Metalfire ULTIME C WHE 1S Owner's manual

ULTC_WHE_EN_05 1
ULTIME C WHE 1S
Ultime C MF 600-75 WHE 1S
Ultime C MF 800-50 WHE 1S
Ultime C MF 800-75 WHE 1S
Ultime C MF 1050-50 WHE 1S
Ultime C MF 1050-75 WHE 1S
Ultime C MF 1300-50 WHE 1S
Installation and operation instructions

ULTC_WHE_EN_05 2

ULTC_WHE_EN_05 3
1. Table of contents
1. Table of contents................................................................................................................................. 3
2. Introduction.......................................................................................................................................... 5
3. Safety................................................................................................................................................... 6
3.1 CE certification mark ............................................................................................................... 6
3.2 Safety instructions during installation..................................................................................... 6
3.3 Safety instructions for user ..................................................................................................... 6
3.4 Safety facilities......................................................................................................................... 6
4.Technical specifications........................................................................................................................ 7
5. General installation instructions ........................................................................................................ 10
5.1 Standards and rules............................................................................................................... 10
5.2 Transport ............................................................................................................................... 10
5.3 Remarks and tips with regard to the installation.................................................................. 11
5.4 Installation of the cast iron.................................................................................................... 14
5.5 Insulation............................................................................................................................... 18
5.6 Flue gas duct.......................................................................................................................... 19
5.7 Flue gas valve......................................................................................................................... 20
5.8 Convection air ......................................................................................................................... 20
5.9 Supply of ambient air ............................................................................................................ 22
5.10 Combustion air ...................................................................................................................... 22
5.11 Distances to keep from combustible items........................................................................... 24
5.12 Commissioning test ............................................................................................................... 25
5.12.1 Fuel ..................................................................................................................................... 26
5.12.2 Lighting the fire for the first time....................................................................................... 26
5.12.3 Checks to be carried out..................................................................................................... 26
6.Using the appliance............................................................................................................................ 26
6.1 Safety..................................................................................................................................... 26
6.2 Operating instructions........................................................................................................... 27
6.2.1 Opening the lifting door ....................................................................................................... 27
6.2.3 Regulating the combustion air ............................................................................................. 29
6.3 Fuel ........................................................................................................................................ 29
6.4 Lighting the fire ..................................................................................................................... 30
6.5 Burning with closed or open lifting door............................................................................... 30
7. Maintenance...................................................................................................................................... 31
7.1 Cleaning the glass.................................................................................................................. 31
7.2 General maintenance ............................................................................................................ 31
8.Guarantee........................................................................................................................................... 32
8.1 Offered guarantee................................................................................................................. 32
8.2 Reservation............................................................................................................................ 32
8.3 Exclusion................................................................................................................................ 32
9.Problem solver .................................................................................................................................... 33
9.1 The glass turns sooted rapidly:.............................................................................................. 33
9.2 The fire does not respond to the air valve. ........................................................................... 33
9.3 Flue gas returns. .................................................................................................................... 33
9.4 Glass of the vertical sliding door is broken. .......................................................................... 33

ULTC_WHE_EN_05 4

ULTC_WHE_EN_05 5
2. Introduction
We thank you for your confidence in the Metalfire fireplace that you have purchased. Our products
guarantee many years of heating comfort.
Read these installation and use instructions carefully before starting the installation.
Afterwards, you hand them to the customer.
We advise you to check the appliance upon delivery for any transport damage.
The Ultime C range consists of following models:
Ultime C MF 600-75 WHE 1S
Ultime C MF 800-50 WHE 1S
Ultime C MF 800-75 WHE 1S
Ultime C MF 1050-50 WHE 1S
Ultime C MF 1050-75 WHE 1S
Ultime C MF 1300-50 WHE 1S
These appliances are closed wood fires which must be connected to one individual flue pipe. Flue
gases are discharged through this flue pipe. The supply of outdoor air for combustion can be
connected directly to the appliance.
It is very important that these wood fireplaces are installed only by
a qualified fitter, according to national and local regulations.
Metalfire NV
Noorwegenstraat 28
9940 Evergem

ULTC_WHE_EN_05 6
3. Safety
3.1 CE certification mark
This appliance has been tested according to EN 13229-2001 and EN 13229-A2:2004 standards.
3.2 Safety instructions during installation
The installation of this wood fireplace may only be carried out by a recognized installer according to
applicable national and/or local standards and building regulations.
Take the necessary precautions using incombustible materials so that items in the immediate vicinity
of the appliance (curtains, floor, walls and so on) are not overheated.
Check that the fireplace is functioning correctly before commencing with the surrounding fireplace
finish. (5.2.2.1. Checking the fireplace)
3.3 Safety instructions for user
These wood fires radiate significant levels of heat. The entire outside of the fireplace becomes
extremely hot (the metalwork, glass in the door, surface and surround).
So, ensure that young children and older people always keep sufficient distance from the fireplace so
that they cannot come into contact with it, and provide a fireplace guard around the fireplace if
necessary.
Never let children operate the fireplace.
Make sure that flammable materials (wooden mantels, curtains, flammable liquids, furniture and so on)
are always separated from the fireplace by at least 0.8 m both above and around it.
Following installation, all visible parts of the fireplace should be considered as active heating surfaces
and therefore should not be touched when the fireplace is in use.
Touching these parts constitutes a risk of burns.
Do not use the appliance if the glass in the door is cracked or broken.
If defective, the glass in the door must be replaced immediately by a competent Metalfire installer.
This fireplace is only intended for additional heating, i.e. not for continuous use.
3.4 Safety facilities
The installer must take all measures required to prevent overheating of adjacent materials. These
measures must comply with national and/or local standards and regulations and the installation must
meet all (national and European) standards. Take the necessary measures by using fireproof and
insulating materials to prevent overheating of flammable materials in the vicinity of the fireplace. See
Table 1 for the minimum insulation thicknesses.
The heat radiation through the fireplace
window can be considerable. Therefore,
a distance of at least 80 cm must be kept
from flammable material.

ULTC_WHE_EN_05 7
4.Technical specifications
Standards EN 13229:2001 and EN 13229 A2:2004
Model
ULTIME C MF 600-75 WHE
1S
ULTIME C MF 800-75 WHE
1S
Fuel
Logs
Logs
Nominal heat output
19.4 kW
23.4 kW
Efficiency (%)
76.2
76.3
Optimum usage range
10 kW –19.5 kW
10 kW –23 kW
Wood consumption rate/hour (max.
15% humidity)
3.5 kg –6 kg
3.5 kg –7 kg
Max. wood consumption limit/hour
Max. 5 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Max. 6 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Flue gas flow (g/s)
17.7
20.3
Flue gas temperature (C°)
298
321
CO at 13% O2 (%)
0.11
0.09
Dust content at 13% O2 (mg/nm³)
44
38
Min. chimney draught (Pa)
12
12
*Min. insulation thickness top (cm)
Only non-flammable material
Only non-flammable material
*Min. insulation thickness sides
(cm)
12
12
*Min. insulation thickness rear (cm)
14
14
*Min. insulation thickness bottom
(cm)
Only non-flammable material
Only non-flammable material
Chimney connection (mm)
Ø250
Ø250
Combustion air connector (mm)
1 x Ø150 (± 1 x 180cm²)
1 x Ø150 (± 1 x 180cm²)
Convection connector inlet (mm)
2 x Ø150 (± 2 x 180cm²)
2 x Ø150 (± 2 x 180cm²)
Convection connector outlet (mm)
4 x Ø150 (± 4 x 180cm²)
4 x Ø150 (± 4 x 180cm²)
Weight incl. cast iron reeded
panels (kg)
366
416
Dimensions (LxWxH) (mm)
800x600x1930
1000x600x1930
* Standard insulation “Pumica K,550: 0.14 W/m.K.

ULTC_WHE_EN_05 8
Model
ULTIME C MF 1050-75 WHE
1S
ULTIME C MF 800-50 WHE
1S
Fuel
Logs
Logs
Nominal heat output
27.5 kW
20.0 kW
Efficiency (%)
76.2
77.2
Optimum usage range
12 kW –27.5 kW
10 kW –20 kW
Wood consumption rate/hour (max.
15% humidity)
4 kg –8 kg
3.5 kg –6 kg
Max. wood consumption limit/hour
Max. 7 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Max. 5 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Flue gas flow (g/s)
22.9
17.6
Flue gas temperature (C°)
321
291
CO at 13% O2 (%)
0.08
0.11
Dust content at 13% O2 (mg/nm³)
33
47
Min. chimney draught (Pa)
12
12
*Min. insulation thickness top (cm)
Only non-flammable material
Only non-flammable material
*Min. insulation thickness sides
(cm)
11
9
*Min. insulation thickness rear (cm)
13
12
*Min. insulation thickness bottom
(cm)
Only non-flammable material
Only non-flammable material
Chimney connection (mm)
Ø300
Ø250
Combustion air connector (mm)
1 x Ø150 (± 1 x 180cm²)
1 x Ø150 (± 1 x 180cm²)
Convection connector inlet (mm)
2 x Ø150 (± 2 x 180cm²)
2 x Ø150 (± 2 x 180cm²)
Convection connector outlet (mm)
4 x Ø150 (± 4 x 180cm²)
4 x Ø150 (± 4 x 180cm²)
Weight incl. cast iron reeded
panels (kg)
484
327
Dimensions (LxWxH) (mm)
1250x600x1930
1000x600x1430
* Standard insulation “Pumica K,550: 0.14 W/m.K.

ULTC_WHE_EN_05 9
Model
ULTIME C MF 1050-50 WHE
1S
ULTIME C MF 1300-50 WHE
1S
Fuel
Logs
Logs
Nominal heat output
21.6 kW
27.0 kW
Efficiency (%)
76.5
77.6
Optimum usage range
10 kW –21.6 kW
12 kW –27 kW
Wood consumption rate/hour (max.
15% humidity)
3.5 kg –7 kg
4 kg –8 kg
Max. wood consumption limit/hour
Max. 6 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Max.7 pieces measuring 30
cm in length and with a
circumference of 30 cm ± 3
Flue gas flow (g/s)
16.9
19.9
Flue gas temperature (C°)
317
335
CO at 13% O2 (%)
0.09
0.10
Dust content at 13% O2 (mg/nm³)
54
26
Min. chimney draught (Pa)
12
12
*Min. insulation thickness top (cm)
30
Only non-flammable material
*Min. insulation thickness sides
(cm)
-
13
*Min. insulation thickness rear (cm)
-
10
*Min. insulation thickness bottom
(cm)
38
Only non-flammable material
Chimney connection (mm)
Ø250
Ø250
Combustion air connector (mm)
1 x Ø150 (± 1 x 180cm²)
1 x Ø150 (± 1 x 180cm²)
Convection connector inlet (mm)
2 x Ø150 (± 2 x 180cm²)
2 x Ø150 (± 2 x 180cm²)
Convection connector outlet (mm)
4 x Ø150 (± 4 x 180cm²)
4 x Ø150 (± 4 x 180cm²)
Weight incl. cast iron reeded
panels (kg)
398
433
Dimensions (LxWxH) (mm)
1250x600x1430
1500x600x1430
* Standard insulation “Pumica K,550: 0.14 W/m.K.

ULTC_WHE_EN_05 10
5. General installation instructions
5.1 Standards and rules
- The national and European standard and construction rules of the country where the
installation is carried out apply to the installation of the appliance.
5.2 Transport
- The appliance can only be transported in upright position.
- Remove the packaging, and sort the waste keeping in mind the environment.
- We put a set of transport handles at your disposal, which can be inserted at the side of the
appliance in the openings provided for that purpose (figure 1).
- Check the goods for damage before installing them ! (report damages within 48 hrs)
- DO NOT REMOVE the bolt blocking the vertical sliding door during transport!
There is a box in the fireplace containing all accessories like connection rings, handle and the
manual.
Figure 1: Transport
Handle
Handle

ULTC_WHE_EN_05 11
5.3 Remarks and tips with regard to the installation
- The appliance must always be placed on a surface having sufficient carrying capacity. In case
the existing surface does not meet this requirement, appropriate measures should be taken to
reinforce the surface.
- Remove the bolt blocking the vertical sliding door before building the appliance into the masonry
(figure 2) (photograph 1-2).
Also remove the warning sticker.
- Check the functioning of the door and of the air valve!
- Make sure that the door can be tilted forward after the fireplace has been built-in.
- The appliance can be brought at the required height by means of the 4 telescopic legs.
4 adjustable legs are provided for fine levelling the appliance (photograph 3).
Figure 2: Remove bolt
Handle
Handle
Open socket wrench SW 13

ULTC_WHE_EN_05 12
(photo 1-2)
Figure 3: Adjustment legs
- The supplied covering plates are suspended on the hooks provided on the inside
(photograph 4).
1
2
REMOVE BOLT BEFORE INSTALLATION!
LOCKING OF WEIGHT
Height adjustment screw
Adjustment screw for
levelling

ULTC_WHE_EN_05 13
- The cast iron assembly comprises several corrugated parts. Start left and right, always with
the smaller part (see 5.4 Installation of the cast iron).
- A batten approximately 1 cm thick and 2 cm high is also supplied. It acts as a spoiler behind
the air section. Mount one side at a time, and slide the batten between the teeth. Next, slide
the cast iron part against the front of the fireplace (photograph 5-6).
Adjustment leg Covering plate of guide
Mounting spoiler right Mounting spoiler left
3
4
5
6

ULTC_WHE_EN_05 14
5.4 Installation of the cast iron
Step 1: Place the ribbed cast iron parts on the left side.
Start from the front side with 3 large parts (120mm/6 teeth) and end with 1 small part
(54mm/3 teeth).
The tooth must be oriented to the rear side. See figure 4
Step 2: Place one large part of the ribbed cast iron on the right side.
Place it a little bit from the front side.
The tooth must be oriented to the rear side. See figure 4
Step 3: Place the spoiler in the first groove of the first left ribbed cast iron part and in the first
groove of the right ribbed cast iron. See figure 4
Step 4: Move the right ribbed cast iron part to the front side of the fireplace so the spoiler
becomes parallel with the front of the fireplace. See figure 4
1
1
1
2µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
µ
3
4
1
1
2
3
4
Tooth
Figure 4: Cast iron

ULTC_WHE_EN_05 15
Step 5: Place the ribbed cast iron parts on the rear side of the fireplace.
Starting from the left side to the right side. Start with a large cast iron part (120mm/6
teeth). The tooth must be oriented to the right side. See figure 5
Step 6: The last cast iron part, marked as “x” is different depending on the type of fireplace.
See the figures below to check which part to use to finish the rear side.
5
5
5
5
5
5
x
5
Figure 5: Cast iron
Tooth

ULTC_WHE_EN_05 16
Ultime MF 600-75 WHE 1S:
x = 30mm long (2 teeth)
Ultime MF 800-50 WHE 1S / Ultime MF 800-75 WHE 1S:
x = 110mm long (6teeth)
Ultime MF 1050-50 WHE 1S / Ultime MF 1050-75 WHE 1S:
x = 120mm standard piece (6teeth)
Ultime MF 1300-50 WHE 1S:
x = 120mm standard piece (6teeth)
1 2 3 4 5 x
1 2 3 4 5 6 x
1 2 3 4 5 6 7 8 x
1 2 3 4 5 6 7 8 9 10 x

ULTC_WHE_EN_05 17
Step 7: Place the ribbed cast iron parts on the right side.
Start from the front after the first part with 2 large parts and end with 1 small part. The
tooth must be oriented to the rear side. See figure 6.
7
7
7
Tooth
Figure 6: Cast iron

ULTC_WHE_EN_05 18
5.5 Insulation
-Fitting additional insulation around the convection case, appropriate for such applications
(temperature range, fire safety, no dust emission) is compulsory.
-For insulating the fireplace, only Promafour 400 with 15 mm thickness can be used. This is a
solid panel having no loose fibres. Hence, no loose fibres can enter the convection current.
-Custom-made Promafour panels are available as an option.
-The installer must take the necessary measures in order to prevent overheating of
surrounding materials in accordance with the locally applicable standards.
-Profiled sections have been provided at the appliance where you can easily insert the
Promafour panels (photograph 7).
-At the time of building in, the minimum insulation thicknesses must be observed (refer to 4.
Technical specifications).
Figure 7: Fitting the Promafour panels
Panel
Top
Side panel
Panel
Rear wall
1 left
1 right

ULTC_WHE_EN_05 19
Profiled section for fixing of insulation
5.6 Flue gas duct
-The minimum height of the chimney for a comfortable fire is 5 m measured from the
connection nozzle to the top of the chimney excluding the rain cap.
-The appliance has been designed for a natural draught of 12Pa.
-The duct must be insulated thermally in order to avoid condensation and to improve the
draught.
-The connection must run 1m vertical before a change in direction can be made
-Changes in direction up to 45° are admissible with a maximum of 2 bends.
-Connecting under an angle of 90° is strictly forbidden.
-It is absolutely forbidden to connect 2 or more appliances to 1 flue gas duct.
-Close off flue gas ducts that are not used.
-It is recommended to install a rain cap because it is advantageous for the lifespan of the
appliance and the flue gas duct.
-The outlet and position of the chimney in the roof surface and with respect to surrounding
buildings is very important, and can only be carried out according to the rules that are locally
applicable.
-An oversized flue gas duct can have a negative effect on the good operation, and has a direct
influence on the efficiency.
-We recommend a rigid stainless steel pipe for connecting the appliance. The pipe is to be
insulated with a ceramic wool blanket.
-An excessive draught can be decreased by means of a draught regulator. A poor draught can
be improved using a flue gas fan.
-Please contact MF when you want to connect an appliance to a flue gas duct that has a
smaller diameter than specified in 4. Technical specifications.
-We refer to the table below for the minimum configuration of the flue duct, a change in
direction of 45° must be compensated by 1m additional in height.
Minimum height flue duct in function of flue diameter
Ultime C type
Ø300
Ø250
Ø230
Ø200
Air Ext
MF 600-75 WHE 1S
>=5
>=5
>=7
Ø150
MF 800-75 WHE 1S
>=5
>=6
>=10
Ø150
MF 1050-75 WHE 1S
>=5
>=7
-
-
Ø150
MF 800-50 WHE 1S
>=5
>=5
>=7
Ø150
MF 1050-50 WHE 1S
>=5
>=6
>=8
Ø150
MF 1300-50 WHE 1S
>=5
>=7
-
Ø150
7

ULTC_WHE_EN_05 20
5.7 Flue gas valve
-Every appliance is provided with an automatic flue gas valve. When the vertical sliding door is
opened, the valve opens automatically so that there will be no smoke emission when firing
with the door open.
-The flue gas valve can be adjusted in function of the chimney draught. The initial adjustment
can solely be carried out by Metalfire. Please contact your dealer.
5.8 Convection air
The appliance is fitted with a convection system ensuring heat recovery in the room. To that end, a
number of rules must be observed. In most cases, the convection functions in a natural way. As an
option, we offer an air fan for boosting the convection current.
-For connecting it, use non-combustible aluminium flexibles with 150 mm diameter.
-Make sure that the flexible duct has the same resistance (= length, diameter and number of
bends).
-In the case where connecting pieces are closed off or when there is a variation in resistance,
we cannot guarantee a uniform spread of the temperature.
-Keep in mind the nett cross-section of the grate when placing grates on the outlets. The
surface area must correspond to the connected flexible duct.
-Use only grates that cannot be closed.
-Mounting of the grate at a minimum distance of 30 cm from the ceiling so as to avoid
discolouration and deposits as much as possible.
-Always 2 connecting nozzles must be connected at the top of the appliance. The pre-cut
openings for the connection can be easily removed (photograph 8 and 9)
-The appliance is provided with sufficient connecting nozzles for allowing connecting it. They
are fixed to the convection jacket by means of a self-tapping screw (photograph10).
-Use below table to determine the number of flexible inlet and outlet connections according the
installed model.
Number of flexibles and convection outlets
Ultime C type
Number of flexible
inlets convection
jacket
Net cross section
inlets
Number of flexible
outlets convection
jacket
Net cross
section outlets
MF WHE 600-75 1S
2 x Ø150 mm
350 cm²
2 x Ø150 mm
350 cm²
MF WHE 800-75 1S
2 x Ø150 mm
350 cm²
2 x Ø150 mm
350 cm²
MF WHE 1050-75 1S
2 x Ø150 mm
350 cm²
4 x Ø150 mm
700 cm²
MF WHE 800-50 1S
2 x Ø150 mm
350 cm²
2 x Ø150 mm
350 cm²
MF WHE 1050-50 1S
2 x Ø150 mm
350 cm²
4 x Ø150 mm
700 cm²
MF WHE 1300-50 1S
2 x Ø150 mm
350 cm²
4 x Ø150 mm
700 cm²
