LeMond Fitness Wireless Cadence Meter Pilot II User manual

WIRELESS CADENCE METER
FOR THE LEMOND® REVMASTER
INSTRUCTION MANUAL
S
T
A
R
T
S
T
O
P
>
>
C
A
D
E
N
C
E
C
L
R
H
R
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
INST
85 10:30
2.0 96
121

© 2007 LeMond Fitness
All rights reserved
© 2007 LeMond Fitness. LeMond, RevMaster, and Pilot are registered trade-
marks of LeMond Fitness in the United States and other countries.

IMPORTANT SAFETY INSTRUCTIONS
!
WARNING
BEFORE BEGINNING THIS OR ANY EXERCISE
PROGRAM, CONSULT YOUR PHYSICIAN.
C , ,     
     ,  
      , /  -
, /   . Y -
       
     .

Page 4
is is to certify that the Pilot© wireless cadence meter is warranted by
LeMond Fitness Inc. to be free of all defects in materials and workman-
ship. is warranty does not apply to any defect caused by negligence,
misuse, accident, alteration, improper maintenance, or an
“act of God.” e Pilot cadence meter can only be used on the Rev-
Master indoor cycling bike. Any attempts to use this meter on any other
equipment voids the warranty.
e Pilot carries a one year warranty on the meter and transmitter. Bat-
teries are not warranted. Contact our Customer Service Department
to report any problems. When calling, please be prepared to provide
the customer service representative with the following information:
Your name, the serial number of the inoperable unit, and the date(s) of
purchase for the meter. If warranty replacement parts are shipped to you,
you may be required to return the inoperable part.
LeMond Fitness Inc. neither makes, assumes nor authorizes any rep-
resentative or other person to make or assume for us, any other war-
ranty whatsoever, whether expressed or implied, in connection with
the sale, service, or shipment of our products. We reserve the right to
make changes and improvements in our products without incurring any
obligation to similarly alter products previously purchased. In order to
maintain your product warranty and to ensure the safe and ecient op-
eration of your cadence meter, only authorized replacement parts can be
used. is warranty is void if parts other than those provided by LeMond
Fitness are used.
SPECIFICATIONS
Cadence Meter
Heart Rate Range: 30 to 240 bpm (beats per minute)
Heart Rate Accuracy: ± 4 bpm
Battery: 2 AA batteries
Battery Life: 6 months to 1 year, depending on usage
Transmitter
Emitted Frequency: 122 kHz
Battery: 3 AA batteries
Battery Life: 6 months to 1 year, depending on usage
WARRANTY

Page 5
Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation on the RevMaster
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Console. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Transmitter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Quick Start Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Custom HR Training and Calorie Calculation. . . . . . . 15
Key Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cadence Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Appendix
FCC Compliance. . . . . . . . . . . . . . . . . . . . . . . . . 24
Changing the Console and Transmitter Codes25
Dip Switch Codes . . . . . . . . . . . . . . . . . . . . . . . . 26
Console Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . 27
NOTE:
Press any key to turn on the Pilot console.•
Never disassemble the console or transmitter as it•
can not be reassembled.
e console is water resistant, not water proof. Do•
not deliberately place it in water.
To clean the console, wipe it o with a clean rag•
sprayed with diluted household cleaner.
CONTENTS

Page 6
e Pilot assembly consists of a console, a magnet, and a
transmitter. A sensor in the transmitter counts the number
of times a magnet mounted in the right crank passes the sen-
sor.
e transmitter will then send a coded RF (radio frequency)
signal to the console containing the measured values.
e console has inboard receivers that pick up RPM signals
from the transmitter and heart rate signals from a telemetry
chest strap. e heart rate is then shown in the display win-
dow. e console will track cadence (RPMs), speed (MPH/
KPH), time, distance, and caloric expenditure.
NOTE:
Excessive use of the back light [• ]will drain the
console batteries prematurely.
Expected life of the console batteries is 6 months to•
1 year.
If the console battery power is low, then “• BATT
LOW” will be shown in the display window for 2
seconds aer the display is turned on to inform
you to change the console batteries.
Expected life of the transmitter batteries is 6•
months to 1 year.
DESCRIPTION

Page 7
e console and the transmitter use AA batteries as a source
of power. Install the supplied batteries in the console and in
the transmitter prior to using.
To install the meter (console and the transmitter), you will
need
the following tools:
Phillips Screwdriver•
2.5-mm Hex Key (supplied)•
3-mm Hex Key (supplied)•
4-mm Hex Key (supplied)•
INSTALLATION OF PILOT
NOTE:
e Cadence Meter can only be installed on a
LeMond RevMaster bike.

Page 8
INSTALLATION OF PILOT
Transmitter Battery Installation:
Remove the battery cover screw and cover from the1.
transmitter with a 2.5-mm hex key.
Install three (3) AA batteries in the battery compart-2.
ment.
Retain the battery cover and its screw until you have3.
installed the transmitter on the bike. You will reinstall
the battery cover at that time.
Batteries, AA x 3

Page 9
INSTALLATION OF PILOT
Console Battery Installation:
Loosen the battery cover screw and remove the battery1.
cover from the console.
Insert 2 AA batteries into the battery compartment and2.
reinstall the battery cover.
Batteries, AA x 2
Handlebar Console Clamp
Mounting
Screws
Battery Cover &
Screw
Console Installation:
Ensure that the console turns on.1.
Spread the bottom of the console clamp apart and clamp2.
it back together over the top center of the handle bar.
Insert a mounting screw into each hole and use a 4-mm3.
hex key to tighten the screws.

Page 10
Transmitter Installation:
Ensure that the batteries are installed in the transmitter.1.
From the le side of the bike, use a 3 mm hex key to re-2.
move two counter sunk hex head screws located on the
inside of the drive cover. (See illustration below.)
Position the transmitter next to the cover.3.
Note: Th e RPM sensor at the back of the transmitter will align with
the indentation in the back of the drive cover.
Batteries
& Cover
M4 x 40 (2)
Transmitter
Drive
Cover
INSTALLATION OF PILOT

Page 11
Secure the transmitter to the bike with two M4 x 404.
screws; tighten with a 3 mm hex key.
Reinstall the transmitter battery cover and screw;5.
tighten with a 2.5 mm hex key.
Checking the Installation:
Turn the console on by pressing START.1.
Rotate the cranks for 10 seconds and verify that the2.
console is picking up the crank rotation and displaying
RPM’s in the cadence section of the display window.
If you do not see RPMs in the display window, press3.
the [CADENCE] key repeatedly until “INST” RPM
is shown in the display window. If RPM still does
not show, refer to the troubleshooting section of this
manual.
INSTALLATION OF PILOT

Page 12
S
T
A
R
T
S
T
O
P
>
>
C
A
D
E
N
C
E
C
L
R
H
R
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
INST
85 10:30
2.0 96
121
HEART RATE
TIME
DISTANCE
CALORIES
(KCAL)
CADENCE
CADENCE
Cadence is the measurement of how fast the crank is rotat-
ing in RPM’s. e approximate speed of the bike can also be
displayed (MPH/KPH) in this area.
TIME
Time is the length of time (min:sec) since you pressed the
start button.
DISTANCE
Distance is the measurement of the approximate distance of
the bike if the user was riding a bike with tires the same size
of the ywheel.
DISPALY WINDOW

Page 13
KCAL
Kcal is the approximation of calories burned during your
workout. e calories are estimated by measuring your
instantaneous heart rate (HR) and factoring in your age,
ambient HR, and weight.
HEART RATE
is is the measurement , by telemetry (chest strap), of your
heart rate in beats per minute (BPM).
Note: You must wear a chest strap during your workout in order to
see your heart rate. The Pilot console will detect heart rate
signals from most chest straps that emit an analog signal,
or a digital Cardiosport® chest strap. An “A” (analog) or “D”
(digital) will be displayed for a few seconds in the heart rate
display section of the display window when a HR signal is
initially received, to indicate the type of signal being re-
ceived.
!
WARNING
I        
 ,    -
,  ,     , 
 . I   -
,      

The Pilot also features heart zone training. After selecting
your maximum and minium heart rate limits, the console
will show flashing up or down arrows over the heart icon
to indicate that you need to adjust your intensity either up
or down to stay within your selected heart rate zone. See
pg. 15 for more info.

Page 14
Any time you want to bypass entering your personal data
and start using the meter, simply press any key to turn on the
console. Aer you press the [START] key, the timer will start
counting and the console will start tracking usage informa-
tion.
e Pilot will calculate calories burned based on the follow-
ing default perimeters for Quick Start Workout:
Ambient Heart Rate (AHR): 70 bpm
Age: 30 Years old
Weight: 175 lbs.
QUICK START PROGRAM
S
T
A
R
T
S
T
O
P
>
>
C
A
D
E
N
C
E
C
L
R
H
R
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
INST
00:00
0.0 0
0

Page 15
Press and1. hold the [HR] key until the display window
shows “∨240.”
Use the [2. ∨] key to change the upper limit of your tar-
get heart rate from 240 BPM to your desired beats per
minute and press [HR] to select the number. Or, simply
press [HR] to accept the default value of 240 BPM.
Note: If your heart rate during your workout session is higher than
the selected upper limit of your target heart rate range, there
will be a ashing “∨” above the heart icon in the display win-
dow. This indicates that you should adjust
your workout to
bring your heart rate down
e display window will now show “3. ∧30.”
Use the [4. ∧] key to change the bottom limit of your
target heart rate from 30 BPM to your desired beats per
minute and press [HR] to select the number. Or, simply
press [HR] to accept the default value of 30 BPM.
Note: If your heart rate is lower than the selected bottom limit
of your target heart rate range, there will be a ashing “∧”
above the heart icon. This indicates that you should adjust
your workout to bring your heart rate up.
e lower right portion of the display window will show5.
70 BPM as the default ambient heart rate (AHR).
CUSTOM HEART RATE TRAINING AND
CALORIE CALCULATIONS

Page 16
Use the [6. ∧] or [∨] key to change the default AHR value
to your AHR value.
Press the [7. HR] key to select your AHR value.
e default age of 30 years old will be displayed. Use the8.
[∧] or [∨] key to change the default age to your age.
Press the [9. HR] key to select your age.
e default weight of 175 lbs. will be displayed. Use10.
the [∧] or [∨] key to change the default weight to your
weight.
Press the [11. HR] key to select your weight and return you
to the main screen.
Press the [12. START] key to activate the timer and start
tracking usage information.
CUSTOM HEART RATE TRAINING AND
CALORIE CALCULATIONS

Page 17
KEY FUNCTIONS
[START]
e start key will start the timer and enable the cadence me-
ter to begin calculating HR and Kcal values.
[CLEAR]
A short press (< 3 sec) of the clear key will reset the time,•
distance and calorie measurements.
Pressing and holding the clear key (> 3sec) will reset the•
AVG (average) and MAX (maximum) values for cadence
and HR measurements. In addition, the calorie calcula-
tion values will be reset to their default values
[STOP]
e stop key will stop the calculation of the time, distance
and calorie measurements without resetting the values of the
measurements. Pressing the start key again will restart the
console
[CADENCE]
e cadence key allows you to change the cadence section
of the display window between INST (instantaneous) RPM,
AVG (average) RPM, MAX (maximum) RPM, INST (instan-
taneous) MPH/KPH, AVG (average) MPH/KPH, and MAX
(maximum) MPH/KPH.
[∧]
e up arrow allows you to increase the default max HR,
min HR, ambient HR, age, and weight for target heart zone
training and calorie calculations.

Page 18
[∨]
e down arrow allows you to decrease the default max HR,
min HR, ambient HR, age, and weight to select your values
for target heart zone training and calorie calculations.
[HR]
A short press of the heart rate key allows you to change•
the display of the HR section of the display window
between INST (instantaneous) HR, AVG (average) HR
and MAX (maximum) HR.
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
MAX
85 10:30
2.0 96
121
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
AVG
85 10:30
2.0 96
120
MI
RPM
INST
CADENCE
DISTANCE KCAL
TIME
INST
85 10:30
2.0 96
118
A long press (> 3sec), places you in the HR data entry•
mode where you can use the [∧] and [∨] keys to select
your upper target HR and lower target HR. You can also
modify the ambient HR, age, and weight default values for
more user specic calorie calculations.
∨
30
∧
240
∧
175
WT
Lb
70
AHR 30
∧
∧
AGE

Page 19
[ ]
Pressing the light key will back-light the display window for
5 seconds. If another key is pressed while the light is on, the
back light will stay on for an additional 5 seconds. As long as
keys are pressed with the back light on, the console light will
stay on.
Note: When the back light is on, all calculations are suspended.
During this time, heart rate and cadence are not detected.

Page 20
CADENCE TRAINING
Denition of Cadence
How rapidly the cranks are rotated or the rhythm of the ped-
al stroke; oen referred to as RPM (revolutions per minute).
Concepts using Cadence for training
You can choose the goal of your workout in relation to
Resistance, Cadence, and Heart Rate . e intensity of your
workout is aected by pedal speed change and the resistance
applied. is is quantied as RPE - Relative Perceived Ex-
certion)
Resistance Cadence Heart Rate RPE Feeling
Used
Light RPM 50-70 35%-50% MHR 1-2 Very easy
Light RPM 70-90 50%-60% MHR 3-4 Easy
Light RPM 90-100 60%-70% MHR 5 Steady;
comfortable
Light RPM 100-135 70%-85% MHR 6+ Challenging
Moderate RPM 50-70 55%-65% MHR 4-5 Somewhat
hard
Moderate RPM 70-90 65%-75% MHR 5-6 Challenging,
steady
Moderate RPM 90-100 75%-85% MHR 6-7 Hard!
Moderate RPM 100+ 85%-100% MHR 7-10 Very hard;
chasing
Heavy RPM 50-60 70%-80% MHR 6-7 Hard; talking
ishard
Heavy RPM 60-70 80%-85% MHR 7-8 Very hard;
pushing
Heavy RPM 70-80 85%-90% MHR 8-9 Very Hard!!
Heavy RPM 80+ 90%-100% MHR 9-10 Maximal
