Leoxsys Networks LEO-150N-BT User manual

11N Wireless Storage Router
LEO-150N-BT
User Manual
1

Contents
Introduction…………………………………………………………………............ 4
1.1 Package Contents………………………………..………………….…............ 4
1.2 Description……………………….……………….……………….……............. 4
1.3 Key Features……………………………………………..…………..…............ 4
1.4 Specification…………………………………………………………….............. 5
ardware installation…………………………….……………………….............. 6
2.1 T e Front Panel…………………………………………………………............ 6
2.2 T e Rear Panel………………………………….………………………............ 6
2.3 System Requirements……………………………………………..……........... 7
Installing And Using Wireless Router …………………………...…................ 8
3.1 Network configuration setup………………………………………….….......... 8
3.2 Computer configuration setup……………………………………...……......... 8
3.3 Configure IP addresses………………………………………......……............ 9
Management……………………………………………………………….….......... 10
4.1 Wireless Router configuration setup……………………..……................. 10
4.2 Wireless Settings……………………….…………………...…………........... 11
4.2.1 Basic Settings…………………………………..……………………….......... 11
4.2.2 Advance……………………………………………………………………...... 13
4.2.3 Security………………………………………………………...…………........ 14
4.2.4 WPS………………………………………………………………………........ 15
4.2.5 Station List……………………………………………….....……………........ 15
4.3 WAN setting…………………………………………….………….……........... 16
4.3.1 WAN Interface………………………………………..…………………......... 16
4.3.2 WAN Advanced……………………………………..……………………....... 18
4.4 LAN Setting……………………………………......……………………........... 19
4.4.1 LAN Interface…………………………………....……………………..…...... 19
4.4.2 DHCP Setting………………………………...…………………………......... 20
4.5 Security…………………………….………..…………………………….. ….. 21
4.5.1 Firewall………………………………..…….………………………………... 21
4.5.2 IP/Port Filtering…………………………….……………………….……...... 21
4.5.3 MAC Filtering……………………………....………………………..……..... 22
4.6 Service…………………………………..……………………………..…......... 23
4.6.1 DMZ……………………………………..…………………………………....... 23
4.6.2 Virtual Server………………………..………………………………..…….... 23
4.6.3 Remote Control…………………..……..………………………………….... 24
4.6.4 DDNS……………………………......……………………………….……….. 25
4.6.5 NTP Setting……………………...………………………………………….... 25
4.6.6 Print server setup..................................................................................... 26
4.7 Storage…………………..…………………………………………................... 32
4.7.1 User settings…………………………………………………………….......... 32
4.7.2 Disk ………………………………….…………………................................. 33
4.7.3 FTP Server…………………………………………………………………...... 33
4.7.4 SMB Server…………………………………………………………………..... 34
2

4.8 USB Apps…………………..…………………………………………............... 32
4.8.1 Printer Server…………………………………………………………….......... 32
4.8.2 DL Settings………………………………….…………………....................... 33
4.8.3 DL Torrents…………………………………………………………………...... 33
4.8.4 DL HTTP/FTP………………………………………………………………..... 34
4.9 Management…………………..…………………………………………......... 32
4.9.1 Operation Mode…………………………………………………………….... 32
4.9.2 Load Factory Defaults………………………………….………………….... 33
4.9.3 Upgrade……………………………………………………………………….. 33
4.9.4 Save/Reload…………………………………………………………………... 34
4.9.5 Command……………………………………………………………………... 35
4.9.6 Password……………………………………………………………………... . 35
4.9.7 Reboot………………………………………………………………………..... 36
4.9.8 System Log……………………………………………………………………. 36
4.10 Status…………………………………………………………………………...... 37
4.10.1 Status…………………………………………………………………………… 37
4.10.2 Statistics……………………………………………………………………….. 38
4.10.3 Cable C eck………………………………………………………………….... 38
Appendix 1: Wireless Basics
Appendix 2: Wireless Modes
Appendix 3: FAQ
3

1.Introduction
1.1 Package Contents
T ank you for purc asing 802.11n Wireless Router. Before you start, please c eck
all t e contents of t is package.
T e product package s ould include t e following:
1. One Wireless Router
2. One Power Adapter
3. One User Manual
4. One Detachable Antenna
5. One Quick Installation Guide
1.2 Description
T e 802.11n Wireless Router is compatible wit IEEE802.11n standard, w ic
supports data rate up to 150 Mbps in 2.4 GHz band, w ic is also compatible wit
IEEE 802.11g/b wireless devices. T e Wireless router allows multiple users to s are
one broadband connection, as well as secures your private network. Wit its built-
in 4-port switc and wireless AP, LAN users can s are files, and playing network
games all at a ig speed.
To provide a secure wireless network, t is Wireless router supports wireless data
encryption wit 64/128-bit WEP, WPA and WPA2. Network Address Translation
(NAT) Firewall is also support to s ield your communications and network from
ackers and wireless eavesdroppers.
T e Wireless Router built-in wit 4-port 10/100Mbps Fast Et ernet Switc is t e
latest generation of Wireless router product for Home/Office and SOHO users. T is
full-feature and self-contained compact Wireless Router will be fully for broadband
access in bot of LAN and Wireless environment. T is device as been specifically
designed to provide LAN and Wireless users t e most cost-effective met od wit
multiple accesses to t e Internet at t e cost of a single public IP address (IP
S aring)and enjoy t e true Plug-and-Play installation. Moreover, t e built-in 4-port
10/100Mbps switc lets users plug t e network cable into t e device wit out buying
additional switc .
T is device is also an Access Point. It as a built-in wireless LAN. Users can
connect to Internet using wireless network interfaces anyw ere wit in t e range of
its radio transmission. It’s ideal for SOHO users w o require instant and
4

convenient access to Internet wit out t e restriction of connecting cables
LEO-150N-BT router also act as USB Print Server, connect your USB printer wit
router and s are t e printer resources over network environment.
Simply connect USB storage wit LEO-150N-BT and build up personal File
Server,FTP Sever,Torrent Server in a few clicks.
LEO-150N-BT allow server manager to create User ID and Password and define
aut ority and quota for eac user.
It also provide user to manage access aut ority of FTP server and s are files wit
friends and customers worldwide over internet using inbuilt DDNS functionality.All
t ey ave to do is just type DDNS link and t ey can s are files over internet .
LEO-150N-BT as inbuilt Torrent/HTTP/FTP download function wit sc eduler.User
can add Torrent/HTTP/FTP download files and sc edule it.LEO-150N-BT
automatically download all TORRENT/HTTP/FTP files directly to router attac ed
storage wit out using computer.
LEO-150N-BT is designed for small office/ Home office (SOHO) market,w ere user
can s are t eir data over internet from attac ed USB storage and download
TORRENT/HTTP/FTP data directly from internet to attac ed USB storage just using
LEO-150N-BT router.
1.3 Key Features
T e Router provides t e following key features:
Complies wit 2.4GHz IEEE802.11n Draft v2.0 and backward compatible wit
IEEE 802.11b/g standards
Supports NAT/NAPT IP s aring
WAN Protocols: PPPoE/Static IP/PPTP/DHCP
Supports advanced MIMO tec nology to en ance t e t roug put and coverage
range significantly
Hig speed data rate - up to 150Mbps.
Supports Virtual Server and DMZ
Supports Wi-Fi Protected Setup ( WPS ) wit reset button
Supports 64/128-bit WEP encryption and WPA-PSK, WPA2-PSK security
Supports WMM function to meet t e multimedia transmission requirement
Supports WDS mode
Supports Special Applications (Port Triggers)
Supports DDNS (DynDNS, TZO), and QoS
Supports MAC/IP filtering and URL blocking
Supports DHCP server and Anti-Dos firewall
Web user interface (remote configuration)
System status and security log
Firmware upgradeable
5

1.4 Specification
Standards IEEE 802.11nIEEE 802.11gIEEE 802.11bIEEE 802.3IEEE
802.3uCSMA/CACSMA/CDTCP/IPDHCPICMPNATPPPE
Interface Type 4 x 10/100M RJ45 Port Auto MDI/MDIX
1 x 10/100M RJ45PortAuto MDI/MDIX
Frequency range 2.4~2.4835GHz
Radio Data Rate
11n270/243/216/162/108/81/54/27Mbps
135/121.5/108/81/54/40.5/27/13.5Mbps
130/117/104/78/52/39/26/13Mbps
65/58.5/52/39/26/19.5/13/6.5Mbps
11g54/48/36/24/18/12/9/6M
11b11/5.5/2/1M
C annel 13
Sensitivity @PER
270M-68dBm@10% PER130M -68dBm@10% PER
108M-68dBm@10% PER54M-68dBm@10% PER
11M-85dBm@8% PER6M-88dBm@10% PER
1M-90dBm@8% PER
RF Power 20dBmMax
Antenna Type 3 External
Cabling Type
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
LEDs Power, M1, WAN
， WLAN, 1,2,3,4
Dimensions
L x W x H
WR910 : 201mm × 120mm × 31.10 mm
WR910+:186.2mm x 119.7mm x 26.5mm
Power Supply DC 12V 1.0A
Environmental and P ysical
Operating Temp 0~40 (32~104)
Operating
Humidity
10% - 95% RH, Non-condensing
6

ardware installation
2.1 The Front Panel
T e front panel of t e 802.11n Wireless Router consists of several LED indicators,
w ic is designed to indicate connections. Viewed from left to rig t, t e table
describes t e LEDs on t e front panel of t e router.
Name
Action
Description
Power
OFF
No Power
ON
Power on
SYS
ON
T e router is initializing
Flas ing
T e router is working properly
OFF
T e router as a ardware error
WLAN
ON
T e Wireless Radio function is enabled
Flas ing
T e Wireless Radio function is transmitting data.
WPS
ON
Security Protect On
WAN
OFF
T ere is no WAN linked to t e corresponding port
ON T ere is a device linked to t e corresponding port
but no activity
Flas ing T ere is an active device linked to t e
corresponding port
1/2/3/4
OFF
T ere is no device linked to t e corresponding port
ON
T ere is a device linked to t e corresponding port
but no activity
Flas ing
T ere is an active device linked to t e
corresponding port
7

2.2 The Rear Panel
T e rear panel contains t e following features. (Viewed from left to rig t:)
Rear Panel 1
1. Wireless antenna, one Unfix antenna.
2. WAN RJ45 port for connecting t e router to a cable, DSL modem or
Et ernet.
3. Four LAN 10/100Mbps RJ45 ports for connecting t e router to t e local
PCs .
4. DC power jack: only use t e power adapter supplied wit Wireless
Router, use of a different adapter may result in product damage.
5. Factory Default Reset button.
6. WPS Button.Wireless Protected Setup.
7. USB 2.0 port ,Connect USB Printer or USB arddisk,flas drive etc.
T ere is a way to reset t e router's factory defaults:
1. Use t e Factory Default Reset button:
A) Turn on t e router's power.
B) Press and old t e default reset button, until t e system LED lig ts up(about 5
seconds).
C)Release t e reset button and wait for t e router to reboot.
Notice: Ensure t e router is powered on before it restarts completely.
8

2.3 System Requirements
• Broadband Internet Access Service (DSL/Cable/Et ernet).
• One DSL/Cable modem t at as an RJ45 connector (you do not need it if you
connect t e router to Et ernet).
• Eac PC on t e LAN needs a working Et ernet Adapter and an et ernet cable
wit RJ45 connectors.
• TCP/IP protocol must be installed on eac PC.
• Web browser, suc as Microsoft Internet Explorer 5.0 or later, Netscape Navigator
6.0 or later.
Installing And Using Wireless Router
T is C apter provides a step-by-step guide to t e installation and configuration of t e
Wireless Router. We suggest you go over t e w ole c apter and t en do more
advanced operation.
3.1 Network configuration setup
Steps to build up t e network:
 Connect t e ADSL or Cable modem to t e Et ernet WAN port on t e back of t e
Wireless Router by using t e UTP cable.
 Connect t e p one line from t e wall socket to t e line-in port on t e ADSL
modem, or t e coaxial cable to t e line-in port on t e Cable modem.
 Plug-in t e power adapter to t e modem and turn on t e power. Install t e
Et ernet card into t e computer by referring to t e User Guide t at came wit t e
card.
 Connect t e computer to t e Wireless Router by using standard twisted-pair
Et ernet cable from t e computer’s Et ernet card to an 10/100Mbps Et ernet port
on t e back
of t e Wireless Router.
 Plug-in t e power adapter to t e Router and t e ot er side to t e wall outlet.
.
3.2 Computer configuration setup
In order to communicate wit t is Wireless Router, you ave to configure t e IP
addresses of your computer to be compatible wit t e device. T e router supports
DHCP server and it is enabled as default. Users t at configure your IP address as
“Obtain an IP address automatically” may skip t e following IP configuration
instruction.
9

Note:
1. T e default network setting of t e device:
IP address: 192.168.7.1
Subnet Mask: 255.255.255.0
D CP Server: enabled
2. In t e following TCP/IP configuration guide, t e IP address “192.168.7.2” is
assumed to be your IP address if you want to specify IP addresses manually. Please
DO NOT c oose “192.168.7.1” for t e IP address (192.168.7.1) as been set as t e
default IP for t is device.
3. T e following TCP/IP configuration guide uses windows XP as t e presumed
operation system.
3.3 Procedures to configure IP addresses for your computer
1. If you are in Classic Start menu view, click Start > Settings > Control Panel >
Network Connections. If you are in Start menu view, click Start > Control Panel
> Network Connections.
2. Double click Local Area Connection.
3. C oose Internet Protocol (TCP/IP) and click Properties.
10

4. You may c oose “Obtain an IP address automatically”(recommend) to get IP
address automatically or c oose “Use t e following IP address” to specify IP
addresses manually. Please click t e OK button after your configuration.
Management
4.1 Wireless Router configuration setup
T is product provides Web based configuration sc eme, w ic is configuring by
Netscape Communicator or Internet Explorer. Take example for Microsoft Internet
Explorer.
1. Activate your browser, select Tools, point to Internet option, click connect ， select
dial-up network never, affirm inspect setting automatically, configure scrip
automatically and use agency server on LAN setting not to be selected.
2. Type ttp://192.168.7.1 in Address field and press Enter. Key in t e user name
and password (if you use it first, you can type t e factory default setting .User name
is admin and password is admin), click on t e OK button.
11

After login successfully, web-configuration will be displayed.
4.2 Wireless Settings
4.2.1 Basic Settings
You can set up t e configuration of your Wireless and monitor t e Wireless
Clients associate wit your AP
12

1 Radio Status: T e Status of Wireless.
2 Radio On/Off: Click t e button to enable t e wireless function. If you want to use
wireless, click t e button ‘Radio On’, and if you don’t want to use wireless, click t e
button ‘Radio off’.
3 Network mode: Select one of t e following: 11g - Select if all of your wireless
clients are 802.11g. 11b/g - Select if you are using bot 802.11b and 802.11g
wireless clients. 11b - Select if all of your wireless clients are 802.11b. 11b/g/n -
Select if you are using a mix of 802.11n, 11g, and 11b wireless clients.
4 Network Name(SSID): Service Set Identifier (SSID) is t e name of your wireless
network. You can use more t an one SSID , but less t an eig t. Create a name using
up to 32 c aracters. T e SSID is case-sensitive.
5 Broadcast Network Name(SSID): Enable is t e default setting. C oose Enable
to broadcast t e SSID across t e network. All devices on a network must s are t e
same SSID (Service Set Identifier) to establis communication. C oose Disable if
you do not wis to broadcast t e SSID over t e network.
6 BSSID: T e value of BSSID.
7 Frequency(Channel): Indicates t e c annel setting for t e Wireless Router. By
default t e c annel is set to 1. T e C annel can be c anged to fit t e c annel setting
for an existing wireless network or to customize t e wireless network. If you enable
Auto Channel Scan, t is Extension Channel will be grayed out.
13

8 WDS Mode: WDS is commonly used in areas requiring multiple APs, w ere
wiring is not possible or costly and for providing back-up pat s between APs. T e
number of ports on an AP available for t e WDS is dependent on t e AP model.
Disable – select if t ere is only one LAN and t e range of wireless cover is enoug .
Lazy Mode - select if you don’t known t e AP MAC Address on ot er APs, but you
must select t e Phy Mode and EncryptType w ic is t e same as ot er APs.
Bridge Mode – select if you two different LAN in network, and want to link toget er.
Of course, you need to select t e Phy Mode and EncryptType in t e same mode as
Lazy Mode, and need t e AP MAC Address too, t ere you can use fill AP MAC
Address. Repeater Mode – select if you want to extend t e LAN range. Of course,
you need to select t e Phy Mode and EncryptType in t e same mode as Lazy
Mode, and need t e AP MAC Address too, t ere you can use fill AP MAC Address.
9 Operating Mode: T is is t e default setting Mixed Mode or setting Green Field;
10 Channel Bandwidth: Select t e C annel Widt : 20/40 - T is is t e default
setting. Select if you are using bot 802.11n and non-802.11n wireless devices. 20 -
Select if you are not using any 802.11n wireless clients.
11 Guard Interval: Auto – c eck if reduce t e guard interval time t erefore
increasing t e data capacity. However, it’s less reliable and may create ig er data
loss. Reverse if c eck t e long.
12 MCS: T is is t e default setting Auto Mode
13 Reverse Direction Grant(RDG): Enable - facilitate increased communication
c annel bandwidt efficiency in association wit sc eduled time periods t at allocate
c annel access to particular stations. According to various aspects, systems and
met ods are described t at facilitate providing and/or utilizing reverse direction
grants in connection wit sc eduled c annel access. It can mitigate an amount of
unused c annel access time after a station completes data transmission prior to an
end of t e allocated period. Disable – select if you don’t need t is function.
14 Extension Channel: If t e Frequency(Channel) select is not autoselect , t e
Extension Channel is enable. You can select t e Extension Channel you want to. It
can elp speed recovery.
15 Aggregation MSDU(A-MSDU):
16 Auto Block ACK: Enable – select if you want to block ACK automatically. Or else
you can select Disable.
17 Decline BA Request: Enable – select if you want to Decline BA Request. Or else
you can select Disable.
4.2.2 Advance
You can set advanced wireless LAN parameters of t is router. We recommend not
c anging t ese parameters unless you know w at c anges will be t ere on t is
router.
14

1 BG Protection Mode: Select eit er Auto On or Off. Default is Auto
2 Basic Data Rates: Select t e data rate. Default is 1-2-5.5-11-22-54Mbps
3 Beacon Interval: Beacons are packets sent by an Access Point to sync ronize a
wireless network. Specify a value. 100 is t e default setting and is recommended.
4 Data Beacon Rate (DTIM): (Delivery Traffic Indication Message) 1 is t e default
setting. A DTIM is a countdown informing clients of t e next page for listening to
broadcast and multicast messages.
5 Fragment Threshold: T e fragmentation t res old, w ic is specified in bytes,
determines w et er packets will be fragmented. Packets exceeding t e 2346 byte
setting will be fragmented before transmission. 2346 is t e default setting.
6 RTS Threshold: T is value s ould remain at its default setting of 2432. If
inconsistent data flow is a problem, only a minor modification s ould be made.
7 TX Power (SSID): Set t e transmit power of t e antennas.
8 Short Preamble: C eck t is box to reduce t e guard interval packet t erefore
increasing t e data capacity. However, it’s less reliable and may create ig er data
loss.
9 Short Slot: C eck t is box to reduce t e guard interval time t erefore increasing
t e data capacity. However, it’s less reliable and may create ig er data loss.
10 Tx Burst: Click eit er Enable or Disable. Default is Enable.
11 Pkt_Aggregate: if Click Enable, t e packets will be Aggregated before t ey sent.
Click eit er Enable or Disable. Default is Enable.
15

12 IEEE 802.11 : T is enables 802.11 operation. 802.11 is a wireless
specification developed to allow implementation of wireless networks in countries t at
cannot use t e 802.11 standard. T is feature s ould only be enabled if you are in a
country t at requires it. Click eit er Enable or Disable. Default is Disable. only in A
band
13 Country Code: Here you can select t e Country Code.
14 WMM: WMM is QoS for your wireless network. Enable t is option to improve t e
quality of video and voice applications for your wireless clients.
15 WMM Parameters: Click t is button, you will see t e configuration of t e WMM
w ic appears in anot er page. In t e page, you can configure t e parameters of
WMM.
16 Multicast-to-Unicast: Enable – select if allow multicast traffic to pass t roug t e
router from t e Internet. Disable – select if not allow.
4.2.3 Security
It is recommended to enable encryption on your wireless router before your wireless
network adapters. Please establis wireless connectivity before enabling encryption.
Your wireless signal may degrade w en enabling encryption due to t e added
over ead.
1 SSID choice: select t e SSID w ic you want to set its Security Mode.
2 Security Mode: set t e security mode at t e SSID w ic you select. T ere are
nine modes for you to select. W atever you select, t e page will s ow you w at
parameters you configure. Refer to page 60 for more information regarding wireless
security.
16

4.2.4 WPS
1 WPS: Enable – select if you want to make t e WPS enable. If you don’t need,
select disable and click Apply button. T e following display t e setting and status of
WPS.
2 WPS mode: t e mode of WPS, if you select PIN button, you need a PIN, or else,
you select t e PBC button. And t en click Apply button.
3 WPS Status: t e status log of WPS.
Station List
17

In t is page, you can see t e status station list of t e wireless network, w ic display
MAC Address, Aid , PSM.
4.3 WAN Setting
4.3.1 WAN Basic
1 WAN Connection Type: t e connection mode of WAN port. T ere are five c oice
you can select.
If you select D CP (Auto Config), information automatically from your ISP. Select
t is option if your ISP does not give you any IP numbers to use. T is option is
commonly used for Cable modem services. ost Name (optional): T e Host Name
is optional but may be required by some ISPs.
18

C oose PPPoE (Point to Point Protocol over Et ernet) if your ISP uses a PPPoE
connection. Your ISP will provide you wit a user name and password. T is option is
typically used for DSL services. Make sure to remove your PPPoE software from
your computer. T e software is no longer needed and will not work t roug a router.
User Name: Enter your PPPoE user name.
Password: Enter your PPPoE password and t en retype t e password in t e next
box.
MTU: Maximum Transmission Unit - you may need to c ange t e MTU for optimal
performance wit your specific ISP. 1492 is t e default MTU.
MRU: Maximum Receive Unit - you may need to c ange t e MRU for optimal
performance wit your specific ISP. 1492 is t e default MTU.
C oose PPTP (Point-to-Point-Tunneling Protocol ) if your ISP uses a PPTP
connection. Your ISP will provide you wit a user name and password. T is option is
typically used for DSL services.
PPTP Server IP Address: Enter t e Server IP provided by your ISP (optional).. User
Name: Enter your PPTP user name.
Password: Enter your PPTP password and t en retype t e password in t e next
box.
MTU:Maximum Transmission Unit - you may need to c ange t e MTU for optimal
performance wit your specific ISP. 1492 is t e default MTU.
Address Mode: Select Static if your ISP assigned you t e IP address, subnet mask,
gateway, and DNS server addresses. In most cases, select Dynamic. IP Address:
Enter t e IP address (Static PPTP only).
Subnet Mask: Enter t e Primary and Secondary DNS Server Addresses (Static
PPTP only).
Default Gateway: Enter t e Gateway IP Address provided by your ISP.
19

C oose L2TP (Layer 2 Tunneling Protocol) if your ISP uses a L2TP connection.
Your ISP will provide you wit a user name and password. T is option is typically
used for DSL services.
L2TP Server IP Address: Enter t e Server IP provided by your ISP (optional).
User Name: Enter your L2TP user name.
Password: Enter your L2TP password and t en retype t e password in t e next box.
MTU: Maximum Transmission Unit - you may need to c ange t e MTU for optimal
performance wit your specific ISP. 1492 is t e default MTU.
Address Mode: Select Static if your ISP assigned you t e IP address, subnet mask,
gateway, and DNS server addresses. In most cases, select Dynamic. IP Address:
Enter t e L2TP IP address supplied by your ISP (Static only).
Subnet Mask: Enter t e Subnet Mask supplied by your ISP (Static only).
Default Gateway: Enter t e Gateway IP Address provided by your ISP.
Select Static IP Address if all t e Internet port’s IP information is provided to you
by your ISP. You will need to enter in t e IP address, subnet mask, gateway address,
and DNS address(es) provided to you by your ISP. Eac IP address entered in t e
fields must be in t e appropriate IP form, w ic are four octets separated by a dot
(x.x.x.x). T e Router will not accept t e IP address if it is not in t is format.
IP Address: Enter t e IP address assigned by your ISP.
Subnet Mask: Enter t e Subnet Mask assigned by your ISP.
Default Gateway: Enter t e Gateway assigned by your ISP.
Primary DNS Server: T e DNS server information will be supplied by your ISP
(Internet Service Provider.).
Secondary DNS Server: T e DNS server information will be supplied by your ISP
(Internet Service Provider.).
20
