LG F1258RDS Series User manual

F1258RDS
F1258RDS(0~9)
Thank you for buying a
LG Fully Automatic Washing machine.
Please read your owner's manual carefully, it rovides
instructions on safe installation, use and maintenance.
Retain it for future reference.
Record the model and serial numbers of your washing machine.
P/No.: MFL62526807
Washing Machine
OWNER'S MANUAL

roduct Feature
P
ontents
C
2
Warnings ......................................................................................................................3
S ecification...................................................................................................................5
Installation......................................................................................................................6
Care before washing....................................................................................................12
Adding detergent..........................................................................................................13
Function ....................................................................................................................15
How to use washer ......................................................................................................16
Maintenance ................................................................................................................25
Troubleshooting guide .................................................................................................29
Terms of Warranty .......................................................................................................33
Direct Drive System
The advanced Brushless DC motor directly drives the drum without
belt and ulley.
Water Circulation
S rays detergent solution and water onto the load over and over.
Clothes are soaked more quickly and thoroughly during wash cycle.
The detergent suds can be removed more easily by the water shower during rinse
cycle. The water circulation system uses both water and detergent more efficiently.
Tilted Drum and Extra Large Door Opening
Tilted drum and extra large o ening make it ossible to load
and unload clothing more easily.
Steam Washing and Refresh
Steam Washing features u graded washing erformance with low energy and
water consum tion. Refresh cycle removes wrinkles from dry clothes.
RollerJets
Washing ball enhances the wash erformance and reduces damage
to the clothing. The jets s ray and hel tumble clothes to enhance
washing erformance while maintaining fabric care.
Automatic Wash Load Detection
Automatically detects the load and o timizes the washing time.
Built-in Heater
Internal heater hel s to maintain water tem erature at its o timum level for selected
cycles.
Child Lock
The Child lock revents children from ressing any button to change the settings
during o eration.
추가선택, 예약,

arnings
W
3
For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion, electric shock, or to prevent property damage,
personal injury, or loss of life.
!
READ ALL INSTRUCTIONS BEFORE USE
WARNING!
• Do not install or store the washer where it will
be ex osed to the weather.
• Do not tam er with controls.
• Do not re air or re lace any art of the washer
or attem t any servicing unless s ecifically
recommended in the user-maintenance
instructions or ublished user-re air instructions
that you understand and have the skills to carry
out.
• Kee the area underneath and around your
a liances free of combustible materials such as
lint, a er, rags, chemicals, etc.
• Close su ervision is necessary if this a liance
is used by or near children or infirm ersons.
Do not allow them to lay on, with, or inside this
or any other a liance.
• Kee washer away from fire.
• Do not leave the washer door o en.
An o en door could entice children to hang on
the door or crawl inside the washer.
• Never reach into washer while it is moving. Wait
until the drum has com letely sto ed.
• The laundry rocess can reduce the flame
retardant of fabrics.
• Do not wash or dry articles that have been
cleaned in, washed in, soaked in, or s otted with
combustible or ex losive substances (such as
wax, oil, aint, gasoline, degreasers, dry
cleaning solvents, kerosene, etc.) which may
ignite or ex lode. Oil may remain in the tub after
a whole cycle resulting in fire during drying. So,
do not load oiled clothes.
• Always follow the fabric care instructions
su lied by the garment manufacturer.
• Do not slam the washer door closed or try to
force the door o en when locked. This could
result in damage to the washer.
• To minimize the ossibility of electric shock,
un lug this a liance from the ower su ly or
disconnect the washer at the household
distribution anel by removing the fuse or
switching off the circuit breaker before
attem ting any maintenance or cleaning.
• Never attem t to o erate this a liance if it is
damaged, malfunctioning, artially
disassembled, or has missing or broken arts,
including a damaged cord or lug.
• Dryer is intended for only drying textile material.
• If the washer has been ex osed to water, call an
authorized service rovider to avoid any risk of
fire or electric shock.
GROUNDING INSTRUCTIONS
This a liance must be grounded. In the event of malfunction or breakdown, grounding will reduce the risk
of electric shock by roviding a ath of least resistance for electric current. This a liance is equi ed with
a cord having an equi ment-grounding conductor and grounding lug. The lug must be lugged into an
a ro riate outlet that is ro erly installed and grounded in accordance with all local codes and ordinance.
• Do not use an ada ter or otherwise defeat the grounding lug.
• If you don’t have the ro er outlet, consult an electrician.
IMPORTANT SAFETY INSTRUCTIONS
WARNING : To reduce the risk of fire, electric shock, or injury to ersons when using
the washer, follow basic recautions, including the following:
SAVE THESE INSTRUCTIONS
WARNING :Im ro er connection of the equi ment-grounding conductor can result in risk of electric
shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the a liance is
ro erly grounded. Do not modify the lug rovided with the a liance - if it does not fit the outlet, have a
ro er outlet installed by a qualified electrician.

arnings
W
4
To minimize the risk of fire in a tumble dryer, the following should be observed:
• Items that have been s otted or soaked with vegetable or cooking oil constitute a fire
hazard and should not be laced in a tumble dryer.
Oil-affected items can ignite s ontaneously, es ecially when ex osed to heat
sources Such as in a tumble dryer. The items become warm, causing an oxidation
reaction in the oil. Oxidation creates heat. If the heat cannot esca e, the items can
become hot enough to catch fire. Piling, stacking or storing oil-affected items can
revent heat from esca ing and so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been
contaminated by hair care roducts be laced in a tumble dryer they should first be
washed in hot water with extra detergent-this will reduce, but not eliminate, the
hazard. Washed in hot water with extra detergent-this will reduce, but not
eliminate, the hazard. The ‘cool down’ cycle of tumble dryers should be used to
reduce the tem erature of the items. They should not be removed from the tumble
dryer or iled or stacked while hot.
• Items that have been reviously cleaned in, washed in, soaked in or s otted with
etrol/gasoline, dry-cleaning solvents or other flammable or ex losive substances
should not be laced in a tumble dryer.
Highly flammable substances commonly used in domestic environments include
acetone, denatured alcohol, etrol/gasoline, kerosene, s ot removers (some
brands), tur entine, waxes and was removers.
• Items containing foam rubber (also known as latex foam) or similarly testured
rubber. like materials should not be dried in a tumble dryer on a heat setting.
Foam rubber materials can, when heated, roduce fire by s ontaneous combustion.
• Fabric softeners or similar roducts should not be used in a tumble dryer to eliminate
the effects of static electricity unless this ractice is s ecifically recommended by the
manufacturer of the fabric softener or roduct.
• Undergarments that contain metal reinforcements should not be laced in a tumble
dryer.
Damage to the tumble dryer can result if metal reinforcements come loose during
drying. When available a drying rack could be used for such items.
• Plastic articles such as shower ca s or babies water roof na kin covers should not
be laced in a tumble dryer.
• Rubber-backed articles, clothes fitted with foam rubber ads, illows, galoshes and
rubber-coated tennis shoes should not be laced in a tumble dryer.

5
pecification
S
Name : Front loading washing machine
Power su ly : 220 V~, 50/60 Hz
Size : 686 mm(W) x 756 mm(D) x 983 mm(H)
Weight : 92 kg
Wash ca acity : 15 kg
Dry ca acity : 8 kg
Max. Watt : 2200 W (Wash) / 2150 W (Dry) / 1900 W (Steam)
S in s eed : Gentle / 400 / 800 / 1000 / 1200
Permissible water ressure :
0.3-10 kgf/㎠(30-1000 kPa)
❋The a earance and s ecifications may be varied without notice to im rove the units quality.
S anner
Inlet hose(2EA)
 Accessories
Control Panel
Shipping Bolts
Power Plug
• If the su ly cord is damaged,
it must be re laced by the
manufacturer or its authorized
service technician in order to
avoid a hazard.
Drum
Drain Plug Drain Pump Filter
Lower cover cap
Door
Adjustable Feet
Drain Hose
Dispenser
Air Vent for Safety Hot Water Inlet
Cold Water Inlet
Back of Washer

6
nstallation
I
1. To revent internal damage during
trans ort, the s ecial 4 bolts are locked.
Before o erating the washer, remove
the bolts along with the rubber bungs.
• If they are not removed, it may cause heavy
vibration, noise and malfunction.
3. Take out the 4 bolts along with the rubber
bungs by slightly twisting the bung. Kee
the 4 bolts and the s anner for future use.
• Whenever the a liance is trans orted, the
transit bolts must be refitted.
The a liance is fitted with transit bolts to revent internal damage during trans ort.
• Packing and all transit bolts
must be removed before using
the washer.
󳢹When unpacking the base, be
sure to remove the additional
packing support in the middle
of the base packing.
2. Unscrew the 4 bolts with
the s anner su lied.
4. Close the holes with the ca s su lied.
 Transit bolts
Install or store where it will not be ex osed to tem eratures below freezing or ex osed to
the weather.
Pro erly ground washer to conform with all governing codes and ordinances.
The base o ening must not be obstructed by car eting when the washing machine is
installed on a car eted floor.
In countries where there are areas which may be subject to infestation by cockroaches or
other vermin, ay articular attention to kee ing the a liance and its surroundings in
clean condition at all times.
Any damage which may be cause by cockroaches or other vermin will not be covered by
the a liance guarantee.
 Removing transit bolts
Base Packing
Washer
Packing Su ort

7
nstallation
I
Level floor :
Allowable slo e under entire washer is 1°
Power outlet :
Must be within 1.5 meters of either side of location of
washer. Do not overload the outlet with more than one
a liance.
Additional Clearance :
For wall, door and floor modeling is required.
(10cm : rear / 2cm : right & left side)
Do not lace or store laundry roducts on to of washer at
any times.
They can damage the finish or controls.
 Installation place requirement
 Positioning
Install the washer on a flat hard floor.
Make sure that air circulation around the washer is not impeded by carpets,rug etc.
• Before placing the washer on tiles, apply a rubber mat under the feet.
• ever try to correct any unevenness in the floor with pieces of wood, cardboard or similar
materials under the washer.
• If it is impossible to avoid positioning the washer next to a gas cooker or coal burning
stove,an insulating(686 x 756 x 983 mm) covered with aluminum foil on the side facing the
cooker or stove,must be inserted between the two appliance.
• The washer must not be installed in rooms where the temperature can drop below 0°C.
• Please ensure that when the washer is installed, it is easily accessible for the engineer in
the event of a breakdown.
• With the washer installed adjust all four feet using the transit bolt spanner provided
ensuring the appliance is stable, and a clearance of approximately 20mm is left between
the top of the washer and the underside of the work-top.
Washer
approx.
2cm
Drain Hose
Laundry
Tub

8
nstallation
I
▶ Water supply pressure must be between 30kPa and 1000kPa
(0.3~10kgf/cm2)
▶ D n’t strip r cr ssthread when c nnecting Inlet h se t the valve.
▶ If the water supply pressure is m re than 1000kPa, a dec mpressi n
device sh uld be installed.
• Two rubber seals are su lied with the water inlet hoses these are in
order to revent water leaks.
• Check water tightness of washing machine connections by turning
the ta com letely on.
• Periodically check the condition of the hose and re lace the hose if
necessary.
• Make sure that there is no kink on the hose and that it is not crushed.
▶ When y ur washer has tw valves,
• The Inlet hose which has red connector is for the hot water ta .
• If the washer has two valves, the energy is saved by using hot valve.
 Washing Machine is to be connected to the water mains using new hose-sets and that old
hose-sets should not be used.
 Connecting water supply hose
1. Do not use an extension cord or double ada ter.
2. If the su ly cord is damaged, it must be re laced by the manufacturer or its service agents or similarly
qualified erson in order to avoid a hazard.
3. Always un lug the machine and turn off the water su ly after use.
4. Connect the machine to an earthed socket in accordance with current wiring regulations.
5. The a liance must be ositioned so that the lug is easily accessible.
• Re airs to the washing machine must only be carried out qualified ersonnel. Re airs carried out by inex erienced ersons
may cause injury or serious malfunctioning. Contact your local service center
• Do not install your washing machine in rooms where tem eratures below freezing may occur. Frozen hoses may burst under
ressure. The reliability of the electronic control unit may be im aired at tem eratures below freezing oint.
• If the a liance is delivered in the winter months and tem eratures are below freezing : Store the washing machine at room
tem erature for a few hours before utting it into o eration.
 Electrical connection
CAUTION concerning the Power Cord
Most a liances recommend they be laced u on a dedicated circuit; that is, a single outlet circuit which
owers only that a liance and has no additional outlets or branch circuits. Check the s ecification age of
this owner's manual to be certain. Do not overload wall outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed ower cords, or damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric shock or fire. Periodically examine the cord of your a liance,
and if its a earance indicates damage or deterioration, un lug it, discontinue use of the a liance, and
have the cord re laced with an exact re lacement art by an authorized servicer. Protect the ower cord
from hysical or mechanical abuse, such as being twisted, kinked, inched, closed in a door, or walked
u on. Pay articular attention to lugs, wall outlets, and the oint where the cord exits the a liance.
CAUTION
The a liance is not intended for use by young children or infirm ersons without su ervision.
Young Children should be su ervised to ensure that they do not lay with a liance.
CAUTION
NOTE
After completing connection, if water leaks from the hose, the repeat the same steps. Use the most conventional
type of faucet for water supply. In case the faucet is square or too big, remove the spacing ring before inserting
the faucet into the adaptor.

9
nstallation
I
 Normal Tap without thread & screw type inlet hose
 Normal Tap without thread & one touch type inlet hose
1.Unscrew the fixing screw to
attach the ta .
2.Push the connector u till the
rubber acking is in tight contact
with the ta . Then tighten the 4
screws.
3.Push the water su ly hose
vertically u wards so that the
rubber acking within in the
hose can adhere com letely to
the ta and then tighten it by
screwing it to the right.
1.Un tighten the u er connector
screw.
2.Push the u er connector u till
the rubber acking is in tight
contact with the ta . Then
tighten the 4 screws.
3. Connect the water su ly hose
to the middle connector,
ushing the late down.
• Make sure that there are no
kinks in the hose and that it is
not crushed.
• Make sure that the rubber seal
is inside the hose connector.
U er
Connector Rubber
acking
Middle
connector
Fixing screw
Guide late
Connector
Rubber seal
Hose connector
Used the horizontal tap
Horizontal ta
Extension ta
Square ta
Rubber acking
U er
Connector
Middle
connector
Plate
U er
Connector
Water su ly
hose
• In case the diameter of the ta is
large remove the guide late.
• Turn the middle connector not
to have water leaked.
• To se arate the water su ly
hose from the middle connector
shut off the ta . Then ull the
inlet hose down, ushing the
late down.

10
nstallation
I
 Installation of drain hose
max. 100cm
min. 60cm
Hose
Retainer
Laundry tub
Tie
stra
max. 100cm
min. 60cm
• The drain hose should not be laced higher than
100 cm above the floor. Water in the washer does
not drain or drains slowly.
• Pro er securing of the drain hose will rotect the
floor from damage due to water leakage.
• When the drain hose is too long, do not force back
into the washer. This will cause abnormal noise.
• When installing the drain hose to a sink,
secure it tightly with a string.
• Pro er securing of the drain hose will
rotect the floor from damage due to
water leakage.
This equi ment is not designed for maritime use or for use mobile installations such as
caravans, aircraft etc.
Turn off the sto cock if the machine is to be left for any length of time (e.g. holiday),
es ecially if there is no floor drain(gully) in the immediate vicinity.
When dis osing of the a liance, cut off the mains cable, and destroy the Plug.
Disable the door lock to revent young children being tra ed inside.
Packaging material (e.g. Films, Styrofoam) can be dangerous for children. There is a risk
of suffocation ! Kee all ackaging well away from children
max. 100 cm
min. 60 cm
about 105 cm
about 145 cm
about 100 cm
max. 100 cm
about 105 cm
about 145 cm
about 100 cm
min. 60 cm

11
nstallation
I

Concrete floors

Wooden floors (Suspended floors)
• The installation surface must be clean, dry and level.
• Install washer on a flat hard floor.

Tile floors (Slippery floors)
• Position each foot on the Tread Mate and level the machine to suit. (Cut Tread Mate into 70x70 mm
sections and stick the pieces on to the dry tile where machine is to be placed.)
※※
Tread Mate is a self adhesive material used on ladders & steps that prevents slipping.
• Wooden floors are particularly susceptible to vibration.
• To prevent vibration we recommend you place rubber cups under each foot,
at least 15mm thick under the washer, secured to at least 2 floor beams with screws.
• If possible install the washer in one of the corners of the room, where the floor is more stable.
※※
Insert the rubber cups to reduce vibration.
※※
Rubber cups ( p/no. 4620ER4002B ) can be purchased from the L spare parts department.
Important!
• Proper placement and levelling of the washer ensures long, regular and reliable operation.
• The washer must be absolutely horizontal and stand firmly in position.
• It must not “Seesaw” across corners under load.
• The installation surface must be clean, free from floor wax and other lubricant coatings.
• Do not let the feet of the washer get wet. If feet of the washer get wet, slipping may occur.
※
It can be purchased from
hardware suppliers.
 Level adjustment
1. Adjusting the washing machine level ro erly revents excessive
noise and vibration.
Install the a liance on a solid and level floor surface, referably in
a corner of the room.
2. If the floor is uneven, adjust the adjustable feet as required. (do
not insert ieces of wood etc. under the feet)
Make sure that all four feet are stable and resting on the floor and
then check that the a liance is erfectly level. (use a s irit level)
※※
After the washer is level, tighten the lock nuts up towards of the base of
the washer. All lock nuts must be tightened.
❊ Diagonal Check
When pushing down the edges of the washing machine top plate diagonally, the
machine should not move up and down at all. (Please, check both of two directions)
If machine rocks when pushing the machine top plate diagonally, adjust the feet again.
NOTE
Timber or suspended type flooring may contribute to
excessive vibration and unblance errors.
NOTE
In the case that the washing machine is installed on a raised
platform, it must be securely fastened in order
to eliminate the risk that it might fall off.
Rubber Cu
Adjustable
feet
Adjustable
feet
Lock nut

12
are before washing
C
1. Care Labels
Look for a care label on your clothes. This will tell you about the fabric content of your garment and
how it should be washed.
2. Sorting
To get the best results, Sort clothes into loads that can be washed with the same wash cycle.
Water tem erature and s in s eed and different fabrics need to be washed in different ways.
Always sort dark colors from ale colors and whites. Wash se arately as dye and lint transfer can
occur causing discoloration of white etc. If ossible, do not wash heavily soiled items with lightly
soiled one.
Soil (Heavy, Normal, Light) Se arate clothes according to amount of soil.
Color (White, Lights, Darks) Se arate white fabrics from colored fabrics.
Lint (Lint roducers, Collectors) Wash lint roducers and lint collectors
se arately.
3. Caring before loading
 Caring before washing
 Before the first washing
 Combine large and small items in a load. Load large items first. Large items sho ld not be more than half
the total wash load.
Do not wash single items. This may ca se an o t-of-balance load. Add one or two similar items.
• Check all ockets to make sure that they
are em ty. Items such as nails, hair cli ,
matches, ens, coins and keys can damage
both your washer and your clothes.
• Close zi ers, hooks and strings to
make sure that these items don’t
snag on other clothes.
• Pre treat dirt and stains by brushing a little
detergent dissolved in water onto stains like
collars and cuffs to hel shift dirt.
Select a cycle (COTTON 60°C, add a half load of detergent) allow the unit to wash
without clothing. This will remove residues and water from the drum that may have been left
during manufacturing.
• Check the folds of the flexible gasket (gray) and
remove any small articles,if any.
• Check inside of the drum and remove any left
items in it for next wash cycle.
• Remove any clothing or items on the flexible
gasket to revent clothing and the gasket
damages.

13
dding detergent
A
• Main wash only ➔
• Pre Wash + Main Wash ➔
• Do not exceed the maximum fill line.
Close the dis enser drawer slowly.
Overfilling can cause early dis ensing
of the fabric softener which could stain
clothes.
• Do not leave the fabric softener in the
detergent drawer for more than 2 days.
(Fabric softener could harden)
• Softener will automatically be added
during the last rinse cycle.
• Do not o en the drawer when water is
su lied.
• Solvents(benzene, etc) are not
allowable.
1. The Dispenser Drawer
2. Adding Fabric Softener
 Adding detergent and fabric softener
Do not pour fabric softener
directly on the cloths
NOTE
( )
( )
( )
( )
( )

dding detergent
A
14
• The detergent sh uld be used acc rding t the
instructi n f the detergent manufacture.
• If t much detergent is used, t many suds
can ccur and this will decrease the washing
result r cause heavy l ad t the m t r.
• Use p wder detergent nly f r the fr nt
l ading washer.
❇ If suds ccur t much, pleas reduce the
detergent am unt.
• Detergent usage may need to be adjusted
for water tem erature, water hardness,
size and soil level of the load. For best
results, avoid oversudsing.
4. Water softener
• A water softener, such as Anti limescale
(Clagon) can be used to cut down on the
use of detergent in extremely hard water
areas. Dis ense according to the amount
s ecified on the ackaging.
First add detergent and then the water
softener.
• Use the quantity of detergent as for soft
water.
❋ Tips
Full load : according to
manufacturer’s recommendation.
Part load : 3/4 of the normal
amount.
Minimum load : 1/2 of full load.
• Detergent is flushed from the dis enser
at the beginning of the cycle.
1) O en the door and Tablets into the
drum.
3. Detergent dosage
5. Using the Tablets
2) Load the laundry into the drum.
3) Close the door.

15
unction
F
 Recommended courses according to the laundry type
❋ Water Temperature : Select the water tem erature to the wash cycles.
Always follow garment manufacture’s care label or instructions when laundering.
❋ Pre Wash : If the laundry is heavily soiled, “Pre Wash” o tion is recommended.
Normal
Sanitary
Baby Care
Refresh
Tub Clean
Allergy Care
Hand
Wash /
Wool
Silent
Duvet
Color fast garments
(shirts, night dresses,
ajamas...)and lightly soiled
white cotton (underwear...)
- Soak
- Pre Wash
- Main Wash
- Small Load
- Less Steam
- Turbo Steam
- Main Wash
- Turbo Steam
- Main Wash
- Small Load
- Soak
- Pre Wash
- Main Wash
- Small Load
- Less Steam
- Turbo Steam
- Main Wash
- Small Load
Polyamide, Acrylic, Polyester.
Delicate laundry easily damaged.
Machine washable woolens with
ure new wool only.
“Hand Wash” marked delicate
and wool laundry.
Colored Laundry which is lightly
soiled fast.
Cotton bedding with filling, duvet,
illow, blanket, sofa cover with
light filling.
40˚C
(Cold, 30˚C,
60˚C)
40˚C
(Cold, 30˚C,
60˚C)
Cold
(30˚C, 40˚C)
95˚C
Rating
3
1
2
4
5
4
5
1
2
3
4
5
1
2
3
2
3
4
5
1
3
4
5
1
2
5.0kg
6.0kg
5 items
–
6.0kg
3.0kg
5.0kg
1 king size
(9 Tog)
––
–
40˚C
(Cold, 30˚C)
Maximum
Load
Rinse
Additional
Option
Program Fabric Type
Proper
Temp.
(Option)
Lightly soiled baby wear
Cotton mixed, Polyeter mixed
Dress shirts, blouses (It just makes
wrinkled clothes easy to iron)

16
ow to use washer
H
• Press the Power button to start.
• Press the Start/Pause button.
• Initial condition
- Wash : Main wash
- Rinse : 3
- Water temperature : 40°C
- Spin : 800 rpm
- Program : Normal
• Press the Power button to turn the
washer on.
• Select the desired cycle with the
rogram dial and if required, make any
changes to the washing conditions by
ressing the buttons accordingly.
For selecting the each conditions, please
refer to the page 17~page24
• Press the Start/Pause button to
commence the cycle.
1. Cotton automatically
selected upon power on.
2. Manual Selecting

17
ow to use washer
H
Program
1. Power
2. Initial Program
Power
• Press the Power button to turn ower on
and off.
• To cancel the Time Delay function, the
Power button must be ressed.
• When the Power button is ressed, the
washer is ready for Cotton rogram. And
the other initial conditions as follows.
• So, if you want to advance into the
washing cycle without changing the
rogram, just ress Start/Pause button
and then the washer will roceed.
■ Initial program
- Normal Program / Main Wash / Rinse:3 /
40°C/ 800rpm
(1) (3) (4)(10) (6) (7) (8) (11) (9)(5)(2)
(1)Button: Power
(2)Dial: Program
(3)Button: Start/Pause
(4)Button: Wash
(5)Child lock
(6)Button: Rinse
(7)Button: S in
(8)Button: Tem erature
(9)Button: Dry
(10)Button: Turbo Steam
(11)Button: Time Delay
• 9 rograms are available according to the
laundry ty e.
• Dial lam will light u to indicate selected
rogram.
• When Start/Pause button is ressed, the
Cotton rogram is automatically selected.
- By turning the Program dial, the rogram is
selected in order of “Normal – Sanitary –
Silent – Hand Wash/Wool – Duvet –
Refresh – Allergy Care – Baby Care – Tub
Clean”.
For information regarding laundry type for
each program, please refer to page 15.

18
ow to use washer
H
Wash
• By ressing the o tion
button, only one o tion
function may be selected.
NOTE:
De ending on the selected
rogram cycle, not all
O tions may be selectable.
2. Pre Wash
• Use this o tion for loads that need
retreatment. This adds 17 minutes of re
washing before draining.
- When using Pre Wash o tion, do not use
a liquid detergent for the main wash.
Use owder for the main wash.
• Available in Silent, Sanitary and Normal.
3. Main Wash
• It is the washing ty e for the general one.
4. Small Load
• Use it for the small laundry.
5. Less Steam
• When you want to do a steam wash for
only a small amount of laundry, select the
this o ton.
1. Soak
• Use this mode to wash normal clothes or
think and heavy clothes which are
excessively dirty.
• Available in Silent, Sanitary and Normal.
Start/Pause
• This Start/Pause button is used to start
wash cycle or ause the wash cycle.
• If tem orary sto of wash cycle is needed,
ress “Start/Pause” button.
• When in Pause, the ower is turned off
automatically after 4 minutes.
• NB. The door will not o en before 1 to 2
minutes when Pause is selected,
or at the end of the wash cycle.
1. Start
2. Pause
• Lights whenever the door of the washer is
locked.
• The door can be unlocked by ressing the
Start/Pause button to sto the washer.
• The door can be o ened after a short delay.
• Use it to change the
number of rinsings.
Door Lock
Rinse

19
ow to use washer
H
Child lock
If you choose to lock the buttons on the
control assembly to revent tam ering, this
function may be selected.
• Child lock can be set by ressing and
holding the Wash and Rinse button
simultaneously. (About three seconds)
• When child l ck is set, all butt ns are
in perable except f r p wer butt n.
• To deactivate Child lock system, ress
and hold the
Wash and Rinse button
simultaneously again.
(About three seconds)
• To change to the desired rogram, whilst in
child lock mode.
1. Press and hold both
Wash and Rinse
button to cancel the child lock.
(About three seconds)
2. Press the Start/Pause button.
3. Select the desired rogram and ress the
Start/Pause button again.
• The child lock can be set at any time and it
is automatically canceled when o erational
errors occur.
Time Delay
Preparing washing before starting “Time Delay”
- Turn on the water ta .
- Load laundry and close the door.
- Place the detergent and fabric softener in
the drawer.
• How to set “Time Delay”
- Press Power button.
- Turn the Program dial to select
the rogram you require.
- Press Time Delay button and set the
desired time.
- Press the Start/Pause button.
(“ ” lam is blink)
• If Time Delay button is ressed, “3:00” is
dis layed. The maximum delayed time is
19:00 hours and the minimum time is 3:00
hours.
• Each ressing of the button advances time
delay by one hour.
• To cancel the time delay, ress the
Power button.
• Time Delay is ‘ex ected time’ from the
resent to the com letion of washing cycle
or selected rocess (Wash, Rinse, S in).
• According to the condition of water supply and
temperature, the delayed time and the actual
washing time may vary.
Change
the desired
program

20
ow to use washer
H
1. Spin selection
Spin
• S in s eed is available according to the rogram
as follows.
- Silent & Sanitary & Normal & Baby Care &
Allergy Care
Gentle – 400 – 800 – 1000 – 1200
- Duvet & Hand Wash/Wool
Gentle – 400 – 800
• By ressing the S in button, the
s in s eed can be chosen.
Water Temperature
• By ressing the Tem .
button, the water
tem erature can be
selected.
- Cold
- 30˚C / 40˚C / 60˚C / 95˚C
• Water tem erature can be selected as below
according to the rogram.
- Silent & Normal
Cold – 30°C – 40°C – 60°C
- Hand Wash/Wool & Duvet
Cold – 30˚C – 40˚C
- Sanitary
95°C
The required temperature lamp will light up for
identification.
For the more detailed information, please refer to
the page15.
