Introduction
This manual describes show to control a BOSE LIFESTYLE 18/28 system, by means of a Bang&Olufsen
BEO4 remote control.
The system is designed for owners of a Bang&Olufsen Television, whom wants to use the existing BEO4 to
remote control a BOSE LIFESTYLE 18/28.
An infrared converter, LinTronic TT455-RT-238 (with BOSE feature enabled) or TT455-RT-003 (dedicated
BOSE controller), receives the infrared signals from the BEO4, converts them into an appropriate BOSE
infrared signal, and sends it to the BOSE system.
It is assumed that the user owns:
-a BOSE LIFESTYLE 18/28 SERIES II system.
-a Bang&Olufsen Television (optional)
-a BEO4 remote control

Bang&Olufsen to BOSE 18/28 SERIES II Updated: 2006 June 7’th
http://www.lintronic.dk
Preparations
The LinTronic TT455-RT-238/TT455-RT-003 must be powered by 9 - 18 Volt dc, by an adaptor capable of
delivering 350 mA or higher, and must be located so it can receive the BEO4 signals and reach the BOSE
system when transmitting.
The BOSE system must be programmed to receive IR signals. Use the original BOSE remote control to
change the following:
Activate the BOSE remote control, key SYSTEM and watch the SYSTEM MENU appear on the TV screen.
Goto REMOTE CONTROL and set IR CONTROL to ON (do not select LEARN).

Bang&Olufsen to BOSE 18/28 SERIES II Updated: 2006 June 7’th
http://www.lintronic.dk
Operation
The BOSE system can be controlled by the BEO4 in the following modes:
TV, RADIO, SAT/DTV, DVD, CD, VTAPE/VMEM, ATAPE/AMEM
In order to change mode on the BOSE system:
For TV mode, activate BEO4 TV
For RADIO mode, activate BEO4 RADIO
For CAB-SAT mode, activate BEO4 SAT or DTV
For DVD mode, activate BEO4 DVD
For CD mode, activate BEO4 CD
For VCR mode, activate BEO4 VTAPE or VMEM
For HARDDISK mode (STORED), activate BEO4 ATAPE or AMEM
In order to control the most BOSE features, we had to work around a few obstacles.
Menu/Settings
In any mode, in order to get access to the BOSE menu, activate the ”YELLOW” button
which brings up the BOSE menu on the TV. Also it allows you to use all four directions
key on the BEO4 to navigate in the BOSE menu. The GO button will act as ENTER.
Activate ”EXIT” to skip the menu. This will bring the direction keys back the normal
operation.
DVD menu
In DVD mode, in order to get access to the DVD menu, activate the ”RED” button which
brings up the DVD menu on the TV. Also it allows you to use all four directions key on the
BEO4 to navigate in the DVD menu. The GO button will act as ENTER.
Activate ”EXIT” to skip the menu. This will bring the direction keys back the normal
operation.
Speakers 2-3-5
In any mode, in order to adjust the surround load-speaker sound level, activate the
”BLUE” button. Adjust sound level by ”<<” and ”>>”.
Activate ”EXIT” to skip Speaker 2-3-5 mode.
Shuffle
Activate ”RANDOM - GO” in any mode.
Repeat
Activate ”REPEAT - GO” in any mode.
Pause
Activate ”STOP” in any mode.
Stop
Activate ”STOP - STOP” in any mode.
The following BOSE features cannot be controlled from the BEO4:
MUTE ALL
GUIDE
0 - 9 and Standby keep the same functionality in any mode.

Bang&Olufsen to BOSE 18/28 SERIES II Updated: 2006 June 7’th
http://www.lintronic.dk
In order not to conflict with features of the Bang&Olufsen Televison, some of the BEO4 buttons change
functionality depending on the mode in which they are operated.
TV
Volume Down <<
Volume Up >>
Play GO
RADIO
Scan backward <<
Scan forward >>
Next station Up
Previous stationDown
DVD
Volume Down <<
Volume Up >>
Up Up
Down Down
Play GO
DVD – RED (DVD MENU)
Left <<
Right >>
Up Up
Down Down
Enter GO
CD
Rewind <<
Fast forward >>
Next number Up
Previous number Down
Play GO
Pause STOP
Stop STOP – STOP
VTAPE / VMEM
Volume Down <<
Volume Up >>
HARDDISK - ATAPE / AMEM
Open Library Menu
Close Library Exit
Left <<
Right >>
Up Up
Down Down
Enter GO
YELLOW (BOSE MENU)
Arrow left <<
Arrow right >>
Arrow up Up
Arrow down Down
Enter GO

Bang&Olufsen to BOSE 18/28 SERIES II Updated: 2006 June 7’th
http://www.lintronic.dk
RA DIO
LI GHTTV
CD
DVDSAT
AT APE
RECORD VTAPE
9
87
6
54
3
2 1
ME NU
0
TE X T
GO
EXIT
LIST
STOP
>
>
>
>
> >> >
MO D E SETT IN G S
SPEAKERDVD MENU
MODES
}
