Welcome to the TETRA computer Technologies® Tpad™, the rugged,
multipurpose handheld device designed, tested, and manufactured to meet
the environmental and physical real-world challenges faced by today’s mobile
workers.TheTpadnotonly works the way you do, but can alsotaketheabuses
of everyday wear and tear.
Advancedtechnologyand an innovative, rugged designprovide true mobility in
harshoperatingconditions.EquallyimportantisLogicInstrument’scommitment
to ensuring that you are treated with the same respect and honesty you offer
to your customers and peers every day.
TPAD User’s Handbook page 11
Welcome

The Tpad is a high-performance, handheld personal digital assistant (PDA)
that runs on the Microsoft® Windows® CE. NET operating system.
Your Tpad includes the following features:
Small and light-weight ergonomic design for true mobility
Ruggedized for portable and mobile applications in harsh operating
environments
High-performance Intel processor
High-resolution, daylight-readable, full-color VGA LCD display with
integrated touchscreen
Open architecture for support of multiple internal and external expansion
options
Compact Flash slot and extra features options
Extended operating time provided by user-replaceable, high capacity
lithium-ion battery pack
Versatile docking station with optional battery charger for desktop, wall,
and mobile applications
Integrated bluetooth
•
•
•
•
•
•
•
•
•
TPAD User’s Handbook page 12
Welcome
About the Tpad

Check to make sure your package includes the following items:
Base Unit and Battery Pack
• Install the battery and then plug in the adapter to handheld device.
• Attach the AC adapter to AC outlet. The adapter LED indicates the power is ready.
Charge LED will light up till the battery is full. Charging time will be about 2 hours.
• Press the power button momentarily to turn on this device.
• Follow up the instruction on screen to nish the basic setting.
• Press power button momentarily to turn OFF
•
TPAD User’s Handbook page 13
Package contents
Base Unit AC power cord Pack
Welcome
Stylus
Compact Flash Cap
AC adapter
Battery Pack
CF cap Screw
Quick check

Docking station
Battery charger
•
•
Docking cradle
Desk stand
TPAD User’s Handbook page 14
Welcome
Battery charger
Data sync cable (USB)
Optional accessories

Quick Start Guide
This handbook
Your package also includes any optional accessories you ordered.
Power adapter
Secure Data (SD) card
MultiMedia (MMC) card
Handstrap/carrying case
Stylus
Expansion modules
Battery charger
Universal Compact Flash cover
•
•
•
•
•
•
•
•
•
•
TPAD User’s Handbook page 15
Welcome

If you purchased your Tpad from an authorized TETRA computer dealer,
contact the dealer for service and support.
If you purchased your Tpad directly from Logic Instrument, use any of the
following methods to contact Logic Instrument for service and support:
Tel [phone]
Fax [phone]
E-mail [email protected]
Web site http://www.tetracomputer.com
Before you contact Logic Instrument, have the following information ready so
that the customer support representative can quickly provide a solution:
Product name: Tpad
Product serial number
Purchase date
Conditions under which the problem occurred
Any error messages that were displayed
Type of device connected, if any
TPAD User’s Handbook page 17
Contacting Logic Instrument
The serial number is on
the back of the Tpad
Welcome

This chapter provides basic information about your Tpad.
TPAD User’s Handbook page 19
1 Getting Started

This section shows the locations of some of the Tpad’s important
components.
Front view
TPAD User’s Handbook page 20
Chapter 1. Geting Started
Getting to know the Tpad
Getting to Know The T pad
Features and controls
For more information
about each component,
see Chapter 2.
Speaker
Light sensor
Compact Flash socket
Status indicator
Touchscreen
Bluetooth Comm
indicator
Cursor Control
Keypad Microphone
Stylus pen
Power key
Function key
