eléctrica
es compatible con la indicada en el aparato.

38 39
KWM5316
ES
lavadora
1.5. Advertencias de seguridad
• Siga las instrucciones de este manual,
que le ayudarán a instalar y poner correc-
tamente en funcionamiento este producto
y disfrutar de sus características avanza-
das. Guarde las instrucciones para refe-
rencia futura.
• Lea todas las instrucciones antes de usar
el aparato.
• Las operaciones de reparación o manteni-
miento deben ser realizadas únicamente
por profesionales autorizados.
• Cualquier daño provocado por modica-
ciones manuales al producto no estará
cubierto por la garantía.
• Si usa el producto para otros nes que no
sean para los que ha sido originalmente
diseñado, o si no está correctamente co-
nectado, el producto podrá sufrir daños y
la garantía quedará anulada.
• Para su seguridad, siga la información de
este manual para minimizar el riesgo de
incendio, explosión, descargas eléctricas,
o para evitar daños en la propiedad, lesio-
nes personales o la muerte. Explicación
de los símbolos:
¡Advertencia!
Esta combinación de símbolo y palabra de
advertencia indica una situación potencial-
mente peligrosa que puede causar la muer-
te o lesiones graves a menos que se evite.
¡Precaución!
Esta combinación de símbolo y palabra de
advertencia indica una situación potencial-
mente peligrosa que puede causar lesiones
leves o daños a la propiedad y al medio am-
biente.
Nota!
Esta combinación de símbolo y palabra de
advertencia indica una situación potencial-
mente peligrosa que puede causar lesiones
leves.
¡Advertencia! ¡Descarga eléctrica!
• Si el cable de alimentación está dañado,
debe ser sustituido por el fabricante, el
Servicio de Atención al Cliente o personas
igualmente cualicadas para evitar riesgos.
• Utilice solamente los nuevos juegos de
mangueras suministrados con la lavadora;
los juegos de mangueras antiguos no de-
ben reutilizarse.
• Antes de cualquier mantenimiento del apa-
rato, desenchufe la lavadora de la corriente.
• Desenchufe siempre la máquina y cierre el
suministro de agua después de utilizarla.
La presión máxima de entrada de agua se
proporciona en pascales. La presión míni-
ma de entrada de agua se proporciona en
pascales.
• Por su seguridad, debe insertar el enchufe
del cable de alimentación en una toma con
