LITE-In LGSF3000 User manual

Bluetooth GPS Receiver
GSF3000 Directory
LGSF3000
Bluetooth GPS Receiver
Express Directory
7. 7, 2006 V1.0
LITE-In Tech. Co., Ltd.,
4F, No. 20, Lane 50, Sec. 3, Nangang Rd., Taipei 115, Taiwan, R.O.C.
Phone：[phone] Fax：[phone]
E-Mail：[email protected] Web：http://www.lite-in.com
All Right Reserved
- 0 -

Bluetooth GPS Receiver
GSF3000 Directory
TableofContents page
1. Express introduction & initial settlement……………… ………………2~3
1.1 Package contents
1.2 Charging the battery
1.3 Connecting to Bluetooth device
1.4 Create shortcut
1.5 Check and settle compliant Bluetooth Serial Port Profile
1.6 Select the correct Bluetooth output Serial Port Profile
1.7 Turn off the Bluetooth function
1.8 Other information
2. General characteristics……………………………………………….. ………4~5
2.1 product feature
2.2 product specification
2.3 caution notes
3. Hardware interface……………………………………………………….………5
3.1 Hardware input & output interface
3.2 charge connector
4. Certification………… …………………………………….……………6
4.1 BQB
4.2 R&TTE
4.3 CE
4.4 FCC
5. Limited Warranty……………………………………………………..…………6
6. Troubleshooting Guide………………………………………..…………………6
Appendix I………………………………………………………………………….7
- 1 -

Bluetooth GPS Receiver
GSF3000 Directory
1. Express introduction
1.1 Package contents
GPS receiver, rechargeable lithium-on battery, Cigarette lighter adaptor,
power adapter, USB cable, user guide。
1.2 Charging the battery
Please put the battery into the GPS Receiver’s battery tank, and charge it for
10-12hours before you use it.
1.3 Connecting to Bluetooth device
Before use it, please start the PDA or PC Bluetooth function, and press the
power switch for 3 seconds, then ready to pair Bluetooth serial port profile.
If there is no Bluetooth on your device, you may need Bluetooth CF card and
Bluetooth SD card.
Note：There is an enquiry window for Bluetooth pairing pin code appeared
at the first time.
(Bluetooth pairing pin code：0000)
1.4 Create shortcut
After establishing the pairing function, the system will build a pair
illustration automatically. The illustration will be on your Bluetooth device.
As soon as touching the illustration, the signal will connect to the Bluetooth
GPS receiver easily
1.5 Check and settle compliant Bluetooth Serial Port Profile
After establishing the pairing function, then touch serial port Profile to
confirm the port. Please select the transmission serial port on your PDA or
PC.
1.6 Select the correct Bluetooth output Serial Port Profile
Please set the correct output Serial Port on the software.
1.7 Turn off the Bluetooth function
After turning off the PDA or PC, press the power switch of GPS Receiver
for 3 seconds, the LED indicator will be shutdown.
- 2 -

Bluetooth GPS Receiver
GSF3000 Directory
1.8 Other information
1.8.1 LED indicator
status flashing / light
orange / charging Battery charging in progress：orange
red / low power low power：red
1. waiting for Bluetooth connection：
flashing blue (once per 2 seconds)
blue / Bluetooth 2.Bluetooth connect to a device：
flashing blue (once per 5 seconds)
1. GPS positioning in progress：
flashing green (once per 2 seconds)
green / satellite
connect 2. GPS positioned：flashing green
(once per 5 seconds)
(Definite LED indicators can be seen from the trunk lip)
1.8.2 Bluetooth pairing pin code
The pairing pin code of LGSF3000：‘0000’
1.8.3 Datum
datum：WGS84
protocol output data ：GGA, GLL, GSA, GSV, RMC, VTG
baud rate：4800
- 3 -

Bluetooth GPS Receiver
GSF3000 Directory
2. General characteristics
2.1 Product feature
Bluetooth GPS receiver is a compact design with internal passive antenna,
with Bluetooth wireless technology and build in flash based firmware.
Without any wiring requirement GPS receiver adds GPS positioning
capability to any Bluetooth enabled device with lower power consumption.
The high performance and high sensitivity to -159dBm may survey
20channels all-in-view tracking by the cold start.
With the LED indicators, user may get the statues of power, Bluetooth and
position surveying.
Bluetooth GPS receiver supply an incredible high sensitivity for acquisition
and superior navigation performance in urban, canyon and foliage
environments.
The applications include vehicle tracking, fleet management, chart, location-
based Services security, marine navigation and agriculture.
2.2 Product specification
2.2.1 Physical characteristics
dimension：49(W) x 85(L) x 31(H) mm
weight：80g (with battery)
internal passive antenna and GPS receiver
2.2.2 power source
input charging circuit：5v DC
Lithium-ion battery：+3.7v, 1100 mAh or 1000 mAh
2.2.3 GPS specification
Chipset: SiRF Star Ⅲwith high performance, low power consumption.
Channels：20 channels all-I –view tracking
Support Standard：NMEA-0183
Hot start：1s (average)
Warm start：38s (average)
Cold start：42s (average)
Acceleration：4g max..
Altitude︰18000m max..
Reacquisition︰100ms
Velocity︰515m/s max..
Position accuracy︰10m 2DRMS
Reacquisition Time︰1 microsecond synchronized to GSP time
2.2.4 Bluetooth specification
Wireless requirement Compatible with Bluetooth devicesv1.1 v1.2
v2.0
- 4 -

Bluetooth GPS Receiver
GSF3000 Directory
Bluetooth standard all transmission standard w/ extend standard
SCO
Bluetooth profile Serial Port Profile (SPP)
Frequency range 2.4 GHz public free channel ISM
Transmission range (by open space) 10m (30feet)
Input sensitivity < -85dBm
2.2.5 Battery
1) Form replaceable rechargeable lithium-ion battery
2) Capacity 1100 mAh
3) Current consumption 3.7 V
4) Load impedance (after package) 30 – 70 ohms
5) Weight 23 g
6) Max. charge ampere 1.0 A（1000mA）
7) Charging circuit 4.20 ± 0.05 V
8) Max. discharge ampere 1.0 A（1000mA）
9) Charge CC/CV
10) Operation temperature range charge：0 ~ 45 °C
discharge：-20 ~ +60 °C
11) Storage temperature range within 1 month：-20~+60 °C
within 3 months：-20~+40 °C
within1year：-20~+20 °C
2.2.6 Interface
Communication with host platform via Bluetooth Serial Profile
v2.0，auto-adjust transmission velocity
NMEA 0183 2.2. ASCII output format (GPGGA, GPGLL, GPGSA,
GPGSV, GPRMC, GPVTG).
2.3 Caution notes
1) Bluetooth GPS receiver the operating time is -20 ~ +60 °C. It will be
damaged under the over-high or over-low temperature.
2) There is no harm to the battery by external power source. -40 ~ +85°C.
3) Please charge it for 10-12 hours at first time to use it.
3. Hardware interface
3.1 Hardware input & output interface
The Bluetooth GPS receiver is with Bluetooth wireless technology, internal
passive antenna and rechargeable lithium-ion battery, as put it on the
instrument panel or any direction to the sky. The GPS signal will be
transmitted via Bluetooth serial port profile to your notebook, PDA or other
devices.
- 5 -

Bluetooth GPS Receiver
GSF3000 Directory
3.2 Charge connector
USB cable (also may connect to notebook or PC for charging) easily connect
to the car charger
4. Certification
4.1 BQB - Bluetooth Qualification Body
4.2 R&TTE - Radio and Telecommunications Terminal Equipment
4.3 CE - European Union Regulatory
4.4 FCC - FCC ID：UH6-LGSF3000
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate
this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
- 6 -

Bluetooth GPS Receiver
GSF3000 Directory
This equipment complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. To maintain compliance with
FCC RF exposure compliance requirements, please avoid direct contact
to the transmitting antenna during transmitting.
5. Limited warranty
The company warrants this product to be free from defects in materials and
workmanship for one year from the original date of consumer purchase. This
limited warranty in non-transferable and does not apply if the products has been
damaged by negligence, accident, abuse, misuse, modification, misapplication.
The manufacture’s liability under this warranty is limited to the repair or
replacement of the defective product.
There are no other oral or written warranties, expressed or implied, including but
not limited to those of merchantability or fitness for a particular purpose.
6Troubleshooting Guide
Problem Possible Cause Solution
Positioning fail
but the satellite
signal appears
normal
The place of GPS Receiver
get weak signal or no
signal
Please move GPS Receiver
to a signal receivable place.
The high building, ceiling of
the car and the super heat
insulation film may cause
positioning fail and weak
signal.
Bluetooth
function
unstable
Start Bluetooth Serial Port
Profile fail (GPS Receiver
un-connection), or
Bluetooth Serial Port
Profile is occupied by other
devices.
Restart PDA or PC, reset
GPS Receiver connection, or
reinstall the navigation
software.
Device is no
Bluetooth
found, GPS
connection
fail
GPS Receiver low power,
or turn on the switch
erroneously.
Please recharge it or repress
the switch button for 3
seconds again.
＊ Consult the dealer for help, if there are no solutions above-mentioned.
- 7 -

Bluetooth GPS Receiver
GSF3000 Directory
Appendix I
Warranty
Model No._______________________________________________
Date of Purchase: __________________________________________
Name: ___________________________________________________
Address: _________________________________________________
__________________________________________________
E-mail Address: ___________________________________________
Distributor Stamp Here
