Makita UH5580 User manual

GB Hedge Trimmer Instruction manual
F Taille-haie Manuel d’instructions
D Heckenschere Betriebsanleitung
I Tagliasiepi Istruzioni per l’uso
NL Heggenschaar Gebruiksaanwijzing
E Desmalezadora eléctrica Manual de instrucciones
P Aparador de cercas elétrico Manual de instruções
DK Hækkeklipper Brugsanvisning
GR Ψαλίδι Μπορντούρας Οδηγίες χρήσης
UH5580
UH6580
UH7580
009312

2
1009317 2009319
3009281 4009313
5007542 6009316
12
3
4
5
6
78
5
4
6
9
10

3
7007545 8009324
9007559 10 009315
11 009318 12 009285
13 009320 14 009321
9
11
9
12
13 14
15

4
15 009322 16 009323
17 009290 18 009291
19 009292 20 009293
21 009295 22 009296
16 17
18
19
18
20
21
22
23
24
25
26
27
28 27

5
23 009297 24 009298
25 009299 26 009300
27 009301 28 009302
29 009303 30 009304
29
30
26
19
30
31
31
30
30

6
31 009325

7
ENGLISH (Original instructions)
Explanation of general view
SPECIFICATIONS
• Due to our continuing program of research and development, the specifications herein are subject to change without
notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
Symbol END220-5
The following show the symbols used for the equipment.
Be sure that you understand their meaning before use.
...... Read instruction manual.
................ DOUBLE INSULATION
................ Do not expose to rain.
................ Remove plug from the mains
immediately if the cable is damaged or
cut.
................ Only for EU countries
Do not dispose of electric equipment
together with household waste
material!
In observance of European Directive
2012/19/EU on waste electric and
electronic equipment and its
implementation in accordance with
national law, electric equipment that
have reached the end of their life must
be collected separately and returned to
an environmentally compatible
recycling facility.
Intended use ENE014-1
The tool is intended for trimming hedges.
Power supply ENF002-2
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and can
only be operated on single-phase AC supply. They are
double-insulated and can, therefore, also be used from
sockets without earth wire.
General Power Tool Safety
Warnings GEA010-1
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and
instructions for future reference.
HEDGE TRIMMER SAFETY
WARNINGS GEB041-9
1. Keep all parts of the body away from the cutter
blade. Do not remove cut material or hold material
to be cut when blades are moving. Make sure the
switch is off when clearing jammed material. A
moment of inattention while operating the hedge
trimmer may result in serious personal injury.
2. Carry the hedge trimmer by the handle with the
cutter blade stopped. When transporting or
storing the hedge trimmer always fit the cutting
device cover. Proper handling of the hedge trimmer
1. Switch trigger B
2. Switch trigger A
3. Switch trigger C
4. Hook complete
5. Tool’s cord
6. Extension cord
7. Hook
8. Tool
9. Holder
10. Waist cord hook
11. Cord
12. Arm cord hook
13. Trimming direction
14. Tilt the blades
15. Hedge surface to be trimmed
16. Press
17. Chip receiver
18. Nut
19. Shear blade
20. Branch catcher
21. Hooks
22. Fit the hooks into groove
23. Grooves
24. Press the levers on both sides
25. Unlock the hooks
26. Screws
27. Blade cover
28. Under cover
29. Gear housing cover
30. Crank
31. Ellipse of shear blade
Model UH5580 UH6580 UH7580
Blade length 550 mm 650 mm 750 mm
Strokes per minute (min-1) 1,500 1,500 1,500
Overall length 970 mm 1,049 mm 1,157 mm
Net weight 4.3 kg 4.4 kg 4.6 kg
Safety class /II

8
will reduce possible personal injury from the cutter
blades.
3. Hold the power tool by insulated gripping surfaces
only, because the cutter blade may contact hidden
wiring or its own cord. Cutter blades contacting a
“live” wire may make exposed metal parts of the
power tool “live” and could give the operator an
electric shock.
4. Keep cable away from cutting area. During
operation the cable may be hidden in shrubs and can
be accidentally cut by the blade.
5. Do not use the hedge trimmer in the rain or in wet or
very damp conditions. The electric motor is not
waterproof.
6. First-time users should have an experienced hedge
trimmer user show them how to use the trimmer.
7. The hedge trimmer must not be used by children or
young persons under 18 years of age. Young persons
over 16 years of age may be exempted from this
restriction if they are undergoing training under the
supervision of an expert.
8. Use the hedge trimmer only if you are in good physical
condition. If you are tired, your attention will be
reduced. Be especially careful at the end of a working
day. Perform all work calmly and carefully. The user is
responsible for all damages to third parties.
9. Never use the trimmer when under the influence of
alcohol, drugs or medication.
10. Check to make sure that the voltage and frequency of
the power supply correspond to the specifications
given on the identification plate. We recommend the
use of a residual-current-operated circuit breaker
(ground-fault circuit interrupter) with a tripping current
of 30 mA or less, or an earth leakage current
protector.
11. Work gloves of stout leather are part of the basic
equipment of the hedge trimmer and must always be
worn when working with it. Also wear sturdy shoes
with anti-skid soles.
12. Before starting work check to make sure that the
trimmer is in good and safe working order. Ensure
guards are fitted properly. Check cable for damage
before starting work and replace if necessary. The
hedge trimmer must not be used unless fully
assembled.
13. Keep cable away from the cutting area. Always work
in such a way that the extension power cord is behind
you.
14. Remove plug from the mains immediately if cable is
damaged or cut.
15. Make sure you have a secure footing before starting
operation.
16. Hold the tool firmly when using the tool.
17. Do not operate the tool at no-load unnecessarily.
18. Immediately switch off the motor and unplug the
mains plug if the cutter should come into contact with
a fence or other hard object. Check the cutter for
damage, and if damaged repair immediately.
19. Before checking the cutter, taking care of faults, or
removing material caught in the cutter, always switch
off the trimmer and unplug the mains plug.
20. Switch off the trimmer and disconnect and secure the
mains plug before doing any maintenance work.
21. When moving the hedge trimmer to another location,
including during work, always unplug the mains plug
and put the blade cover on the cutter blades. Never
carry or transport the trimmer with the cutter running.
Never grasp the cutter with your hands.
22. Clean the hedge trimmer and especially the cutter
after use, and before putting the trimmer into storage
for extended periods. Lightly oil the cutter and put on
the cover. The cover supplied with the unit can be
hung on the wall, providing a safe and practical way to
store the hedge trimmer.
23. Store the hedge trimmer with the cover on, in a dry
room. Keep it out of reach of children. Never store the
trimmer outdoors.
24. Do not operate the tool at no-load unnecessarily.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product (gained
from repeated use) replace strict adherence to safety
rules for the subject product. MISUSE or failure to
follow the safety rules stated in this instruction
manual may cause serious personal injury.
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function on the
tool.
Switch action (Fig. 1)
For your safety, this tool is equipped with a triple switching
system. To turn on the tool, press two out of three triggers
A, B and C. Release either one of the two pressed triggers
to turn off. The sequence of switching is unimportant as
the tool only starts when both switches are activated.
Straight cut (Fig. 2)
To trim the hedge straight, pull triggers A and B.
Vertical cut (Fig. 3)
Cut upwards with both hands pull the switch triggers B
and C and move it in front of your body.
Far area cut (Fig. 4)
To trim the hedge in far area with both hands pull the
switch triggers A and C.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and
unplugged before carrying out any work on the tool.
Engage the extension cord
CAUTION:
• Make sure that the extension cord is unplugged to the
mains outlet. (Fig. 5)
When engaging the extension cord, secure it to the tool’s
cord with the hook complete. Attach the hook about 100 -

9
200 mm from the extension cord connector. This will help
prevent unintentional disconnection.
Waist cord hook
CAUTION:
• Do not attach the holder of waist cord hook to other
than the extension cord. Do not attach it in a position
closer to the tool beyond the hook complete. Failure to
do so may cause an accident or personal injury.
• Attach firmly one hook of the hook complete to the
tool’s cord and the other hook of hook complete to the
extension cord. Working with the tool with a sole hook
only attached may cause an accident and injury.
Using the waist cord hook helps to minimizing a risk of
cutting off the extension cord unexpectedly caused by the
loose extension cord. (Fig. 6)
Press in or pull out the cord through the opening of the
holder. (Fig. 7)
CAUTION:
• Do not force the opening of the holder. Failure to do so
may cause deflection and damage to it.
Arm cord hook (Accessory)
CAUTION:
• Do not attach the holder of arm cord hook to other than
the extension cord. Do not attach it in a position closer
to the tool beyond the hook complete hooks. Failure to
do so may cause an accident or personal injury.
• Attach firmly one hook of the hook complete to the
tool’s cord and the other hook of hook complete to the
extension cord. Working with the tool with a sole hook
only attached may cause an accident and injury.
Using the arm cord hook helps to minimize a risk of
cutting off the extension cord unexpectedly caused by the
loose extension cord. (Fig. 8)
Attach firmly the arm cord hook placing around your arm
and pass the extension cord through the holder. The
length of the arm cord hook band is adjustable.
NOTE:
• Do not pass the extension cord through the band.
• Do not force the opening of the holder. Failure to do so
may cause deflection and damage to it.
• Using the arm cord hook together with the waist cord
hook is more helpful.
OPERATION
CAUTION:
• Be careful not to accidentally contact a metal fence or
other hard objects while trimming. The blade will break
and may cause serious injury.
• Overreaching with a hedge trimmer, particularly from a
ladder, is extremely dangerous. Do not work from
anything wobbly or infirm.
Do not attempt to cut branches thicker than 10 mm
diameter with this trimmer. These should first be cut with
shears down to the hedge trimming level. (Fig. 9)
CAUTION:
• Do not cut off dead trees or similar hard objects. Failure
to do so may damage the tool.
Hold the trimmer with both hands pull the switch trigger A
or B and move it in front of your body. (Fig. 10)
As a basic operation, tilt the blades towards the trimming
direction and move it calmly and slowly at the speed rate
of 3 - 4 seconds per meter. (Fig. 11 & 12)
To cut a hedge top evenly, it helps to tie a string at the
desired hedge height and to trim along it, using it as a
reference line. (Fig. 13)
Attaching the chip receiver (accessory) on the tool when
trimming the hedge straight can avoid cut off leaves’ being
thrown away. (Fig. 14)
To cut a hedge side evenly, it helps to cut from the bottom
upwards. (Fig. 15)
Trim boxwood or rhododendron from the base toward the
top for a nice appearance and good job. (Fig. 16)
Installing or removing chip receiver
(accessory)
CAUTION:
• Always be sure that the tool is switched off and
unplugged before installing or removing chip receiver.
NOTE:
• When replacing the chip receiver, always wear gloves
so that hands and face does not directly contact the
blade. Failure to do so may cause personal injury.
• Always be sure to remove the blade cover before
installing the chip receiver.
• The chip receiver receives cut-off leaves and alleviates
collecting thrown-away leaves. This can be installed on
either side of the tool. (Fig. 17)
Press the chip receiver on the shear blades so that its slits
overlap with the nuts on the shear blades. At this time,
make sure that the chip receiver does not contact branch
catcher at the top of the shear blades. (Fig. 18)
At this time, the chip receiver needs to be installed so that
its hooks fit into grooves in the shear blade unit. (Fig. 19)
To remove the chip receiver, press its lever on both sides
so that the hooks are unlocked. (Fig. 20)
CAUTION:
• The blade cover (standard equipment) cannot be
installed on the tool with the chip receiver being
installed. Before carrying or storing, uninstall the chip
receiver and then install the blade cover to avoid blade
exposure.
NOTE:
• Check the chip receiver for secure installment before
use.
• Never try to uninstall the chip receiver by an excessive
force with its hooks locked in the blade unit grooves.
Using the excessive force may damage it.
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and
unplugged before attempting to perform inspection or
maintenance.
Cleaning the tool
Clean out the tool by wiping off dust with a dry or soap-
dipped rag.

10
CAUTION:
• Never use gasoline, benzine, thinner, alcohol or the
like. Discoloration, deformation or cracks may result.
Blade maintenance
Smear the blade before and once per hour during
operation using machine oil or similars.
After operation, remove dust from both sides of the blade
with wired brush, wipe off it with a rag and then apply
enough low-viscosity oil, such as machine oil etc. and
spray-type lubricating oil.
CAUTION:
• Do not wash the blades in water. Failure to do so may
cause rust or damage on the tool.
Removing or installing shear blade
CAUTION:
• Before removing or installing shear blade, always be
sure that the tool is switched off and unplugged.
• When replacing the shear blade, always wear gloves
without removing blade cover so that hands and face
does not directly contact the blade. Failure to do so
may cause personal injury.
NOTE:
• Do not wipe off grease from the gear and crank. Failure
to do so may cause damage to the tool.
• For specific way of removing and installing shear
blades refer to the reverse of a package for accessory
shear blades.
Removing the shear blades
Reverse the tool and loosen four screws. (Fig. 21)
NOTE:
• Be careful not to get your hands dirty as grease is
applied in the shear blade driving area.
Remove the under cover. (Fig. 22)
Remove the gear housing cover. (Fig. 23)
Set the crank at the angle as shown in the figure with a
slotted bit screwdriver. (Fig. 24)
Remove two screws from the shear blades and the shear
blade unit will be taken out. (Fig. 25)
CAUTION:
• Return the gear to the original position in such a
manner as it was installed if it should be taken away by
mistake.
Installing the shear blade
Prepare 4 removed screws (For under cover), 2 screws
(For shear blade), gear housing cover, under cover, and
new shear blades.
Adjust the crank position as shown in the figure. At this
time, apply some grease provided with new shear blades
to the periphery of the crank. (Fig. 26)
Overlap the oval hole in the upper blade with that in the
lower one. (Fig. 27)
Take out the blade cover from the old shear blades and fit
it onto the new ones for easy handling during the
replacement of blades. (Fig. 28)
Place the new shear blades on the tool so that the oval
holes in the shear blades fit onto the crank. Overlap the
holes in the shear blades with the screw holes in the tool
and then secure them with two screws. (Fig. 29)
Check the crank for smooth turn with a slotted bit
screwdriver. (Fig. 30)
Install the gear housing, under cover on the tool. Tighten
the screw firmly.
Remove the blade cover and then turn on the tool to
check it for proper movement.
NOTE:
• When the shear blades does not operate properly,
there is a poor fit between the blades and crank. Redo
from the beginning.
Storage
The hook hole in the bottom of the blade cover is
convenient for hanging the tool from a nail or screw on the
wall. (Fig. 31)
Put the blade cover on the shear blades so that the blades
are not exposed. Store the tool out of the reach of children
carefully.
Store the tool in the place not exposed to water and rain.
To maintain product SAFETY and RELIABILITY, repairs,
carbon brush inspection and replacement, any other
maintenance or adjustment should be performed by
Makita Authorized Service Centers, always using Makita
replacement parts.
OPTIONAL ACCESSORIES
CAUTION:
• These accessories or attachments are recommended
for use with your Makita tool specified in this manual.
The use of any other accessories or attachments might
present a risk of injury to persons. Only use accessory
or attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• Blade cover
• Hook complete
• Shear blade assembly
• Waist cord hook
• Arm cord hook
NOTE:
• Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.
Noise ENG905-1
The typical A-weighted noise level determined according
to EN60745:
Sound pressure level (LpA): 86.5 dB (A)
Sound power level (LWA): 94.5 dB (A)
Uncertainty (K): 0.7 dB (A)
Wear ear protection.
Vibration ENG900-1
The vibration total value (tri-axial vector sum) determined
according to EN60745:
Work mode: hedge trimming
Vibration emission (ah): 4.4 m/s2
Uncertainty (K): 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test method
and may be used for comparing one tool with another.
