Meraki MX68CW User manual

Meraki MX68CW Installation Guide
This document describes how to install and set up the MX68CW security appliance. Additional reference
documents are available online at: www.meraki.com/library/products.
MX68CW Overview
The Meraki MX68CW (model: MX68CW-HW-NA & MX68CW-HW-WW) is an enterprise security appliance
designed for distributed deployments that require remote administration. It is ideal for network
administrators who demand both ease of deployment and a state-of-the-art feature set. This appliance
provides the following new features:
2.4-Ghz (2 spatial streams) and 5-GHz (2 spatial streams) radios for 802.11abgn/ac support.
USB port, to support approved 3G/4G cards for failover to cellular networks.
Support for 10 LAN connections (2 of 10 offer 802.3at support)
Wall screws and anchors for mounting drywall surface, either vertically or horizontally
MX68CW Operational Temperature: 32 o F to 104 o F (0 o C to 40 o C)
Package Contents
In addition to the MX68CW, the following are provided.
SIM Slot Pin

The MX68CW Ports and Connections
USB, Ethernet (LAN/WAN), SIM, K-Lock, Power, Antennas
The MX68CW front panel
Ports and Status Indicators
The MX68CW uses a single LED to inform the user of the device's status.
Function
LED Status
Meaning
Power Up/Boot
Solid Orange
Power is applied

Connecting
Rainbow
Device in process of connecting to the Meraki Dashboard
Connected
Solid White
Fully operational
Upgrading
Flashing
White
During boot or no WAN link
LTE Enabled
Purple
LTE is on and connected
The MX68CW back panel
Additional functions on the back panel are described below, from left to right.
LAN ports
Ten (Ports 3 through 12) provide connectivity to computers, printers, access points, or
Ethernet switches. Two of these ten (Ports 11 and 12) also provide PoE+ (802.3at) support.
Two LEDs -- one for activity, another for connectivity. A steady green LED indicates
bidirectional connectivity while a flashing green LED indicates traffic.
Internet ports
Two ports provide connectivity to the WAN.
Power input
Designed for use only with the unit’s power supply.
Antenna ports
Two RP-SMA ports for dipole antennas (two antennas included)
The MX68CW side panel
Restore button
Insert a paper clip if a reset is required.
A brief, momentary press: To delete a downloaded configuration and reboot.
Press and hold for more than 10 sec: To force the unit into a full factory reset.
Kensington
Security Slot
The slot is a portion of the Kensington lock system and is compatible with any Kensington
cable.

USB port
USB 2.0 for 3G/4G wireless cards.
The MX68CW bottom panel
Please note that the serial number is located on the product label, which is located on the bottom of the
MX68CW. The blank region in the center of the label will be populated with regulatory marks on
commercial units.
Mounting hardware
The supplied wall screws and anchors allow you to mount the appliance on a drywall surface, either
vertically or horizontally. The distance between the holes you drill should be 165 mm.
For mounting on drywall, use a ¼ -in drill bit, then insert the plastic and screw assemblies.
For mounting on wood or a similar surface, use only the screws.
Allow the heads of the screws to stick out far enough to be inserted securely into the back of the
appliance.
This equipment is only suitable for mounting at heights ≤ 2 m
Warning: This equipment may not work when mains power fails.
Connecting to the WAN

All Meraki MX devices must have an IP address. This section describes how to configure your local area
network before you deploy it. A local management web service, running on the appliance, is accessed
through a browser running on a client PC. This web service is used for configuring and monitoring basic
ISP/WAN connectivity.
Setting up a static IP address
To ensure that the client PC is redirected to the local web service in the following step, you must disable
all other network services (e.g., Wi-Fi) on your client machine.
Do the following to configure basic connectivity and other networking parameters:
1. Using a client machine such as a laptop, connect to one of the ten LAN ports of the MX.
2. Using a browser on the client machine, access the appliance's built-in web service by browsing
to http://setup.meraki.com. (You do not have to be connected to the Internet to reach this address)
3. Click Uplink configuration under the Local status tab.
4. Choose Static for the IP Assignment option.
5. Enter the IP address, subnet mask, default gateway IP and DNS server information.
Setting up a DHCP IP address
By default all MX devices are configured to DHCP from upstream WAN / ISP servers. Simply plug one of
the MX's WAN / Internet ports into your upstream circuit and wait a few minutes for the unit to negotiate
a DHCP address.
Icon
When the WAN connection is fully enabled, the Internet 1 or 2 LED 1 will turn green.
Additional settings
Please note that all these settings below are accessible only via the local management console.
Setting VLANs
If your WAN uplink is on a trunk port, choose VLAN tagging > Use VLAN tagging and enter the
appropriate value for VLAN ID for your network.
Setting PPPoE
PPPoE authentication may be required if you are connecting the MX to a DSL circuit. You need to know
your authentication option and credentials (supplied by your ISP) in order to complete these steps.
Choose Connection Type > PPPoE.
Select your Authentication option.
If you select Use authentication, enter appropriate values for Username and Password.

Web proxy settings
These settings take effect if the MX device has to fall back to using HTTP to contact the Cloud Controller.
By default, web proxy is disabled. To enable web proxy, do the following:
Choose Web proxy > Yes.
Enter values as appropriate for Hostname or IP and Port.
If you require authentication, choose Authentication > Use authentication, and enter appropriate
values for Username and Password.
To apply all configuration settings to the appliance, be sure to click Save Settings at the bottom of the
page.
Configuring physical link settings
To configure physical link settings on the Ethernet ports, click Local status > Ethernet configuration.
You can enable half duplex, full duplex, and auto-negotiation, as well as set 10- or 100-Mbps data rates.
