LG CNS LPT-200AR User manual

User Guide for LPT-200AR
A n d r o i d Ta b l e t P C

Table of Contents
2
- -
1. Overviewing Product
2. H/W Spec.
3. Wi-Fi Output Power
4. Easy Setting Icons
5. Setting
1. Wi-Fi
2. Bluetooth
3. Airplane mode
4. Tethering & portable hotspot
5. Display
6. Sound & Notification
7. Storage
8. Apps
9. User
10. Location
11. Security
12. Accounts
13. Language & Input
14. Backup & Reset
15. Date & Time
16. Accessibility
17. Developer options
18. About Tablet
5. Front Camera
6. Music
7. SAR INFORMATION

Overviewing Product
3
- -
2
4
3
5
1
①Illuminance Sensor
②Front Camera
③Mic.
④Micro SD Card Slot
⑤Earjack Port

Overviewing Product
4
- -
①IMEI Label
②WIFI & BT MAC Address
③Certification Label
④Home Key
⑤Back Key
⑥Recent Key
⑦FCC Waring Label
⑧Micro SD Card Slot
⑨Speaker
1
2
3
9 9
4
5
6
7
8

H/W Spec.
5
- -
Dimension
246 X 175 X 14.5mm
Weight
620g
Buttons
Home, Back, RECENT
USB
USB 2.0 OTG
Speaker
Channel
Stereo
Frequency Range
20Hz~20,000Hz
Max Output
Left 0.5W+Right 0.5W (With 8Ω )
Display
Inch
10.1"
Resolution
1280 x 800 / MIPI
Panel type
TFT
Touch type
Capacitive
Battery
N/A
CPU
MEDIATEK MT8127A/BA
RAM
1GB (512MB * 2)

H/W Spec.
6
- -
Flash
eMMC / 16GB
Wi-Fi
IEEE 802.11 b/g/n/a
Camera
Front 2M
3G & LTE Telec Ceritfication Module (Model : LPT-201AR Only)
MIC
Omni
-direction
Bluetooth
v4.0(LE)
Sensor
Light illumination/Acceleration/Gyro/Geomagnetic/NTC
SD Socket
Micro SD Socket
SIM Socket
Nano USIM socket
OS
Android Lollipop 5.1
Media
File format
3GPP, MPEG
-4, ADTS raw AAC, MPEG-TS, MP3
Video codec
H.264 AVC
Audio codec
MPEG
-4 AAC Profile, MPEG-4 HE-AACv1, MPEG-4 HE-AACv2
MPEG
-4 Audio Object Type ER AAC ELD, MP3

Wi-Fi Output Power
7
- -
Bandwidth Mode Freq. Data Rate Output Power
20Mhz
b 2.4G 11Mbps 19dBm
g 2.4G 54Mbps 16.5dBm
a5G 54Mbps 17dBm
n
2.4G MCS7 16dBm
5G MCS7 16dBm
40Mhz n
2.4G MCS7 15dBm
5G MCS7 17dBm

Easy Setting Icons
8
- -
1. Down Scroll from up to down 2. Check Easy-Setting Icons
3
21
①Setting
②Account
③Brightness
④Wi-Fi On/Off
⑤Bluetooth On/Off
⑥Airplane mode On/Off
4 5
6

Setting –Wi-Fi
9
- -
1. Run by selecting the “Wi-Fi” icon on Settings app. 2. Turn on Wi-Fi by selecting on/off switch button.

Setting –Wi-Fi
10
- -
3. When the scan is completed,
the screen will appear briefly scanned AP list.
Select the AP you want to connect to.
4. When the AP connection password settings screen
2
1
①enter the password
② and press ‘CONNECT’ button.

Setting –Wi-Fi
11
- -
5. Screen of the AP connection complete. 6. Run by selecting the “Browser" icon on the Home
screen.
When the connection is completed,
press the "HOME" button, and go to the main screen,

Setting –Wi-Fi
12
- -
7. Click your web browser address bar, and enter
“www.youtube.com".
8. Once connected the youtube web page
21
①select search icon on right-top
② and enter “star wars”

Setting –Wi-Fi
13
- -
9. Select the video you want to watch, you can watch the video.

Setting –Bluetooth
14
- -
1. Run by selecting the “Bluetooth” icon on Settings
app.
2. Turn on Bluetooth by selecting on/off switch button.

Setting –Bluetooth
15
- -
3. When the scan is completed,
the screen will appear briefly scanned device list.
Select the device you want to pair to.
4. Press PAIR button.

Setting –Bluetooth
16
- -
5. Screen of the pairing complete.
When the pairing is completed,
press the "HOME" button, and go to the main screen,

Setting –Bluetooth
17
- -
※ Receive file
7. When request is received,
the screen will show a message
[Incoming file from another device ….]
6. On paired device, send a image file to my tablet.
Wait until the file transferred from paired the device.

Setting –Bluetooth
18
- -
※ Receive file
9. press ACCEPT button.8. Pull down notification bar,
and tap on the notification that says
[Bluetooth share: Incoming file].

Setting –Bluetooth
19
- -
※ Receive file
11. When file receiving is completed,
the screen will show a message
[Bluetooth share: Received /storage/…].
10. The screen will show a message
[The file will be received…]

Setting –Bluetooth
20
- -
※ Receive file
13. You can see received image file.
Select image file you want to see.
12. Run by selecting the “Gallery" icon on the Home
screen.
