Lightolier Lytespan 8226WH User manual

3 3/8"
2"
5 3/16"
4"
4
CYLINDER 20 WITH HINGED ADAPTER
CYLINDER 20 WITH LOW PROFILE ADAPTER
2 1/4"
5 13/16"
4"
3
1
2
Lytespan®Track Li htin System 8226WH
Pa e 1 of 2 PAR-TechTMCylinder 20 Shade
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Notes:
Lig tolier a Genlyte Thomas Company www.li htolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the ri ht to chan e details of desi n, materials and finish.
© 2002 Genlyte Thomas Group LLC (Li htolier Division) • A0902
Features
1. S ade Attac ment: Zinc plated and painted C.R. steel. Bayonet fittin .
2. S ade: Sin le piece die-cast aluminum.
3. Mounting Groove: For accessories holder.
4. Integral Verti-Grooves: with black inside finish for lare control.
Options & Accessories
2 1/2” Beam Smoother, Beam Elon ator, Louver and Barn Doors. All require
Accessory Holder 8582. See Li htolier Specification Sheets AL2HC, AF2LF,
AF2AS.
Finis
All painted finishes baked enamel.
Labels
UL; I.B.E.W.
8226WH
8226BK
Catalog No. Finis es Mounting Lamps
8226WH Matte White All Lytespan Track Systems PAR20, 50W Max. (Tun sten-Halo en)
8226BK Matte Black
Ordering Information

Lytespan®Track Li htin System 8226WH
Pa e 2 of 2 PAR-TechTMCylinder 20 Shade
Lig tolier a Genlyte Thomas Company www.li htolier.com
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the ri ht to chan e details of desi n, materials and finish.
© 2002 Genlyte Thomas Group LLC (Li htolier Division) • A0902
Job Information Type:
Lig ting Data
600 2,500
35W PAR20
WFL (Halogen) 40°
3' 67 2.2' 2.2'
5' 24 3.6' 3.6'
7' 12 5.1' 5.1'
9' 7 6.6' 6.6'
3' 1.7' 43 3.0' 2.5'
5' 2.8' 16 5.1' 4.2'
7' 4.0' 8 7.1' 5.9'
9' 5.2' 5 9.1' 7.6'
2' 2.0' 53 3.4' 2.1'
3' 3.0' 24 5.0' 3.1'
4' 4.0' 13 6.7' 4.1'
5' 5.0' 8 8.4' 5.1'
1' 1.7' 75 4.8' 1.5'
2' 3.5' 19 9.7' 2.9'
3' 5.2' 8 14.5' 4.4'
4' 6.9' 5 19.3' 5.8'
3' 100 1.6' 1.6'
5' 38 2.7' 2.7'
7' 18 3.8' 3.8'
9' 11 4.8' 4.8'
3' 1.7' 65 2.2' 1.6'
5' 2.9' 23 3.7' 3.1'
7' 4.0' 12 5.1' 4.3'
9' 5.2' 7 6.6' 5.6'
2' 2.0' 80 2.3' 1.5'
3' 3.0' 35 3.5' 2.3'
4' 4.0' 20 4.6' 3.0'
5' 5.0' 13 5.8' 3.8'
1' 1.7' 113 2.7' 1.1'
2' 3.5' 28 5.5' 2.1'
3' 5.2' 13 8.2' 3.2'
4' 6.9' 7 10.9' 4.3'
900 2,500
35W PAR20 FL
(Halogen) 30°
6' 167 0.8' 0.8'
8' 94 1.1' 1.1'
10' 60 1.4' 1.4'
12' 42 1.7' 1.7'
5' 2.9' 156 0.9' 0.8'
7' 4.0' 80 1.3' 1.1'
9' 5.2' 48 1.7' 1.5'
11' 6.4' 32 2.1' 1.8'
3' 3.0' 236 0.8' 0.6'
5' 5.0' 85 1.4' 1.0'
7' 7.0' 43 2.0' 1.4'
9' 9.0' 26 2.5' 1.8'
2' 3.5' 188 1.1' 0.6'
3' 5.2' 83 1.7' 0.8'
4' 6.9' 47 2.3' 1.1'
5' 8.7' 30 2.8' 1.4'
6,000 2,000
50W PAR20
NSP (Halogen) 8°
DFC L W DC FC L W DC FC L W DC FC L W
Beam Spread Beam Center Rated
50% Max. CP C.P. Candelas Life-Hrs
1,850 2,000
50W PAR20
NFL (Halogen) 27°
4' 116 1.9' 1.9'
6' 51 2.9' 2.9'
8' 29 3.8' 3.8'
10' 19 4.8' 4.8'
3' 1.7' 134 2.0' 1.7'
5' 2.9' 48 3.3' 2.8'
7' 4.0' 25 4.6' 3.9'
9' 5.2' 15 5.9' 5.0'
3' 3.0' 73 3.1' 2.0'
4' 4.0' 41 4.1' 2.7'
5' 5.0' 26 5.1' 3.4'
6' 6.0' 18 6.1' 4.1'
1' 1.7' 231 2.3' 1.0'
2' 3.5' 58 4.8' 1.9'
3' 5.2' 26 7.0' 2.9'
4' 6.9' 14 9.3' 3.8'
6' 89 1.6' 1.6'
8' 50 2.1' 2.1'
10' 32 2.8' 2.8'
12' 22 3.2' 3.2'
5' 2.9' 83 1.8' 1.5'
7' 4.0' 42 2.5' 2.1'
9' 5.2' 26 3.2' 2.7'
11' 6.4' 17 3.9' 3.3'
3' 3.0' 126 1.6' 1.1'
5' 5.0' 45 2.7' 1.9'
7' 7.0' 23 3.8' 2.6'
9' 9.0' 14 4.8' 3.4'
2' 3.5' 100 2.2' 1.1'
3' 5.2' 44 3.3' 1.6'
4' 6.9' 25 4.4' 2.1'
5' 8.7' 16 5.6' 2.6'
3,200 2,000
50W PAR20
SP (Halogen) 15°
6' 83 0.8' 0.8'
8' 47 1.1' 1.1'
10' 30 1.4' 1.4'
12' 21 1.7' 1.7'
5' 2.9' 78 0.9' 0.8'
7' 4.0' 40 1.3' 1.1'
9' 5.2' 24 1.7' 1.5'
11' 6.4' 16 2.1' 1.8'
3' 3.0' 118 0.8' 0.6'
5' 5.0' 42 1.4' 1.0'
7' 7.0' 22 2.0' 1.4'
9' 9.0' 13 2.5' 1.8'
2' 3.5' 94 1.1' 0.6'
3' 5.2' 42 1.7' 0.8'
4' 6.9' 23 2.3' 1.1'
5' 8.7' 15 2.8' 1.4'
3,000 2,500
35W PAR20 NSP
(Halogen) 8°
FC
D
LC
A
W
L
W
FC
DFCL
C
D
A
LAMP 0˚ AIMING ANGLE A=30˚ AIMING ANGLE A=45˚ AIMING ANGLE A=60˚ AIMING ANGLE
Aiming Angle 0˚ 30˚, 45˚ or 60˚ Horizontal 30˚, 45˚ or 60˚ Vertical
LBeam Length
WBeam Width
CDistance to center beam
DDistance
AAiming Angle
FC Footcandles
Land Ware the outer points where the candle
power drops to 50% of the maximum. FC are the
initial footcandles at the center of the beam.
