Mat-Tuner mAT-10 User manual

Instruction Manual
mAT-10
Automatic Tuner with QRP Transceivers
Instruction Manual Version V1.0
INTRODUCTION
The mAT-10 is a compact and tuner designed for YAESU FT-817/818, that can a so be used
with any QRP transceiver. When connected to YAESU FT-817/818 through the supp ied
dedicated contro cab e mode mAT-CY, it is contro ed by “one touch” tuning through the
transceiver. If no contro cab e is used, it is a universa QRP tuner for a ow-power transceivers.
The mAT-10 is used for QRP transmission and its ACC interface is on y designed for the
YAESU FT-817/818. It can not be used for other YAESU transmitters. Higher power YAESU
transceivers can contro the mAT-TUNER mAT-30 tuner. Visit our website to earn about the
mAT-30.
The mAT-10 is connected to the ACC port of the FT-817/818 transceiver through supp ied
contro cab e mAT-CY. The ACC interface a ows an externa device such as a PC or the mAT-10
to contro the FT-817/818 by sending it seria commands. The mAT-10 has the function of "one
key tuning". When the mu ti-function key on tuner is pressed, the mAT-10 command FT-817/818
switches to FM mode and transmits a carrier to initiate a tuning cyc e. After waiting for the tuning
cyc e to comp ete, it stops transmitting the carrier, saves the settings, and restores the transmitter
to its previous mode. This process is automated and does not require manua operation.
When mAT-10 is used with other QRP transceivers, it does not need a contro cab e and works
on y by connecting RF cab es. The tuning process is comp eted by pressing the the TUNE &
POWER mu ti-function button on the pane . Press and ho d for 1 second and the tuning cyc e wi
start.
The tuner operates within the range of 1.8MHz to 54MHz, at power eve s up to 30 watts.
It wi tune dipo es, vertica s, Yagis, or virtua y any coax-fed antenna. The impedance matching
range is 5-1500 ohms, in excess of automatic tuners used in many HF transceivers or other
avai ab e externa automatic tuners.
The mAT-10 has 16,000 frequency memories. When tuning on or near a previous y tuned
frequency, the mAT-10 uses “Memory Tune” to reca the previous tuning parameters in a fraction
of a second. If no memorized settings are avai ab e, the tuner runs a fu tuning cyc e, storing the
parameters for memory reca on subsequent tuning cyc es on that frequency. In this manner, the
mAT-10 “ earns” as it is used, adapting to the bands and frequencies as it goes. You can a so start
a tuning cyc e manua y whenever necessary.
Two 10440 ithium batteries are insta ed in the interior of the mAT-10, which provides power
for the tuner. Because of the use of advanced magnetic retaining re ays, the power consumption
of mAT-10 is very sma . The ithium battery can operate for a ong time after it is fu y charged.
Specia chargers are provided with tuners. You must use its own charger to charge the tuner. It is
dangerous to charge with an incorrect charger.
In addition to the mAT-10 tuner, the package inc udes the mAT-CY contro cab e mAT-CY,
ithium battery charger and user manua . Latest version of user manua s can a so be down oaded
direct y from our web page. The same contro cab e mAT-CY can a so be used with the mAT-30
tuner. They are identica .
1 / 5

Instruction Manual
SPECI ICATIONS
-Max 30 watts SSB and CW peak power, 5 watts on PSK and digita modes.
-1.8 to 54.0 MHz coverage. 16,000 memories for instantaneous frequency
-Tuning time: 0.1 to 5 seconds fu tune, 0.1 seconds memory tune.
-For dipo es, vertica s, Vees, beams, ong wire or any coax-fed antenna.
-Dimensions: 13.8cm x 6.1cm x 2.3cm (L x W x H).
-Weight: 300g.
RONT PANEL
The mAT-10 has a mu ti-function key and six indicator ights. The mu ti-function key has main
power switch, on- ine/off- ine, start tuning cyc e,
battery power eve disp ay function.
SWR & Battery Indicator: When the tuner is turned
on, the three ights show the current SWR. When the
tuner is turned off, after pressing the mu ti-function
key, the three indicators show the battery's power eve .
Online/Bypass: The tuner is on ine when the indicator
ights up. When the indicator ight is off, it means the
tuner is in an bypass state.
Tuning: When the tuner starts the tuning process, the
indicator ights up. Indicator ight goes off to indicate
the end of the tuning process.
Power Indicator: Light on means the tuner is
operationa , off means power off
There are two BNC RF sockets and one ACC socket
at the top of the mAT-10. The "ANT" connector is
used to connect the antenna. The "RADIO" connector
is connected to RF output of transceiver via coaxia
cab e. "ACC" uses contro cab e mAT-CY to connect
the ACC socket of FT-817/818.
The charging socker of the mAT-10 is on the
bottom. Two 10440 ithium batteries insta ed inside
tuner to provide power for the tuner. Tuner can on y be
charged with its attached 8.4 vDC charger.
Important Note: Before the first use of the tuner or
after the battery is replaced, the tuner must be
charged by the charger.
CONTROL CABLE mAT-CY
The mAT-10’s contro cab e mAT-CY provides contro signa s between FT-817/818 and the
tuner. When the mAT-10 is turned on, it wi automatica y detect whether it is connected to
YAESU FT-817/818 through the contro cab e. If so, the interna software matching FT-817/818
wi start running. If it is not connected to FT-817/818, the interna genera tuner software wi be
run.
2 / 5

Instruction Manual
The supp ied mAT-CY transceiver contro cab e is 50 centimeters ong. If desirab e to position
mAT-10 farther from the transceiver than this cab e ength a ows, a custom cab e wi need to be
constructed. This can be accomp ished in two ways: Cut the supp ied cab e and so der a jumper
wire between a the connections, or purchase new connectors and cab e to construct a custom
ength contro cab e from scratch.
1、+13.5V 2、TX GND
3、GND 4、DATA IN
5、DATA OUT 6、SENSE
7、RESET 8、TX INH
INSTALLATION
The mAT-10 tuner is designed for indoor operation on y, it is not water resistant. If you use it
outdoors (Fie d Day, for examp e), you must protect it from the rain. A ways turn your transceiver
off before p ugging or unp ugging anything. The transceiver may be damaged if cab es are
connected or disconnected whi e the power is on.
CONNECTING YAESU T-817/818 TRANSCEIVERS
When the tuner is connected to FT-817/818 transceivers, the cab e connection between the
tuner and the transceiver is comp eted by the fo owing steps. Make sure that both the transceiver
and the tuner are shut down during cab e connection operation.
1. Connect the HF/50 MHz antenna jack on the transceiver to the “RADIO” jack on the top
of the mAT-10 with coaxia cab e.
2. Connect the contro cab e mAT-CY to the mini-DIN 8-pin jack on the rear of the mAT-10
marked “ACC” and other end of this cab e to the ACC jack on the rear of the FT-817/818
transceiver.
3. Connect the antenna feed ine coaxia cab e to the “ANT” jack on the rear of the mAT-10.
CONNECTING OTHER TRANSCEIVERS
Fo ow instructions for FT-817/818, skipping step 2 for the contro cab e.
OPERATION
BATTERY LEVEL INDICATION When the mAT-10 is turned off and the mu ti-function
button is pressed, the three indicator ights in the upper ha f of the tuner are used to indicate the
battery power eve . When the button is re eased, the tuner is sti turned off.
POWER ON AND O Since the tuner wi detect if the FT-817/818 transceiver is current y
connected at startup, turn on the power of the transceiver first and then turn on the power of the
tuner. Press the mu ti-function button unti the "Power Indication" ight in the ower ha f of the
tuner is it. To turn power off, press and ho d the mu ti-function button unti a the ights
inc uding the "Power indication" ight is off.
ONLINE / BYPASS By pressing the mu ti-function button, mAT-10 can switch between
"On ine" and "Bypass". The indicator amp marked "On ine/Bypass" wi be it to indicate that the
tuner is in ine and ready to use. When off, it indicates that the tuner is bypass.
3 / 5

Instruction Manual
TUNING PROCESS, YAESU T-817/818
Press and ho d the mu ti-function button unti the "Tuning" ight is turned on and then re ease
it. The tuner wi automatica y contro the transceiver to comp ete the fo owing operations,
without manua operation by the user.
a. The tuner sends contro commands to FT-817/818 and the transmitter wi be activated and
a carrier signa wi be sent out.
b. The tuner asks the current frequency data of FT-817/818 and reads the matching data from
its own memory to match the capacitance and inductance in the LC circuit. Then the current SWR
is detected. If the SWR is not higher than 1.5:1, the tuning is comp eted and the fo owing step d
is executed, otherwise step c is executed.
c. Start a comp ete tuning cyc e. LC circuit in the mAT-10 wi be se ected/ adjusted for
optimum SWR.
d. When tuning is comp ete, transmission wi cease, and you wi be ready for operation.
The tuner stores the configuration data in the memory corresponding to the current frequency.
The data in the memory can sti be stored effective y after shutdown unti overwritten by data the
next time the tuner is used on the same frequency.
TUNING PROCESS, OTHER TRANSCEIVERS
For other transceivers, the tuning steps are different, requiring the user to comp ete the process
manua y as fo ows:
a. Set the transceiver to the FM, FSK or RTTY mode, in order to make the transceiver output
a stab e carrier signa .
b. Reduce power output to 5 watts or ess.
c. Press and ho d the PTT key of the transceiver, then press and ho d the mu ti-function
button of the tuner unti the "Tuning" indicator ights up. Re ease the mu ti-function button.
Continue to ho d down the PTT of the transceiver unti the tuning indicator of the tuner goes out
and the tuning process ends.
d. Restore mode and power eve of the transceiver to desired settings. The tuning process is
over, The front pane 's three ights are used to disp ay the current SWR.
OPERATION NOTE
During the tuning process of the mAT-10 tuner, high SWR can be detected by the transmitter.
There are a few transmitters that stop transmitting when SWR is high and cause the tuner to be
unab e to tune due to zero power output.
BATTERIES AND TUNING
Two 10440 ithium batteries insta ed inside mAT-10 provide power for the tuner. Tuner can
on y be charged with inc uded 8.4 vD charger. The mAT-10 uses itt e power whi e tuning, and
essentia y zero power when in standby. If batteries need to be rep aced, p ease use the same type
of batteries.
The indicator on the charger shows the charging process. The ye ow ight indicates charging is
in progress, and the green indicator indicates charging is comp eted.
Before the first use or after the battery is rep aced, the tuner must be charged by the charger to
activate the interna protection circuit before it can be used norma y.
TRANSPORT
Because there are two ithium batteries insta ed inside the tuner, P ease comp y with oca
aws when transporting.
4 / 5

Instruction Manual
TECHNICAL SUPPORT
Visit the Support Center at: http://www.mat-tuner.com/en
PRODUCT EEDBACK
We encourage product feedback! Te us what you rea y think of your MAT-TUNER product.
In an emai te us how you used the product and how we it worked in your app ication.
We ike to share your comments with our staff, our dea ers, and even other customers at the MAT-
TUNER website.
We come to http://www.mat-tuner.com/en/ for more information
We come to http://www.mat-e ectronics.com/en/ for more information
MAT-TUNER
BG3MZU 2019.07.15
