GLC-130S Outdoor CPE Series
Quick User Guide V1.0
Page 2
PLEASEREADTHESESAFETYPRECAUTIONS!
RFEnergyHealthHazard
The radio equipment described in this guide uses radio frequency transmitters.
Althoughthepowerlevelislow,theconcentratedenergyfromadirectionalantenna
mayposeahealthhazard.
Donotallowpeopletocomeincloseproximitytothefrontoftheantennawhilethetransmitter
isoperating.
ProtectionfromLightning
Beforeconnectingthisinstrumenttothepowerline,makesurethatthevoltageof
the power source matches the requirements of the instrument. The unit must be
standards.
DisposalandRecyclingInformation
Pursuant to the WEEE EU Directive electronic and electrical waste must not be
disposed of with unsorted waste.Please contact your local recycling authority for
disposalofthisproduct.
ReductionofHazardousSubstances
This CPE is compliant with the EU Registration, Evaluation, Authorisation and
Restriction ofChemicals (REACH) Regulation (Regulation No 1907/2006/EC of the
EuropeanParliament
andoftheCouncil)andtheEURestrictionofHazardousSubstances(RoHS)Directive(Directive
2002/95/ECoftheEuropeanParliamentandoftheCouncil).
FCCNotice,USA
TheGLC-130SSeriesCPEunitscomplywithPart25oftheFCCrules.Operationissubjecttothe
followingtwoconditions:
•Thisdevicemaynotcauseharmfulinterference.
•Thisdevicemustacceptanyinterferencereceivedincludinginterferencethatmaycause
undesiredoperation.
ThisdeviceisspecificallydesignedtobeusedunderPart15,SubpartEoftheFCCRulesand
Regulations. Any unauthorized modification or changes to this device may void the user’s
authoritytooperatethisdevice.
Furthermore,thisdeviceisintendedtobeused only when installedinaccordancewiththe
instructionsoutlinedinthismanual.Failuretocomplywiththeseinstructionsmayalsovoidthe
user’sauthoritytooperatethisdeviceand/orthemanufacturer’swarranty.
Page 3
1.
Overview
GLC-130S Seriesisa high performance LTECPE (CustomerPremises
Equipment)productdesignedtoenablequickLTEservicedeployment
to the remote customers. It provides high data throughput and
networking features to end users who need both bandwidth and
roamingcapabilitiesinthecertainarea.
!
UserInterfaceSpecification
Model
Description&UserInterface
GLC-130SSeries
- Panelantenna:
B42_4315dBi
B41_714dBi
- 1RJ4510/100MLANPort
- PWR,RUN,LAN,SIM,andLTE(1-6)LEDs
- 48VDCPoEsupply,ODUPower<10Watts
- Dimensions:203mm(L)×203mm(W)×76mm(D)
- Weight:<2Kg
!
LTEInterfaceSpecification
FrequencyBands
Band73840414243
RadioAccess
3GPPE-UTLARelease9
OperationMode
TDD/FDD,2x2MIMODL
OutputPower
>23dBmatantennaport
Throughput
Category4
SIM Support
SIMcardslot
Page 4
2.
GettingStarted
1)
Packinglist
Upon receiving the product, please unpack the product package carefully. Each product is
shippedwiththefollowingitems:
Table2-1PackingList
OutdoorCPEProducts
Quantity
ODUunit
1
PoEadapter
1
PowerLine
1
Mountingbrackets
1
PCEthernetCable
1
Ifyoufindanyoftheitemsismissing,pleasecontactourlocaldistributorimmediately.
2)
UnpackingtheEquipment
Tab le2-1listsallthestandardpartsthataresuppliedinyourLTECPEUnitInstallationPackage.
Pleasetakethetimetounpackthepackageandcheckitscontentsagainstthislist.
3)
InstallingtheEquipment
!
DeviceLogicconnection
For outdoor CPE product, it is suggested that the CPE device be installed in a shaded area to avoid
direct sun light exposure which may cause over heat in certain extreme weather condition. The CPE
should be properly grounded for proper protection against lighting or power surge.
Page 5
To power on the device, the outdoor CPE must uses a 48V PoE integrated DC power supply adapter.
The power adapters can operate in 90-250V AC range and therefore can be used in different country.
Once the device is powered up, the user should wait for about 2 minutes before the device becomes
operational. For CPE with the RUN LED indicator, a slowly flashing light indicates the system has
completed the startup procedure.
To connect PC, LAN switch or other type of IP device to the CPE product, the user should use standard
CAT5 Ethernet cable and connect to the appropriate LAN port. Once connect the CPE LAN LED
indicator should come on.
!
InstallingOutdoorUnit(ODU)
Mounting Bracket::
Page 6
Header Connection:
3.
RFSignalAdjusting
!
RF Signal Adjusting
After the CPE outdoor unit has installed, the direction of antenna’s azimuth and pitch angle needs to
adjust for the best signal strength. In near line of sight condition, the CPE will have the best signal when
the antenna is directly pointing the base station.
User can adjust the holder to change the direction and angle of the antenna while observing the RF
LED on the outdoor unit which indicates the signal strength.
Page 7
!
Wireless Link Status
The user can further view more detailed wireless link through the WEB GUI interface under the
“Interface Info” link. The following wireless link information can be displayed.
4.
ManagingCPEDevice
GLC-130S Series CPE supports several management interfaces including TELNET, WEB, and TR-
069 for local or remote managements. However normal end user is only provided with WEB based
access
!
WEB Login
It is a preferred to setup the CPE using a Web browser from a local PC connected to device LAN port.
Page 8
The user should ensure that the connected PC have acquired IP address via DHCP from the device.
After IP connectivity is established between the PC and CPE device, the user may launch a Web
browser and specify http://10.1.1.1 in the address bar. A window will pop up requesting password. Input
the user login password and then click the “Log In” button. After successful log on, the default home
page of the WEB GUI interface will appear. Note that the default user password is “user123”.
!
Device Status
Once the user is logged in, the following window device status window will be prompted for viewing. It
contains both the wireless link information, networking and device information configured for the device.
For wireless info gives quite detailed information about the radio connection and user can use it to
determine the receiving signal strength and transmit power of the device.
Page 9
!
LAN Configuration
The LAN setting allows user to specify the DHCP server setting for the LAN devices including the pool
address, IP and MAC binging and whether DHCP server should be enabled.
User is advised to leave the default setting unchanged for quick configuration and smooth device
operation.
Page 10
!
Applications Configuration
Port Range Forwarding:
Certain applications may require to open specific ports in order for it to function correctly. Examples of
these applications include servers and certain online games. When a request for a certain port comes
in from the Internet, the device will route the data to the computer you specify. Due to security concerns,
you may want to limit port forwarding to only those ports you are using, and uncheck the Enable
checkbox after you are finished.
Port Forwarding:
Certain applications may require to open specific ports in order for it to function correctly. Examples of
these applications include servers and certain online games. When a request for a certain port comes
in from the Internet, the device will route the data to the computer you specify. Due to security concerns,
you may want to limit port forwarding to only those ports you are using, and uncheck the Enable
checkbox after you are finished.
Page 11
!
UPnP Setting
Forwards:
Configure Port forwarding for UPnP. Click the trash sign to delete individual entry.
UPnP Service:
Allows applications to automatically setup port forwarding.
!
Maintenance
Firmware Upgrade over HTTP:
Click on the Browser button to select the firmware file to be uploaded to the device.
Page 12
Click the Upgrade button to begin the upgrade process. Upgrade must not be interrupted.
Old Password:
The password currently in use.
New Password:
The new password must not exceed 63 characters in length and must not include any spaces. Enter
the new password a second time to confirm it.
Firmware Update Checking:
This will disable or enable the firmware update check during user login. The user will be promoted option
to perform device firmware upgrade if new version is available.
Restore Factory Defaults:
This will restore the device to original factory setting. User will need to reconfigure the authentication
setting in order to get the device operational.
System Reboot:
Click the Reboot button to restart the device.
5.
DeviceReset
In case the user forget the login password, a reset password can be obtain from the operator by given
the device MAC address. The user can enter the reset password in the login window and a system
reset will be performed and the unit will be rebooted. The user can then be allowed to use the original
default login password to gain access to the unit WEB GUI again.
After factory reset, the device may need to be reconfigured by the user or even operator to gain network
access. This is not a recommended operation and special care must be taken to ensure the device will
be properly re-configured after factory reset.
6.
LEDDisplay
LED Indicator
Function
Description
PWR
Power Indicator
Green Color – Device is powered on
RUN
System Run Indicator
Fast Blinking – Device is rebooting
Slow Blinking – Device is in normal operation
LAN
LAN port status
Solid Green – LAN port is up
Blinking Green – LAN data activity in progress
SIM
SIM Card Indicator
Light is on – SIM Card Error
RF (5 LEDs)
RF Signal Strength
5 level signal strengths indication by 6 green LEDs
Page 13
7.
FAQandTroubleshooting
1) My PC cannot connect to the CPE.
!Re-plug the PC Ethernet cable and check if the PC LAN connection is up or showing activity.
!Check if the PoE power adapter LED is on. If it is not, check the power cord and make sure it
is connected properly. Also verify that the AC power supply is available.
!If the PC LAN shows no activity and PoE adapter LED is off but the power cord is connected
properly and there is AC supply, then it is likely the PoE adapter is damaged. Please contact
distributor to obtain replacement part.
2) My PC cannot acquire IP from the CPE.
!First check if the NIC is up and working properly. Then check the PC NIC configuration and
make sure the DHCP is enabled.
!Open the MS-DOS window, enter “ipconfig /release” and “ipconfig /renew” commands and see
if PC can obtain IP correctly.
!If the problem persists, please contact the operator or distributor for further diagnose.
3) My CPE networking is not working properly.
!You may want to check if the LTE connection is up and running properly. You can do this by
login the WEB GUI and check the Interface Info page.
!You may want to perform a factory reset and see if the problem is being corrected. You can do
this by log into the WEB GUI using “user” password and perform restore the unit to default
factory setting.
!If the problem cannot be corrected by factory reset, please contact the operator or distributor
for further diagnose.
4) I forget the login password and like to reset the unit to factory default.
!Please contact the operator or distributor and give them the MAC address of the unit. The
operator or distributor can issue you a RESET password for you to enter in the WEB login
window.
!After the unit is reset to factory default, you can login using the default password.
