Manhattan 451147 User manual

HARD DRIVE
DOCKING KIT
USER
MANUAL
Models 451147
& 451154
MAN-451147/451154-UM-0408-01
Model 451147
Model 451154

INTRODUCTION
Thank you for purchasing the MANHATTAN
®
Hard Drive Docking Kit,
Model 451147 (aluminum and plastic case) or Model 451154 (plastic
case).
The easy-to-follow instructions in this user manual help make setup
and operation quick and simple, so you’ll also soon be enjoying the
benets of these additional features:
• Easily converts any 3.5” SATA hard drive into a portable storage
solution — installs into any 5.25” bay
• Supports data transfer rates of up to 3 Gbps
• Ideal for securing and transporting data between multiple locations
and PCs; hot-swappable
• Electronic lock disconnects power for safe removal and helps reduce
unauthorized access, drive damage and data loss
• Built-in cooling fan maximizes airow and cooling efciency
• Anti-vibration construction help shield drive from shock
• Lifetime Warranty
System Requirements
• Available 12 V Molex power and SATA L-type data connections
• Windows 2000/XP or MAC OS version 8.6 or above
Package Contents
• Hard Drive Docking Kit with mounting screws
• User manual
2

3 3
HARDWARE INSTALLATION
The MANHATTAN Hard Drive Docking Kit is designed for installation
in most PC cases with an available 5.25-inch drive bay. Generalized
instructions for installation are presented in this manual since the design
of computer cases varies. Refer to your computer’s manual whenever
in doubt about procedures.
This Hard Drive Docking Kit is composed of two components: the docking
case (above) and the drive case (below, with cover removed).
Key lock
Power LED
Drive Activity LED
SATA Data
Connector SATA Power
Connector
Diagrams are representational
of the entire line of MANHATTAN
docking kits and may not depict
specic cables/connectors.

44
Installing the Docking Case
1. Turn off the power to your computer and any other connected peripheral
devices. Follow these precautions for static electricity discharge:
• Discharge any static electricity buildup in your body by touching a
grounded metal surface such as the computer case, if plugged in.
• During installation procedures, avoid any contact with internal device
parts.
2. Unplug the power cord from the back of the computer.
3. Remove your computer’s cover.
4. Remove the computer’s front cover plate from the 5.25-inch drive bay
in which you plan to install your MANHATTAN Hard Drive Docking Kit.
5. Remove (separate) the drive case from the docking case by lifting the
handle and pulling it out.
6. Slide the docking case into the 5.25-inch drive bay.
7. Attach the SATA cable from the computer to the SATA connector on the
back of the docking case.
8. Attach an available 4-pin power cable from the system’s power supply
to the 4-pin connector on the back of the docking case. The power
connector is “D”-shaped to ensure proper orientation when making
the connection. (See image below.)
9. Replace the computer’s cover; reconnect the power and other external
cabling.

5 5
Mounting a Drive in the Drive Case
These steps are for installing a 3.5-inch
drive device in the drive case.
NOTE: A special adapter kit is required
in order to install a 2.5-inch drive.
1. Remove the drive case
cover by sliding it
toward the back of
the unit.
2. If you plan to install a drive that features removable media, carefully
punch out the center part of the front panel.
IMPORTANT: If you are installing a new hard drive in the case, you
may need to congure the drive before you
install it. Refer to the drive manufacturer’s
documentation and congure the
drive as Master, Cable Select
or Slave depending on the
conguration of your
computer. After you
complete this
installation, you
may also need to
re-congure the
computer’s BIOS
setup to make the
drive functional in the system.
SATA Connector Power Connector
Diagrams are representational
of the entire line of MANHATTAN
docking kits and may not depict
specic cables/connectors.

66
3. The drive case’s SATA cable supports 3.5-inch drives. Attach the
power and SATA cables from the drive case to the drive. The power
connector is “D”-shaped to help orient the connector correctly.
NOTE: In order to install a 2.5-inch drive, you need a 44-pin-to-40-pin
connector adapter.
4. Carefully position the drive inside the drive case
5. Secure the drive in place using the supplied mounting screws. Use
the mounting holes on the sides or bottom, depending on the design
of the drive.
6. Slide the drive case cover back on.
The hardware installation is now
complete; the drive case is
ready to use.

7 7
Hot-Swapping
The power to your computer can be on both when the drive is inserted or
removed. Use the key to turn the drive on after inserting it and off before
removing it.
To insert the drive case:
1. Insert the drive case (with drive installed) into the installed docking case,
pushing rmly until the drive is seated.
2. Insert the provided key and lock the case in place by pushing the key
in and turning it clockwise. The LED beneath the switch lights after a
slight delay, indicating the device is ready to use.
To remove the drive case:
1. Unlock the drive case (if locked) by turning the key counterclockwise.
CAUTION: Do not turn the key to unlock the drive case while the drive
is in use, as loss of data may occur.
2. Gently pull on the handle to slide the drive case out.
SPECIFICATIONS
Standard and Certications
• SATA 300/150, CE, TÜV, RU
General
• SATA-to-SATA interface
• Supports data transfer rates of up to
3 Gbps
• Electronic locking mechanism &
integrated power switch (2 keys)
• Single rear-mount cooling fan,
4 cm (1.5 in.)
• LED indicators: Power & Activity
Connections
• Drive-to-tray: SATA power,
SATA L-type data
• Tray-to-chassis: Centronic-type
connector (gold-plated)
• Chassis: SATA L-type data, 4-pin
Molex 12 V power, 2-pin fan power
Physical
• Material:
- Model 451154: plastic (94V-0 ABS)
- Model 451147: aluminum & plastic
(94V-0 ABS)
• Chassis: 219 x 146 x 41 mm
(8.625 x 5.75 x 1.625 in.)
• Tray: 195 x 117 x 36 mm
(8 x 4.625 x 1.5 in.)
• Weight:
- Model 451154: 385.5 g (13.6 oz.)
- Model 451147: 649.2 g (22.9 oz.)
Environmental
• Operating temp.: 23 – 122˚F
(-5 – 50˚C)
• Storage temperature: -4 – 149˚F
(-20 – 65˚C)
• Operational humidity: 10 – 80%
• Storage humidity: 10 – 90%
