Kwikee SuperSlide II PowerSlide User manual

© 2/07 Kwikee #3010000926 Rev. 0A
Operation
Guide
SuperSlide II
PowerSlide
SuperSlide II
PowerSlide
Operation Guide
This coach is equipped with a SuperSlide II PowerSlide mechanism from
Kwikee products. PowerSlide utilizies a quad motor system to move the cargo
tray between the stowed drivers and passenger side of the coach.
The PowerSlide is made of an inner tray which rolls on a set of outer guide
rails. The tray is designed to move 60" out in both directions of travel. Power
to move the tray is provided by engaging urethane covered drive rolls with the
channel mounted on the side of the tray. The drive rolls are tensioned, to
allow for wear in the urethane and maintain good contact. To prevent
movement during coach travel, a center lock mechanism is employed to lock
the tray into its stowed position.
Introduction
Operating Safety Precautions
Prior to extending or retracting the cargo tray, take a moment to ensure
the following:
1. Open the luggage compartment doors to make sure that there are no
obstacles that could interfere with the tray's movements, either in or out to
either side.
2. Make sure that there are no obstacles on the outside of the coach that
would interfere with tray movement or be damaged due to tray movement.
3. Check to ensure that stored gear has not shifted and that no obstructions
exist between the inside of the compartment and the stowed gear.
 READ ALL
OPERATING INSTRUCTIONS
FIRST BEFORE USING YOUR
POWERSLIDE CARGO TRAY.
CAUTION
p
!
 Contents
1
1
2
2
2
3
3
Introduction
Safety Precautions
Extending Your Tray
Stowing Your tray
Program Remote
Troubleshooting
Manual Retract
Make sure the area is clear of all persons or
obstructions before operating
CAUTION
p
!

Extending Your Cargo Tray
PowerSlide Operation Manual Page 2
1. To extend the tray from the stowed center position, use one of the following
two options.
 • Push and hold the rocker switch provided by the coach manufacturer
 in the desired direction.
 • Momentarily press the arrow on the remote control in the desired
 direction.
2. The tray will continue to travel to the full extension point or until either the
rocker is released or any button on the remote control is pressed again.
3. To extend the tray from one side to the other, the tray will need to be
stowed first by either pressing "Stow" or the direction of travel arrow on the
remote control. If the rocker switch is used, after the tray is centered, the
rocker must be released before the tray can be further extended.
Note: To stop the tray,
release the rocker switch
or momentarily press
any button on the remote
control panel.
Stowing Your Cargo Tray
1. To stow the cargo tray, press the stow button on the remote control or the
arrow in the desired direction required to stow the tray. The slide will stow
automatically.
2. If using the rocker switch to retract the cargo tray, press and hold the
switch. The cargo tray will momentarily pause just before centering. Continue
to hold the rocker switch down until all action stops.
Programming Your Remote
To program the power module to the RF remote transmitter, insert the eraser
end of a pencil through the hole in the top of the ABS cover on the power
slide, as shown in figure 1. The hole is located on the passenger top side of
cover.
Figure 1
With the eraser end of the pencil, press the switch on the top of the
control. When pressed, a red LED light will start to flash. The LED can
be seen through the hole in the cover. Once flashing, select which set
of buttons you would like to have correspond to this slide. Press any
button on the remote that corresponds to Slide 1 or Slide 2. this will
program the slide to that remote setting.
CAUTION
p
!
See operating safety precautions before proceeding.
CAUTION
p
!
See operating safety precautions before proceeding.

PowerSlide Operation Manual Page 3
Troubleshooting
1. Unit fails to extend or retract using remote control.
 • Low battery.
 • Out of range, move closer to bay.
• Potential radio interference.
2. My tray extended when my neighbor runs his tray.
 • Change your remote code (see section on setting code).
3. The unit pauses before centering then goes forward and stops.
 • This is normal, it is allowing time for the center latch to move.
4. Unit is not running correctly after working before.
 •
May be caused by dead battery. Position tray in center, then reboot
 system by cycling power to tray.
Manually Retracting Your Cargo Tray
In the event the cargo tray will not function, a manual release lever may be
actuated to retract the tray for service.
The lever must be rotated toward the driverside of the coach about 90°. This
will allow you to move the tray in for travel.
Once the tray is centered, return the release lever to its normal position to
lock the tray in place.
The manual release is meant as a temporary override and service should be
scheduled as soon as possible.
 Release lever
is spring loaded. Use
caution when releasing to
prevent injury.
CAUTION
p
!
