dv 465 – Present like a pro.
Liesegang’s dv 465 is made for medium-sized conference rooms and even for use at daylight,
considering its powerful 2000 ANSI lumens. The ample number of ports and presentation tools
makes the dv 465 a very versatile partner. The XGA resolution is responsible for its very detailed
and crystal-clear projections.
dv 465
Present like a pro
dv 465
•XGA resolution
•Bright 2000 ANSI lumens
•2 RGB-Inputs,
separate Monitor-Output
•Ideal for mobile use
•Easy lamp change

dv 465
Present like a pro
• Extremely compact casing and therefore ideal suited for mobile use
• Integrated, mechanical lens protection
• Keystone Correction
• Individual programming starting image
• 2 RGB-Inputs, separate Monitor-Output
• Input for Component Video
• Easy lamp change
• Integrated De-Interlacer for Progressive Scan
Liesegang dv 465 0219 027C 0000
including power cord, connection cables,
user manual, remote control, softcase
EAN 4044714219019
Accessories
165 W Spare lamp ZU 0218 04 4010
Ceiling mounting /carrier plate ZU 0218 75 0005
Ceiling mounting /column CM 25 ZU 0260 75 0006
Anti-theft key lock ZU 0266 78 0000
Anti-theft combination lock ZU 0061 78 0000
Updated on: 09/2004
Your Liesegang specialist dealer
Liesegang Optoelectronics GmbH Liesegang Corp.
Kaistrasse 5 1001 W. Cypress Creek Rd. 103
40221 Duesseldorf Ft. Lauderdale, FL 33309
Germany USA
phone [phone] phone [phone]
fax [phone] fax [phone]
www.liesegang.com www.liesegangcorp.com
[email protected] [e-mail]
limited
projector warranty limited lamp warranty
Technical Specifications* dv 465
Technology 3x 0.7" LCD
Native resolution XGA, 1024x 768 pixel
Supported resolution up to UXGA
Video compatibility PAL, SECAM, NTSC, HDTV
Contrast ratio 500:1
Brightness Standard Mode 2000 ANSI lumens
Brightness Whisper Mode 1600 ANSI lumens
Lamp, Lifetime** 165 W UHB, 2000 h
Mains voltage 100–120 VAC/ 220–240 VAC,
50–60 Hz
Power consumption 250 W/ < 10 W stand-by
Dimensions (W x H x D) 297 x 64 x 233mm (11.7" x 2.5" x 9.2")
Weight 2.45 kg (5.4 lbs)
Keystone correction ± 35° vert.
Scanning frequency hor. / vert. 15–91 kHz/ 50–120 Hz
Pixel clock 130 MHz
Image uniformity > 85 %
Speaker 1 x 1W
Projection lens F = 1.7 –1.9, f = 21.7 –26.1 mm
1.2 x manual zoom
Digital zoom 4 x
Projection distance 0.9– 9.2 m (wide angle)
1.1–11m (tele)
Screen size (diagonal) 0.77–7.70 m (30"–300")
Throw ratio 1.49 – 1.79
Noise level 36 dB Standard Mode
32 dB Whisper Mode
Connectors
Computer in 2 x RGB analog (D-Sub HD)
Mouse 1 x USB
Control 1 x RS-232
1 x RGB analog (D-Sub HD)
Video in 1 x Video (RCA)
1 x S-Video (Mini-DIN)
1 x Component (RCA)
Audio in 2 x Audio Stereo (RCA)
Audio out 1 x Audio (Mini jack)
Approvals CE, FCC B, UL, TÜV
Miscellaneous specifications • Automatic signal detection
• Multilingual on-screen menu
• Suitable for 4:3 and 16: 9 aspect ratio
• Kensington Lock™ slot
* Subject to modification, ** average life time
Distance in Image size in m (inch) Image diagonal in m (inch)
m (inch) from to from to
1.5 |(59.1") 0.84 |(32.99") 1.01 |(39.63") 1.05 |(41.24") 1.26 |(49.54")
2.0 |(78.7") 1.12 |(43.99") 1.34 |(52.85") 1.40 |(54.99") 1.68 |(66.06")
2.5 |(98.4") 1.40 |(54.99") 1.68 |(66.06") 1.75 |(68.73") 2.10 |(82.57")
3.0 |(118.1") 1.68 |(65.98") 2.01 |(79.27") 2.09 |(82.48") 2.52 |(99.09")
5.0 |(196.9") 2.79 |(109.97") 3.36 |(132.11") 3.49 |(137.47") 4.19 |(165.14")
7.0 |(275.6") 3.91 |(153.96") 4.70 |(184.96") 4.89 |(192.45") 5.87 |(231.20")
