Light Concept LC Show.LED 910 IP User manual

9*10w 4in1 RGBA wireles P LED akku s ar
User manual
P le a se rea
d
t he ins t r u
ction
s ca refu ll y before use

2
TABLE OF CONTENTS
1. S af ety I nst r uctions ..................................................................................................... 2
2. Technical Specifications ...........................................................................................4
3. How To Control The Unit .......................................................................................5
4. Remind ......................................................................................................................10
statement
The product has well capability and intact packing when leave
factory. All of the user should comply with warning item and manual, any
misuse cause of the damages are not included in our guarantee, and
also can not be responsible for any malfunction & problem owing to
ignore the manual.
1. S af ety I nst r uctions
Please keep this User Guide for future consultation. If you sell the unit to another
user, be sure that they also receive this instruction booklet.
Unpack and check carefully there is no transportation damage before using
the unit.
Before operating, ensure that the voltage and frequency of power
supply match the power requirements of the unit.
It’s important to ground the yellow/green conductor to earth in order
to avoid electric shock.
The unit is for indoor use only. Use only in a dry location.
The unit must be installed in a location with adequate ventilation, at
least 50cm from adjacent surfaces. Be sure that no ventilation slots are
blocked.

3
Disconnect main power before replacement or servicing.
Make sure there are no flammable materials close to the unit while operating as
it is fire hazard.
Use safety cable when fixes this unit. DO NOT handle the unit by taking its head
only, but always by taking its base.
Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the
temperature is higher than this Unit surface temperature may reach up to 85℃.
DO NOT touch the housing bare-hand during its operation. Turn off the power
and allow about 15 minutes for the unit to cool down before replacing or serving.
In the event of serious operating problem, stop using the unit
immediately.Never try to repair the unit by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the
nearest authorized technical assistance center. Always use the same type
spare parts.
DO NOT touch any wire during operation as high voltage might be causing
electric shock.
Warning:
Please set one light only as master when used Master-slave model in the same
channel.
DO NOT set any light as master when used DMX hold model.
To prevent or reduce the risk of electrical shock or fire, do not expose the unit to
rain or moisture.
DO NOT open the unit within five minutes after switching off.

4
The housing, the lenses, or the ultraviolet filter must be replaced
if they are visibly damaged.
Caution:
There are no user serviceable parts inside the unit. DO NOT open the housing
or attempt any repairs yourself. In the unlikely event your unit may require
service, please contact your nearest dealer.
Installation:
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating.
And make sure that the structure to which you are attaching the unit is secure
and is able to support a weight of 10 times of the unit’s weight. Also always use a
safety cable that can hold 12 times of the weight of the unit when installing the
fixture.
The equipment must be fixed by professionals. And it must be fixed at a place
where is out of the touch of people.
2. Technical Specifications
Light
Sources: 9*10w RGBA 4in1 LED
Beam Angle:
20°
Power
Consumption:
90W
Power Voltage: AC 100-240V, 50/60Hz
Net Weight: 6Kgs
Control
DMX Channel: 5/9 Channel
Control Modes: DMX and wireless

5
Construction
Display: OLED Display
Data In/Out socket: 3-pin XLR sockets
Power Socket: Powercon in/out
Protection Rating: IP65
Features
* OLED display
* IP65 Powercon in/Out ,IP65 DMX in/out
* Option for change LED Power (Eco, Medium, High power)
* Battery Charging Information and Wireless Channel change in Display
* Emergency Mode (enable / disable)
* DMX hold （on/off）in display
3. How To Control The Unit
Th e D M X512 is w id ely used in intellig ent ligh ti ng co n tr ol,with a DMX 512
controller.connect several lights together,dmx in and dmx out,
3 p in XLR co nn ectors : Pin 1: G ND , Pin 2: Nega tive s ig n a l (-), Pin 3: P o s itive s i gna l
(+)
Display:
MENU To select the programming functions
DOWN To go backward in the selected functions
uP To go forward in the selected functions
ENTER To confirm the selected functions
Set DMX Address Code
1 Press "Menu" to "Set DMX Address",and press"ENTER" keys to enter
into
2 Show "Set DMX Address DMX Address:001",Press the "UP and DOWN"

6
keys to amended
3 Press "ENTER"keys to save and Exit,Press the"MENU"Keys does not
save and Exit
4 Turn on operation: when in charging or turn off, press "MENU" 3-5s
then screen will display clients' logo and model of products,
there are "MENU","UP"."DOWN" for your selection to choose the function,
press" ENTER" to confirmed and enter the next menu,press "MENU"
could back to the last menu.
When turn on , press" MENU" for more than 4s,the screen will display " P
ower Off",and will close LED output by then.
If charger connect with electricity,the screen will display charging icon and
percentage of battery power. Or will be turn off directly,and the battery
powered wll be totally cut off.
5When using Master-Slave model,apart from the first one as Master without
setting,the others need to set as Slave.
6When using DMX512 controller,all the lights need to set as DMX model.
MENU
Choose Pattern
Static Color
Static Color
Show Mode
Sound model
User Colors
User Run
RGBA (0-255) Strobe( 0-255)
001-016
AUTO / FADE / SNAP / STRO(RGBA)
Sound ( 1-3) outdoor no the function
RGBA ( 000-255) Bank: 1/16
1. Static Color
2. Auto Mode
User setting
Channel
DMX512 Address
Slave Mode
5-CH / 9CH
001-512

7
System setting
White balance
Show Battery
Display sleep
Dimmer option
Auto power
IRC Setting
RF 2.4 setting
RF 2.4 FREQ
Power Setting
Emergency Lamp
DMX Hold
RGBA
(
0-255)
Yes / No?
Open/5Sec/10Sec/15Sec
Normal - lowest
Yes/No
Yes/No
Yes/No
Receiver Pairing ( Yes / No)
High / Medium / Low
Yes / No
Yes / No
Information
Led Temp:
Work Hours:
Software Version
Hardware version
Logo
30℃-70℃
000H-999H
V.1.05
OLED 4in1 90
LC 910 IP
* Press "MENU” 3-5 seconds,will turn on or turn off the display.
* About “Auto power” function, when set “ Yes” on it, it will turn on automatically
when power cable plugged, disconnect the power cable will turn off.
* About
" Emergency Lamp " function,when set Emergency
Lamp
on, and lights
work
with
power
cable
connection.
If power cable is interrupted,
LEDs
will turn
omberan . This feature suit to special scenes.
* About “DMX hold” function, when set “Yes” on it, it would keep the former
status when signal suddenly broken.
(Turns Amber) full to

8
* About checking the power information.
A-when light on, you can see the info on the upper right corner of the display.
B-when light off, press the menu button lightly,will show it in display.
* About how to connect wireless transmitter
Set “ RF 2.4 setting “ and “ RF 2.4 FREQ “ both for “ Yes “ .
With the indicator in “ blue “ color, click the “ FUNCTION “ on the transmitter
once.
* How to check whether is success to connect or not.
Set the lights on “ Slave Mode “ and it will show “ connect “ or “ disconnect “.
* If you need to reconnect the other transmitter, please set “ RF 2.4 FREQ “ for
“ No” to remove the connection with last transmitter first, then set for “ Yes
“ again, or it will connect the last transmitter automatically.
Wireless transmitter
PLEASE SWEDEN SOLUTION WIRELESS USE

9
* When in “ blue “ color, click “ FUNCTION “ once,it will connect with the lights.
* Press “ FUNCTION “ until the color change to “ pink “, it means remove all the
lights connection.
DMX channel´s functions and values (5/9 DMX channels):
5CH
No.
DMX512
Value
Function
1
0~255
Red dimmer
2
0~255
Green dimmer
3
0~255
Blue dimmer
4
0~255
Amber dimmer
5
0~19
Normal model
20~39
Dimmer curve （slow )
40~59
Dimmer curve （slower )
60~255
Dimmer curve （slowest )
9CH
No.
DMX512
Value
Function
1
0~255
Total dimmer for CH9 (0~9)
2
0~9
Strobe off
10~255
Strobe：10 lowest，255 fastest
3
0~255
Red，the max depend on total dimmer
NOTE: 1.4 V since deactivated is Control Sound

10
4
0~255
Green，the max depend on total dimmer
5
0~255
Blue，the max depend on total dimmer
6
0~255
Amber，the max depend on total dimmer
7
0~9
Dimmer model
10~29
Color choose ：CH8
30~49
Jump variable effect ：CH8 control the speed
50~69
gradual variable effect ：CH8 control the speed
70~89
mutation effect：CH8 control the speed
90~109
Red + strobe:CH8 control the speed
110~129
Green + strobe:CH8 control the speed
130~149
Blue + strobe:CH8 control the speed
150~169
Total strobe: CH8 control the speed
170~209
Sounds control the jump variable effect
210~229
Sounds control the jump variable effect + gradual
variable effect
230~255
Sounds control the strobe
8
0~255
This channel’s function are depending on the value of
CH7：
When the value is 10~29，then the function is colors
choose.
When the value is 30~189，then the function is speed
control: 0 is the lowest,255 is the fastest.
9
0~19
Normal model
20~39
Dimmer curve （slow )
40~59
Dimmer curve （slower )
60~255
Dimmer curve （slowest )
4.Remind
It
need
to cha
rge a times
for each
two months,and 50% battery power
at
least, if for a long time without using  closed! is case if charge not Do.
