Lkgps LK330 User manual

Standby 5 years
GPS Tracker Manual
Preface
Thank you for purchasing the tracker. This manual shows how to operate the device smoothly and
correctly.
Make sure to read this manual carefully before using this product. Please note that specification an
d
information are subject to changes without prior notice in this manual. Any change will be integrate
d in the
latest release. The manufacturer assumes no responsibility for any errors or omissions in this docu
ment.

1. Summary
Working Based on existing GSM/GPRS network and GPS satellites, this product can locate and
monitor any
remote targets by SMS or internet. The most advanced technology of GPS and AGPS dual
positioning. built-in high capacity battery, super long standby, easy installation + strong magnetic
adsorption portable GPS locator, deep sleeping working mode can be 5 years standby
2. Applications
1. Vehicle rental / Fleet management etc
2.container/assets ..
3.Hardware Description

4. Content Specs.
Content
Specs.
Dim.
120mm x 64mm x 35mm
Weight
250g
Network
GSM/GPRS
Band
850/900/1800/1900Mhz
GPS chip
UBLOX
GPS sensitivity
-159dBm
GPS accuracy
10m
Time To First Fix
Cold status 35-80s
Warm status 35s
Hot status 1s
Battery
Un-chargeable 16000mAh
Storage Temp.
-40°C to +85°C
Operation Temp.
-20°C to +55°C
Humidity
5%--95% non-condensing
5.Userage:
5.1 SIM card installation
1.Open the rubber plug . 2.Insert the GSM SIM card. 3.close the rubber plug.
5.2Startup
Put the SIM card and battery in place.
Turn on the unit outdoors by Pushing the button to“On”the indicator is on.
Set admin number,APN , IP and open GPRS
Eg: Step1.admin123456+space+your phone number
Step2.apn123456+ space+local apn content
Step3.adminip123456+space+101.1.16.228+space+7700
Step4. gprs123456
In 10 or 40 seconds, the unit will begin to work and acquire the GSM signals as well as the

GPS signals. The indicator will keep flashing every 3 seconds when the unit has received the
signals.
When this unit receives GPS signals normally, you can use it and do any setting as the
instructions of this manual.
5.3 Upload
5.3.1set frequency
command format: dw005,24,0900
005 means the device wake up work for 5 minutes,value 005-999
24 means the device would wake up to uplaod data to sever every 24 hours,value 02-48
0900 means 09:00,the device upload data at 09:00
5.3.2set upload GPS data
command format: gpsloc123456,1
1 means open,0 means close
5.4 Dropped Alarm（effect the admin number）
5.4.1 Open Alarm（default as open，calling+ SMS alarm ）
SMS command format: SOS1 ,SOS2 or SOS3
5.4.2 Close Alarm：
SMS Command format：SOS0
5.4.3 Type of alarm：
SOS1=Calling
SOS2=SMS
SOS3=Calling +SMS
5.5 working mode
5.5.1 The working time for the first time：after turn on the device ,it will be worked for 4 min ,then
it will be go into deep sleeping working condition (GSM off GPS off GPRS off )
5.5.2 deep sleeping working mode：GSM off,GPRS off,GPS off;upload LBS data every 12
hours.when the device upload LBS data,GSM on,GPRS on,GPS off for 5 minutes.
5.5.3 shock sleeping working mode :GSM on,GPRS on,GPS on;without any option more than 10
minutes,GSM on,GPRS off,GPS off.
1.send sms command:dw999,when the device received this command,the device came into
shock sleep mode(the device always in shock sleep mode);if the user do not want the device
always in shock sleep mode,pls send command likes below
2.send sms command:dw005(005 means 5 minutes,value 5-360 minutes),when the device
received command,the device came into shock sleep mode(the device would in shock sleep mode
in the time which you set,but after that it comes into deep sleep mode)
5.5.4 deep sleeping working mode change to shock sleeping working mode
press drop button more than 15 seconds and unstuck drop button more than 3 seconds,device
send out drop alarm.at the same time device wake up and being online normal work for 4
minutes,and work by shock sleep mode in 30 minutes.

6. Web platform and sever ip&port
Website
Sever IP
Port
www.lkgps.net
101.1.16.228
7700
7.App download
7.1 android version: scan below QR code
7.2 ios version: search “LKGPS” in app store
8. Faults & The solutions

Faults
Solution
Startup Fail
Check the battery and see if it is fully charged or
correctly installed.
Hang up Fail
In existence of an authorized number, an unauthorized
number dials up the unit. Please initialize the unit and re-set up
the authorized numbers.
Monitoring failure
Please check the authorization number is set to the correct time
No GSM Signal
Please make sure SIM Card is GSM Net and installed correctly; also call display
should be on; but no call transfer and PIN code off.
