Magma C10-601T-CSA User manual

Gas Grill Models: C10-601T-CSA, C10-603T-CSA
OWNER’S MANUAL
IMPORTANT, read these instructions carefully before use. Familiarize yourself with the appliance
before connecting it to its gas container. Keep these instructions for future reference.
TM
1-800-86-MAGMA
7:00 a.m. - 5:00 p.m.
Pacific Time Monday thru Friday
or e-mail us at
[email protected]
For questions regarding performance,
assembly, operation, parts, or returns,
contact the experts at MAGMA directly
by calling TOLL FREE
For questions regarding performance, assembly,
operation, parts, or returns, contact the experts
at MAGMA by calling [phone]
7:00 a.m. - 5:00 p.m. Pacific Time Monday thru
Friday or e-mail us at [e-mail]

POUR VOTRE SÉCURITÉ
Que faire si vous sentez une odeur de gaz:
1.Ne pas tenter d’allumer d’appareils.
2.Éteindre toute flamme.
3.Couper l’alimentation en gaz à la source.
FOR YOUR SAFETY
If you smell gas:
1.Do not attempt to light appliance.
2.Extinguish any open flame.
3.Disconnect from fuel Supply.
MONOXYDE DE CARBONE
Cet appareil peut produire du
monoxyde de carbone, un gaz
inodore.
L’utilisation de cet appareil dans
des espaces clos peut entraîner
la mort.
Ne jamais utiliser cet appareil
dans un espace clos comme un
véhicule de camping, une tente,
une automobile ou une maison.
CARBON MONOXIDE HAZARD
This appliance can produce
carbon monoxide which has no
odor.
Using it in an enclosed space
can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car or home.
POUR VOTRE SÉCURITÉ
Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables à
appareil.
FOR YOUR SAFETY
Do not store or use gasoline or other liquids
with flammable vapours in the vicinity of
this or any other appliance
DANGERDANGER
2
• USE OUTDOORS ONLY.
• DO NOT USE THIS APPLIANCE INSIDE ANY ENCLOSED SPACE.
• GRILLS RADIATE HEAT. CLEARANCE FROM COMBUSTIBLES, 24” SIDES AND BACK. NEVER USE UNDER AWNINGS,
PATIO COVERS, ETC.
• USE PROPANE GAS ONLY. FUEL STORAGE SHOULD BE IN COMPLIANCE WITH THE NATIONAL FIRE PROTECTION
ASSOCIATION (NFPA) STANDARD 58 LIQUID PETROLEUM GAS CODE AND OCCUPATIONAL HEALTH AND SAFETY
ADMINISTRATION (OSHA) STANDARD 29 CFR 1910.101
• FOR NATURAL GAS APPLICATION CONTACT MAGMA.
• ALWAYS LIGHT GRILL WITH LID OPEN.
• NEVER LEAVE HOT GRILL UNATTENDED.
• DO NOT OVERHEAT GRILL, SEE OPERATING INSTRUCTIONS
• ALWAYS TURN GRILL OFF AFTER USE.
• USE GLOVE OR HOT PAD WHEN HANDLING HOT GRILL.
• NEVER LEAVE GAS CYLINDERS AND REGULATOR CONNECTED WHEN Stored.
• STORE GAS CYLINDERS IN A SECURE WELL VENTILATED AREA, OFF OF THE GROUND, ON A NON-
COMBUSTIBLE BASE.
• DO NOT STORE GAS CYLINDERS INDOORS, IN DIRECT SUNLIGHT, BELOW DECKS ON BOATS, OR IN LOCKERS
NOT APPROVED FOR BUTANE OR PROPANE STORAGE.
• CAUTION: CHECK FOR GAS LEAKS EACH TIME CYLINDER IS CHANGED.
• NEVER CHECK FOR GAS LEAKS WITH A FLAME!
• DO NOT BLOCK, RESTRICT, OR OTHERWISE OBSTRUCT COMBUSTION OR VENTILATION AIR OPENINGS.
• DO NOT MODIFY THIS APPLIANCE.
• KEEP AREA CLEAR AND FREE FROM COMBUSTIBLE MATERIALS, GASOLINE, AND OTHER
FLAMMABLE VAPOURS AND LIQUIDS.
• CHECK THAT VALVE SEALING WASHER (A) IS IN PLACE AND IN GOOD CONDITION BEFORE
CONNECTING THE GAS CONTAINER.
• INSTALL CANISTERS IN WELL VENTILLATED AREA AND AWAY FROM OPEN FLAME, HEAT
SOURCE OR SPARKS. KEEP AWAY FROM OTHER PEOPLE OR FLAMMABLE MATERIALS.
A
IMPORTANT SAFETY WARNINGS
READ ALL INSTRUCTIONS BEFORE OPERATING.
Each Magma
®
Gas Grill is individually fire tested before it leaves the factory.
For this reason, the burner on your grill may be slightly discolored.

INSTALLATION INSTRUCTIONS
3
See Magma website
for replacement part numbers
and valve applications.
www.MagmaProducts.com
MOUNT HARDWARE
Fasteners are supplied for Single Mount
mounting option. See Magma Website for
mount selection.
Carriage bolt,
washer & lock nut
Single mount through-bolt applications
4 Carriage bolts, washers & lock nuts.
Note: Place washers on carriage bolts as shown above.
Burner
Lid Lock
Lid
Handle
Grill Grates
Radiant Plate
Outer Shell
Match Light Hole
Mount Support Pad
with Folding Legs
Valve Chamber
Electronic
Ignition
Slide Out Grease Tray
Control Valve
Regulator Type1
Low-Output
Thermometer
CONTROL VALVE REGULATOR
•Uses standard 1-lb. disposable propane canisters (DOT-39 NRC).
•Prior to installing valve, become familiar with the valve function and graphics
on valve knob. Never force the knob. Always turn or push gently.
•Turn control valve to “lock” and install gas canister being careful not to cross
the threads. Check for leaks prior to use, by brushing soapy water solution
around threads and orifice hole checking for bubbles.
•Position valve with gas bottle as shown (A). Gently insert valve stem into
valve chamber. Rotate until valve stem key aligns with lock detent allowing
valve to fully insert. Rotate gas canister down, so knob faces you (B) or
straight up (C) depending on application.
Indicator
Off
Medium
Lock
Unlock
High
Low
(A)
(B)
(C)
Valve will feel loose and will rotate easily. Even though the valve feels loose, it will not leak. The
valve was designed to be loose fitting in order to allow safe, easy installation and removal of
the propane canister and so it easily swings without resistance to fit all applications.

4
OPERATING PROCEDURES
OPERATE ONLY ON “LOW” WHEN LID IS CLOSED.
ALWAYS OPERATE WITH GREASE TRAY IN PLACE.
WARNING: Do not overheat grill. Magma Grills do not require pre-heating. Stainless Steel loses
anti-corrosive characteristics when subjected to extreme heat. Most grilling is done on low
temperature with the lid closed. If medium or high heat is required, grill with lid open.
LIGHTING INSTRUCTIONS
• Open lid during lighting.
• Depress knob and rotate counter-clockwise to the “HIGH” flame position.
• Push Electronic Igniter. • Visually confirm ignition. • Turn knob to adjust flame.
• If grill does not light (see page 5).
• If electronic ignition fails to ignite the gas, see MATCH LIGHTING INSTRUCTIONS.
NOTE: Before lighting, lid lock must be positioned not to engage. Open lid and turn lock to
locked position.
NOTE: Electronic ignition comes equipped with battery preinstalled. Replace with “AAA”
alkaline battery only.
MATCH LIGHTING INSTRUCTIONS
(Back up system allows use of grill until ignition system is repaired.)
• Open lid during lighting. • Place flame up to burner through the match light hole.
• Depress valve and turn counter-clockwise to the “HIGH” flame position.
• Visually confirm ignition.
TO REDUCE FLARE-UP
• Empty and clean grease tray prior to each use.
• Trim excess fats from meat. • Use non-oil based marinades.
• Reduce heat. • Use water spray directly on flare-ups.
FOLDING LEGS
For storage, transport or while using mounting option. Fold up back legs first, then front legs (as
shown). If legs become loose they can be tightened with a 5/32” Hex Key Wrench.
PRACTICAL HINTS:
Before lighting your grill, be sure that …
• Grill is secure and properly mounted.
• Internal components and grease tray are clean and correctly positioned.
• You have plenty of gas in the canister.
• Gas canister is attached properly and there are no gas leaks.
• Lid lock has been set not to engage.
• You have a water spray bottle handy to cool a hot grill or stop any flare-ups.
STOWING TIPS
• Always disconnect the fuel canister from the valve prior to stowing.
• Stow the valve in a clean, dry area to protect from corrosion to valve.
• Always store propane in a sealed propane storage locker that allows leakage to vent
or use Magma Propane / Butane Storage Locker / Tote Bag.
Indicator
Off
Medium
Lock
Unlock
High
Low
Indicator
Off
Medium
Lock
Unlock
High
Low

ELECTRODE SPARK ADJUSTMENT
CAUTION: Spark can cause small shock. Do not leave
fingers on or near electrode wire while engaging igniter.
• Electrode wire should be approximately 1/8” from gas
exit hole in burner . Carefully adjust wire if required.
5
A
DISASSEMBLY & RE-ASSEMBLY
• Remove radiant plate’s retainer pin (see B) and remove radiant plate by sliding it out
of securing tabs (see E).
• Remove burner retainer pin (see C), remove burner. Inspect burner, remove obstructions.
CAUTION: WHEN REPLACING BURNER, CUT SLOTS IN BURNER MUST FACE DOWN.
• Remove lid by removing hinge screws and nuts with 3/16” hex key wrench
(supplied) and 1/2” wrench or pliers. CAUTION LOCK NUTS MUST BE INSTALLED WITH
LOCKING INDENT MARKS SHOWING (see F). IMPROPER INSTALLATION WILL DAMAGE
HINGE SCREWS AND LOCK NUT.
• Clean as indicated in Maintenance (page 6).
• To disconnect or replace igniters ceramic electrode. First remove two screws on valve
chamber (see D) and remove cover plate. Gently pull wire off connector (see D).
Remove electrode screw and nut with a small Phillips head screwdriver and 1/4”
wrench or pliers. Gently pull electrode with wire out of grill body inspect for damage,
replace if necessary.
• To re-assemble, reverse above procedure.
BC
E
Electrode
Disconnect
wire
D
Screws
Battery
Locking
Indents
F
Retainer Pin Retainer Pin
Radiant Plate
Radiant Plate
Securing Tabs
Burner

6
MAINTENANCE
USING GRILL WITH LPG (PROPANE) SYSTEMS
Stainless steel contrary to popular belief can rust. Most commonly, deposits on surface of the product will trap moisture. It is
this moisture that robs stainless steel of oxygen. Oxygen is the element that reacts with stainless steel to form a protective layer of
chrome oxide. Robbed of oxygen, this reaction does not take place and “crevice corrosion” or “surface rusting” occurs. To
minimize this effect, thoroughly clean your grill with soap and water, rinse with fresh water, and dry. Avoid using stainless steel
polishes on grill exterior as most leave a residue that may discolor when grill is heated.
Additionally, stainless steel that is exposed to high heat will change color and texture over time. The “amber” color of grill
exterior and internal components is not a failure of the stainless steel and will not affect products operation. When this happens,
we recommend using “Magma Magic” Grill Restorer to remove the “amber” color and return grill to its original luster.
However, prolonged exposure to extreme high heat will cause chromium and nickel to “burn out” of stainless steel. At this point
stainless steel will become more susceptible to corrosion and will start to deteriorate. We recommended replacement of internal
components as they become seriously deteriorated.
We recommend thoroughly cleaning grill and internal components after each outing. Disassemble interior components and
remove all food residue. Use a “Scotch Brite” pad or similar product and “Easy-Off” oven cleaner for cleaning grills interior
components, followed by thoroughly washing with soap and water, rinse with fresh water & dry. AVOID CONTACT OF OVEN
CLEANER WITH SKIN, CONTROL VALVE, IGNITOR ELECTRODE & WIRE. CAUTION: DO NOT USE ANY TYPE OF ABRASIVE PAD ON
EXTERIOR MIRROR FINISH AS IT WILL SCRATCH SURFACE, USE ONLY A SOFT CLOTH. We recommend covering grill between uses.
Grill covers are available at Magma retailers or directly from Magma. See our website: magmaproducts.com After cooking Do
Not turn grill to high heat to burn off grilling residue. The grill is not a self cleaning oven & this extreme heat can damage
stainless steel components.
Grill Grates -Clean with brass wire brush while grill is warm. Use Oven & Grill cleaner for burnt-on residue. Wash with
soapy water and dry prior to storage.
Ceramic Electrode - Located just beside the burner, it should be kept clean of grease and debris. Be careful not to damage the
ceramic insulation or the wire. See page 5 for electrode spark adjustment.
Control Valve -All valves are set and tested at our factory. Do not attempt to adjust or disassemble the valve in any way.
Call Magma if you suspect it is not adjusted properly. Clean valve with a cloth and remove any debris obstructing the orifice.
Repair/Replacement Parts - All replacement parts are readily available at your Magma Retailers or directly from Magma.
For a complete list of replacement parts visit our website MagmaProducts.com.
• Magma LPG (Propane) Valves & Hose Kits allow Magma
Grills to be installed within existing, pre-regulated low
pressure LPG (Propane) system.
• Use only Magma Type 3 Low Pressure LPG (Propane)
Valves. See our Valve Application Guide at
MagmaProducts.com for correct valve.
• In North America use Magma A10-225 LPG 10' Gas
Grill Connection Kit in conjunction with Type 3 Valve.
Outside North America check
your local dealer for proper hose and fittings.
• A primary shutoff valve (supplied with Gas Grill
Connection Kit) must be used with this control valve at
point of connection into your system. This allows shut off
of gas supply to hose leading to grill.
• In Australia & New Zealand LPG fuel systems must
be installed by a certified
gas technician.
Gourmet
Gas Grill
Align valve stem key
to valve chamber
lock detent and rotate
Gourmet
Gas Grill
Propane (LPG) Gas Regulator
A10-225 LPG (Propane)
10' Gas Grill Connection Kit
To other LPG
appliance
or use cap
Shut off
valve
Cylinder Valve
Gauge
Gourmet
Gas Grill
Gourmet
Gas Grill
Type 3
Valve
Type 3
Valve
Solenoid
Typical Pre-Regulated
LPG Application
Gourmet
Gas Grill
Align valve stem key
to valve chamber
lock detent and rotate
Gourmet
Gas Grill
Propane (LPG) Gas Regulator
A10-225 LPG (Propane)
10' Gas Grill Connection Kit
To other LPG
appliance
or use cap
Shut off
valve
Cylinder Valve
Gauge
Gourmet
Gas Grill
Gourmet
Gas Grill
Type 3
Valve
Type 3
Valve
Solenoid
Typical Marine &
R.V. Application

7
USING GRILL WITH CNG (NATURAL GAS) SYSTEMS
• Magma on-board CNG (natural gas) valves allow Magma grills to be installed to an existing on-board, pre-regulated low
pressure CNG (natural gas) system.
• Use only Magma Type 4 Low Pressure CNG (natural gas) control valves. Visit out website at MagmaProducts.com to view
valve application guide. See your local dealer for proper hose and fittings.
Problem
Electrode covered with grease or residue
Igniter/electrode too far from burner
Electrode wire loose, disconnected, or corroded
Wire is shorted causing spark from wire before
electrode
No spark being generated
No gas flow
Obstructed gas flow
Excessive cooking temperature
Grease and/or residue build-up
Excessive fat in meats
Excessive oils in marinades
Obstructed gas flow
Flame too low
Wind directly on burner
Obstructed gas flow
Grill not level
Grease or residue build-up
Excessive fat in meats
Excessive oil in marinades
Clean electrode
Adjust electrode until proper spark appears
(see page 5)
Clean, adjust & reconnect wire between igniter
& electrode, see Complete Disassembly (page 5)
Replace Igniter, Electrode & Wire
See website for part number
Adjust electrode until proper spark appears.
Unscrew igniter push button, remove/inspect
“AAA” battery, replace “AAA” alkaline battery if
necessary, reinstall & re-assemble push button
Replace Igniter, Electrode & Wire
See website for part number
Check fuel level, replace canister or
refill cylinder
Clean burner and valve orifice.
Remove debris/spider webs
Operate only on low when lid is closed
Reduce flame level
Leave lid open
Use water spray to cool
Clean components
Trim fat from cuts of meat before grilling
Use non-oil based marinades
Clean burner and valve orifice.
Remove debris/spider webs
Increase flame
Block wind when opening lid
Clean burner and valve orifice.
Remove debris/spider webs
Level Grill
Clean components
Trim fat from cuts of meat before grilling
Use non-oil based marinades
Hot Spots
Blow-out
Yellow sooty
flame
Flare-up
Burner will
not light even
with match
Burner will
not light with
igniter
TROUBLE SHOOTING GUIDE
Possible Solution Possible Cause
7

LIMITED WARRANTY
Magma Products, Inc. guarantees this product to be free from defects in materials or workmanship to the original consumer. This guarantee is for the
periods herein specified when used under normal and reasonable conditions, one (l) year from the date of original purchase. This warranty does not include
the cost of property damage or any inconvenience due to the failure of the product. Nor does it cover damage due to misuse, abuse, accident, or damage
resulting from transportation of the product. Nor does it include damage resulting from the commercial use of this product. Nor does it include, on stainless
steel products, "Surface Rust'; Excessive Corrosion due to exposure to salt water; or Discoloration or Corrosion caused by exposure to excessive heat or failure
to properly clean and care for the stainless steel surfaces. If the product fails to operate due to a defect in materials or workmanship during the warranty
period, the defective part will be repaired or replaced at Magma's option. If you wish to obtain performance under this limited warranty, you should contact
Magma's Customer Service Department via telephone at [phone], or via e-mail at [email protected], or via U.S. Postal Service mail at "Magma
Products, Inc., Attention Customer Service, 3940 Pixie Ave. Lakewood, CA, 90712". The defective part, along with proof of purchase, must be returned post-
age prepaid to Magma Products, Inc. We suggest that you keep your purchase receipt as we may require reasonable proof of purchase.
In the state of California only, if refinishing or replacement of the product is not commercially practicable, the retailer selling the product, or Magma
Products, Inc., will refund the purchase price paid for the product, less the amount directly attributable to use by the original consumer prior to the discovery
of the nonconformity. In addition, in the state of California only, you may take the product to the retail establishment from which it was purchased or to any
retail establishment selling this product in order to obtain performance under this warranty. All implied warranties, including the implied warranties of mer-
chantability and fitness for a particular purpose, are limited in duration to the express warranty periods specified herein for the parts described herein. Some
states do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Neither Magma dealers, nor the retail
establishment selling this product has any authority to make any warranties or to promise remedies in addition to or inconsistent with those stated above.
Magma's maximum liability shall not exceed the purchase price of the product paid by the original consumer. Some states do not allow the exclusion or limita-
tion of incidental or consequential damages, so the above limitation orexclusions may not apply to you. The warranty gives you specific legal rights and you
may also have other rights which vary from state to state.
MAGMA and the Magma logo are registered trademarks of Magma Products, Inc. • Newport is a trademark of Magma Products, Inc. • Patent pending.
Magma Products, Inc.
3940 Pixie Avenue, Lakewood, CA 90712 • USA
Phone [phone] • e-mail: [e-mail]
MagmaProducts.com
83-600T-CSA 0217
CALIFORNIA PROPOSITION 65 – WARNING – The burning of gas cooking fuel generates some by-products, which are on the list of substances, which
are known by the State of California to cause cancer or reproductive harm. California law requires businesses to warn customers of potential exposure to
such substances. To minimize exposure to these substances, always operate this unit according to the use and care manual, ensuring you provide good
ventilation when cooking with gas.
CONTENTS
Contents
A
Bx 4 x 4
A) (1) 3/16” Hex key wrench for lid removel.
B) Pack of (4) 1/4”-20 x 5/8” carriage bolts and lock nuts
for dual mount and single mount applications.
