Maytag MTW6600TB1 User manual

TOP AND CABINET PARTS
1
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
1−08 Printed In U.S.A. (drd) Part No. W10172452 Rev. A
AUTOMATIC WASHER

TOP AND CABINET PARTS
2
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10092685 Use & Care Guide
W10092700 Tech Sheet
W10092751 Quick Start Guide
8577781 Wiring Diagram
W10092763 Energy Guide
2 Top
8565314 White
W10053420 Black
3
W10162416 Frame Assembly,
Cabinet Top
(Includes
Items 31 & 38)
4 8576784 Sound Absorber,
Cabinet
5 Cabinet
8566156 White
W10050330 Black
6 8566090 Panel, Rear
7
W10160572 Retainer, Drain
Hose Storage
8
W10167599 Bushing,
Suspension (Set of
4−Includes Item 9)
9
W10111536 Ball, Suspension
(Set of 4 −
Includes Item 8)
10 8566146 Damper Assembly,
Tub Suspension
(Set Of 4−Includes
Items 8,9,48 & 49)
11 1157158 Screw, 8−18 x 3/8
12
W10042120 Locator, Top (2)
13
W10078270 Screw, Lid
Hinge Mounting (4)
14 Hinge Wire (2)
8563965 (L.H.)
8572974 (R.H.)
15 Hinge, Spring
Assembly
(Glass Lid)
8563962 (Left)
8563963 (Right)
16 8565184 Absorber, Sound
(Bottom)
17
W10052730 Bearing, Lid
Hinge (2)
18 3390647 Screw, 8−18 x 1/2
19 Lid, Glass
Assembly
W10131142 White
W10131143 Black
20 8578826 Foot Assembly,
Leveling (4)
21
W10059150 Dispenser,
Fabric Softener
22 Bezel, Fabric
Softener Dispenser
8566210 White
8580017 Elephant
23
W10161865 Dispenser, Stain
Remover
24 Bezel, Stain
Remover Dispenser
8566211 White
8580019 Elephant
25 Dispenser,
Detergent
8564976 White
W10059180 Elephant
26 Bezel, Detergent
Dispenser
8564979 White
W10045210 Elephant
27
W10106990 Nozzle Assembly,
Fresh Water
28 371503 Clamp, Hose
29
W10059230 Lock Assembly, Lid
30 Bezel, Lid Lock
8572019 White
W10052520 Black
31 8564458 Absorber, Impact
32 8564456 Hinge, Top (2)
33 18849 Pad, Top Hinge (2)
34 343641 Screw,
10−16 x 1/2 (2)
35 8563941 Cover, Harness
36 693995 Screw, 8−18 x 3/8
37 8543784 Bracket,
Drain Hose
38 8578386 Shield, Wire
Harness
39 8281136 Screw, 10−16 x 3/4
40 8576476 Spacer, Rear
(Cabinet/Top)
41 370451 Clamp, Hose
42 371503 Clamp, Hose
43 3400061 Screw,
10−16 x 9/16
44 90016 Clip, Harness (5)
45 8281736 Wire,
Ground Jumper
46 3400076 Screw, 10−32 x 5/8
47 8563785 Lock, Top−
Front (2)
48 8577896 Washer, Suspension
Umbrella (4)
49 8564017 Cup,
Suspension (4)

CONTROL PANEL PARTS
3
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452

CONTROL PANEL PARTS
4
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452
Illus. Part
No. No. DESCRIPTION
1 W10155109 Control Unit
Assembly,
Machine & Motor
2
W10130502 Gasket, Valve Tray
3 Tray Assembly,
Console (Includes
Items 2 & 4)
8565304 White
8565305 Black
4 8565259 Gasket,
Console/Tray
5
W10128457 Valve, Log
Assembly
6
W10110196 Knob, Control
7
W10051092 User Interface
8
W10004990 Screw, 6−20 x 1.2
9 Console
W10090708 White
W10090709 Black
10 8564265 Cover, Rear−
User Interface
11
W10003770 Screw,
6−19 x 1/2 (3)
12
W10022060 Nut, Push−In (3)
13
W10128687 Harness, Upper
(Includes Item 21)
14 8565324 Screw,
10−16 x 1.75
15 8281136 Screw, 8−18 x 3/4
16 3407203 Cord Assembly,
Power
17 98460 Nut, Push−In (2)
18 3976300 Washer, Water
Inlet Hose
(1−1/16 x 5/8)(4)
19 Hose, Water Inlet
8571377 Blue Coupler
8571378 Red Coupler
20 3351614 Screw, Power
Cord Ground
21 3407187 Harness,
Thermistor

5
MOTOR, BASKET AND TUB PARTS
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452

MOTOR, BASKET AND TUB PARTS
6
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452
Illus. Part
No. No. DESCRIPTION
1 W10106600 Cap, Impeller
2
W10076270 Screw & Washer
Assembly
3
W10076260 Washer
4
W10130807 Tub Ring
5 8572540 Hose Pressure
Switch
6
W10141017 Impeller
(Washplate)
7 8533953 Screw,
8−16 x 1.000 (6)
8
W10118114 Hub, Basket−Driven
(Includes Item 9)
9 8545953 Hub, Basket−Driver
(Includes Item 8)
10
W10118182 Basket Assembly
(Includes Items
7, 8, & 9)
11
W10128830 Tub & Drive Shaft
Assembly
12
W10137697 Harness, Lower
(Includes Item 5)
13
W10005430 Clamp, Pressure
Hose Retainer
14 8533957 Screw, 10−16 x 1/2
15
W10137698 Shield,
Drive Motor
(Includes Item 16)
16 8565172 Tube, Buffer
(Set Of 4)
17 8565170 Stator, Motor
(Includes Item 18)
18 8557836 Plate, Stator
(Set Of 2)
19 8534042 Screw,
1/4−20 x .968 (4)
20
W10137685 RPS Assembly
21 8565177 Rotor, Main Drive
Motor (Includes
Item 22)
22 Bolt, Rotor
Assembly
Non−Serviceable
(Supplied W/Rotor)
23 8533928 Screw,
8−18 x 3/4 (2)
24 8566197 Filter, Dual
Pump Hood

PUMP PARTS
7
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452
Illus. Part
No. No. DESCRIPTION
1 W10049390 Pump Assembly,
Drain
2
W10128765 Hose, Drain
3 8543774 Hose, Recirc
4
W10049400 Pump Assembly,
Recirc
5
W10004910 Screw,
12−16 x 1.125
6 370449 Clamp, Hose
7 8269146 Clamp, Hose
8 8317496 Clamp, Hose
9 8182771 Grommet, Pump
Mounting (4)
10 8534021 Clamp, Recirc
Hose Retainer
11 8533943 Screw, 10−16 x 3/4
12 8182768 Clamp,
Drain Pump Hose
13 8576642 Retainer,
Drain Hose
14 3347868 Cable Tie
15 8182769 Hose, Recirc Pump
16 8182770 Clamp,
Recirc Pump Hose
17 8182767 Hose, Drain Pump

OPTIONAL PARTS (NOT INCLUDED)
8
For Models: MTW6600TQ1, MTW6600TB1
(White) (Black)
W10172452
Illus. Part
No. No. DESCRIPTION
PAINT, TOUCH−UP (1/2oz.)
72017 White
72032 Black
PAINT, PRESSURIZED SPRAY
(12 oz.)
350938 Primer, Gray
350930 White
285006 Black
PAINT, BULK (1 qt.)
799344 White (Uncut)
786032 Black (Uncut)
WATER SYSTEM PARTS
285442 Connector Kit,
Plastic Drain
Hose
285321 Sleeve Kit,
(Contains 2
Sleeves)
285320 Siphon Break Kit
367031 Drain Protector
SEALER
285195 Sealer, Gasket
(.20 Fl. Oz.) (6 ml)
COUPLING
384496 Coupling, Hose
