Maytag Whirlpool MHN33PR Reference manual

MHN33PR Product Introduction
September 2016

Outline
I.Installation
II.Technical Information/Description
III.Installation (How To)
a.Physical/Mounting
b.Programming (Card and Non-Card)
IV.Usage and Demo
V.Servicing
a.Diagnostics
b.Disassembly
c.Re-assembly
d.Common Issues and Solutions

Feature Definition
•10.5 Kg Capacity
•Advance Spin Technology
•Duracore Drive System
•Intelligent Controls
•With M-series Technology
•Energy-efficient Cleaning
•Clothespin™ App By Maytag
Compatible
•HWD in mm: 961 x 686 x 732

Accessories
For Card System
Operation

Technical Specifications
HWD in mm: 961 x 686 x 732
BREAKER/FUSE MIN. REQUIREMENTS
15A
MOTOR:
Variable
-speed, reversible, thermo-
protected, high
-efficiency,
controlled induction
Yes
EXTRACT SPEED
Maximum RPM
Maximum g
-force
1,000
300
MHN33PR
11kg. Capacity
Energy Advantage ™ High-Efficiency Front-Load Washer

Pre-installation Requirements
•Faucet with thread (3/4)
•Standing Pipe
-30-39 inches in height
- 2 inches in diameter
MHN33PR
11kg. Capacity
Energy Advantage ™ High-Efficiency Front-Load Washer

Installation Procedure
•Using a 1/2" wrench, loosen each of the shipping bolts at the back of
the unit.
•Once all 4 bolts are removed, discard the bolts and spacers.

Installation Reminders
Using a 1/2" wrench, loosen each of the shipping bolts at the back of the unit.
Check the levelness of the washer by placing a
level on the top edge of the washer, first side to
side, then front to back.
After the washer is level, use a 9/16"
open-end wrench to turn the nuts on the
feet tightly against the washer cabinet.

Operational Requirements
Water Pressure:
20-100 psi (137.9-689.6 kPa)
Water Flow Rate:
1L/10sec or 1.5L/15sec
Space Requirements:
To avoid operational noise created by the unit’s vibration, customer must provide enough spacing.
Front and Back** Left and Right

Installation Reminders
Using a 1/2" wrench, loosen each of the shipping bolts at the back of the unit.
Check the levelness of the washer by placing a
level on the top edge of the washer, first side to
side, then front to back.
After the washer is level, use a 9/16"
open-end wrench to turn the nuts on the
feet tightly against the washer cabinet.

Programming Procedure
1. This model is original setup for self-
service laundry that’s why it initially
displays a price of “0.00” on the
screen.
2. Make sure to set it up to free
cycle first before operating it.

Programming Procedure
There are 2 ways to enter the
Setup Mode
1
1. Press the upper left key pad.
2. Press the lower right key pad.
3. Press the upper right key pad.
4. Press the lower left key pad

Programming Procedure
There are 2 ways to enter the
Setup Mode
Press or toggle the reset switch
(whichever is installed) at the back
of the unit.
2

Programming Procedure
This product has TWO operational
modes:
1
FREE CYCLE: No money is
needed to operate the machine
HWD in mm: 961 x 686 x 732

Programming Procedure
HWD in mm: 961 x 686 x 732
This product has TWO operational
modes:
DEBIT CARD: A card reader will
be attached to the unit,
customer will need a debit card
to start using the machine
2

Programming Procedure
HWD in mm: 961 x 686 x 732
DEBIT CARD: A card reader will
be attached to the unit,
customer will need a debit card
to start using the machine

Free Cycle Setup
No money is needed to operate the machine, can be used in a typical
Laundry Shop Setup

Free Cycle Setup
After entering the setup
mode, “6 07” will appear on
the screen
1
Set-up Code:
Represents the different parameters needed to
setup the washing machine

Free Cycle Setup
After entering the setup
mode, “6 07” will appear on
the screen
1
Set-up Code:
Represents the different parameters needed to
setup the washing machine

Free Cycle Setup
After entering the setup
mode, “6 07” will appear on
the screen
1
Set-up Code Value:
This can vary between 0 –99 depending on the
parameter that needs to be adjusted.
