Maytag w10631155a User manual

W10631155A
W10631156A-SP
WASHER INSTALLATION
INSTRUCTIONS
Table of Contents
WASHER SAFETY.........................................................1
INSTALLATION REQUIREMENTS................................2
Tools and Parts................................................................2
Location Requirements ..................................................3
Drain System ...................................................................4
Electrical Requirements .................................................5
INSTALLATION INSTRUCTIONS..................................5
Connect Drain Hose........................................................6
Connect Inlet Hoses........................................................7
Level Washer ...................................................................8
Complete Installation Checklist.....................................9
WASHER SAFETY
INSTALLATION NOTES
Date of purchase:_________________________________
Date of installation: _______________________________
Installer: ________________________________________
Model number: ___________________________________
Serial number: ___________________________________
NOTES SUR L’INSTALLATION
Date d’achat :____________________________________
Date d’installation : _______________________________
Installateur : _____________________________________
Numéro de modèle :_______________________________
Numéro de série :_________________________________
Table des matières
SÉCURITÉ DE LA LAVEUSE ......................................10
EXIGENCES D’INSTALLATION ..................................11
Outillage et pièces ........................................................10
Exigences d’emplacement ...........................................12
Système de vidange......................................................14
Spécications électriques............................................14
INSTRUCTIONS D’INSTALLATION............................15
Raccordement du tuyau de vidange............................16
Raccordement des tuyaux d’arrivée d’eau.................17
Établissement de l’aplomb de la laveuse....................19
Liste de vérication pour l’achèvement
de l’installation ..............................................................20
INSTRUCTIONS
D’INSTALLATION
DE LA LAVEUSE
Para obtener acceso al instrucciones de instalación en español, o para obtener información adicional acerca
de su producto, visite: www.whirlpool.com

2
Alternate parts: (Not supplied with washer)
Your installation may require additional parts. To order, please
refer to toll-free numbers on the back page of your “Use and
Care Guide”.
If you have: You will need:
Overhead sewer Standard 20 gal. (76 L) 39" (990 mm)
tall drain tub or utility sink, sump
pump and connectors (available from
local plumbing suppliers)
1" (25 mm) standpipe 2" (51 mm) diameter to 1" (25 mm)
diameter Standpipe Adapter
Part Number 3363920
Connector Kit Part Number 285835
Drain hose too short Extension Drain Hose Part
Number 285863
Connector Kit Part Number 285835
Lint clogged drain Drain Protector Part Number 367031
Connector Kit Part Number 285835
Floor drain system Siphon Break Kit Part Number 285834
Connector Kit (x2) Part Number 285835
Extension Drain Hose Part
Number 285863
Alternate Inlet Hoses: (may be required for some
installations, not supplied with washer)
n 8212656RP 10 ft. (3.0 m) Inlet hose, Black EPDM (2 pack)
n 8212641RP 5 ft. (1.5 m) Inlet hose, Black EPDM (2 pack)
n 8212546RP 4 ft. (1.2 m) Inlet hose, Black EPDM (2 pack)
n 8212545RP 5 ft. (1.5 m) Inlet hose, Red and Blue EPDM
(2 pack)
n 8212487RP 5 ft. (1.5 m) Nylon braided inlet hose (2 pack)
n 8212638RP 6 ft. (1.8 m) Nylon braided inlet hose, space
saving 90° elbow, hypro-blue steel couplings
(2 pack)
n 8212637RP 6 ft. (1.8 m) Inlet hose, Black EPDM, space
saving 90° elbow, hypro-blue steel couplings
(2 pack)
Optional tools:
Parts supplied:
NOTE: All parts supplied for installation are in the washer
basket.
4" min
(102 mm)
Wood block
Adjustable or open end
wrenches 1/2" (13 mm)
and 9/16" (14 mm)
Ruler or measuring tape
Level
Pliers that open to
19⁄16" (39.5 mm)
Flashlight Bucket
Cable tie
Drain hose with clamp
and form (may be shipped
unassembled)
Tools needed:
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather required tools and parts before starting installation.
Transport bolt hole
plugs (4)
Available Accessories:
An optional matching pedestal is available for your washer.
Please contact your retailer for ordering information, or see
the “Assistance or Service” page on the back of your “Use and
Care Guide”.
Parts needed: (Not supplied with washer)
Water inlet hoses (2) Flat inlet hose washers (4)

3
LOCATION REQUIREMENTS
Proper installation is your responsibility.
You will need:
n A water heater set to 120° F (49° C).
n A grounded electrical outlet located within 6 ft (1.8 m) of
power cord on back of washer.
n Hot and cold water faucets located within 4 ft (1.2 m) of hot
and cold water ll valves on washer, and water pressure of
20-100 psi (137.9-689.6 kPa).
n A level oor with maximum slope of 1" (25 mm) under entire
washer. Installing on carpet or surfaces with foam backing is
not recommended.
n Floor must support washer’s total weight (with water and load)
of 315 lbs (143 kgs).
IMPORTANT: Do not install, store or operate washer where it will
be exposed to weather or in temperatures below 32° F (0° C).
Water remaining in washer after use may cause damage in low
temperatures. See “Washer Care” in your “Use and Care Guide”
for winterizing information.
Whirlpool Models*
383/4" - 393/4"
(948 mm - 1010 mm)
27"
(686 mm)
335/16"
(846 mm)
523/4"
(1340 mm)
Maytag Models
383/4" - 393/4"
(948 mm - 1010 mm)
27"
(686 mm)
523/4"
(1340 mm) 331/8"
(841 mm)
383/4" - 393/4"
(948 mm - 1010 mm)
27"
(686 mm)
3215/16"
(837 mm)
5215/16"
(1345 mm)
All dimensions show recommended spacing allowed, except for
closet door ventilation openings which are the minimum required.
For each arrangement, consider allowing more space for ease of
installation and servicing, and spacing for companion appliances
and clearances for walls, doors, and oor moldings.
Space must be large enough to allow door to fully open.
Add spacing of 1" (25 mm) on all sides of washer to reduce
noise transfer. If a closet door or louvered door is installed, top
and bottom air openings in door are required.
761/2"
(1943 mm)
5"
(127 mm)
6"
(152 mm)
1"
(25 mm)
24 in.2
(155 cm2)
48 in.2
(310 cm2)
3"
(76 mm)
6"
(152 mm)
3"
(76 mm)
Recessed area or closet installation
(stacked washer and dryer):
Custom under counter installation:
* For additional details (or information) specic to your model,
refer to the Dimension Guide at www.whirlpool.com.
* Add spacing of 1" (25 mm) on all sides of washer/dryer.
*

4
4"
(102 mm)
1"
(25 mm)
7"
(178 mm)
14"
(356 mm)
Custom cabinet installation:Recessed area or closet installation (washer only):
1"
(25 mm)
24 in.2
(155 cm2)
48 in.2
(310 cm2)
3"
(76 mm)
3"
(76 mm)
4"
(102 mm)
Floor drain system requires a Siphon Break Kit (Part Number
285834), 2 Connector Kits (Part Number 285835), and an
Extension Drain Hose (Part Number 285863) that may be
purchased separately. See “Alternate Parts”. Minimum siphon
break height: 28" (710 mm) from bottom of washer. (Additional
hoses may be needed.)
Minimum diameter for a standpipe drain: 2" (51 mm). Minimum
carry-away capacity: 17 gal. (64 L) per minute. A 1/4" (6 mm)
diameter to 1" (25 mm) diameter Standpipe Adapter Kit is
available (Part Number 3363920). Top of standpipe must be at
least 30" (762 mm) high; install no higher than 96" (2.44 m) from
bottom of washer. If you have an overhead sewer and need to
pump higher than 96" (2.44 m), a sump pump and associated
hardware are needed. See “Alternate Parts”.
Wall standpipe drain system
Laundry tub drain system
Minimum capacity: 20 gal. (76 L). Top of laundry tub must
be at least 30" (762 mm) above oor; install no higher than
96" (2.44 m) from bottom of washer.
4.5"
(114 mm)
Floor standpipe drain system
4.5"
(114 mm)
See requirements for oor standpipe drain system.
30"
(762 mm)
min.
4.5"
(114 mm)
Floor drain system
DRAIN SYSTEM
Drain system can be installed using a oor drain, wall standpipe,
oor standpipe, or laundry tub. Select method you need.
IMPORTANT: To avoid siphoning, only 4.5" (114 mm) of drain
hose should be inside standpipe. Always secure drain hose with
cable tie.
* Add spacing of 1" (25 mm) on all sides of washer. ** Recommended 4" (102 mm), minimum 1.5" (38 mm)
**
** **

5
INSTALLATION INSTRUCTIONS
NOTE: To avoid oor damage, set washer onto cardboard
before moving it.
48"
(1.2 m)
1. Move washer
It is necessary to remove all shipping materials for proper
operation and to avoid excessive noise from washer.
Move washer to within 4 ft (1.2 m) of its nal location. It must
be in a fully upright position.
ELECTRICAL REQUIREMENTS
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
WARNING
n A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical
supply is required. A time-delay fuse or circuit breaker is
recommended. It is recommended that a separate circuit
breaker serving only this appliance be provided.
nThis washer is equipped with a power supply cord having
a 3 prong grounding plug.
nTo minimize possible shock hazard, the cord must be plugged
into a mating, 3 prong, grounding-type outlet, grounded in
accordance with local codes and ordinances. If a mating outlet
is not available, it is the personal responsibility and obligation
of the customer to have the properly grounded outlet installed
by a qualied electrician.
nIf codes permit and a separate ground wire is used, it is
recommended that a qualied electrician determine that
the ground path is adequate.
n Do not ground to a gas pipe.
n Check with a qualied electrician if you are not sure the
washer is properly grounded.
nDo not have a fuse in the neutral or ground circuit.
2. Locate transport bolts
Locate four transport bolts on rear of washer.

6
Loosen bolts with a 1/2" (13 mm) wrench. Slide each bolt and
spacer to center of hole. Pull bolts and plastic spacers from
back of washer. Discard bolts and spacers.
3. Remove transport bolts from
washer
Close bolt holes on cabinet back with four transport bolt hole
plugs included with washer parts.
4. Cover bolt holes with transport
bolt hole plugs
Pull power cord through opening in rear panel and close hole
with attached cap.
NOTE: If washer is transported at later date, call your local
service center to avoid suspension and structural damage,
a certied technician must properly set up washer for
relocation.
5. Remove power cord
CONNECT DRAIN HOSE
6. Place power cord over top
Remove the yellow shipping strap from the cord. Gently
place power cord over top of washer to allow free access
to back of washer.
IMPORTANT: Do not plug washer in until installation has
been completed.
If clamp is not already in place on elbow end of drain hose,
squeeze clamp with pliers and slide it over end of hose,
centering it between the ribs, as shown. Squeeze clamp with
pliers and slide elbow end of drain hose onto drain port and
secure with clamp.
For a laundry tub or standpipe drain, go to step 9.
For a oor drain, remove the preinstalled drain hose form
as shown in Step 8. You may need additional parts with
separate directions. See “Alternate Parts”.
7. Attach drain hose to drain port
Ribs

7
Run water for a few seconds through hoses into a laundry
tub, drainpipe, or bucket to avoid clogs. Water should run
until clear.
12. Clear water lines
11. Connect inlet hoses to water
faucets
For oor drain installations, you will need to remove the drain
hose form from the end of the drain hose. You may need
additional parts with separate directions. See “Alternate Parts”.
8. Remove drain hose form
(oor drain installations only)
Place hose into standpipe (shown in picture) or over side of
laundry tub.
IMPORTANT: Only 4.5" (114 mm) of drain hose should be
inside standpipe; do not force excess hose into standpipe or
lay on bottom of laundry tub. Drain hose form must be used.
9. Place drain hose in standpipe
4.5"
(114 mm)
Drain
hose form
CONNECT INLET HOSES
IMPORTANT: To avoid leaks, check that your water inlet
hoses have at washers at both ends. Washer must be
connected to water faucets with new inlet hoses with at
washers (not provided). Do not use old hoses. Do not use
hoses without washers.
Attach the hose labeled hot to hot water faucet. Screw
on coupling by hand until it is seated on washer. Use pliers
to tighten couplings an additional two-thirds turn. Repeat
this step with the hose labeled cold for the cold water faucet.
Both hoses must be connected for washer to work properly.
IMPORTANT: Do not overtighten or use tape or sealants on
valve when attaching to faucets or washer. Damage can result.
HELPFUL TIP: Make note of which hose is connected to hot
water to help in attaching hoses to washer correctly. In most
standard congurations, hoses will cross over each other
when attached correctly.
Insert new at washers
10.
A. Coupling B. Washer

8
LEVEL WASHER
Leveling your washer properly reduces excess noise
and vibration.
Remove cardboard from beneath washer. Place a level on top
edges of washer, checking each side and front. If not level, tip
washer and adjust feet up or down as shown in steps 18 and
19, repeating as necessary.
16. Check levelness of washer
Place level here
17. Rock washer to test foot contact
Grip washer from top and rock back and forth, making sure all
four feet are rmly on oor. Repeat, rocking washer from side
to side. If washer rocks, go to step 18 and adjust leveling feet.
If all four feet are in rm contact with oor, go to Step 19.
13. Connect inlet hoses to washer
Not Level LEVEL Not Level
Attach hot water hose to hot water inlet valve. Screw coupling
by hand until it is snug. Use pliers to tighten couplings an
additional two-thirds turn. Repeat with cold water inlet valve.
IMPORTANT: Do not overtighten or use tap or sealants on
valve when attaching to faucets or washer. Damage can result.
NOTE: To reduce risk of hose failure, replace the hoses every
5 years. Record hose installation or replacement dates for
future reference.
nPeriodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.
Slowly turn on water faucets to check for leaks. A small
amount of water may enter washer. It will drain later.
14. Check for leaks
Secure drain hose to laundry tub leg, drain standpipe, or inlet
hoses for wall standpipe with cable tie.
15. Secure drain hose
4.5"
(114 mm)
4.5"
(114 mm)
4.5"
(114 mm) 4.5"
(113 mm)
4.5"
(114 mm)
Laundry Tub Standpipe Wall

9
20. Plug into a grounded 3 prong outlet
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
re, or electrical shock.
WARNING
COMPLETE INSTALLATION
CHECKLIST
qCheck electrical requirements. Be sure you have correct
electrical supply and recommended grounding method.
qCheck that all parts are now installed. If there is an extra part,
go back through steps to see what was skipped.
qCheck that you have all of your tools.
qCheck that transport materials were completely
removed from back of washer.
qCheck that both hot and cold hoses are attached and water
faucets are on.
qCheck for leaks around faucets, valves, and inlet hoses.
qRemove protective lm from console and any tape
remaining on washer.
qCheck that washer is plugged into a grounded
3 prong outlet.
qDispose of/recycle all packaging materials.
qRead “Using Your Washer” in your Washer “Use and Care
Guide”.
qTo test and clean your washer, press power and choose the
QUICK WASH cycle and run it without clothes. Use only HE
detergent. Use 1/2 the manufacturer’s recommended amount
for a medium-size load.
If washer is not level, use a 9/16" or 14 mm open-end or
adjustable wrench to turn jam nuts clockwise on feet until they
are about 1/2" (13 mm) from the washer cabinet. Then turn the
leveling foot clockwise to lower the washer or counterclockwise
to raise the washer. Recheck levelness of washer and that all
four feet are rmly in contact with the oor. Repeat as needed.
HELPFUL TIP: You may want to prop up front of washer
about 4" (102 mm) with a wood block or similar object that
will support weight of washer.
When washer is level and all four feet are rmly in contact with
the oor, use a 9/16" or 14 mm open-end or adjustable wrench
to turn jam nuts counterclockwise on leveling feet tightly
against washer cabinet.
HELPFUL TIP: You may want to prop washer with
wooden block.
18. Adjust leveling feet
Jam nut
19. Tighten leveling feet
Jam nut
