LENCO MC-4100 USB User manual

STEREO CD/MP3 MICRO SYSTEM
WITH USB/SD PLL RADIO WITH RDS
MC-4100 USB
INSTRUCTION MANUAL

LOCATION OF CONTROLS
1) LCD DISPLAY
2) CD PLAY/PAUSE BUTTON
3) CD STOP BUTTON
4) MEMORY/CLOCK ADJUST BUTTON
5) F UNCTION S SE LECTOR
6) BAND SELECTOR BUTTON
7) PRE - UP FUNCTION BUTTON
8) CD SKIP / RADIO TUNING DOWN BUTTON
9) CD SKIP / RADIO TUNING UP BUTTON
10) USB SOCKET
11) STEREO HEADPHONE JACK
12) CD DOOR OPEN BUTTON
13) STANDBY LED INDICATOR
14) REMOTE SENSOR
15) POWER ON/STANDBY BUTTON
16) VOLUME UP/DOWN BU TTON
17) PRESET EQ BUTTON
18) MEMORY CARD SLOT
19) USB/CARD SLOT COVER
20) FM WIRE ANTENNA
21) SPEAKER WIRE CONNECTOR (L/R)
22) AUXILIARY INPUT JACK
23) AC POWER CORD
CAUTION:
USAGE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
THIS UNIT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE EXCEPT QUALIFIED SERVICE PERSONNEL.
IMPORTANT:
SINCE MOVEMENT OF THE CD MECHANISM AND THE SENSITIVE CIRCUITY MAY CAUSE INTERFERENCE TO
THE RADIO TUNER NEARBY, SWITCH THIS UNIT OFF WHILE OPERATING OTHER RADIO DEVICES.
PRECAUTIONS FOR USE
INSTALLATION
UNPACK ALL PARTS AND REMOVE PROTECTIVE MATERIAL.
DO NOT CONNECT THE UNIT TO THE MAINS BEFORE CHECKING THE MAIN VOLTAGE AND BEFORE ALL
OTHER CONNECTIONS HAVE BEEN MADE.
DO NOT COVER ANY VENTS AND MAKE SURE THAT THERE IS A SPACE OF SEVERAL CENTIMETERS
AROUND THE UNIT FOR VENTILATION.
CONNECTION
1. CONNECT THE POWER CORD TO AC OUTLET
2. WHEN YOU FIRST PLUG THE UNIT INTO THE MAINS, THE UNIT WILL GO INTO STANDBY MODE AND THE
LED I NDICATOR ( 13) WILL LIGHT UP, THE DISPLAY WILL SHOW -- -- : -- -- AND FLASHING.
3. CONNECT THE SPEAKER WIRE TO THE SPEAKER TERMINAL (2 1) LOCATED ON THE REAR SIDE OF UNIT.
4. TURN ON THE POWER (15), IF THE LCD DISPLAY IS ON WITH BACKLIGHTING, IT MEANS THE POWER
SUPPLY IS NORMAL. NOW YOUR SYSTEM IS READY TO PLAY THE MUSIC.
SETTING THE CLOCK
1. SET UNIT IN STANDBY MODE.
2. PRESS & HOLD THE MEM/CLK-ADJ BUTTON (4 ) FOR FEW SECONDS, THE DISPLAY WILL START FLASHING.
PRESS OR BUTTON ( 8,9 ) TO SELECT THE APPROPIATE AR EA HOUR (12H/24H)
3. PRESS MEM/CLK-ADJ BUTTON (4) AGAIN, THE FIRST SECOND DIGIT OF 0 IS FLASHING. PRESS OR
BUTTON ( 8,9 ) TO SET THE CORRECT HOUR. PRESS MEM/CLK-ADJ BUTTON (4)TO STORE THE
CORRECT HOUR.
4. THE THIRD FOURTH DIGIT OF 00 IS FLASHING, PRESS THE OR BUTTON ( 8,9 ) TO SET THE
CORRECT MINUTES. THEN PRESS MEM/CLK-ADJ (4 ) TO STORE THE CORRECT MINUTE.
THE PRE-SET TIME WILL BE RE-SET COMPLETELY IF DIS-CONNECTING THE MAIN POWER
SUPPLY. YOU ARE RECOMMENDED TO SWITCH THE SYSTEM INTO STANDBY MODE F OR
CONVENIENCE USAGE. E-1

LISTENING TO RADIO
MANUAL TUNING
1. PRESS FUNCTION BUTTON (5) TO SELECT TUNER MODE.
2. PRESS BAND BUTTON (3 ) TO SELECT DESIRED BAND (AM/MW OR FM).
3. TUNE TO THE REQUIRED STATION BY PRESSING THE TUNING OR BUTTON ( 8,9 ).
4. ADJU ST VOLUME CONTROL ( 16 ) TO THE DESIRED VOLUME LEVEL.
AUTO TUNING
1. PRESS FUNCTION BUTTON ( 5 ) TO SELECT TUNER MODE.
2. PRESS BAND BUTTON (3) TO SELECT DESIRED BAND (AM/MW OR FM).
3. PRESS AND HOLD THE TUNING OR BUTTON ( 8,9 ) FOR 1 - 2 SECONDS AND THEN RE LEASE.
4. THE UNIT WILL START SEEKING AUTOMATICALLY AND STOP UNTIL A RADIO STATION IS REACHED.
5. REPEAT STEP 3 & 4 UNTIL THE DESIRED RADIO STATION IS BEING REACHED.
6. ADJUST VOLUME CONTROL (16) TO THE DESIRED VOLUME LEVEL.
PRESET STATIONS
YOU CAN STORE UP TO 40 RADIO STATIONS IN THE MEMORY (30 - FM/10 - AM).
1. SET TO TUNER MODE.
2. TURN TO THE DESIRED RADIO STATION BY MANUAL OR AUTO TUNING METHOD.
3. PRESS MEM/CLK-ADJ BUTTON (4) TO ENABLE PROGRAM STATE & MEMORY INDICATOR IS FLASHING
ON LCD ( 1)
4. PRESS REP -UP BU TTON ( 7 ) TO SELECT THE DESIRED STATION MEMORY FOR STORAGE.
5. PRESS MEM/CLK-ADJ BUTTON (4 ) AGAIN TO CONFIRM THE SETTING.
6. REPEAT STEP 2 TO 5 TO STORE OTHER STATIONS.
7. TO RETURN NORMAL TUNER MODE, LEAVE KEYS FREE.
8. NOW YOU CAN SELECT THE PRESETS STATIONS IN ORDER BY PRESSING THE REP -UP BUTTON (7) OR
PRE - DN BUTTON (AT REMOTE HANDSET)
THE PRE-SET MEMORIES WILL BE CANCELLED COMPLETELY IF DIS-CONNECTING THE MAIN POWER
SUPPLY. YOU ARE RECOMMENDED TO SWITCH THE SYSTEM INTO STANDBY MODE FOR CONVENIENCE
USAGE.
THER E ARE 10 SECONDS FOR PROGRAM STATE, AFTER 10 SEC. THIS STATE WOULD RESUME TO
NORMAL TUNER MODE AUTOMATICALLY.
YOU CAN OVERWRITE A PRESENT STATION BY STORING ANOTHER FREQUENCY IN ITS PLACE.
FM & FM - STEREO RECEPTION (BY REMOTE HANDSET)
PRESS THE MONO/ST. BUTTON AT REMOTE HANDSET REPEATEDLY, THE FM PROGRAMS ARE
RECEIVING IN MONO AND STEREO MODE REPEATEDLY. IN PARTICULAR WHEN STEREO SIGNALS ARE
WEAK. IT IS PREFERABLE TO RECEIVE THE PROGRAM IN MONO.
IF STEREO SIGNAL IS BEING RECEIVED, THE ST INDICATOR WILL APPEAR ON LCD (1) TO
SHOW FM STEREO PROGRAM IS NOW RECEIVING.
HINTS FOR BEST RECEPTION: -
- AM : THE RECEIVER HAS A BUILD-IN AM BAR ANTENNA. IF AM RECEPTION IS WEAK, SLIGHT ROTATE OR
RE - POSITIONING OF THE UNIT WILL USUALLY IMPROVE THE AM RECEPTION.
- F M : THE RECEIVER HAS A BUILD - IN FM WIRE ANTENNA (20) HANGING AT THE REAR CABINET. THIS WIRE
SHOULD BE TOTALLY UNRAVELED AND EXTENDED FOR THE BEST RECEPTION.
RADIO DATA SYSTEM (RDS) CONTROL BY REMOTE HANDSET
THIS IS THE FEATURES TO DISPLAY THE INFROMATIO N WHICH RELEASED FROM THE RADIO BROADCASE: -
RDS MODE : PRESS TO ACTIVE THE RDS FUNCTION AND DISPLY THE INFORMATION IN THE SEQUENCE OF
STATION NAME (PS) BROADCASE PROGRAM TYPE (PTY) TEXT MESSAGE (RT) AND
REPEATEDLY .
RDS SEL (SEARCH) : PRESS ONCE PTY SEL WILL DISPLAY, THEN PRESS TUNING UP/BACK BUTTON TO
SELECT THE PROGRAM TYPE YOU WANT TO LISTEN . THEN PRESS AGAIN THE RDS SEL (SEARCH) BUTTON
TO START RDS SEARCHING AND THE UNIT SEARCH ALL PRESETED STATIONS AND STOPS WHEN IT FINDS A
STATION OF THE PROGRAM (PTY) YOUR HAVE SELECTED
REMARK : IF NO PRGORM IS FOUND, NOT AND FOUND ALTERNATELY APPEAR ON THE DISPLAY. NO
PS NOR PTY APPEARS IF NO RDS SIGNAL IS SENT.
BROADCAST PROGRAMMES ARE CLASSIFIED AS FOLLOWS:
NEWS, AFFAIRS (current affa irs), INFO (information), SPORT , EDUCATE (education), DRAMA, CULTURE, SCIENCE,
VARIED, POP M (pop music), ROCK M (rock music), MOR M (middle of the road music), LIGHT M (light classical),
CLASSICS (serious classical), OTHER M (other music), WHEATHER, FINANCE, CHILDREN, SOCIAL A, RELIGION,
PHONE IN, TRALEISURE, JAZZ. COUNTRY, NATIONAL, OLDIES, FOLK M (folk music), DOCUMENTS.
E-2

NOTES
PROGRAMME SERVICE STATION NAME (PS)
THIS IS A NAME CONSISTING OF LESS THAN 8 ALPHANUMERIC CHARACTERS, WHICH IS DISPLAYED IN
ORDER TO INFORM LISTENERS ABOUT THE PROGRAMME SERVICE BEING BROADCASTBY THE RADIO
STATION. EXAMPLE: BBC 1
PROGRAMME TYPE IDENTIFICATION (PTY)
PTY ALLOWS SELECTION BY ONE OF 15 PROGRAMME TYPES RATHER THAN BY A STATION.
RADIO TEXT (TEXT)
INFORMATION SUCH AS THE CAST LIST OF A PLAY OR THE TITLE OF A SONG IS SHOWN ON THE DISPLAY.
PLAYING COMPACT DISC
GETTING START
1. PRESS FUNCTION BUTTON ( 5 ) TO SELECT CD MODE.
2. PRESS OPEN/CLOSE BUTTON (12) TO OPEN THE CD DOOR.
3. PLACE A CD WITH THE PRINTED SIDE FACING UP INSIDE THE TRAY & THEN CLOSE THE CO DOOR.
4. FOCUS SEARCH IS PERFORMING, THE LCD DISPLAY (1) WILL SHOW THE TOTAL NUMBER OF TRACKS &
TOTAL PLAYING TIME.
PLAY / PAUSE MODE
1. PRESS THE PLAY/PAUSE BUTTON (2 ) TO START PLAYBACK, THE FIRST TRACK WILL START PLAYBA CK.
2. TO INTERRUPT, PRESS THE PLAY/PAUSE BUTTON (2 ) ONCE, AND THE PLAYING TIME WILL BE FREEZE &
FLASHING ON THE LCD DISPLAY ( 1 ). PRESS AGAIN TO RESUME NORMAL PLAYBACK.
STOP MODE
1. IF CD STOP BUTTON (3 ) IS PRESSED DURING PLAY OR PAUSE MODE, SYSTEM WILL G O TO STOP MODE.
SKIP MODE (SKIP UP / SKIP DOWN )
1. DURING PLAY OR PAUSE MODE, IF SKIP UP BUTTON (9) IS PRESSED. IT WILL GO TO NEXT TRACK AND
DISPLAY THE TRACK NO. AND THEN REMAIN THE PLAY OR PAUSE MODE.
2. DURING PLAY OR PAUSE MODE, IF SKIP DOWN BUTTON (8) IS PRESSED. IT WILL GO BACK TO THE
BEGINNING OF THE TRACK, ORIGINAL TRACK NO. IS DISPLAY AND REMAIN THE PLAY OR PAUSE MODE.
3. AFTER STEP 2, PRESS SKIP DOWN BUTTON (8 ) AGAIN WILL GO TO THE PREVIOUS TRACK AND REMAIN
THE PLAY OR PAUSE MODE.
FOR MP3 DISC
1. PRESS PRE-UP (7) OR PRE- DN BUTTON, THE ALBUM NO. CHANGE
2. PRESS SKIP UP (9) OR SKIP DOWN (8) BUTTON, THE TRACK NO. CHANGE.
3. WHEN THE DESIRED TRACK IS BEING SELECTED, PRESS THE CD PLAY/PAUSE BUTTON (2) TO START
PLAYBACK.
ID3 (TRACK/ALBUM TITLE) FUNC TION (BY REMOTE HANDSET)
1. PRESS AND HOLD THE FIND BUTTON DURING PLAY MODE, THE SONG TITLE IS BEING DISPLAYED.
PRESS AND HOLD THE FIND BUTTON AGAIN TO DISABLE THE FUNCTION.
TITLE/ALBUM SEARCH FUNCTION (BY REMOTE HANDSET)
YOU CAN SEARCH THE TRACK BY THE TITLE/FLODER NAME IN DISC: -
1. PRESS THE FIND BUTTON ONCE, THEN PRESS THE SKIP UP (SKIP DOWN) BUTTON (9 OR 8), YOU CAN
SEARCH THE TITLE OF EACH SONG ONE BY ONE AND DISPLAY ON LCD, THEN PRESS THE CD
PLAY/PAUSE BUTTON (2) TO START THE PLAYBACK OF THE SELECTED TRACK.
2. PRESS AGAIN FIND BUTTON, THE ALBUM NAME IS BEING DISPLAYED. THEN PRESS THE PRE-UP (7)
OR PRE -DN BUTTON TO SELECT THE DESIRED ALBUM, AND PRESS THE CD PLAY/PAUSE BUTTON (2) TO
START PLAYBACK OF ALL TRACKS INSIDE THAT SELECTED A LBUM.
REMARK: -
- IN THAT CASE OF NO NAME HAD BEEN ASSIGNED FOR THE TRACK, NONE OR UN_KNOWN IS BEING
DISPLAYED ON DISPLAY (1).
- IN THAT CASE OF NOALBUM NAME OR NOALBUM FORMAT IN THE DISC, ROOT IS BEING DISPLAYED.
- THE LCD DISPLAY SUPPORT ENGLISH LANGUAGE ONLY
- TITLE SEARCH IS NOT APPLICABLE FOR USB/SD/MMC CARD MODE
MP3 TRACK FORMAT REQUIREMENT: -
- BIT RATE : 32 KBPS~320KBPS, SAMPLING RATE : 32KHZ, 44.1KHZ AND 48 KHZ DECODABLE
- THE PERFORMANCE OF PLAYING MP3 DISC IS VARIOUS FROM THE QUALITY OF RECORDING DISC AND
THE METHOD OF RECORDING. FURTHERMORE, THE SEARCHING LEAD - TIME FOR MP3 -CD IS LONGER
THAN NORMAL CD DUE TO DIFFERENCE FORMAT.
E-3

REPEAT MODE (BY REMOTE HANDSET)
PRESS THE REPEAT BUTTON BEFORE OR DURING PLAY, A SINGLE TRACK, SINGLE AL BUM (MP3 ONLY) OR ALL
THE TRACKS CAN BE REPEATED. EACH PRESS SWITCH THE REPEAT MODE AS FOLLOW: -
FOR CD
REPEAT INDICATOR
(1) REPEAT 1 (2) REPEAT ALL (3) REPEAT OFF REPEAT MODE ON LCD DISPLAY
REPEAT TRACK REPEAT
REPEAT ALL REPAT ALL
REPEAT OFF ---------------
FOR MP3 DISC
(1) REPEAT 1 (2) REPEAT ALL (3) REPEAT ALBUM (4) REPEAT OFF
REPEAT INDICATOR
REPEAT MODE ON LCD DISPLAY
REPEAT SINGLE TRACK REPEAT
REPEAT ALL TRACKS REPEAT ALL
REPEAT CURRENT ALBUM REPEAT ALBUM
REPEAT OFF -----------------
RANDOM PLAY (BY REMOTE CONTROL)
YOU CAN LISTEN ALL THE TRACKS IN A RANDOM ORDER BY THIS FUNCTION
1. PRESS RANDOM BUTTON AND RANDOM INDICATOR LIGHT UP ON THE LCD DISPLAY (1 ).
2. TH E CD/MP3 DISC WILL START PLAYBACK IN RANDOM ORDER.
3. PRESS RANDOM BUTTON AGAIN TO CANCEL RANDOM MODE.
INTRO PLAY (BY REMOTE CONTROL)
YOU CAN LISTEN THE BEGINNING (10 SECONDS) OF EACH TRACK IN A CD BY THIS FUNCTION & SAVING YOUR
TIME TO SEARCH THE DESIRE SONG
1. PRESS INTRO BUTTONAFTER PLACINGA CD INSIDE THE UNITAT CD MODE
2. SYSTEM START PLAYING THE FIRST 10 SECONDS OF EACH TRACK OF THE ENTIRE CD CONTINUOUSLY.
3. PRESS INTRO BUTTON ONCE AGAIN IF IT REACH YOUR DESIRED TRACK FOR NORMAL PLAYBACK.
CD DISC PRO GRAMMING
UP TO 64 TACKS CAN BE PROGRAMMED FOR DISC PLAY IN ANY ORDER. BEFORE USE, BE SURE TO PRESS
THE CD STOP BUTTON (3)
1. SET IN CD MODE & STOP THE CD PLAYBACK.
2. PRESS THE MEM/CLK-ADJ BUTTON (4) , MEMORY WILL APPEAR ON LCD DISPLAY (1). MOREOVER, IT
WI LL INDICATE PROGRAM NO. AND DIGITS FOR TRACK NO. TO BE PROGRAMMED.
3. SELECT A DESIRED TRACK BY PRESSING SKIP OR BUTTONS (9 OR 8).
4. PRESS THE MEM/CLK-ADJ BUTTON (4) TO STORE THE TRACE INTO MEMORY.
5. REPEAT STEPS 3 AND 4 TO ENTER ADDITIONAL TRACKS INTO THE M EMORY IF NECESSARY.
6. WHEN ALL THE DESIRED TRACKS HAVE BEEN PROGRAMMED, PRESS CD PLAY/PAUSE BUTTON (2) TO
PLAY THE DISC IN ASSIGNED ORDER.
7. PRESS CD STOP BUTTON (3) TO TERMINATE PROGRAM PLAY.
DURING PROGRAM MODE, PRESS MEM/CLK-ADJ BUTTON (4) TO REVIEW THE TRACKS CURRENTLY
PROGRAMMED.
MP3 DISC PROGRAMMING
1. FOLLOW THE SAME STEP 1 AND 2 AS CD PROGRAMMING PROCEDURE.
2. SELECT A DESIRED ALBUM NUMBER BY PRESSING SKIP OR BUTTONS (9 OR 8).
3. PRESS THE MEM/CLK-ADJ BUTTON (4) TO STORE THE SELECTED ALBUM INTO MEMORY, THEN PRESS
SKIP OR BUTTONS (9 OR 8)AGAIN TO SELECT THE TRACK NO. TO BE PROGRAMMED.
4. REPEAT STEPS 2 AND 3 TO ENTER ADDITIONAL TRACKS INTO THE MEMORY IF NECESSARY
5. WHEN ALL THE DESIRED TRACKS HAVE BEEN PROGRAMMED, PRESS CD PLAY/PAUSE BUTTON (2) TO
PLAY THE DISC IN THE ORDER YOU HAVE PROGRAMMED.
6. PRESS CD STOP BUTTON (3) TO TERMINATE PROGRAM PLAY.
THE PROGRAMMING MODEL WILL AUTOMATICALLY STOP IF NO BUTTON IS BEING PRESSED IN A PERIOD
OF ABOUT 10 SECONDS AFTER PRESSING THE MEM/CLK - ADJ BUTTON (4).
E-4

PLAYBACK OF MP3 SONG VIA USB STORAGE MEDIA OR MEMORY CARD
CONNECTING
THE SYSTEM IS ABLE TO DECODE AND PLAYBACK ALL MP3 FILE WHICH STORED IN THE MEMORY MEDIA
WITH USB CONNECTING PORT, MULTI - MEDIA CARD (MMC) OR SECURE DIGITAL (SD) MEMORY CARD.
1. PRES S FUNCTION BUTTON (5) TO SELECT CARD-USB MODE.
2. OPEN THE USB/CARD SLOT COVER (19)
3. PLUG -IN THE USB PLUG WITH THE FACE UP & MAKE SURE IT GOING INTO
COMPLETELY OR INSERT THE MEMORY CARD IN THE DIRECTION OF THE
ARROW AS SHOWN IN THE LABEL ON THE UNDERSIDE OF THE MEMORY
CARD SLOT COVER. INSERT STRAIGHT WITHOUT BENDING.
CONNECTING THE USB / MEMORY CARD UPSIDE DOWN OR BACKWARDS
COULD DAMAGE THE AUDIO SYSTEM OR THE STORAGE MEDIA (USB /
MEMORY CARD). CHECK TO BE SURE THE DIRECTION IS CORRECT BEFORE
CONNECTION .
4. THE SYSTEM WILL START READING THE STORAGE MEDIA AUTOMATICALLY AFTER CONNECTING, AND
LCD DISPLAY (1) WILL SHOW THE TOTAL NUMBER OF MP3 FILES AND TOTAL NUMBER OF ALBUM BEING
DETECTED.
5. REPEAT THE SAME PLAYBACK PROCEDURE AS PLAYING CD/MP3 DISC AS ABOVE
REMA RK
- THE SYSTEM CAN READ EITHER ONE OF THE STORAGE MEDIA ONLY. IF BOTH THE USB TYPE AND
MEMORY CARD TYPE STORAGE MEDIA HAVE BEEN CONNECTED, THE SYSTEM WILL READ THE MEMORY
CARD TYPE ONLY. OR THE ONE WHICH CONNECTING TO THE SYSTEM FIRSTAT CARD-USB MODE
- T HE SYSTEM CAN DETECT AND READ THE FILE UNDER MP3 FORMAT ONLY THOUGH THE USB
PORT/MEMORY CARD SLOT.
- IF CONNECT THE SYSTEM TO MP3 PLAYER VIA THE USB SOCKET, DUE TO VARIANCES IN MP3 ENCODING
FORMAT , SOME MP3 PLAYER MAY NOT BE ABLE TO PLAY VIA THE USB SOCKET . IN THESE CASES
PLEASE USE THE MP3 PLAYER CONNECTED TO THE AUX - IN SOCKETS AT THE REAR OF THE UNIT .
REMOVING OF USB / MEMORY CARD
TO REMOVE THE USB / MEMORY CARD, TURN OFF THE POWER OR SWITCH THE FUNCTION MODE TO EITHER
CD, AUX OR TUNER FIRST. FOR USB PORT UN - PLUG IT BY PULLING OUT THE USB SOCKET DIRECTLY, FOR
MEMORY CARD PRESS THE MEMORY CARD INWARD & THEN RELEASE, NOW THE CARD BEING PARTIALLY
EJECT AND YOU CAN REMOVE IT BY HAND.
MORE FEATURES
A. SLEEP SETTING (BY REMOTE CONTROL)
1. PRESS SLEEP BUTTO N AND SLEEP INDICATOR SHOWN ON THE LCD ( 1 ).
2. KEEP PRESSING THE BUTTON TOADJUST THE SLEEP TIMER IN THE ORDER OF 90 > 80 >70 .10 MINUTES.
3. SYSTEM WILL STOP AND GOTO STANDBY MODE AUTOMATICALLY AFTER THE SELECTED TIMING.
4. TO CANCEL THE SLEEP MODE, PRESS SLEEP BUTTON UNIT IT REACH 0 MINUTES.
B. ALARM CLOCK SETTING (BY REMOTE CONTROL)
THIS FUNCTION ALLOWS THE SYSTEM TO TURN ON AUTOMATICALLY AND WAKE YOU UP BY SOFT MUSIC OR
RADIO.
FIRST, PRESS AND HOLD THE TIMER BUTTON TO ENTER THE PROGREM MODE UNTIL THE TIME IS
FLASHING ON LCD DISPLAY, THEN YOU CAN START THE ALARM SETTING: -
1) ON TIME SETTING : PRESS THE SKIP UP/DOWN BUTTON TO SET THE TIME. THEN PRESS AGAIN TIMER
BUTTON TO ENTER OFF TIMER MODE
2) OFF TIME SETTING : PRESS THE SKIP UP/DOWN BUT TON TO SET THE OFF TIMEER. THEN PRESS
TIMER BUTTON AGAIN TO ENTER WAKE UP MODE.
3) WAKE UP MODE : PRESS SKIP UP/DOWN TO SET THE WAKE UP MODE (CD OR TUNER). THEN PRESS
TIMER BUTTON TO ENTER THE VOLUME MODE.
4) VOLUME LEVEL : PRESS SKIP UP/DOWN BUTTON TO SET THE VOLUME LEVEL, THEN PRESS TIMER
BUTTON AGAIN TO COMPLETE THE SETTING.
ACTIVE/DE - ACTIVE TIMER FUNCTION
1. PRESS THE TIMER BUTTON ON REMOTE HANDSET, THE PRESET TIME AND THE TIMER INDICATOR
IS SHOWN ON LCD DISPLAY (1 ).
2. TO CANCEL ALARM FUNCTION BY PRESS AGAIN TIMER BUTTON UNTIL THE TIMER INDICATOR
DISAPPEAR. E-5

REMARK
THE LCD WILL DISPLAY THE PRESETS INFORMATION (ON/OFF TIME WAKE UP MODE/VOLUME LEVEL) IN
SEQUENCE EVERY TIME WHEN ACTIVE THE TIMER FUNCTION.
C D ALARM MODE SETTING
1. AFTER TIME SETTING, INSERT THE SELECTED CD AND THEN SWITCH THE SYSTEM INTO STANDBY MODE.
2. ACTIVE THE TIMER BY PRESSING THE TIMER BUTTON ON REMOTE HANDSET UNTIL THE TIMER
INDICATOR APPEARS.
RADIO ALARM MODE SETTING
1. SET TO TUNER MODE & SELECT THE DESIRED RADIO STATION FOR WAKE UP PURPOSE.
2. SWITCH THE SYSTEM INTO STANDBY MODE.
3. ACTIVE THE TIMER BY PRESSING THE TIMER BUTTON ON REMOTE HANDSET UNTIL THE TIMER
INDICATOR APPEAR.
C. MUTE FUNCTION (BY REMOTE HANDSET)
PRESS TO TERMINATE THE SOUND OUTPUT FROM SPEAKER TEMPORARILY AND PRESS AGAIN TO RESUME
NORMAL PLAYBACK.
D. PRE - SET EQ FUNCTION
THIS UNIT PROVIDES 5 DIFFERENCES SOUND MODE TO ENHANCE YOUR LISTENING EXPERIENCE. YOU CAN
SELECT THE DESIRED EFFECT BY PRESSING THE EQ BUTTON (17) REPEATEDLY AT FOLLOWING
SEQUENCE: -
PASS CLASSIC ROCK POP JAZZ
REMOTE CONTROL TRANSMITTER
CONTROL FUNCTIONS
BATTERY INSTALLATION (BATTERY NOT PROVIDED)
THE INFRA -RED TRANSMITTER REQUIRE 2 PCS AAA BATTERY FOR OPERATION
E-6

BUTTON DESCRIPTION
MUTE PRESS TO ACTIVE MUTE FUNCTION
POWER PRESS TO SWITCH ON/STANDBY THE SYSTEM
FUNCTION PRESS TO SELECT THE FUNCTIONS (CD/TUNER/USB/AUX))
FIND / MONO/ST. IN MP3 MODE : PRESS TO ACTIVE T ITLE/ALBUM SEARCH FUNCTION
IN TUNER MODE : PRESS TO SWITCH FM MONO/STEREO SINGAL
BAND PRESS TO SELECT THE RADIO BAND
NUMBER KEY (1 - +10) PRESS TO SELECT THE NUMBER OF CD TRACK DIRECTLY
REP - UP/PRE - DOWN IN MP3 MODE : PRESS TO SKIP UP/DOWN TH E ALBUM NUMBER
IN TUNER MODE : PRESS TO CALL OUT THE PRESET MEMORY IN ORDER
VOLUME - /+ PRESS TO ADJUST VOLUME UP/ DOWN
SKIP UP /DOWN IN CD MODE : TO SELECT PREVIOUS / NEXT CD TRACK
IN TUNER MODE : PRESS TO STEP UP/DOWN OF FREQUENCY
PLA Y/PAUSE IN CD MODE, PRESS ONCE TO START PLAYBACK. PRESS ONCE AGAIN TO
STOP THE DISC PLAY TEMPORARILY
STOP PRESS TO TERMINATE CD PLAYBACK OR CANCEL PROGRMMED CD
MEMORY
RDS SEL /REPEAT TUNER MODE : ACTIVE RDS SEARCH FUNCTION
CD MODE : PRESS TO ACT IVE THE REPEAT FUNCTION FOR CD
RDS MODE/ RANDOM TUNER MODE : SELECT RDS MODE INFORMATION (PS/PTY/RT)
CD MODE : PRESS TO ACTIVE THE RANDOM PLAYBACK FOR CD
INTRO PRESS TO START THE INTRO SCAN PLAYBACK FOR CD
MEMORY IN STANDBY MODE : PRESS AND HOL D FOR CLOCK SETTING
IN CD/TUNER MODE : PRESS TO ACTIVE PROGRAM FUNCTION
SLEEP PRESS TO ACTIVE SLEEP FUNCTION
TIMER PRESS TO SET THE ALARM ON/OFF
EQ PRESS TO SELECT EQ MODE FOR ENJOYMENT
E-7
