Calculite®HID Adjustable Accent C4P20MHA
Page 1 of 2 4 1/2" Aperture, PAR20 Ceramic Metal Halide
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Li htolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • ( 08) 679-8131 • Fax ( 08) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • P0711
Features
1. Reflector Trim: Low brightness, specular Clear anodized or Comfort Clear™
Diffuse with integral flange in painted white or polished to match inside of cone.
2. Lamp Holder / Trim Adjustment Assembly: Unitized optics insure
alignment of lamp and aperture cone regardless of ceiling thickness. Provides
3 ° vertical tilt, 360°+ horizontal rotation; lockable. EZ-Aim Helical Drive
System provides fast and accurate hot aiming with Philips screwdriver.
3. Socket: Medium base porcelain pulse rated socket with nickel plated screw-
shell.
4. Frame Housin : Steel, 0.029" (22-Ga.), matte black finish.
5. Frame Vertical Adjustment Mechanism: Accommodates mounting to vir-
tually any ceiling system using pre-installed mounting bars, or 1/2" EMT tub-
ing (by others). Single locking feature secures all adjustments. Alignment
holes and markings allow fixture to be pre-set prior to installation. Final
adjustment can be made from below from inside fixture.
6. Mountin Bars: Galvanized steel, 0.048" (18-ga.), pre-installed telescoping
bars extend to 30" long and lock securely into position. Built-in locking tabs
provide positive attachment to common T-bar systems. Self-centering feature
simplifies installation in 24" O.C. grid systems. Attaches to steel or wood
joists without accessories.
7. Retention Sprin s: Rust resistant springs secure trim for quick, tool-less
installation.
8. Ballast / Cover Assembly: Accessible from below and removable without
tools for inspection and ballast replacement .
9. Junction Box: 0.0 9" (16-ga.) galvanized steel. UL listed for 8 No. 12 AWG,
90°C through branch circuit conductors. Allows inspection from below.
10.Accessory Holder: Sold separately catalog # CAH4; die-formed steel, matte
black finish, slide-in installation. Accepts up to two 3 3/4" dia. media.
11.Thermal Protector: (Not Shown) Meets NEC and UL requirements. Do not
install insulation above nor within 3" (76mm) of any part of the luminaire.
Electrical
Electronic Ballast: 120V or 277V, 0/60 Hz. encased, high power factor,
T.H.D. <1 %, thermally and transient protected, RMI/RFI complies with
FCC part8 non-consumer limits, shut-down circuit at end of lamp life, sound
rating "A", - ° F minimum starting temperature, Type 1 Outdoor rating.
Ballast ANSI Code Volta e Max. Amps Input Watts
39WMH M130 120/277 0.39/0.17 44
Options and Accessories
CAH4: Accessory Holder. Accepts up to two 3 3/4" dia. media.
Chica o Plenum: Consult Factory
Labels
UL. (Suitable for damp locations), I.G.E.W.
Ceilin Cutout: 1/8” (130 mm) Dia.
Reflector Trim Frame-In Kit Lamp
C4P20MHA CLW Specular Clear, White Painted Flange.
CLP Specular Clear, Matching Flange.
CCDW Comfort Clear Diffuse, White Painted Flange.
CCDP Comfort Clear Diffuse, Matching Flange.
CCZW Champagne Bronze, White Painted Flange.
CCZP Champagne Bronze, Matching Flange.
C4A39P20E1 Electronic 120V 39W PAR20 Ceramic MH
C4A39P20E2 Electronic 277V 39W PAR20 Ceramic MH

Calculite®HID Adjustable Accent C4P20MHA
Page 2 of 2 4 1/2" Aperture, PAR20 Ceramic Metal Halide
Li htolier a Genlyte Thomas Company www.lightolier.com
631 Airport Road, Fall River, MA 02720 • ( 08) 679-8131 • Fax ( 08) 674-4710
We reserve the right to change details of design, materials and finish.
© 2011 Genlyte Thomas Group LLC (Lightolier Division) • P0711
Job Information Type:




(FC) is initial footcandles at center of
beam. Beam length (L) and beam width
(W) are to where the candlepower is
reduced to 50% of the center beam
candlepower. (C) is the distance to the
center of the beam.
10,000
5,000
15,000
20,000
2,500
1,250
3,750
5,000
30°
60°
30°
60°
CANDLEPOWER DISTRIBUTION
30° Aimin An le
Vertical Surface
DC FC LW
2' 3.5' 659 1.7' 0.8'
3' 5.2' 293 2.6' 1.3'
' 6.9' 165 3.5' 1.7'
6' 10. ' 73 5.2' 2.5'
8' 13.9' 1 7.0' 3. '
ANGLE WALL 39W PAR20 CERAMIC MH - SPOT
0 375
5 50
10 675
15 1356
20 3875
25 11562
30 21102
35 12936
0 3535
5 997
50 20
55 21
60 0
65 0
70 0
75 0
80 0
85 0
90 0
30° Aimin An le
Horizontal Surface
DC FC LW
8' .6' 50 5. ' .6'
10' 5.8' 32 6.8' 5.8'
12' 6.9' 22 8.1' 6.9'
15' 8.7' 1 10.2' 8.6'
20' 11.5' 8 13.6' 11.5'
30° Aimin An le
Vertical Surface
DC FC LW
3' 5.2' 69 7. ' 3.0'
' 6.9' 39 9.8' .0'
6' 10. ' 17 1 .7' 6.0'
8' 13.9' 10 19.6' 8.0'
12' 20.8' 29. ' 12.0'
ANGLE WALL 39W PAR20 CERAMIC MH - FLOOD
0 628
5 666
10 980
15 1727
20 3396
25 772
30 9 6
35 80
0 075
5 2630
50 1168
55 23
60 22
65 0
70 0
75 0
80 0
85 0
90 0
AIMED 30°. TOWARD WALL
LAMP: 39W PAR20 FL CERAMIC MH,
PHILIPS
LUMEN RATING: 2000 LMS.
CBCP: 9 6
Beam Angle: 28
AROMAT 39W ELECTRONIC BALLAST
DATE: MAR 11, 200
CERTIFIED TEST REPORT NO. 2535FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
AIMED 30°. TOWARD WALL
LAMP: 39W PAR20 SP CERAMIC MH,
PHILIPS
LUMEN RATING: 2000 LMS.
CBCP: 21102
Beam Angle: 12
AROMAT 39W ELECTRONIC BALLAST
DATE: MAR 11, 200
CERTIFIED TEST REPORT NO. 2538FR
COMPUTED BY LSI PROGRAM
**TEST-LITE**
30° Aimin An le
Horizontal Surface
D C FC LW
6' 3.5' 381 1.7' 1.5'
8' .6' 21 2.3' 1.9'
10' 5.8' 137 2.8' 2. '
12' 6.9' 95 3. ' 2.9'
15' 8.7' 61 .2' 3.6'
