M 18 Digital Mixer User’s Manual
1
M 18 Digital Mixer - User’s Manual
Date:
10
mag
2016
Rev.: 1.1.020
p/n: 10399006 rev. C
This document refers to:
-Firmware version 203
-iOS MixRemote app version 1.1.0 (build 105)
This manual also applies to firmware 182 and app ver. 1.0.2, with side notes to highlight the differences and/or limitations.

RCF spa
M 18 Digital Mixer User’s Manual
2
What’s new in firmware 203 / app ver. 1.1.0
M18 firmware release history:
version 182 (released 2016-01-14)
version 203 (released 2016-04-20)
Version 203 adds the following features:
REC page; this feature was not enabled in firmware 182
Redesigned and improved PREAMP graphics
PFL indication on MAIN VU meters
Improved VU Meter calibration
Audio Player has louder output level
plus a series of bug fixes.
We recommend to deploy the latest MixRemote app version that matches the installed firmware.
MixRemote ver. 1.1.0 (build 105) is compatible with both released firmware versions.
RCF S.p.A. accepts no liability for any loss which may be suffered by any person who relies either wholly or in part upon
any description, photograph, or statement contained herein. Technical specifications, appearances, and other
information are subject to change without notice. All trademarks are the property of their respective owners.
Summary
The M series Digital Mixers by RCF............................................................................................................... 4
M 18 features .............................................................................................................................................. 6
Overview ................................................................................................................................................. 6
Internal Reverb........................................................................................................................................ 8
MultiFX.................................................................................................................................................... 9
Master Processor....................................................................................................................................10
VALVE WARMER .................................................................................................................................10
XCITER ................................................................................................................................................10
MAXIMIZER.........................................................................................................................................10
Storing and recalling parameters ............................................................................................................11
MixRemote iOS app ....................................................................................................................................13
FADERS > INPUTS view............................................................................................................................14

RCF spa
M 18 Digital Mixer User’s Manual
3
Input channels: preamplifier, dynamics, MultiFX.....................................................................................15
Input channels: EQ section......................................................................................................................23
FADERS > SEND view...............................................................................................................................24
EFFECTS view ..........................................................................................................................................25
EFFECTS > SEND ..................................................................................................................................25
EFFECTS > MULTIFX.............................................................................................................................26
OUTPUTS view........................................................................................................................................27
PHONES view..........................................................................................................................................28
PLAY/REC view........................................................................................................................................29
PLAY....................................................................................................................................................29
REC .....................................................................................................................................................30
METERS view ..........................................................................................................................................33
LOAD/SAVE view.....................................................................................................................................34
SETTINGS view........................................................................................................................................35
Hardware Description.................................................................................................................................39
Connectors .............................................................................................................................................39
Startup sequence and recovery from an error condition .........................................................................41
Restoring the unit with firmware ver. 182...............................................................................................42
Restoring the unit with firmware ver. 203...............................................................................................43
M 18 Usage.................................................................................................................................................43
Secrets of mixing on a digital console......................................................................................................44
Sound Shaping with M 18 .......................................................................................................................45
DRUMS ...............................................................................................................................................46
BASS ...................................................................................................................................................48
KEYBOARDS.........................................................................................................................................48
ELECTRIC GUITARS ..............................................................................................................................49
ACOUSTIC GUITARS.............................................................................................................................49
VOICE..................................................................................................................................................50
A1 - Block Diagram......................................................................................................................................51
A2 – MIDI implementation chart.................................................................................................................53

RCF spa
M 18 Digital Mixer User’s Manual
4
The M series Digital Mixers by RCF
A new family of compact Digital Mixers have been designed by RCF, with the aim to address the
requirements of modern performing musicians.
The main goal is to allow the user to minimize the amount of equipment needed for a live act. Therefore, a
significant effort has been spent to include all the main features to ensure a seamless performance. These
features are the following:
-compact size: the mixer is small and can be placed anywhere within the stage or between the
instruments
-full remote control over WiFi of all features
-integration of high-quality amplifier modeling
-internal WiFi Access Point and Power Supply
The M series of Digital Mixers are ideal in all cases where a dedicated sound engineer may not be available,
and therefore a FOH mixer would be inappropriate. The musicians themselves can perform the sound check
by moving in from of the house PA with a tablet and setting up the mixer accordingly.
Two independent amplifier simulation algorithms, licensed from Overloud ™, have been included into a
multieffect-like organization of internal effects. This enables a further option to avoid bringing on the stage
bulky and large amplifiers, relying on the main PA and stage monitors.
A high-quality stereo player is available on the unit, accessing files from a USB flash drive, representing a
further option in minimizing the amount of equipment required for a live gig.
Therefore, you can leave home several items, such as the multicore snake, external effects that would
normally connect to the mixer, guitar and/or bass amplifiers, external file player, and yet obtain a high-
quality and professional result.

RCF spa
M 18 Digital Mixer User’s Manual
5
This document is available to help you in exploring the various features of the M 18 Digital Mixer, and is
arranged in different sections:
M 18 Features
An overview of the most interesting features of the M 18 Digital Mixer is presented,
focusing on the unique aspects of the unit. It includes details on the internal high-quality
digital reverb, on the MultiFX concept, on the Master Processor, and on the options to
save and recall internal parameters.
MixRemote iOS app
Detailed reference of the MixRemote app for iOS, which is the primary way to interact with
the mixer itself. All app views and controls are presented in detail.
Hardware Description
Overview of the connections available on rear panel.
Detailed indications on the startup sequence and recovery options.
M 18 Usage
Useful tips on how to make the best use of the M Series Digital Mixer.
This section includes advices on the gain structure concept, and several practical hints on
equalization and compression settings for specific instrument types.
Appendixes
A1 – Block Diagram
A2 – MIDI implementation

RCF spa
M 18 Digital Mixer User’s Manual
6
M 18 features
